TIJ-BIOTOKEN-MStarSign Bio Token 3.0 M

StarSign® Bio Token 3.0 M USB Token Reference Manual Edition 10.2005 ID No. 30017639 © Copyright 2005 by Giesecke & Devrient GmbH Prinzregentenstr. 159 Postfach 80 07 29 D-81607 München This document as well as the information or material contained is copyrighted. Any use not explicitly per- mitted by copyright law requires prior consent of Giesecke & Devrient GmbH. This applies to any repro- duction, revision, translation, storage on microfilm as well as its import and processing in electronical systems, in particular. Subject to technical changes. StarSign® Bio Token is a registered trademark of Giesecke & Devrient GmbH. © Copyright 2005 by Giesecke & Devrient GmbH - Germany – Prinzregentenstr. 159, P.O. Box 80 07 29, D-81607 München © 2005 Giesecke & Devrient GmbH. All rights reserved The names of the other products mentioned are trademarks of their respective owners. This hardware key is in compliance with the following test specification: CEI EN 61000-4-2; CEI EN 61000-4-3; CISPR22 as required by: CEI EN 61000-6-1, CEI EN 61000-6-2, CEI EN 61000-6-3, CEI EN 61000-6-4 which are specified for the following test: • “ESD Immunity test” • “Radiated radio-frequency and electromagnetic field immunity test” • “Radiated Emission Verification” In compliance with the “Essential Requisites” for the EMC Directive 89/336/EEC. FCC ID: TIJ-BIOTOKEN-M Giesecke & Devrient GmbH StarSign® Bio Token 3.0 M Supply: 5V DC Absorption: 250 mA This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. IMPORTANT REMARKS Due to the limited space on the product shell, all FCC certification references are on this technical manual. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Contents Reference Manual StarSign® Bio Token 3.0 M/Edition 10.2005 ID No. 30017639 Contents About StarSign Bio Token 3.0 M .......................................................................................... 1 About the Document ........................................................................................................... 2 1Basics3 1.1General Introduction to Biometrics............................................................................. 4 1.2Biometrics, Smart Cards and Tokens .......................................................................... 5 1.3LED Status ................................................................................................................. 6 2 Command Reference9 2.1ENROLL FINGERPRINT............................................................................................... 10 2.2VERIFY FINGERPRINT ................................................................................................ 12 2.3VERSION INFO.......................................................................................................... 14 Appendix15 AOverview of Status Bytes.......................................................................................... 16 BTechnical Specifications............................................................................................ 18 CReference Literature................................................................................................. 19 DGlossary................................................................................................................... 20 Index ............................................................................................................................... 23 Contents Reference Manual StarSign® Bio Token 3.0 M/Edition 10.2005 ID No. 30017639 About StarSign Bio Token 3.0 M Reference Manual StarSign® Bio Token 3.0 M/Edition 10.2005 1 of 23 ID No. 30017639 About StarSign Bio Token 3.0 M Characteristics StarSign Bio Token 3.0 M is a USB-PKI token based on the STARCOS 3.0 operating system. The token comprises a fingerprint sensor and on-to- ken fingerprint verification functionality. The biometric data never leaves the token. StarSign Bio Token 3.0 M is supported by StarSign middleware and can therefore be used for all public key applications supporting MS CAPI (CSP) or PKCS#11. Fingerprint verification can be used instead of – or in addition to – PIN verification, granting a higher user convenience and a real tie between user and token. This is particularly of interest in applications that require non-repudiation. StarSign Bio Token 3.0 M also comprises an independent flash drive. Features Features of StarSign Bio Token 3.0 M include: – Based on STARCOS 3.0 operating system – On-token sensor, image processing and biometric verification (on- card matching) – Supported by StarSign middleware; use with all public key applica- tions supporting MS CAPI (CSP) or PKCS#11 – Security system according to 7816-4; secure writing and messaging – Cryptographic authentication and key management – Encryption – Symmetric encryption: DES, 3DES – Asymmetric encryption: RSA-CRT with up to 2048 bits – Support of up to 4 logical channels – Biometric enrollment and verification functionality – LED status indication – additional flash memory drive Related Standards StarSign Bio Token 3.0 M adheres to the following standards: – ISO/IEC 7816-3 – ISO/IEC 7816-4 – ISO/IEC 19794-2 More information on the relevant standards may be found in the appen- dix (see ’C Reference Literature’ on page 19). About the Document 2 of 23Reference Manual StarSign® Bio Token 3.0 M/Edition 10.2005 ID No. 30017639 About the Document Target Group This manual addresses developers and specialists of smart card applica- tions. Required Knowledge In order to use StarSign Bio Token 3.0 M, you should be familiar with: – Smart card hardware/software – Related ISO/IEC standards – Experience in biometric user authentication and cryptograp…

Text truncated - open the document above for the full version.

FCC.TR. TEST REPORT 05.829 Prima Ricerca & SviluppoSrl soggetta a direzione e coordinamento da parte della Giovanni Maspero & C. S.p.A. – C.I. 02634780130 Sede legale : 22100 Tavernola (CO) Via Conciliazione, 1 Cod. FISC. e N. R.I. CO 02635860139 Sede operativa : Laboratori Via Campagna, 92 22020 Faloppio fraz. Gaggino (CO) Tel. +39 03135000.11 Fax +39 031991309 Edition: 2.0 Issue date: 06/07/2005 sheet 1 of 18 EQUIPMENT UNDER TEST : APPARECCHIO IN PROVA : USB ELECTRONIC KEY STARSIGN BIO TOKEN M REFERENCE STANDARDS : NORME DI RIFERIMENTO : FCC 47 CFR Part 15 CUSTOMER: RICHIEDENTE: • Dept. / Firm : Ente / Società’: GIESECKE & DEVRIENT GMBH • Mr.: Sig.: Dr. Robert Mueller • Address: Indirizzo: Prinzregentenstraße 159, 81677 München Germany • Tel. : Telefono : +49 89 4119 2459 • Telefax Fax : +49 89 4119 1905 • E-mail: e-mail [email protected] Site of test execution: Via Campagna, 92 - 22020 Gaggino Faloppio (CO) - Italy Località esecuzione prove: Date of test samples receipt: 06/07/2005 Date of start test: 06/07/2005 Data ricevimento campioni: Data inizio prove: Date of end test: 06/07/2005 Data fine prove: Witness to the test: Presenti alle prove: Signature of the engineers: Firma esecutore prove: Signature of the Laboratory Director: Firma Direttore Laboratori: Mr. Maffioli ......................................................... .......................................................... Luca Casiraghi .......................................................... R. Furfari The test results recorded in this Test Report are exclusively referred to the tested samples. I risultati del presente rapporto di prova si riferiscono esclusivamente al campione sottoposto a prova. Reproduction of this EMC-Test Report in whole or in part is prohibited without the written authorization of the Laboratory Director La riproduzione di questo Rapporto in modo parziale o totale è PROIBITO senza l’autorizzazione scritta della Direzione del Laboratorio FCC.TR. TEST REPORT 05.829 Prima Ricerca & SviluppoSrl soggetta a direzione e coordinamento da parte della Giovanni Maspero & C. S.p.A. – C.I. 02634780130 Sede legale : 22100 Tavernola (CO) Via Conciliazione, 1 Cod. FISC. e N. R.I. CO 02635860139 Sede operativa : Laboratori Via Campagna, 92 22020 Faloppio fraz. Gaggino (CO) Tel. +39 03135000.11 Fax +39 031991309 Edition: 2.0 Issue date: 06/07/2005 sheet 2 of 18 0. CONTENTS Page Rev Date 0. CONTENTS ................................................................................................. 1. TECHNICAL INFORMATION OF EQUIPMENT UNDER TEST (EUT) ........ 1.1 Identification ......................................................................................... 1.2 Technical data ...................................................................................... 1.3 Modifications incorporated in E.U.T...................................................... 1.4 Ports identification ................................................................................ 1.5 Auxiliary equipment .............................................................................. 2. TEST CONDITIONS .................................................................................... 2.1 Operating test modes and test conditions ............................................ 2.2 Test overview ....................................................................................... 3. REFERENCE STANDARD FOR PERFORMED TESTS ............................. 4. Summary of test results ............................................................................... 4.1 Emission tests ...................................................................................... 5. TEST RESULTS .......................................................................................... 6. EUT TECHNICAL DOCUMENTATION........................................................ 6.1 Wiring diagrams.................................................................................... 6.2 Technical manual ................................................................................. 6.3 Photographic documentation ................................................................ 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 06/07/05 06/07/05 06/07/05 06/07/05 06/07/05 06/07/05 06/07/05 06/07/05 06/07/05 06/07/05 06/07/05 06/07/05 06/07/05 06/07/05 06/07/05 06/07/05 06/07/05 06/07/05 FCC.TR. TEST REPORT 05.829 Prima Ricerca & SviluppoSrl soggetta a direzione e coordinamento da parte della Giovanni Maspero & C. S.p.A. – C.I. 02634780130 Sede legale : 22100 Tavernola (CO) Via Conciliazione, 1 Cod. FISC. e N. R.I. CO 02635860139 Sede operativa : Laboratori Via Campagna, 92 22020 Faloppio fraz. Gaggino (CO) Tel. +39 03135000.11 Fax +39 031991309 Edition: 2.0 Issue date: 06/07/2005 sheet 3 of 18 1. TECHNICAL INFORMATION OF EQUIPMENT UNDER TEST (EUT) 1.1 Identification Brand name: GIESECKE & DEVRIENT GMBH, PRINZREGENTENSTRAßE 159, 81677 MÜNCHEN GERMANY Manufacturer: EUTRON INFOSECURITY Equipment : USB ELECTRONIC KEY Model name or No. : STARSIGN BIO TOKEN M FCC ID : TIJ-BIOTOKEN-M Country of manufacturer: ITALY 1.2 Technical data FCC class: Unintentional radiators, Class B Supply voltage: +5 V dc supplied by USB PC connector Input Power / Current : 100 mA max. Maximum internal frequency generated by EUT 48 MHz Typical usage : Mass storage and document encrypting EUT single or system: Single EUT dimensions : 10,6 x 3,2 x 1,5 cm 1.3 Modifications incorporated in E.U.T. The following items are the modifications introduced in the equipment under test : • None FCC.TR. TEST REPORT 05.829 Prima Ricerca & SviluppoSrl soggetta a direzione e coordinamento da parte della Giovanni Maspero & C. S.p.A. – C.I. 02634780130 Sede legale : 22100 Tavernola (CO) Via Conciliazione, 1 Cod. FISC. e N. R.I. CO 02635860139 Sede operativa : Laboratori Via Campagna, 92 22020 Faloppio fraz. Gaggino (CO) Tel. +39 03135000.11 Fax +39 031991309 Edition: 2.0 Issue date: 06/07/2005 sheet 4 of 18 1.4 Ports i…

Text truncated - open the document above for the full version.
