TJ7BTK-605ABluetooth Audio Dongle

1 BTK-605A Bluetooth Audio Dongle User Manual Characteristics: 1. Send the music in the audio devices or PC to Bluetooth stereo headset to enjoy good quality music. 2. Apply to mini-size audio devices and PSP 3. Connect with two Bluetooth stereo headset at the same time Your dongle overview Charging the dongle Your dongle uses a rechargeable battery. You must charge the battery fully before using the dongle for the first time. 1. Plug the USB cable into the computer 2. Connect the USB cable with dongle as it shown on the picture. The red indicator of headset will turn on when charging. 3. When the battery is fully charged, the red indicator will turn off. 1) Depending on your country, the travel Charger may appear different from above illustration. 2) When the headset is in low battery, the red indicator would flash twice each 5seconds. 2 3) The headset will be fully charged in approximately 1-2 hours. 4) Remove the travel charger from the AC socket. WARNING: Do not attempt to charge the dongle with anything other than the travel charger provided. Using unauthorized travel charger may damage the dongle. IMPORTANT: The dongle cannot be used while charging. BASIC OPERATIONS Please make sure that your dongle is connected with the audio device or PC by plugging the dongle into 3.5mm earphone jack in the audio or PC. Turning the dongle on/off 1. To turn the dongle on Press and hold Power Button for about 2 seconds, the blue indicator of the dongle will flash for 1 second. The dongle is now turned on. 2. To turn the dongle off Press and hold Power Button for about 5 seconds, the red indicator of the dongle will flash for 1 second. The dongle will be turned off. 3. When the blue indicator flashes red, it means the headset is on low battery, please charge the headset. Pairing Before using your dongle for the first time, you must pair it with your Bluetooth stereo headset. 1. Ensure that the dongle is on (see “To turn the dongle on” section). And make sure the Bluetooth Stereo Headset is under pairing mode. 2. Press and hold Power Button for about 2 seconds until the indicator light alternately flashes blue and red，your dongle is under pairing mode. 3. Then the dongle will be connected with the Bluetooth stereo headset after few seconds. If you want to connect with the second Bluetooth stereo headset, please follow the procedures as follows: 1. Press and hold Power Button for about 2 seconds until the indicator light alternately flashes blue and red, and the dongle will disconnect with the first Bluetooth stereo headset. 2. Then the dongle will be connected with the second Bluetooth stereo headset after few seconds. 3. Press Power Button twice to reconnect with the first Bluetooth stereo headset. Connect with two Bluetooth Stereo Headsets at the same time: 1. Ensure that the dongle is on (see “To turn the dongle on” section). And make sure the two Bluetooth Stereo Headsets are under pairing mode. 2. Press and hold Power Button for about 2 seconds until the indicator light alternately flashes blue and 3 red，your dongle is under pairing mode. 3. Then the dongle will be connected with the two Bluetooth stereo headsets after few seconds. Note: Storage of the headset 1. Always store the dongle with the power off and make sure it is safely protected. 2. Avoid storage at high temperatures (above 60°C) such as in a hot vehicle or in direct sunlight. (Storage at high temperatures can damage performance and reduce battery life). 3. Do not expose the dongle or any of its supplied parts to rain or other liquids. Product Specifications Bluetooth Version 2.1+EDR Specifications, Class II Support Bluetooth A2DP & AVRCP Profiles and Bluetooth Stereo Headset Connect with two Bluetooth devices at the same time Built-in lithium-Lon battery Operating Range: Up to 30 feet (10 meters) Frequency: 2402~2480MHz Charging Time: approximate to 2 hours* Play Time: Up to 9 hours* Standby Time: Up to 180 hours* Dimensions (L X W X T): 49.5 x 20.5 x 11mm Weight: 19.2g (excluding accessories) *Depending on the phone type and usage, the actual time may vary. Correct disposal of this product (Waste Electrical & Electronic Equipment)This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources. Household users should contact either the retailer where they purchased this product, or their local government office, for details of where and how they can take this item for environmentally safe recycling. Business users should contact their supplier and check the terms and conditions of the purchase contract. This product should not be mixed with other commercial wastes for disposal. Bluetooth® is a trademark owned by Bluetooth SIG, Inc. 4 FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connec…

Text truncated - open the document above for the full version.

Neutron Engineering Inc. Project No.: 1209C034 Page 2 of 8 Neutron Engineering Inc. Project No.: 1209C034 Page 3 of 8

Neutron Engineering Inc. Project No.: 1209C034 Page 4 of 8 Neutron Engineering Inc. Project No.: 1209C034 Page 5 of 8 Neutron Engineering Inc. Project No.: 1209C034 Page 6 of 8 Neutron Engineering Inc. Project No.: 1209C034 Page 7 of 8 Neutron Engineering Inc. Project No.: 1209C034 Page 8 of 8

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1209C034 Page 1 of 98 FCC Radio Test Report FCC ID: TJ7BTK-605A This report concerns (check one) : Original Grant Class II Change Issued Date : Sep. 14, 2012 Project No. : 1209C034 Equipment : Bluetooth Audio Dongle Model Name : BTK-605A; BTK-606; BTK-607; BTK-605B; BTK-605 Applicant : ShenZhen SHI KISB Electronic Co., LTD Address : 3-5F, A Building, Shanghe Industrial Zone, Nanchang Road, Bao’an District, Shenzhen, China Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: Sep. 05, 2012 Date of Test: Sep. 05, 2012 ~ Sep. 13, 2012 Testing Engineer : (David Mao) Technical Manager : (Leo Hung) Authorized Signatory : (Steven Lu) Neutron Engineering Inc. No.3,Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1209C034 Page 2 of 98 Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of CHINA, or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Neutron Engineering Inc. Report No.: NEI-FCCP-1-1209C034 Page 3 of 98 Table of Contents Page 1 . CERTIFICATION 6 2 . SUMMARY OF TEST RESULTS 7 2.1 TEST FACILITY 8 2.2 MEASUREMENT UNCERTAINTY 8 3 . GENERAL INFORMATION 9 3.1 GENERAL DESCRIPTION OF EUT 9 3.2 DESCRIPTION OF TEST MODES 11 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 11 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 12 3.5 DESCRIPTION OF SUPPORT UNITS 13 4 . EMC EMISSION TEST 14 4.1 CONDUCTED EMISSION MEASUREMENT 14 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 14 4.1.2 MEASUREMENT INSTRUMENTS LIST AND SETTING 14 4.1.3 TEST PROCEDURE 15 4.1.4 DEVIATION FROM TEST STANDARD 15 4.1.5 TEST SETUP 15 4.1.6 EUT OPERATING CONDITIONS 15 4.1.7 TEST RESULTS 16 4.2 RADIATED EMISSION MEASUREMENT 18 4.2.1 RADIATED EMISSION LIMITS 18 4.2.2 MEASUREMENT INSTRUMENTS LIST ANS SETTING 19 4.2.3 TEST PROCEDURE 20 4.2.4 DEVIATION FROM TEST STANDARD 20 4.2.5 TEST SETUP 21 4.2.6 EUT OPERATING CONDITIONS 22 4.2.7 TEST RESULTS (BELOW 30MHZ) 23 4.2.8 TEST RESULTS (BETWEEN30 – 1000 MHZ) 24 4.2.9 TEST RESULTS (ABOVE 1000 MHZ) 26 5 . NUMBER OF HOPPING CHANNEL 50 5.1 APPLIED PROCEDURES / LIMIT 50 5.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 50 5.1.2 TEST PROCEDURE 50 5.1.3 DEVIATION FROM STANDARD 50 5.1.4 TEST SETUP 50 5.1.5 EUT OPERATION CONDITIONS 50 5.1.6 TEST RESULTS 51 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1209C034 Page 4 of 98 Table of Contents Page 6 . AVERAGE TIME OF OCCUPANCY 53 6.1 APPLIED PROCEDURES / LIMIT 53 6.1.1 MEASUREMENT INSTRUMENTS LIST 53 6.1.2 TEST PROCEDURE 53 6.1.3 DEVIATION FROM STANDARD 53 6.1.4 TEST SETUP 54 6.1.5 EUT OPERATION CONDITIONS 54 6.1.6 TEST RESULTS 55 7 . HOPPING CHANNEL SEPARATION MEASUREMENT 67 7.1 APPLIED PROCEDURES / LIMIT 67 7.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 67 7.1.2 TEST PROCEDURE 67 7.1.3 DEVIATION FROM STANDARD 67 7.1.4 TEST SETUP 67 7.1.5 EUT OPERATION CONDITIONS 67 7.1.6 TEST RESULTS 68 8 . BANDWIDTH TEST 72 8.1 APPLIED PROCEDURES / LIMIT 72 8.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 72 8.1.2 TEST PROCEDURE 72 8.1.3 DEVIATION FROM STANDARD 72 8.1.4 TEST SETUP 72 8.1.5 EUT OPERATION CONDITIONS 72 8.1.6 TEST RESULTS 73 9 . PEAK OUTPUT POWER TEST 77 9.1 APPLIED PROCEDURES / LIMIT 77 9.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 77 9.1.2 TEST PROCEDURE 77 9.1.3 DEVIATION FROM STANDARD 77 9.1.4 TEST SETUP 77 9.1.5 EUT OPERATION CONDITIONS 77 9.1.6 TEST RESULTS 78 10 . ANTENNA CONDUCTED SPURIOUS EMISSION 82 10.1 APPLIED PROCEDURES / LIMIT 82 10.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 82 10.1.2 TEST PROCEDURE 82 10.1.3 DEVIATION FROM STANDARD 82 10.1.4 TEST SETUP 82 10.1.5 EUT OPERATION CONDITIONS 82 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1209C034 Page 5 of 98 Table of Contents Page 10.1.6 TEST RESULTS 83 11 . EUT TEST PHOTO 95 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1209C034 Page 6 of 98 1. CERTIFICATION Equipment : Bluetooth Audio Dongle Brand Name : KISS / BTK Model Name : BTK-605A; BTK-606; BTK-607; BTK-605B; BTK-605 Applicant : ShenZhen SHI KISB Electronic Co., LTD Factory : ShenZhen SHI KISB Electronic Co., LTD Address : 3-5F, A Building, Shanghe Industrial Zone, Nanchang Road, Gushu Village, Xixiang Town, Bao’an District, Shenzhen, Guangdong, China Date of Test : Sep. 05, 2012 ~ Sep. 13, 2012 Test Item : ENGINEERING SAMPLE Standards : FCC Part15, Subpart C(15.247) / ANSI C63.4 : 2009 FCC Public Notice DA 00-705, March 30, 2000. The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equ…

Text truncated - open the document above for the full version.

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1209C034 Page 95 of 98 11. EUT TEST PHOTO Conducted Measurement Photos Neutron Engineering Inc. Report No.: NEI-FCCP-1-1209C034 Page 96 of 98 Radiated Measurement Photos 9K~30MHz Neutron Engineering Inc. Report No.: NEI-FCCP-1-1209C034 Page 97 of 98 Radiated Measurement Photos 30~1000MHz Neutron Engineering Inc. Report No.: NEI-FCCP-1-1209C034 Page 98 of 98 Radiated Measurement Photos Above 1000MHz
