TK5-900MOD900MHz Radio Module

InterSense Proprietary Information 1 of 7 InterSense 900MHz Radio Module (Part Number R69-00198) User Manual 1. Overview: The InterSense 900MHz radio module is used for real-time applications where it is important to maintain low and predictable latency. The radio module is a low powered device that operates over a frequency range of 906MHz to 926MHz allowing up to ten radios pairs to coexist by using different channels. The device has two antenna options that will be configured during manufacturing. The device will be used either with a built in chip antenna or with an external strip- line antenna that is connected through an MMCX type connector. 2. Technical Description The radio section of the InterSense 900MHz Radio Module consists of an Atmel ATZB-900-B0 Wireless module which consists of an Atmel ATmega 1281 microcontroller and Atmel AT86RF212 RF Transceiver. All radio configuration and control firmware is programmed into the microcontroller and the user has no ability to manipulate the operation of the radio. InterSense 900MHz Radio Module Block Diagram 3. InterSense 900MHz Radio Module Pin Definitions A 6-pin surface mount connector is included on the InterSense assembly to allow communication to and from the radio using the InterSense VSP serial protocol. Power is also provided through this interface; the radio operates with an input voltage range of 4-9Vdc. An on board voltage regulator reduces the input voltage to 3.3V for proper radio operation. Pin Number Signal Notes 1 Vin 4Vdc – 9Vdc 2 TX UART Transmit - TTL 3 RX UART Receive - TTL 4 GND 5 Trigger 6 CNTL_IN Atmel ATZB-900-B0 Radio Module Antenna 6-pin Mill-Max 399-41-006-21-300000 .050 Pitch Connector InterSense Proprietary Information 2 of 7 4. InterSense 900MHz Radio Module Antenna Options The InterSense 900MHz Radio Module comes configured with either a built in chip antenna or an external PCB antenna (Taoglas PC91.09.0100A.db). When operating with the PC91.09.0100A.db, the InterSense 900MHz Radio Module is assembled with an MMCX type connector to which the external antenna will interface with. 5. InterSense 900MHz Radio Module Mechanical Dimensions PCB thickness 0.039” +/- 0.004 6. Regulatory Compliance Statements Compliance Statement (Part 15.19) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Warning (Part 15.21) Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC Interference Statement (Part 15.105 (b) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to InterSense Proprietary Information 3 of 7 provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Section 7.1.2 of RSS-GEN Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication. This radio transmitter (identify the device by certification number, or model number if Category II) has been approved by Industry Canada to operate with the antenna types listed below with the maximum permissible gain and required antenna impedance for each antenna type indicated. Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device. This device has been designed to operate with the antenna(s) listed below, and having a maximum gain of -10 dB. Antennas not included in this list or having a gain greater than -10 dB are strictly prohibited for use with this device. The required antenna impedance is 50 ohms. List of all Antennas Acceptable for use with the Transmitter - Taoglas PC91.09.0100a.db Section 7.1.3 of RSS-GEN This Device complies with Industry Canada License-exempt RSS standard(s). Operation is subject to the following two conditions: 1. this device may not cause interference, and 2. this device must accept any interference, including interference that may cause undesired operation of the device. This portable transmitter with its antenna complies with FCC/IC RF exposure limits for general population / uncontrolled exposure. InterSense Proprietary Information 4 of 7 OEM Responsibilities to comply with FCC and Industry Canada Regulations The InterSense 900MHz Radio Module has been certified for integration into products only by OEM integrators under the following conditions: 1. The antenna(s) must be installed such that a minimum separation distance of 20cm is maintained between the radiator (antenna) and all persons at all times. 2. The transmitter module must not be co-located or o…

Text truncated - open the document above for the full version.

EXTERNAL PHOTOS Company Name InterSense Incorporated Model # R69‐00198 FCC ID # TK5‐900MOD IC # 6414A‐900MOD Page 1 of 4 EXTERNAL PHOTOS Company Name InterSense Incorporated Model # R69‐00198 FCC ID # TK5‐900MOD IC # 6414A‐900MOD Page 2 of 4 EXTERNAL PHOTOS Company Name InterSense Incorporated Model # R69‐00198 FCC ID # TK5‐900MOD IC # 6414A‐900MOD Page 3 of 4 EXTERNAL PHOTOS Company Name InterSense Incorporated Model # R69‐00198 FCC ID # TK5‐900MOD IC # 6414A‐900MOD Page 4 of 4

TECHNICAL DATA SHEET TT401 Polyimide DESCRIPTION: This material is coated with a permanent pressure sensitive acrylic adhesive and a high opacity, medium gloss white topcoat specifically designed for thermal transfer printing. USES: Designed for barcode or alphanumeric identification of printed circuit boards or related electronic components. It is the ideal label to withstand mixed circuit board processes on either the top or bottom side of the board. It has excellent resistance to harsh fluxes, cleaners, saponifiers, and wave solder environments. Resists all commonly employed methods of cleaning. FACE STOCK: .002 (2.0 mils) thickness ADHESIVE: 2 mil thickness, thermoset acrylic pressure sensitive adhesive. Used for IR Reflow & PCB manufacturing processes. LINER: 50 lb. White APPLY TEMPERATURE: 50º F (10º C) SHELF LIFE 1 Year at 70° f and 40-50% relative humidity RECOMMENDED RIBBONS(S): 8700 series or 6300 RoHS Material is RoHS Compliant ... Continued On Next Page Adhesive thickness ASTM D 1000 0.00200 in. 180 degree peel adhesion ASTM D 1000 24 hour dwell 35 oz/in (39 N/100 mm) 72 hour dwell 50 oz/in (55 N/100 mm) Coated film thickness ASTM D 1000 0.0024-.0027 in. (0.061-0.069 mm) Flammability ASTM D 1000 Average Burn Time< 2 seconds Dielectric Strength ASTM D 1000 > 8 kv PERFORMANCE PROPERTIES TYPICAL RESULTS Short Term High Service Temperature 5 minutes at 500°F (260°C); No visible effect to label at 260°C; Label discolors slightly at 270°C; 300°C label moderately discolors. Label remains functional. Up to 2 hours at 338°F (170°C) No visible effect to label at 170°C; label discolors slightly at 190°C, moderately at 220°C; severely at 260°C. Label remains functional. Long Term High Service Temperature 1000 hours at 212°F (100°C); No visible effect to label at 100°C; Label discolors slightly at 120°C; moderately at 145°C. Label remains functional. CHEMICAL TEST CONDITION PCS Control 260°C heat, 5 minutes 99% Trichloroethane, 74°C, 10 minutes 98% Aquanox SSA 30% aqueous, 40-50°C, 10 minutes 98% RE-ENTRY® KNI 2000 Terpene 40-50°C, 10 minutes 98% BIOACT® EC-7R Terpene 40-45°C, 10 minutes 98% Alpha Metals Inc. 2110 Saponifier 6% aqueous 65-70°C, 10 minutes 98% Isopropanol 99%, 82°C, 10 minutes 99% Deionized Water, 100°C, 10 minutes 99% ** Polyimide, like all other pressure-sensitive materials, should be tested under the actual end use conditions to determine suitability for the intended application.

Place Label over RF Module as shown Printer: DATAMAX H4408 Label Stock: Winco 23038-WT26071 SourceFile:071-00027-0000 Black Thermal Xfr on White stock Finish Lable size 0.7 x 0.4 Model # FCC ID IC ID D C B A A B C D 1 2 3 4 5 6 7 8 8 7 6 5 4 3 2 1 THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF InterSense inc. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF InterSense inc. IS PROHIBITED. PROPRIETARY AND CONFIDENTIAL NEXT ASSY USED ON APPLICATION DIMENSIONS IN mm[INCHES] TOLERANCES: FRACTIONAL 0.01 ANGULAR: MACH 0.01 BEND 0.5 X.XX 0.01 X.XXX 0.0015 INTERPRET GEOMETRIC TOLERANCING PER: ASME Y14.5 MATERIAL FINISH . . DRAWN CHECKED ENG APPR. MFG APPR. Q.A. COMMENTS: DATE NAME InterSense TITLE: SIZE B DWG. NO. REV WEIGHT: SCALE: 1:1 UNLESS OTHERWISE SPECIFIED: A1 Thursday, September 29, 2011 2:47:40 PM SHEET 1 OF 1 071-00027-0000 DO NOT SCALE DRAWING 4 Federal Street Billerica, Ma 01821 WW 900MHz RF Module Label 071-00027-0000 - revA1 900MHz Module . 8/15/2011 For Reference Only *Dimensions are typical and may vary due to technology employed

INTERNAL PHOTOS Company Name InterSense Incorporated Model # R69‐00198 FCC ID # TK5‐900MOD IC # 6414A‐900MOD Page 1 of 1

W66 N220 Commerce Court ● Cedarburg, WI 53012 ● USA Phone: 262.375.4400 ● Fax: 262.375.4248 www.lsr.com TEST REPORT # 311238 LSR Job #:C-1272 Compliance Testing of: 900 MHz Radio Module Test Date(s): July 28, August 8, 9, 12, September 6, 2011 Prepared For: InterSense Attn: Dan Holmes 4 Federal Street Billerica, MA 08121 In accordance with: Federal Communications Commission (FCC) Part 15, Subpart C, Section 15.247 Industry Canada (IC) RSS 210 Annex 8 Digital Modulation Transmitters (DTS) Operating in the Frequency Band 906 MHz – 924 MHz This Test Report is issued under the Authority of: Thomas T. Smith Signature: Date: 10/5/2011 Test Report Reviewed by: Signature: Date: 10/5/2011 Tested by: Peter Feilen, EMC Engineer Signature:Date: This Test Report may not be reproduced, except in full, without written approval of LS Research, LLC. Prepared For: InterSense EUT: 900 MHz Radio Module LS Research, LLC Report # 311238 Model #: R69-00198 Template: Class B DTS 08-2011 LSR Job #: C-1272 Serial #: N/A Page 2 of 46 TABLE OF CONTENTS (page 1 of 2) Contents EXHIBIT 1. INTRODUCTION .......................................................................................................... 4 1.1 SCOPE ................................................................................................................................ 4 1.2 NORMATIVE REFERENCES .......................................................................................... 4 1.3 LS Research, LLC TEST FACILITY ................................................................................. 5 1.4 LOCATION OF TESTING ................................................................................................ 5 1.5 TEST EQUIPMENT UTILIZED ....................................................................................... 5 EXHIBIT 2. PERFORMANCE ASSESSMENT ............................................................................... 6 2.1 CLIENT INFORMATION ................................................................................................. 6 2.2 EQUIPMENT UNDER TEST (EUT) INFORMATION .................................................... 6 2.3 ASSOCIATED ANTENNA DESCRIPTION .................................................................... 6 2.4 EUT’S TECHNICAL SPECIFICATIONS ........................................................................ 7 2.5 PRODUCT DESCRIPTION............................................................................................... 8 EXHIBIT 3. EUT OPERATING CONDITIONS & CONFIGURATIONS DURING TESTS ..... 9 3.1 CLIMATE TEST CONDITIONS ...................................................................................... 9 3.2 APPLICABILITY & SUMMARY OF EMC EMISSION TEST RESULTS .................... 9 3.3 MODIFICATIONS INCORPORATED IN THE EUT FOR COMPLIANCE PURPOSES 9 3.4 DEVIATIONS & EXCLUSIONS FROM TEST SPECIFICATIONS .............................. 9 EXHIBIT 4. DECLARATION OF CONFORMITY ..................................................................... 10 EXHIBIT 5. RADIATED EMISSIONS TEST .............................................................................. 11 5.1 Test Setup ......................................................................................................................... 11 5.2 Test Procedure .................................................................................................................. 11 5.3 Test Equipment Utilized ................................................................................................... 11 5.4 Test Results ........................................................................................................................ 12 5.5 CALCULATION OF RADIATED EMISSIONS LIMITS .............................................. 13 5.6RADIATED EMISSIONS TEST DATA CHART ................................................................ 14 5.7 Screen Captures - Radiated Emissions Test ..................................................................... 16 EXHIBIT 6. CONDUCTED EMISSIONS TEST, AC POWER LINE: ........................................ 21 6.1 Test Setup ......................................................................................................................... 21 6.2 Test Procedure .................................................................................................................. 21 6.3 Test Equipment Utilized .................................................................................................... 21 6.4 Test Results....................................................................................................................... 21 Prepared For: InterSense EUT: 900 MHz Radio Module LS Research, LLC Report # 311238 Model #: R69-00198 Template: Class B DTS 08-2011 LSR Job #: C-1272 Serial #: N/A Page 3 of 46 6.6CONDUCTED EMISSIONSTEST DATA CHART ............................................................ 23 6.7 Screen Captures – Conducted Emissions Test ................................................................. 24 EXHIBIT 7. OCCUPIED BANDWIDTH: ..................................................................................... 25 7.1 Limits ................................................................................................................................ 25 7.2 Method of Measurements ................................................................................................. 25 7.3 Test Equipment List.......................................................................................................... 25 7.4 Test Data ............................................................................................................................. 25 7.5 Screen Captures - OCCUPIED BANDWIDTH ............................................................... 26 8.1 Method of Measurements .................................................................................................. 29 8.2 Data and Analysis .......................…

Text truncated - open the document above for the full version.

W66 N220 Commerce Court ● Cedarburg, WI 53012 ● USA Phone: 262.375.4400 ● Fax: 262.375.4248 www.lsr.com TEST REPORT # 311238 LSR Job #: C-1272 Compliance Testing of: 900 MHz Radio Module Test Date(s): July 28, August 8, 9, 12, September 6, 2011 Prepared For: InterSense Attn: Dan Holmes 4 Federal Street Billerica, MA 08121 In accordance with: Federal Communications Commission (FCC) Part 15, Subpart C, Section 15.247 Industry Canada (IC) RSS 210 Annex 8 Digital Modulation Transmitters (DTS) Operating in the Frequency Band 906 MHz – 924 MHz This Test Report is issued under the Authority of: Thomas T. Smith Signature: Date: 10/5/2011 Test Report Reviewed by: Signature: Date: 10/5/2011 Tested by: Peter Feilen, EMC Engineer Signature:Date:09.07.11 This Test Report may not be reproduced, except in full, without written approval of LS Research, LLC. Prepared For: InterSense EUT: 900 MHz Radio Module LS Research, LLC Report # 311238 Model #: R69-00198 Template: Class B DTS 08-2011 LSR Job #: C-1272 Serial #: N/A Page 2 of 44 TABLE OF CONTENTS (page 1 of 2) EXHIBIT 1. INTRODUCTION .......................................................................................................... 4 1.1 SCOPE ................................................................................................................................ 4 1.2 NORMATIVE REFERENCES .......................................................................................... 4 1.3 LS Research, LLC TEST FACILITY ................................................................................. 5 1.4 LOCATION OF TESTING ................................................................................................ 5 1.5 TEST EQUIPMENT UTILIZED ....................................................................................... 5 EXHIBIT 2. PERFORMANCE ASSESSMENT ............................................................................... 6 2.1 CLIENT INFORMATION ................................................................................................. 6 2.2 EQUIPMENT UNDER TEST (EUT) INFORMATION .................................................... 6 2.3 ASSOCIATED ANTENNA DESCRIPTION .................................................................... 6 2.4 EUT’S TECHNICAL SPECIFICATIONS ........................................................................ 7 2.5 PRODUCT DESCRIPTION............................................................................................... 8 EXHIBIT 3. EUT OPERATING CONDITIONS & CONFIGURATIONS DURING TESTS ..... 9 3.1 CLIMATE TEST CONDITIONS ...................................................................................... 9 3.2 APPLICABILITY & SUMMARY OF EMC EMISSION TEST RESULTS .................... 9 3.3 MODIFICATIONS INCORPORATED IN THE EUT FOR COMPLIANCE PURPOSES 9 3.4 DEVIATIONS & EXCLUSIONS FROM TEST SPECIFICATIONS .............................. 9 EXHIBIT 4. DECLARATION OF CONFORMITY ..................................................................... 10 EXHIBIT 5. RADIATED EMISSIONS TEST .............................................................................. 11 5.1 Test Setup ......................................................................................................................... 11 5.2 Test Procedure .................................................................................................................. 11 5.3 Test Equipment Utilized ................................................................................................... 11 5.4 Test Results ........................................................................................................................ 12 5.5 CALCULATION OF RADIATED EMISSIONS LIMITS .............................................. 13 5.6 RADIATED EMISSIONS TEST DATA CHART ............................................................... 14 5.7 Screen Captures - Radiated Emissions Test ..................................................................... 16 EXHIBIT 6. CONDUCTED EMISSIONS TEST, AC POWER LINE: ........................................ 21 6.1 Test Setup ......................................................................................................................... 21 6.2 Test Procedure .................................................................................................................. 21 6.3 Test Equipment Utilized .................................................................................................... 21 6.4 Test Results....................................................................................................................... 21 6.6CONDUCTED EMISSIONSTEST DATA CHART ............................................................ 23 6.7 Screen Captures – Conducted Emissions Test ................................................................. 24 Prepared For: InterSense EUT: 900 MHz Radio Module LS Research, LLC Report # 311238 Model #: R69-00198 Template: Class B DTS 08-2011 LSR Job #: C-1272 Serial #: N/A Page 3 of 44 EXHIBIT 7. OCCUPIED BANDWIDTH: ..................................................................................... 25 7.1 Limits ................................................................................................................................ 25 7.2 Method of Measurements ................................................................................................. 25 7.3 Test Equipment List.......................................................................................................... 25 7.4 Test Data ............................................................................................................................. 25 7.5 Screen Captures - OCCUPIED BANDWIDTH ............................................................... 26 EXHIBIT 8: BANDEDGE MEASUREMENTS ................................................................................ 29 8.1 Method of Measurements ..............................…

Text truncated - open the document above for the full version.

TEST SETUP PHOTOS Company Name InterSense Incorporated Model # R69‐00198 FCC ID # TK5‐900MOD IC # 6414A‐900MOD Page 1 of 5 TEST SETUP PHOTOS Company Name InterSense Incorporated Model # R69‐00198 FCC ID # TK5‐900MOD IC # 6414A‐900MOD Page 2 of 5 Chip Antenna Set‐up TEST SETUP PHOTOS Company Name InterSense Incorporated Model # R69‐00198 FCC ID # TK5‐900MOD IC # 6414A‐900MOD Page 3 of 5 External Antenna Set‐up TEST SETUP PHOTOS Company Name InterSense Incorporated Model # R69‐00198 FCC ID # TK5‐900MOD IC # 6414A‐900MOD Page 4 of 5 TEST SETUP PHOTOS Company Name InterSense Incorporated Model # R69‐00198 FCC ID # TK5‐900MOD IC # 6414A‐900MOD Page 5 of 5
