TM4-DFU026GrooveStikTM Wireless Audio Solution

·Compatible with iPod Touch/iPhone/iPad and other devices that supply Bluetooth stereo audio player. ·Via Bluetooth wireless access mode, it cooperates with iPod Touch/iPhone/iPad or other series that support Bluetooth stereo audio player to realize the long-distance transmission of stereo audio. ·Three different colors of the LED indicators, the Green LED is charging, the Red LED means low battery, the Blue LED means Bluetooth pairing and communication. ·Built-in green lithium-ion polymer battery. ·It can input stereo audio for portable speakers. WARNING! IMPORTANT SAFETY INSTRUCTION! Failure to read and follow these safety instructions could result in fire, explosion, electrical shock or other hazard, causing serious and/ or fatal injury and/or property damage. 1. Do not modify, disassemble, open, drop, crush, puncture or shred the product 2. Do not expose the product to rain or water 3. Keep away from open flame or sunlight to prevent heat build-up 4. Keep away from high voltage devices 5. This product is not a toy, keep away from children. Ensure that all persons who use the product read and follow these warnings and instructions 1 × GrooveStik 3.5MM Audio Cable,USB Connector Specifications: Compatible with iPod Touch/iPhone/iPad and other series products that support Bluetooth stereo audio player. Executive Standard: Bluetooth SIG, V3.0 Bluetooth Protocol: Bluetooth serial port profile (SPP) Port Interface: BSPP-USB (DFU026 Type) Communication Speed Rate: 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200bps Modulation System: 2.4G ISM direct sequence frequency (FHSS) Operating Temperature/ Storage Temperature: -10-50°C/-20-80°C Transmitting Power/ Receiving Sensitivity: 30mAh/0.6mAh Contents: Features: * the Bluetooth is disconnected more than 10 minutes, the device will turn off automatically. 3. Once connected, connect 3.5MM audio cable to Speaker to realize the transmission of stereo audio. 4. Pressing the switch for 3 seconds, the LED indicator flash/off to realize on/off function (when turn on, the blue LED indicator will flash 3 times; turn off, it will be out.) 5. After turn on the device, soft-pressing the switch to realize music play or pause functional. 1. The blue LED indicator flashes one time each 5 seconds means that the Bluetooth is disconnected. 2. The blue LED indicator flashes one time each second means that the Bluetooth is connected. 3. The red LED indicator flashes means low battery, need to recharge( or the device will turn off automatically) 4. The green LED indicator on means the battery is in charging, The green LED shut down it means charged. The LED indicator information: Open the cap of the GrooveStik, and connect the USB port to any powered USB device. Such as charger (output USB 5V1A, 2.1A), computer, and so on. The green LED indicator will keep lighting when charged. Instructions: 2. Pair GrooveStik with your device a. Long-pressing the switch for 5 seconds to enter into pairing mode, the LED indicator alternately flashing red and blue. b. Choosing DFU026 from the Bluetooth device list on your iPod Touch/ iPhone/iPad devices screen, and start to do pairing. When you complete to do pairing, the red LED indicator will be out, and blue LED indicator will flash quickly for 5 times, then flash 1 time per second. For the device has successfully paired with GrooveStik, no need to do pairing again. a. Please make sure GrooveStik is in shut down. b. Long-time pressing the switch for 3 seconds, turn on and connect the Bluetooth device that paired last time. Then the blue LED indicator will flash quickly 3 times, then one time each 0.5 second. It will go to standby mode if cannot connect successfully in 30 seconds, the blue LED indicator will flash one time in each 5 seconds. When GrooveStik paring with your device 1st time,please make sure the device is power off. * iPod Touch/iPhone/iPad Bluetooth device can connect 2 pcs at the same time (Bluetooth version above 3.0 ) 1. Charging GrooveStik Battery Spec.: 3.7V / 120mAh Effective Range: above 8M -6- -7- -8--9- For technical support, please email us for more information at [email protected]. Model# DFU026 Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

DATE : September 15 , 2012 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint _ Greatwall International Approval Co., Limited Unit 04,7/F,Bright Way Tower, No.33 Mong Kok Road, Kowloon, Hong Kong _, to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with TELEWAY INDUSTRIAL LTD. / 1301B Information Center, Ke Feng Road No.2, GaoXin Zone, Nanshan District, Shenzhen, China Dated this September 15 , 2012 By: Avis Qin Signature Printed Title: Certification Engineer On behalf of : TELEWAY INDUSTRIAL LTD. Telephone: 86-755-26611059

DATE : September 15 , 2012 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: TM4-DFU026 Product Name: GroovestickTM Wireless Audio Solution Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: • Schematics • Block diagram • Operational Description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this September , 2012 By: Avis Qin Signature Printed Title: Certification Engineer On behalf of : TELEWAY INDUSTRIAL LTD. Telephone: 86-755-26611059

Model:DFU026 Model:DFU026

Label Location

The Test Report issued under the responsibility of : Greatwall International Approval Co., Limited Unit 04,7/F,Bright Way Tower, No.33 Mong Kok Road, Kowloon, Hong Kong Tel:00852-69425539 Fax: 00852-35902333 Report No. : E86.12.289.005 This Test Report is Prepared for TELEWAY INDUSTRIAL LTD. 1301B Information Center, Ke Feng Road No.2, GaoXin Zone, Nanshan District, Shenzhen, China Product Name: GrooveStik TM Wireless Audio Solution Model No.: DFU026 Brand Name: Applicable standards: FCC Part 15.247 Test result: The FCC testing has been performed on the submitted samples and found in compliance with ANSI 63.4-2003 and FCC Part15.247 Prepared by : Shirley Xu Assistant Reviewer : Mary Huang/Supervisor Approved & Authorized Signer : Mike Wong/ Manager Note: This report shall not be reproduced except in full, without the written approval of Greatwall International Approval Co., Ltd. This document may be altered or revised by Greatwall International Approval Co., Ltd. personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample Report No: E86.12.289.005 Page 2 of 71 Date: 2012-09-20 The report refers only to the sample tested and does not apply to the bulk. This report is issued in confidence to the client and it will be strictly treated as such by the Greatwall International Approval Co., Limited. It may not be reproduced rather in its entirety or in part and it may not be used for adverting. The client to whom the report is issued may, however, show or send it . or a certified copy there of prepared by the Greatwall International Approval Co., Limited to his customer. Supplier or others persons directly concerned. Greatwall International Approval Co., Limited will not, without the consent of the client enter into any discussion of correspondence with any third party concerning the contents of the report. In the event of the improper use of the report. The Greatwall International Approval Co., Limited reserves the rights to withdraw it and to adopt any other remedies which may be appropriate. Test Report Conclusion Content 1.0 General Details ................................................................................................ 3 1.1 Details of Applicant...................................................................................... 3 1.2 Applicant Details.............................................................................................. 3 1.3 General Description of EUT.................................................................................. 3 2.0 List of Measurement Equipment......................................................................... 4 3.0 Technical Details............................................................................................. 5 3.1 Summary of Test Results..................................................................................... 5 3.2 Test Standards.................................................................................................. 5 4.0 Test Lab Details................................................................................................ 5 5.0 Power Line Conducted Emission Test...................................................................... 6 5.1 Schematics of the Test........................................................................................ 6 5.2 Test Method and Test Procedure............................................................................ 6 5.3 Configuration of the EUT.................................................................................... 6 5.4 EUT Operating Condition....................................................................................7 5.5 Conducted Emission Limit................................................................................... 7 5.6 Test Result...................................................................................................... 7 6.0 Radiated Emission test...................................................................................... 10 6.1 Test Method and Test Procedure............................................................................ 10 6.2 Configuration of the EUT.................................................................................... 10 6.3 EUT Operation Condition....................................................................................10 6.4 Radiated Emission Limit..................................................................................... 11 6.5 Peripherals......................................................................................................11 7.0 20dB Bandwidth Measurement............................................................................... 19 8.0 Maximum Peak Output Power............................................................................... 30 9.0 Carrier Frequency Separation............................................................................... 33 10.0 Number of Hopping Channel................................................................................ 37 11.0 Time of Occupancy (Dwell Time).......................................................................... 41 12.0 Out of Band Measurement................................................................................... 48 13.0 Antenna Requirement........................................................................................ 61 14.0 RF Exposure................................................................................................... 64 15.0 FCC Label...................................................................................................... 65 16.0 Photo of Test Setup and EUT View......................................................................... 66 Report No: E86.12.289.005 Page 3 of 71 Date: 2012-09-20 The report refers only to the sample tested and does not apply to the bulk. This report is issued in confidence to th…
