TN8-OWC-300TWireless Charging Pad

User Manual Please this manual carefully before you use the product. Product detail and features Product Detail Wireless charging pad (OWC-300T) AC power adaptor (19V 0.5A, 100V~240V) User manual Product features PowerHolic disc type wireless charging pad is designed for quick and easy charge experience to mobile phone users with following great features.  PowerHolic disc type wireless charging pad uses concentric pattern, which psychologically encourage users to place mobile phone on the center of the pad.  Concentric waves generate air flow between mobile phone and pad, it minimize excessive heat from conventional pad design. Our curved surface design creates air flow between mobile phone and pad, which minimizes heat radiation.  Charging status can be checked at any time and from any direction by the three LED indicators located on the edges of the pad. This product is WPC Qi certified, so any product attached with a WPC (Wireless Power Consortium) Qi logo are compatible regardless of manufacturer. Basic Instruction 1. Connect Adaptor to the charging pad then to the electrical outlet. 2. Place WPC wireless charging receiver on the center of charging pad. With one short beep sound, charging will start. LED indicator lights located on the edge will blinks. CAUTION: Do not put metallic objects on the pad. It may cause overheat or malfunction. If the charging receiver is not placed properly to the center of the pad, charging of the device might not be possible. Specifications Power output 5W (Max.) Power input 19V, 0.5A (Max.) Operational temperature 0~55°C Humidity Range 0~90% Operational frequency range 110~205KHz Size (mm) 120 x 120 x 11 Weight(g) 77g 2g One year limited warranty Opentech Inc. sells its products with the intent that they are free of defects in manufacture and workmanship for one year from the date of original purchase, except as noted below. Opentech Inc. warrants that its products will be free of defects in material and workmanship under normal use and service. This warranty extends only to customers and does not extend to Retailers. To obtain warranty service on your Opentech Inc. product, mail the product and your dated sales receipt (as proof of purchase), postpaid, to the following address: Opentech Inc. After Service 13F, SJ-Technoville 60-19, Gasan-Dong, Geumcheon-Gu, Seoul, Korea 153-801 Opentech Inc. does not authorize anyone, including, but not limited to, Retailers, the subsequent consumer purchaser of the product from a Retailer or remote purchasers, to obligate Opentech Inc. in any way beyond the term set forth herein. FCC compliance statement This device complies with Part 15 of the Federal Communications Commission (FCC) Rules. Operation is subject to the following two conditions:  This device may not cause harmful interference.  This device must accept any interference received, including interference that may cause undesired operation. CAUTION: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the manufacturer’s instructions, may cause interference harmful to radio communications. There is no guarantee, however, that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:  Reorient or relocate the receiving antenna.  Increase the separation between the equipment and receiver.  Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.  Consult the dealer or an experienced radio or TV technician for help.

CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Page 1 of 4 EUT External Photos CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Page 2 of 4 CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Page 3 of 4 CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Page 4 of 4

CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Page 1 of 1 EUT Label Photos

CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Page 1 of 3 EUT Internal Photos CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Page 2 of 3 CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Page 3 of 3

CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Test Report No.: CTK-2012-01368-5 Date: May 1, 2013 Page 1 of 12 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 Subpart C(Rev.1) RF EXPOSURE REPORT According to : FCC 47CFR part 1 subpart I and part 2 subpart J Test Report No. : CTK-2012-01368-5 Date of Issue : May 1, 2013 FCC ID : TN8-OWC-300T Equipment Under Test : OWC-300T Kind of Product : Wireless Charging Pad Applicant : OPENTECH Inc. Applicant Address : 13F, SJ-Technoville 60-19, Gasan-Dong, Geumcheon-Gu, Seoul, Korea, 153-801 Manufacturer : OPENTECH Inc. Manufacturer Address : 13F, SJ-Technoville 60-19, Gasan-Dong, Geumcheon-Gu, Seoul, Korea, 153-801 Contact Person : Jae Sung, Kim / Project Manager Telephone : +82-2-3397-0184 Received Date : December 6, 2012 Test period : Start : December 6, 2012 End : May 1, 2013 Test Results : In Compliance Not in Compliance The test results presented in this report relate only to the object tested. Tested by Reviewed by Young-taek Lee Test Engineer Young-Joon, Park Technical Manager Date: May 1, 2013 Date: May 1, 2013 CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Test Report No.: CTK-2012-01368-5 Date: May 1, 2013 Page 2 of 12 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 Subpart C(Rev.1) REPORT REVISION HISTORY Date Revision Page No February 7, 2013 Issued (CTK-2012-01368) All March 12, 2013 Issued (CTK-2012-01368-1) Update EUT Operating Modes and Test Modes All March 19, 2013 Issued (CTK-2012-01368-2) Update EUT Operating Modes, Test Modes and Test Results All March 21, 2013 Issued (CTK-2012-01368-3) Update Test Modes All March 25, 2013 Issued (CTK-2012-01368-4) Update Test Modes All May 1, 2013 Issued (CTK-2012-01368-5) Update Test Modes and Test Results All This report shall not be reproduced except in full, without the written approval of CTK Co., Ltd. This document may be altered or revised by CTK Co., Ltd. personnel only, and shall be noted in the revision section of the document. Any alteration of this document not carried out by CTK Co., Ltd. will constitute fraud and shall nullify the document. CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Test Report No.: CTK-2012-01368-5 Date: May 1, 2013 Page 3 of 12 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 Subpart C(Rev.1) TABLE OF CONTENTS REPORT REVISION HISTORY .......................................................................................... 2 1.0 General Product Description ............................................................................... 4 1.1 Model Differences ............................................................................................. 4 1.2 Device Modifications ......................................................................................... 4 1.3 Peripheral Devices ............................................................................................ 4 1.4 EUT Operating Modes ........................................................................................ 5 1.5 Test Modes ...................................................................................................... 5 1.6 Calibration Details of Equipment Used for Measurement ......................................... 7 1.7 Test Facility...................................................................................................... 7 1.8 Laboratory Accreditations and Listings ................................................................. 7 2.0 Summary of tests ............................................................................................. 8 2.1 Test Setup ....................................................................................................... 9 2.2 Radiofrequency radiation exposure limits ........................................................... 10 2.3 Test Results ................................................................................................... 11 APPENDIX A – Test Equipment Used For Tests ................................................................ 12 CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Test Report No.: CTK-2012-01368-5 Date: May 1, 2013 Page 4 of 12 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 Subpart C(Rev.1) 1.0 General Product Description Type of equipment Wireless Charging Pad Equipment model name OWC-300T Frequency Range 110 kHz – 205 kHz Antenna type Coil antenna Power Source AC ADAPTER Input : AC 100-240 V, 50/60 Hz Output : DC 19 V, 0.5 A Test Voltage and Frequency : AC 120 V, 60 Hz 1.1 Model Differences Not applicable 1.2 Device Modifications The following modifications were necessary for compliance: Not applicable 1.3 Peripheral Devices Device Manufacturer Model No. Serial No. FCC ID or DoC AC ADAPTER Shenzhen Huoniu Technology Co., Ltd. HNC190050U - Verification Wireless Charging Cover OPENTECH Inc. OWC-300R - - Mobile Phone Samsung Electronics Co., Ltd. SCH-I535 - A3LSCHI535 CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Test Report No.: CTK-2012-01368-5 Date: May 1, 2013 Page 5 of 12 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 Subpart C(Rev.1) 1.4 EUT Operating Modes Equipment under test was operated during the measurement under the following conditions: Charging and communication mode Modulation Type : CW (Con…
