TS4-TW-201Access Point

Tehama System Installation Guide General Description The Tehama AMR system consists of three device types to remotely monitor various environmental and utility readings and provide the data to a central database or PC for formal presentation and reporting. MDT/Sensor devices will be placed in all locations requiring local monitoring of data. The MDT/Sensors will transmit time stamped data to the DCAP device, which receives the data and stores it in a Database. The database information is available over Ethernet on the local LAN or the Internet. For MDT/Sensors that are out of range from the DCAP, Repeater devices are added in appropriate locations to relay the data between MDT/ Sensors and the DCAP The system operates in the 915Mhz ISM bands using off-the-shelf FSK RFIC radios. The system operates as a Frequency Hopper over 60 narrow band frequency channels, incorporating a bidirectional communication link with Acknowledge (ACK) messages to ensure all data reaches the DCAP. The MDT/Sensors are battery operated, bursting data packets at pre-programmed times then shutting down to conserve battery life, estimated to exceed 5 years. The DCAP and Repeater units are line powered. With an typical MDT/Sensor transmission rate of four per hour for time of use applications, a single DCAP can accommodate many hundreds of MDT/Sensors. Through the use ACK messages and local memory in both the MDT/Sensors and Repeaters, the number of MDT/ Sensors supported can exceed a thousand. There is no limit to the number of repeaters, though an average installation may require one Repeater for every 20-30 MDT/Sensors. Figure 1: Typical System Tehama Installation Guide!1 of 5 A system consists of two or three types of hardware, and a software program: • One DCAP Unit or Access Point • A variable number of Sensors units, each with 2 AA batteries • A variable number of Repeater units (optional, depending on size of installation) with external DC power supply. • Tehama Configuration Utility (CIT) running on a PC Warning Tehama Configuration & Installation Tool (CIT) You should have received a copy of the Tehama Configuration and Installation Tool (CIT) software. This runs on a Windows based PC. More detailed information can be found in the Tehama CIT User Manual or the Tehama QuickStart Guide. The tool can be run on the PC either prior to or during a site installation, or when new MDT/ Sensors are added to a system. The tool is used to add configuration data to the database. Examples of configuration data include the name, type, and location of equipment an MDT/ Sensor is connected to, and alarm trigger settings for the different MDT/Sensors. DCAP/Access Point Setup This step configures the Internet settings for the AP and lets you set unique passwords for remote access. • Power up the AP with the supplied power adaptor. • Screw in the AP antenna that came with the unit. • Attach the supplied USB cable to your computer and to the AP. If this is the first time attaching tan AP, Windows may respond with a “found new hardware” message. Follow the steps to let Windows download the driver software. • Attach the AP to your local LAN with the supplied Ethernet cable. • Launch the CIT tool on the PC • Go to the Config menu and select DCAP. The Serial Port field should be automatically populated with the correct COM port • Click on the Get button to see the current settings • DCHP (Dynamic IP Address) is the default. If you want a static IP, select static and fill out the extra fields. • Set the MySQL database passwords for both users and click “Set”. Clicking on the “Default Vals” button will fill the fields with the factory default passwords. This is provided as a convenience if password security is not an issue (for example in an evaluation system). NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT Tehama Installation Guide!2 of 5 • Click on the “Create a Site Entry” button to auto-fill a Site entry with the information from this panel. • Unplug the USB cable. It is not needed again unless you need to change the IP address or the database passwords at a future time. MDT/Sensor Configuration All MDT/Sensors come from the factory with a default factory-set configuration. The following parameters can be custom configured at the factory . There are no parameters which can be configured on the DCAP or Receiver. • Monitor Type, defined as the type of device the unit is attached to for measurements. This includes temperature via thermocouple or thermistor, humidity, CO2, Pressure, or various pulse type inputs from Utility meters or dry contact outputs from door sensors or other devices. • Transmit Interval, defined as the time between scheduled transmissions of temperature data. A temperature measurement is taken every Transmit Interval, and the data transmitted within 60 seconds after the measurement. The units for this parameter are seconds, and the default value is 900 seconds (15 minutes). • Measure Interval, defined as the time between scheduled temperature measurements. This is used in conjunction with Temperature Change (see below) and must be smaller than the Transmit Interval time. A value of 0 for this parameter will disable measurements in between the Transmit Interval. The units for this parameter are in seconds, with default set to 0. • Temperature Change, defined as a percentage change in the Thermistor resistance value (i.e. temperature) detected by the sensor. A Delta Temp alarm will be generated within the PC Software if a Sensor reading taken at a Measure Interval is more than Temperature Change percent from the prior Transmit Interval value. The units for this parameter are Percent (%), with the default value set to 0. Usage THe MDT/Sensors will come with Batteries installed. With the Configuration Tool running on the PC and the DCAP or Access Point on and…

Text truncated - open the document above for the full version.

654A Natoma Street San Francisco, CA 94103 415 495 7344 www.tehamawireless.com Letter of Authorization Company: Tehama Wireless Design Group Address: 654A Natoma Street, San Francisco, CA 94103 Product Name: Access Point Model Number: TW-201 We authorize MiCOM Labs, 440 Boulder Court, Suite 200, Pleasanton, CA 94566, USA, to act on our behalf on all matters concerning the above named equipment. This shall include the following: - Testing - Approval applications and procedures - Payment of approval fees We declare that MiCOM Labs, 440 Boulder Court, Suite 200, Pleasanton, CA 94566, USA, is allowed to forward all information related to the approval project to the applied notified body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Name: James Orton Date: 11/3/2011 Title: President ____________________________ Signature of applicant

654A Natoma Street San Francisco, CA 94103 415 495 7344 www.tehamawireless.com 7-Feb-2012 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Request for Confidentiality Company name: Tehama Wireless Design Group FCC ID: TS4-TW-201 FCC Part 15 Certification Gentlemen, Pursuant to 47 CFR 0.457(d)(1)(ii) and 0.459, Tehama Wireless Design Group hereby requests permanent confidentiality of the following attachments for the subject application: Exhibit Type File Name Description Schematic Drawings TW-201 Radio board Schematic.pdf Schematic Drawing of the RF Section Operational Description TW-201 Operation.pdf Operational Description Block Diagrams TW-201 Block Diagrams.pdf Block Diagrams These documents contain detailed system and equipment description and related information about the product that Tehama Wireless considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. Since the design is a basis from which future technological products will evolve, Tehama Wireless considers that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, James Orton President Tehama Wireless Design Group

the wireless lab 30 November 2011 Tehama Wireless TW 201 External Photographs EUT Top MiCOM Labs, 440 Boulder Court, Suite 200, Pleasanton, CA 94566 Tel: +1 (925) 462-0304, Fax: +1 (925) 462-0306, Web: www.micomlabs.com the wireless lab EUT Front Page 2 of 6 the wireless lab EUT Back Page 3 of 6 the wireless lab EUT left side Page 4 of 6 the wireless lab EUT Right Side Page 5 of 6 the wireless lab EUT Bottom Page 6 of 6

the wireless lab 19 December 2011 Tehama Wireless Internal Photographs, TW 201 Installation view MiCOM Labs, 440 Boulder Court, Suite 200, Pleasanton, CA 94566 Tel: +1 (925) 462-0304, Fax: +1 (925) 462-0306, Web: www.micomlabs.com the wireless lab Main assy front Page 2 of 4 the wireless lab Main Assy bottom Page 3 of 4 the wireless lab Radio cards top and bottom Page 4 of 4

Test of Tehama Wireless TW-201 To: FCC 47 CFR Part15.247 & IC RSS-210 Test Report Serial No.: TEHA03-U1 Rev A TITLE PAGE TEST REPORT FROM Test of Tehama Wireless TW-201 To FCC 47 CFR Part15.247 & IC RSS-210 Test Report Serial No.: TEHA03-U1 Rev A This report supersedes: None Manufacturer: Tehama Wireless 654A Natoma Street San Francisco California 94103, USA Product Function: 915 MHz FHSS Copy No: pdf Issue Date: 31st January 2012 MiCOM Labs is an ISO 17025 Accredited Testing Laboratory CERTIFICATE #2381.01 This Test Report is Issued Under the Authority of; MiCOM Labs, Inc. 440 Boulder Cour t, Suite 200 Pleasanton, CA 94566 USA Phone: +1 (925) 462-0304 Fax: +1 (925) 462-0306 www.micomlabs.com This test report may be reproduced in full only. The document may only be updated by MiCOM Labs personnel. Any changes will be noted in the Document History section of the report. Title: Tehama Wireless TW-201 To: Serial #: Issue Date: Page: FCC 47 CFR Part15.247 & IC RSS-210 TEHA03-U1 Rev A 31st January 2012 3 of 69 This test report may be reproduced in full only. The document may only be updated by MiCOM Labs p ersonnel. Any changes will be noted in the Document History section of the report. MiCOM Labs, 440 Boulder Court, Suite 200, Pleasanton, CA 94566 USA, Phone: 925.462.0304, Fax: 925.462.0306, www.micomlabs.com This page has been left intentionally blank Title: Tehama Wireless TW-201 To: Serial #: Issue Date: Page: FCC 47 CFR Part15.247 & IC RSS-210 TEHA03-U1 Rev A 31st January 2012 4 of 69 This test report may be reproduced in full only. The document may only be updated by MiCOM Labs p ersonnel. Any changes will be noted in the Document History section of the report. MiCOM Labs, 440 Boulder Court, Suite 200, Pleasanton, CA 94566 USA, Phone: 925.462.0304, Fax: 925.462.0306, www.micomlabs.com TABLE OF CONTENTS ACCREDITATION & LISTINGS.......................................................................................5 RECOGNITION................................................................................................................ 6 PRODUCT CERTIFICATION........................................................................................... 7 1. .................................................................................9 TEST RESULT CERTIFICATE 2. ......................................10 REFERENCES AND MEASUREMENT UNCERTAINTY 2.1. .......................................................................................... 10 Normative References 2.2. ......................................................................... 10 Test and Uncertainty Procedures 3. ........................................11 PRODUCT DETAILS AND TEST CONFIGURATIONS 3.1. .................................................................................................. 11 Technical Details 3.2. ......................................................................................... 12 Scope of Test Program 3.3. .......................................................... 16 Equipment Model(s) and Serial Number(s) 3.4. .................................................................................................... 16 Antenna Details 3.5. ........................................................................................... 16 Cabling and I/O Ports 3.6. ............................................................................................... 16 Test Configurations 3.7. ....................................................................................... 17 Equipment Modifications 3.8. ....................................................................... 17 Deviations from the Test Standard 3.9. .......................................................... 17 Subcontracted Testing or Third Party Data 4. ....................................................................................................18 TEST SUMMARY 5. ......................................................................................................20 TEST RESULTS 5.1. .......................................................................................... 20 Device Characteristics 5.1.1. ....................................................................................... 20 20 dB Bandwidth 5.1.2. ............................................... 30 Transmitter Channels - Channel Spacing 5.1.3. ................................................................................ 33 Transmitter Channels 5.1.4. ............................................................................................ 38 Output Power 5.1.5. ............................................................... 41 Maximum Permissible Exposure 5.1.6. ............................................. 42 Conducted Spurious Emissions Transmitter 5.1.7. ................................................ 49 Conducted Spurious Emissions Stand-By 5.1.8. .................................................................................. 53 Radiated Emissions 5.1.9. .......................... 62 AC Wireline Conducted Emissions (150 kHz – 30 MHz) 6. .....................................................................................................65 PHOTOGRAPHS 6.1. ...................................................................... 65 General Measurement Test Set-Up 6.2. ................................................................................. 66 Radiated Emissions >1 GHz 6.3. ................................................................................. 67 Radiated Emissions <1 GHz 7. .................................................................................68 TEST EQUIPMENT DETAILS Title: Tehama Wireless TW-201 To: Serial #: Issue Date: Page: FCC 47 CFR Part15.247 & IC RSS-210 TEHA03-U1 Rev A 31st January 2012 5 of 69 This test report may be reproduced in full only. The document may only be updated by MiCOM Labs p ersonnel. Any changes will be noted in the Document History section of the report. MiCOM Labs, 440 Boulder Court, Suite 200,…

Text truncated - open the document above for the full version.

the wireless lab 19 December 2011 Tehama Wireless TW 201 Test Setup Photographs General Measurement Test Set-Up MiCOM Labs, 440 Boulder Court, Suite 200, Pleasanton, CA 94566 Tel: +1 (925) 462-0304, Fax: +1 (925) 462-0306, Web: www.micomlabs.com the wireless lab Radiated Emissions >1 GHz Page 2 of 3 the wireless lab ac Wireline Emissions Page 3 of 3
