TTIUM04KOWireless Communication Module

Version 1.0 LTE Ubiquitous Module ® （UM04-KO） Instruction Manual Version 1.0 August 2015 Version 1.0 ― Contents ― Introduction ...................................................................................................................................................................................................... 3 ■ Dimensional outline drawing ............................................................................................................................................................ 4 ■Interface for the external device ...................................................................................................................................................... 5 ■ Available services with this device .................................................................................................................................................. 6 Device specification ...................................................................................................................................................................................... 7 Main specification.......................................................................................................................................................................................... 7 Interface ........................................................................................................................................................................................................ 9 1．Main connector ............................................................................................................................................................................... 9 ２．Pow er supply ................................................................................................................................................................................. 19 ３．UART interface ............................................................................................................................................................................ 28 ４．USB interface ................................................................................................................................................................................ 33 ５．Monitor interface ......................................................................................................................................................................... 35 ６．UIM card interface ..................................................................................................................................................................... 38 ７．RF connector (Main/Sub) ......................................................................................................................................................... 40 ８．External antenna ......................................................................................................................................................................... 41 Precautions for connecting to the external device .......................................................................................................................... 42 Precaution for design of the external device .................................................................................................................................. 42 Recom mended installation method ..................................................................................................................................................... 43 ■In case of using the flexible connector ................................................................................................................................... 43 ■In case of using the BtoB connector ........................................................................................................................................ 43 ■Antenna connection ...................................................................................................................................................................... 44 Operation mode ............................................................................................................................................................................................ 45 C ommunication mode .............................................................................................................................................................................. 45 Service function ........................................................................................................................................................................................... 47 Packet communication ........................................................................................................................................................................... 47 SMS .............................................................................................................................................................................................................. 49 Area Mail ..................................................................................................................................................................................................... 49 Software update ....................................................................................................................................................................................... 50 RF part ON/ OFF function .................................................................................................................................................................... 50 AT command ................................................................................................................................................................................................. 51 AT command list......…

Text truncated - open the document above for the full version.

Hitachi Kokusai Electric Inc. External Photographs Model Name: UM04-KO ■External Photo1 (A-side) ■External Photo2 (B-side) Main connector (flexible connector) RF connector (Main) RF connector (Sub) Main connector (BtoB connector)

Hitachi Kokusai Electric Inc. Label design and label location Model Name: UM04-KO

Hitachi Kokusai Electric Inc. Internal Photographs Model Name: UM04-KO ■Internal Photo1 (A-side) ■Internal Photo2 (B-side) Main connector (flexible connector) RF connector (Main) RF connector (Sub) Main connector (BtoB connector)

Hitachi Kokusai Electric Inc. TUV SUD BABT TCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 5RL Date: August 16, 2015 RF exposure analysis for the equipment UM04-KO (FCC ID: TTIUM04KO) The device (FCC ID: TTIUM04KO) is a module designed to be installed in other devices. This device is to be used only for fixed and mobile applications. If the final product after integration is intended for portable use, new FCC application are required. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all the persons and must not be co-located or operating in conjunction with any other antenna or transmitter except as under the conditions described KDB 447498 D01 General RF Exposure Guidance. MPE exposure limits The table below is excerpted from Table 1B of 47 CFR 1.1310 titled Limits for Maximum Permissible Exposure (MPE), Limits for General Population/Uncontrolled Exposure: Frequency Range (MHz) Power density (mW/cm 2 ) Averaging time (minutes) 300 – 1500 f (MHz) /1500 30 1500 – 100.000 1,0 30 The table below is excerpted from RSS-102, Issue 4, 4.2, titled “RF Limits for Devices used by the General Public”: Frequency Range (MHz) Power density (W/m 2 ) Averaging time (minutes) 300 – 1500 f (MHz) /150 6 1500 – 100.000 10 6 EIRP/ERP limits For 850 MHz frequency band and according to FCC §22.913 the maximum ERP of the device is 7 W (equivalent to 11,48 W EIRP). For 1900 MHz frequency band and according to FCC §24.232, the maximum EIRP of the device should be lower than 2 W. Using the equation 2 4R PG S π = to calculate the exposure to electromagnetic fields where: S = power density (in appropriate units, e.g. mW/cm 2 ) P = power input to the antenna (in appropriate units, e.g., mW) G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) compliance with FCC MPE and EIRP limits is demonstrated following the calculations shown in the next page. Hitachi Kokusai Electric Inc. Sincerely, P.A. __________________________ By: Takashi Okada Title: Assistance Manager Company: Hitachi Kokusai Electric Inc. Telephone: +81-42-322-3111 e-mail: [email protected]

AT4 wireless, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España www.at4wireless.com · C.I.F. A29 507 456 Report No: (NIE) 46883RRF.001 2015-09-16 FCC LISTED, REGISTRATION NUMBER: 720267 Test report No: NIE: 46883RRF.001 Test report REFERENCE STANDARD: USA FCC Part 22 & Part 24 Identificación del objeto ensayado ...................... : Identification of item tested WIRELESS COMMUNICATION MODULE Marca ................................................................... : Trademark NTT Docomo Modelo y/o referencia tipo .................................. : Model and /or type reference UM04-KO Other identification of the product .................... : FCC ID: TTIUM04KO Final HW version ................................................ : Version 0.80 Final SW version ................................................. : Version 0.56 IMEI TAC ........................................................... : 00440131 Características ..................................................... : Features GSM: 850MHz, 900MHz, 1800MHz, 1900MHz W-CDMA: Band1, Band5 LTE: Band1, Band19 Packet communication, SMS Fabricante ........................................................... : Manufacturer HITACHI KOKUSAI ELECTRIC INC. 32, Miyuki-cho, Kodaira-shi, Tokyo 187-8511, JAPAN Método de ensayo solicitado, norma ................... : Test method requested, standard USA FCC Part 22 10-1-14 Edition. USA FCC Part 24 10-1-14 Edition. Measurement Guidance 971168 D01 v02r01 for certification of Licensed Digital Transmitters. ANSI/TIA-603-C (2004). Resultado .............................................................. : Summary IN COMPLIANCE Aprobado por (nombre / cargo y firma) ........... : Approved by (name / position & signature) A. Llamas RF Lab. Manager Fecha de realización ........................................... : Date of issue 2015-09-16 Formato de informe No. ...................................... : Report template No FDT08_17 AT4 wireless, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España www.at4wireless.com · C.I.F. A29 507 456 Report No: (NIE) 46883RRF.001 Page 2 of 80 2015-09-16 Index Competences and guarantees ......................................................................................................................... 3 General conditions ......................................................................................................................................... 3 Uncertainty .................................................................................................................................................... 3 Usage of samples ........................................................................................................................................... 4 Test sample description ................................................................................................................................. 4 Identification of the client ............................................................................................................................. 4 Testing period ................................................................................................................................................ 4 Environmental conditions .............................................................................................................................. 5 Remarks and comments ................................................................................................................................. 6 Testing verdicts ............................................................................................................................................. 7 Appendix A – Test result for FCC Part 22 & FCC Part 24 ........................................................................... 8 AT4 wireless, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España www.at4wireless.com · C.I.F. A29 507 456 Report No: (NIE) 46883RRF.001 Page 3 of 80 2015-09-16 Competences and guarantees AT4 wireless is a testing laboratory accredited by the National Accreditation Body (ENAC -Entidad Nacional de Acreditación), to perform the tests indicated in the Certificate No. 51/LE 147. AT4 wireless is a laboratory with a measurement facility in compliance with the requirements of Section 2.948 of the FCC rules and has been added to the list of facilities whose measurements data will be accepted in conjuction with applications for Certification under Parts 15 or 18 of the Commission's Rules. Registration Number: 720267. In order to assure the traceability to other national and international laboratories, AT4 wireless has a calibration and maintenance program for its measurement equipment. AT4 wireless guarantees the reliability of the data presented in this report, which is the result of the measurements and the tests performed to the item under test on the date and under the conditions stated on the report and, it is based on the knowledge and technical facilities available at AT4 wireless at the time of performance of the test. AT4 wireless is liable to the client for the maintenance of the confidentiality of all information related to the item under test and the results of the test. The results presented in this Test Report apply only to the particular item under test established in this document. IMPORTANT: No parts of this report may be reproduced or quoted out of context, in any form or by any means, except in full, without the previous written permission of AT4 wireless. General conditions 1. This report is only referred to the item that has undergone the test. 2. This report does not constitute or imply on its own an approval of the product by the Certification Bodies or competent Authorities. 3. This document is only valid if complete; no partial reproduction can be made without previous written permission of AT…
