Locks and Alarms 48 L ENGINE IMMOBILISATION Engine immobilisation is an important aspect of the security system. It is designed to safeguard the vehicle from theft, should the driver forget to lock the doors. The system prevents the engine from being started unless the GENUINE remote control key is inserted into the starter switch. Engine immobilisation is automatic five seconds after the key is removed from the starter switch. Note: The engine will be re-mobilised automatically whenever the genuine remote control key is inserted into the starter switch.When this happens, the anti-theft alarm indicator will illuminate for one second and then extinguish. Caution: The immobiliser may suffer interference from other legal users of this frequency band. The immobiliser system operates on a frequency subject to USA Federal Communications Commission (FCC) rules. The device complies with Part 15 of the FCC rules and RSS-210 of the industry Canada. Operation is subject to the two following conditions: 1.The device may not cause harmful interference. 2.This device must accept any interference received, including interference that may cause undesired operation. The immobiliser frequency approval numbers for the USA and Canada are shown below: USA - TTRT5SJB. Canada - IC: 6276A-T5SJBR1 Note: Note: The manufacturer is not responsible for any radio interference or TV interference caused by unauthorized modifications to this equipment. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. SIGN OFF COPY

RF_160, Issue 01 Declaration of Authorization We Name: Lear Corporation Holdings Spain, S.L.U. Address: Fusters, 54, Valls City: Tarragona, 43800 Country: Spain Declare that: Name: RFI Global Services Ltd Address: Ewhurst Park, Ramsdell City: Basingstoke, RG26 5RQ Country: UK is authorized to apply for Certification of the following product(s): Product description: .................................................... Type designation: T5 SLB Trademark: Lear on our behalf. Date: 13 February 2007 City: Tarragona Name: Alberto Alvaro Signature:

Lear T5 SJB

CURRENT VERSION PROPOSAL FCC ID: TTRT5SJB

TEST REPORT FROM RFI GLOBAL SERVICES LTD Test of: Lear Corporation T5 SJB To: FCC Part 15.209: 2004 Including RSS-Gen Issue 1: 2005 Section 4.4.1 Test Report Serial No: RFI/MPTE3/RP47648JD01A Supersedes Test Report Serial No: RFI/MPTE2/RP47648JD01A This Test Report Is Issued Under The Authority Of Andrew Brown, Operations Manager: pp Tested By: Fara Razally pp Checked By: Tony Henriques Report Copy No: PDF01 Issue Date: 13 February 2007 Test Dates: 03 October to 25 October 2005 and 07 August 2006 This report is issued in Adobe Acrobat portable document format (PDF). It is only a valid copy of the report if it is being viewed in PDF format with the following security options not allowed: Changing the document, Selecting text and graphics, Adding or changing notes and form fields. This report may be copied in full. The results in this report apply only to the sample(s) tested. RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI/MPTE3/RP47648JD01A Page 2 of 22 Issue Date: 13 February 2007 Test of: Lear Corporation T5 SJB To: FCC Part 15.209: 2004 Including RSS-Gen Issue 1: 2005 Section 4.4.1 This page has been left intentionally blank. RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI/MPTE3/RP47648JD01A Page 3 of 22 Issue Date: 13 February 2007 Test of: Lear Corporation T5 SJB To: FCC Part 15.209: 2004 Including RSS-Gen Issue 1: 2005 Section 4.4.1 Table of Contents 1. Client Information ............................................................................................................................4 2. Equipment Under Test (EUT) ..........................................................................................................5 3. Test Specification, Methods and Procedures ...............................................................................8 4. Deviations from the Test Specification..........................................................................................9 5. Operation of the EUT During Testing...........................................................................................10 6. Summary of Test Results ..............................................................................................................11 7. Measurements, Examinations and Derived Results ...................................................................12 8. Measurement Uncertainty .............................................................................................................16 9. Measurement Methods ..................................................................................................................17 Appendix 1. Test Equipment Used ...................................................................................................19 Appendix 2. Test Configuration Drawings.......................................................................................20 RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI/MPTE3/RP47648JD01A Page 4 of 22 Issue Date: 13 February 2007 Test of: Lear Corporation T5 SJB To: FCC Part 15.209: 2004 Including RSS-Gen Issue 1: 2005 Section 4.4.1 1. Client Information Company Name: Lear Corporation Address: Fusters 54 Poligono Industrial P.O BOX 23 43800 VALLS TARRAGONA Spain RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI/MPTE3/RP47648JD01A Page 5 of 22 Issue Date: 13 February 2007 Test of: Lear Corporation T5 SJB To: FCC Part 15.209: 2004 Including RSS-Gen Issue 1: 2005 Section 4.4.1 2. Equipment Under Test (EUT) The following information (with the exception of the Date of Receipt) has been supplied by the client: 2.1. Identification of Equipment Under Test (EUT) Model Name or Number: T5 SJB Serial Number: 002015964 Country of Manufacture: Spain FCC ID Number: TTRT5SJB Date of Receipt: 03 October 2005 2.2. Description of EUT The equipment under test manages different inputs-analogue sensors, digital switches, etc and controls them through one micro-controller that is reading them permanently. The micro-controller is the core of the system. It is also plugged to different communication buses, where it is included the CAN and the LIN buses. The micro- controller also manages automotive power loads through Smartfet drivers and relay drivers. The SJB also includes an immobiliser system. 2.3. Modifications Incorporated in the EUT During the course of testing the EUT was not modified. RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI/MPTE3/RP47648JD01A Page 6 of 22 Issue Date: 13 February 2007 Test of: Lear Corporation T5 SJB To: FCC Part 15.209: 2004 Including RSS-Gen Issue 1: 2005 Section 4.4.1 2.4. Additional Information Related to Testing Power Supply Requirement: DC supply of 13.5 V Intended Operating Environment: Automotive Equipment Category: Mobile (Vehicular Use, powered via vehicle regulated supply) Type of Unit: Transceiver Interface Ports: C585 propriety connector – shielded 2 core, 2.3m C583 propriety connector – Shielded 2 core, 2.3m C582 propriety connector – Shielded 2 core, 2.3m C584 propriety connector – Shielded 2 core, 2.3m C586 propriety connector – Shielded 2 core, 2.3m C580 propriety connector – Shielded 2 core, 2.3m Frequency Range: 125 kHz, single frequency operation Channel ID Channel Number Channel Frequency (MHz) Channel Tested: Single Channel N/A 125 kHz Highest Fundamental Frequency: 125 kHz RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI/MPTE3/RP47648JD01A Page 7 of 22 Issue Date: 13 February 2007 Test of: Lear Corporation T5 SJB To: FCC Part 15.209: 2004 Including RSS-Gen Issue 1: 2005 Section 4.4.1 2.5. Support Equipment The following support equipment was used to exercise the EUT during testing: Description: Laptop PC Brand Name: Compaq Model Name or Number: EVO N610C Serial Number: 7E34K782R0EL Cable Length and Type: 50 cm Shielded Multicore Connected to Port: RS232 Description: Test Box Brand Name: LEAR Model Name or Number: T5 Serial Number: 1483 Cable Length and Type: Shielded 2 core, 2.3m Connected to Port: C580-C586 Description: CAN Bus Extender Brand Name: Tesco Model Name or Number: OBE 898 Se…
