TV7CRS109-8G2HNDDigital Transmission System

Mikrotikls SIA

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: May 15, 2014
Application Purpose: Original Equipment
Date of Application: May 15, 2014
Equipment Note: Digital Transmission System
Frequency Range: 2422.00000000 - 2452.00000000
Company: Mikrotikls SIA
Country: Latvia

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

See www.routerboard.com for more information. Contact [email protected] 24/04/14 Cloud Router Switch 8 Ethernet port series Setup Guide and Warranty Information The CRS is a highly configurable switch, powered by RouterOS. These models currently available in the 8 Ethernet port series: • CloudRouterSwitch 109-‐8G-‐1S-‐2HnD-‐IN (8 Ethernet ports, one SFP port, built in 2GHz wireless AP) • CloudRouterSwitch 112-‐8G-‐4S-‐IN (8 Ethernet ports, four SFP ports) First use The device comes preinstalled with RouterOS and is ready to use. Device is compatible with RouterOS v6 and newer, if your device comes preinstalled with an earlier version, please upgrade before using it. CRS112-‐8G-‐4S-‐IN: all the ports are switched. CRS109-‐8G-‐1S-‐2HnD-‐IN: ports 2-‐8 are switched, wireless interface and switch are bridged, and bridge contains a DHCP server. Eth1 and SFP1 have DHCP client configured. Both models can be accessed though the IP 192.168.88.1, username is admin and there is no password. Please connect with your web browser to this IP address to configure it. See this page for connection and configuration guides: http://wiki.mikrotik.com/wiki/Category:Manual Powering The device accepts powering in the following ways: • Direct-‐input power jack: 8-‐56V (24V 0.8A PSU included) • Passive PoE input: 8-‐56V (injector included) Extension Slots and Ports • Eight (8) 10/100/1000 (Gigabit) Ethernet ports (Auto MDI/X) • For CRS109: One SFP cage, compatible with 1.25G SFP modules • For CRS112: Four SFP cages, compatible with 1.25G SFP modules Resetting the device In case you wish to return the device to its original configuration, you can use the RESET button. Hold this button during boot time until LED lights start flashing, then release the button to reset RouterOS configuration. You can use this procedure if you have forgotten the password to access the device, or simply wish to return the unit to its default configuration state. See www.routerboard.com for more information. Contact [email protected] 24/04/14 Buttons and Jumpers • RouterBOOT reset button (image Reset1) has several functions: ü Hold the button before powering on the device, and at power up, the button will force load the backup boot loader. Continue holding the button for the other two functions of this button: ü Release the button when green LED starts flashing, to reset RouterOS configuration. To not load backup boot loader, you can start holding the button after power is already applied ü Release the button after LED is no longer flashing (~20 seconds) to cause device to look for Netinstall servers (required for reinstalling RouterOS over network) • RouterOS reset jumper hole (image Reset2): resets RouterOS software to defaults. Hold screwdriver pressed to this reset hole, and boot the device. Hold screwdriver in place until RouterOS configuration is cleared (10 seconds). Operating System Support Currently tested operating system is MikroTik RouterOS (starting from version 6). Safety Notice Electric shock hazard. This equipment is to be serviced by trained personnel only. Copyright and Warranty information Copyright MikroTikls SIA. This document contains information protected by copyright law. No part of it may be reproduced or transmitted in any form without prior written permission from the copyright holder. RouterBOARD, RouterOS, RouterBOOT and MikroTik are trademarks of MikroTikls SIA. All trademarks and registered trademarks appearing in this document are the property of their respective holders. Hardware. MikroTik warrants all RouterBOARD series equipment for the term of twelve (12) months from the shipping date to be free of defects in materials and workmanship under normal use and service, except in case of damage caused by me-‐ chanical, electrical or other accidental or intended damages caused by improper use or due to wind, rain, fire or other acts of nature. To return failed units to MikroTik, you must perform the following RMA (Return Merchandise Authorization) procedure. Fol-‐ low the instructions below to save time, efforts, avoid costs, and improve the speed of the RMA process. 1. If you have purchased your product from a MikroTik Reseller, please contact the Reseller company regard-‐ ing all warranty and repair issues, the following instructions apply ONLY if you purchased your equipment directly from MikroTik in Latvia. 2. MikroTik does not offer repairs for products that are not covered by warranty. Exceptions can be made for: CCR1016-‐12G, CCR1016-‐12G-‐BU, CCR1036-‐12G-‐4S, RB1100, RB1100AH, RB1100AHx2, RB1200, RB600, RB600A and RB800 as a paid service (fees apply). 3. Out-‐of-‐warranty devices and devices not covered by warranty sent to Mikrotik will be returned to the send-‐ er at sender's cost. If the customer has not organized return of such rejected devices within 12 months from the day of arrival, MikroTik has the right to discard them. RMA Instructions are located on our webpage here: http://rma.mikrotik.com This document is provided “as is” without a warranty of any kind, expressed or implied, including, but not limited to, the im-‐ plied warranty of merchantability and fitness for a particular purpose. The manufacturer has made every effort to ensure the accuracy of the contents of this document, however, it is possible that it may contain technical inaccuracies, typographical or other errors. No liability is assumed for any inaccuracy found in this publication, nor for direct or indirect, incidental, conse-‐ quential or other damages that may result from such an inaccuracy, including, but not limited to, loss of data or profits. Please report any inaccuracies found to [email protected] See www.routerboard.com for more information. Contact [email protected] 24/04/14 CE Declaration of Conformity Full Declaration of Conformity (DoC) may be obtained by visiting this web page: http://routerboard.com/doc/ [EN] English Hereby, MIKROTĪKLS SIA declares that this ROUTE…

Text truncated - open the document above for the full version.

Cover Letter(s)

November 23, 2011 Federal Communications Commission Equipment Approval Services Post Office Box 358315 Pittsburgh, Pennsylvania 15215-5315 To Whom It May Concern: Please be advised that SIA "Mikrotikls" has authorized Scot Rogers of Rogers Labs, Inc. to act on behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters and submittals. All acts carried out by Rogers Labs, Inc. on our behalf shall have the same effects as our own. Rogers Labs, Inc. is authorized to receive and exchange data between our company and the Commission. This Authorization is made pursuant to Paragraph 2.911 of FCC Rules CFR 47. This Authorization is in effect until otherwise notified in writing. Name: Edmunds Zvegincevs Title: Project Engineer Signature of applicant: SIA "Mikrotīkls" VAT # LV40003286799 Billing addr.: Aizkraukles iela 23, LV-1006, Rīga Office addr.: Pērnavas iela 46, LV-1009, Rīga Phone: +371 7317700 Fax: +371 7317701

Cover Letter(s)

May 14, 2014 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Office of Engineering and Technology Federal Communications Commission Columbia, MD 21046 Applicant: Mikrotikls SIA Pernavas 46 Riga, Latvia LV-1009 Re: Confidentiality for submittal information regarding FCC ID number TV7CRS109-8G2HND PRODUCT: Broadband Digital Transmission System operating under CFR47 part 15.247 Dear Sirs: Mikrotikls SIA requests that the material in the Schematics, Block Diagram, and Operational Description be withheld from public disclosure pursuant to Sections 0.457 and 0.459 of the Commission’s Rules following grant of the application. In support of this request, Mikrotikls submits the following: Long Term Confidential Files Include Schematics File Name Conf Schem CRS109 8G2HND.pdf Block diagram File Name Conf BlkDia CRS109 8G2HND.pdf Operational Description File Name Conf OpDes CRS109 8G2HND.pdf 1. Identification of the specific information for which confidential treatment is sought: The materials set forth in the Operational Description, block diagram, and Schematics, which are segregated from the non-confidential exhibits of the application, are those for which confidentiality is sought. 2. Identification of the Commission proceeding in which the information was submitted or a description of the circumstances giving rise to the submission: The proceeding is that involving the application for equipment authorization (certification) under FCC ID No: TV7CRS109-8G2HND 3. Explanation of the degree to which the information is commercial or financial, or contains a trade secret or is privileged: This material includes a detailed theory of operation, circuit diagrams, (schematic diagrams) and any detail Parts List. As such, this material is treated as highly confidential business information. ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 4. Explanation of the degree to which the information concerns a service that is subject to competition: The material for which confidentiality is sought is employed in the design and manufacture of this transmitting equipment that is offered on a highly competitive basis. Customers for this equipment have a variety of competing sources. 5. Explanation of how disclosure of the information could result in substantial competitive harm: Disclosure would, in effect, give away the fruits of the labors of Mikrotikls SIA engineering personnel, who have designed the equipment and the manufacturing process. Disclosure would also offer competitors additional unwarranted insight into the state of the product development, thereby allowing competitors an advantage, not available to Mikrotikls SIA. 6. Identification of any measures taken by the submitting party to prevent unauthorized disclosure: The information for which confidential treatment is sought is kept confidential by Mikrotikls SIA and not made available to third parties except pursuant to non-disclosure agreements. 7. Identification of whether the information is available to the public and the extent of any previous disclosure of the information to third parties: To the knowledge of those preparing this application, the information has not been disclosed publicly heretofore. While the general theory of operation of this equipment has been the subject of numerous disclosures in industry and standards groups as well as in rule making proceedings of the FCC, the protection sought is narrowly drawn and pertains to certain specific implementations of this radio technology. 8. Justification of the period during which the submitting party asserts that the material should not be available for public disclosure: This material should not be disclosed for at least 25 years. While improvements in design are made relatively frequently, disclosure of the design information would lead to insights into both design and manufacturing techniques that could have an adverse competitive effect for many years to come. As such, it is important that the design not be made available to unauthorized persons who might attempt to use knowledge of the design to compromise the applications for which the equipment will be employed. Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers

External Photos

ID Label/Location Info

Internal Photos

RF Exposure Info

Test Report

NVLAP Lab Code 200087-0 Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: CRS109-8G-1S-2HnD SN: 500204DB63F3/413 Louisburg, KS 66053 Test #: 140423 FCC ID#: TV7CRS109-8G2HND Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: May 14, 2014 Revision 1 File: Mikrotikls CRS109 8G2HnD TstRpt 140423 Page 1 of 34 Submittal Application Report FOR GRANT OF CERTIFICATION FOR Model: CRS109-8G-1S-2HnD 2412-2462 MHz Multiple Input Multiple Output (MIMO) Broadband Digital Transmission System FCC ID: TV7CRS109-8G2HND FOR MIKROTIKLS SIA Pernavas 46 Riga, Latvia LV-1009 Test Report Number: 140423 Authorized Signatory: Scot D. Rogers NVLAP Lab Code 200087-0 Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: CRS109-8G-1S-2HnD SN: 500204DB63F3/413 Louisburg, KS 66053 Test #: 140423 FCC ID#: TV7CRS109-8G2HND Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: May 14, 2014 Revision 1 File: Mikrotikls CRS109 8G2HnD TstRpt 140423 Page 2 of 34 Engineering Test Report for Grant of Certification Application FOR CFR 47, PART 15C - Intentional Radiators CFR 47 Paragraph 15.247 License Exempt Intentional Radiator For MIKROTIKLS SIA Pernavas 46 Riga, Latvia LV-1009 MIMO Broadband Digital Transmission System Model: CRS109-8G-1S-2HnD Frequency Range 2412-2462 MHz FCC ID#: TV7CRS109-8G2HND Test Date: April 23, 2014 Certifying Engineer: Scot D. Rogers Rogers Labs, Inc. 4405 West 259 th Terrace Louisburg, KS 66053 Telephone/Facsimile: (913) 837-3214 This report shall not be reproduced except in full, without the written approval of the laboratory. This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 Phone / Fax (913) 837-3214 NVLAP Lab Code 200087-0 Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: CRS109-8G-1S-2HnD SN: 500204DB63F3/413 Louisburg, KS 66053 Test #: 140423 FCC ID#: TV7CRS109-8G2HND Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: May 14, 2014 Revision 1 File: Mikrotikls CRS109 8G2HnD TstRpt 140423 Page 3 of 34 Table Of Contents TABLE OF CONTENTS .................................................................................................. 3 REVISIONS ..................................................................................................................... 4 FORWARD ..................................................................................................................... 5 OPINION / INTERPRETATION OF RESULTS ............................................................... 5 EQUIPMENT TESTED .................................................................................................... 5 APPLICATION FOR CERTIFICATION ........................................................................... 6 EQUIPMENT FUNCTION AND CONFIGURATION........................................................ 7 Equipment Configuration.................................................................................................................................... 7 APPLICABLE STANDARDS & TEST PROCEDURES .................................................. 8 EQUIPMENT TESTING PROCEDURES ........................................................................ 8 AC Line Conducted Emission Test Procedure .................................................................................................. 8 Radiated Emission Test Procedure ..................................................................................................................... 8 Diagram 1 Test arrangement for Conducted emissions ....................................................................................... 9 Diagram 2 Test arrangement for radiated emissions of tabletop equipment ...................................................... 10 Diagram 3 Test arrangement for radiated emissions tested on Open Area Test Site (OATS) ........................... 11 TEST SITE LOCATIONS .............................................................................................. 11 LIST OF TEST EQUIPMENT ........................................................................................ 12 UNITS OF MEASUREMENTS ...................................................................................... 13 ENVIRONMENTAL CONDITIONS................................................................................ 13 INTENTIONAL RADIATORS ........................................................................................ 13 Antenna Requirements ...................................................................................................................................... 13 Restricted Bands of Operation .......................................................................................................................... 13 Table 1 Radiated Emissions in Restricted Bands Data ...................................................................................... 14 Summary of Results for Radiated Emissions in Restricted Bands ................................................................ 14 AC Line Conducted Emissions Procedure ....................................................................................................... 15 Figure 1 AC Line Conducted Emissions Line 1 ................................................................................................ 16 NVLAP Lab Code 200087-0 Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: CRS109-8G-1S-2HnD SN: 500204DB63F3/413 Louisburg, KS 66053 Test #: 140423 FCC ID#: TV7CRS109-8G2HND Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: May 14, 2014 Revision 1 File: Mikrotikls CRS109 8G2HnD TstRpt 140423 Page 4 of 34 Figure 2 AC Line Conducted Emissions Line 2 ................................................................................................ 16 Table 2 AC Line Conducted Emissions Data (Highest Emissions Line L1) .....................…

Text truncated - open the document above for the full version.

Test Setup Photos

Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: CRS109-8G-1S-2HnD SN: 500204DB63F3/413 Louisburg, KS 66053 Test #: 140423 FCC ID#: TV7CRS109-8G2HND Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: May 14, 2014 Revision 1 File: TSup CRS109 8G2HnD Page 1 of 3 Test setup photographs AC Line Conducted Emissions Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: CRS109-8G-1S-2HnD SN: 500204DB63F3/413 Louisburg, KS 66053 Test #: 140423 FCC ID#: TV7CRS109-8G2HND Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: May 14, 2014 Revision 1 File: TSup CRS109 8G2HnD Page 2 of 3 Radiated Emissions Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: CRS109-8G-1S-2HnD SN: 500204DB63F3/413 Louisburg, KS 66053 Test #: 140423 FCC ID#: TV7CRS109-8G2HND Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: May 14, 2014 Revision 1 File: TSup CRS109 8G2HnD Page 3 of 3

Contact Information

Applicant

Edmunds Zvegincevs(Engineer, R&D)

[email protected]+371 67317700Fax: +371 67317701

Test Firm

Rogers Labs, a division of The Compatibility CntrPatrick Powell

[email protected]913-837-3214Fax: 913-837-3214

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
2	15C	2.42 GHz - 2.45 GHz	400.00 mW

Confidentiality

Long Term

Grant Notes

Power listed is conducted. The antenna installation and operating configurations of this transmitter, including any applicable antenna gain and cable loss must satisfy MPE categorical Exclusion Requirements of §2.1091. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operated in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has a 20 MHz and 40 MHz bandwidth mode.
