TV7GROOVE-2HN802.11 DIGITAL TRANSMISSION SYSTEM ROUTER

Mikrotikls SIA
802.11 DIGITAL TRANSMISSION SYSTEM ROUTER - FCC ID TV7GROOVE-2HN - Mikrotikls SIA
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Nov 15, 2011
Application Purpose
Original Equipment
Date of Application
Nov 15, 2011
Equipment Note
802.11 DIGITAL TRANSMISSION SYSTEM ROUTER
Frequency Range
2412.00000000 - 2462.00000000
Company
Mikrotikls SIA
Country
Latvia

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗
↗
↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

See www.routerboard.com for more information. Contact [email protected] for support questions. 15-Nov-2011 RouterBOARD Groove 2Hn Quick Setup Guide and Warranty Information The RouterBOARD Groove 2Hn comes preinstalled in an outdoor enclosure, with a built-in 2GHz 802.11b/g wireless, an N-Male antenna connector, and one 10/100 Ethernet connector which sup- ports MDI-X auto detection. The device is packaged with a 24V power adapter, a PoE injector and two mounting loops. Note: Another model, the Groove A-2Hn is an AP version of this device, and includes a Level4 RouterOS license for wireless access point mode support. First use 1. Connect the antenna to the N-Male connector. 2. Twist to open the Groove case, connect an Ethernet cable to the Ethernet port 3. Use the provided rubber insulator to put on the Ethernet cable, and push it into the case opening, so that the opening is tightly closed 4. The Groove accepts 8-30V Passive PoE from a PoE injector 5. The default IP address from Ether1 is 192.168.88.1 for configuration Username is admin and there is no password Powering The board accepts powering from the Ethernet port (Passive PoE):  Ethernet port accepts passive Power over Ethernet 8-30V DC. Package contains a 24V adapter and a PoE injector. Maximum power consumption of the device is 4W. Booting process This device doesn't come fitted with a Serial Port connector, so initial connection has to be done via the Ethernet cable, using the MikroTik Winbox utility. Winbox should be used to connect to the default IP address of 192.168.88.1 with the username admin and no password. In case IP connection is not available, Winbox can also be used to connect to the MAC address of the device. More infor- mation here: http://wiki.mikrotik.com/wiki/First_time_startup In case you wish to boot the device from network, for example to use MikroTik Netinstall, hold the RESET button of the de- vice when starting it until the LED light turns off, and Groove will start to look for Netinstall servers. Mounting If you wish to tighten the Groove to a pole, you can do it with the provided mounting loops. The Groove comes bundled with two mounting loops - guide the loops around the Groove though the provided edge markings, and around the pole where it will be mounted. You should avoid connecting a loose Ethernet cable to the Ethernet port, secure the cable to a wall or the pole, so that the cable weight is not pulling the port. It is recommended to secure the Ethernet cable less than 2m from the Groove device. This is to ensure that the cable doesn't damage the port by it's weight, or doesn't fall out. Expansion Slots and Ports  Built in 2GHz 802.11b/g wireless, 1x1 MIMO, station mode  One 10/100 Ethernet port, supporting automatic cross/straight cable correction (Auto MDI/X), so you can use either straight or cross-over cable for connecting to other network devices. The Ethernet port accepts 8-30V DC powering from a passive PoE injector. See www.routerboard.com for more information. Contact [email protected] for support questions. 15-Nov-2011 Buttons and Jumpers  RouterOS reset jumper hole (no direct access, board has removed from case) – resets RouterOS software to de- faults. Must short circuit the metallic sides of the hole (with a screwdriver, for example) and boot the device. Hold screwdriver in place until RouterOS configuration is cleared.  RouterBOOT reset button (access through the plastic door) has two functions: o Hold this button during boot time until LED light starts flashing, release the button to reset RouterOS configuration (same result as with reset hole) o Hold this button during boot time longer, until LED turns off, then release it to make the device look for Netinstall servers. Operating System Support Currently tested operating system is MikroTik RouterOS (starting from version v5). Copyright and Trademarks. Copyright MikroTikls SIA. This manual contains information protected by copyright law. No part of it may be reproduced or transmitted in any form without prior written permission from the copyright holder. RouterBOARD, RouterOS, RouterBOOT and MikroTik are trademarks of MikroTikls SIA. All trademarks and registered trademarks appearing in this manual are the property of their respective holders. Hardware. MikroTik warrants all RouterBOARD series equipment for the term of fifteen (15) months from the shipping date to be free of defects in materials and workmanship under normal use and service, except in case of damage caused by me- chanical, electrical or other accidental or intended damages caused by improper use or due to wind, rain, fire or other acts of nature. To return failed units to MikroTik, you must perform the following RMA (Return Merchandise Authorization) procedure. Fol- low the instructions below to save time, efforts, avoid costs, and improve the speed of the RMA process. 1. If you have purchased your product from a MikroTik Reseller, please contact the Reseller company regarding all war- ranty and repair issues, the following instructions apply ONLY if you purchased your equipment directly from MikroTik in Latvia. 2. We do not offer repairs for products that are not covered by warranty. Exceptions can be made for RB1000, RB1100 and RB1200. 3. Out-of-warranty devices and devices not covered by warranty sent to Mikrotikls will be returned to the sender at sender's cost. RMA Instructions are located on our webpage here: http://rma.mikrotik.com Manual. This manual is provided “as is” without a warranty of any kind, expressed or implied, including, but not limited to, the implied warranty of merchantability and fitness for a particular purpose. The manufacturer has made every effort to en- sure the accuracy of the contents of this manual, however, it is possible that it may contain technical inaccuracies, typo- graphical or other errors. No liability is assumed for any inaccuracy found in this publication, nor for direct or indirect, inci- dental, consequential or…

Text truncated - open the document above for the full version.

Cover Letter(s)

SIA "Mikrotīkls" Aizkraukles iela 23, Rīga, LV-1006, Latvia Phone: +371 67317700 Fax: +371 67317701 September 4, 2008 Federal Communications Commission Equipment Approval Services Post Office Box 358315 Pittsburgh, Pennsylvania 15215-5315 To Whom It May Concern: Please be advised that SIA "Mikrotikls" has authorized Scot Rogers of Rogers Labs, Inc. to act on behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters and submittals. All acts carried out by Rogers Labs, Inc. on our behalf shall have the same effects as our own. Rogers Labs, Inc. is authorized to receive and exchange data between our company and the Commission. This Authorization is made pursuant to Paragraph 2.911 of FCC Rules CFR 47. This Authorization is in effect until otherwise notified in writing. Āris Jurkāns engineer, R&D SIA "Mikrotikls"

Cover Letter(s)

November 15, 2011 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Office of Engineering and Technology Federal Communications Commission Columbia, MD 21046 Applicant: Mikrotikls SIA Pernavas 46 Riga, Latvia LV-1009 Re: Confidentiality for submittal information regarding FCC ID number TV7GROOVE-2HN PRODUCT: Broadband Digital Transmission System operating under CFR47 part 15.247 Dear Sirs: Mikrotikls SIA requests that the material in the Schematic, block diagram, and Operational Description is withheld from public disclosure Pursuant to Sections 0.457 & 0.459 of the Commission’s Rules following grant of the application. In support of this request, Mikrotikls submits the following: Long Term Confidential Files Include Schematics File Name Conf Schem GROOVE2HN.pdf Block diagram File Name Conf BlkDia GROOVE2HN.pdf Operational Description File Name Conf OpDes GROOVE2HN.pdf 1. Identification of the specific information for which confidential treatment is sought: The materials set forth in the Operational Description, block diagram, and Schematics, which are segregated from the non-confidential exhibits of the application, are those for which confidentiality is sought. 2. Identification of the Commission proceeding in which the information was submitted or a description of the circumstances giving rise to the submission: The proceeding is that involving the application for equipment authorization (certification) under FCC ID No: TV7GROOVE-2HN 3. Explanation of the degree to which the information is commercial or financial, or contains a trade secret or is privileged: This material includes a detailed theory of operation, circuit diagrams, (schematic diagrams) and any detail Parts List. As such, this material is treated as highly confidential business information. ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 4. Explanation of the degree to which the information concerns a service that is subject to competition: The material for which confidentiality is sought is employed in the design and manufacture of this transmitting equipment that is offered on a highly competitive basis. Customers for this equipment have a variety of competing sources. 5. Explanation of how disclosure of the information could result in substantial competitive harm: Disclosure would, in effect, give away the fruits of the labors of Mikrotik engineering personnel, who have designed the equipment and the manufacturing process. Disclosure would also offer competitors additional unwarranted insight into the state of the product development, thereby allowing competitors an advantage, not available to Mikrotikls SIA 6. Identification of any measures taken by the submitting party to prevent unauthorized disclosure: The information for which confidential treatment is sought is kept confidential by Mikrotikls SIA and not made available to third parties except pursuant to non-disclosure agreements. 7. Identification of whether the information is available to the public and the extent of any previous disclosure of the information to third parties: To the knowledge of those preparing this application, the information has not been disclosed publicly heretofore. While the general theory of operation of this equipment has been the subject of numerous disclosures in industry and standards groups as well as in rule making proceedings of the FCC, the protection sought is narrowly drawn and pertains to certain specific implementations of this radio technology. 8. Justification of the period during which the submitting party asserts that the material should not be available for public disclosure: This material should not be disclosed for at least 25 years. While improvements in design are made relatively frequently, disclosure of the design information would lead to insights into both design and manufacturing techniques that could have an adverse competitive effect for many years to come. As such, it is important that the design not be made available to unauthorized persons who might attempt to use knowledge of the design to compromise the applications for which the equipment will be employed. Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers

Cover Letter(s)

Mikrotikls SIA 46 Pernavas str., Riga LV-1009, LATVIA Tel: +371 6 7317700Fax:+371 6 7317701 DoC Attestation Letter Date:2011/11/15 We Mikrotikls SIA, as the grantee of this project FCC ID:TV7GROOVE-2HN, would like to declare that the composite portion catagorized as computer peripheral has been authorized under the Declaration of Conformity procedures. Regards, FCC Grantee contract person information. Applicant's company name : Mikrotikls SIA Applicant's company address : 46 Pernavas str., Riga LV-1009, LATVIA Signature : Job Tittle and Dept. : Zvegincevs Edmunds / Engineer, R&D E-Mail : [email protected] Tel. : +371 6 7317700

Cover Letter(s)

November 16, 2011 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Federal Communications Commission Equipment Approval Services P.O. Box 35815 Pittsburgh, PA 15251-3315 Applicant: Mikrotikls SIA Pernavas 46 Riga, Latvia LV-1009 Equipment: FCC ID: TV7GROOVE-2HN FCC Rules: Part 15.247 Digital Transmission System approval Gentlemen: The form 731 and application have been electronically submitted and any attachments will be up loaded to your site to be used in obtaining grant of certification. Please note professional Installation is addressed in user manual. Permanent Mikrotikls SIA requests that the material in the Schematic, block diagram, and Operational Description is withheld from public disclosure Pursuant to Sections 0.457 & 0.459 of the Commission’s Rules following grant of the application. Schematics File Name Conf Schem GROOVE2HN.pdf Block diagram File Name Conf BlkDia GROOVE2HN.pdf Operational Description File Name Conf OpDes GROOVE2HN.pdf Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers Rogers Labs, Inc. Enclosures ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 Phone / Fax (913) 837-3214

External Photos

Rogers Labs, Inc. MIKROTIK 4405 W. 259th Terrace Model: Groove-2Hn FCC ID#: TV7GROOVE-2HN Louisburg, KS 66053 Test #: 110915G SN: 30F501538185 Phone/Fax: (913) 837-3214 Test to: FCC (15.247) Date: November 15, 2011 Revision 1 File: ExtPho Groove2Hn Page 1 of 3 External photographs of equipment under test Rogers Labs, Inc. MIKROTIK 4405 W. 259th Terrace Model: Groove-2Hn FCC ID#: TV7GROOVE-2HN Louisburg, KS 66053 Test #: 110915G SN: 30F501538185 Phone/Fax: (913) 837-3214 Test to: FCC (15.247) Date: November 15, 2011 Revision 1 File: ExtPho Groove2Hn Page 2 of 3 Rogers Labs, Inc. MIKROTIK 4405 W. 259th Terrace Model: Groove-2Hn FCC ID#: TV7GROOVE-2HN Louisburg, KS 66053 Test #: 110915G SN: 30F501538185 Phone/Fax: (913) 837-3214 Test to: FCC (15.247) Date: November 15, 2011 Revision 1 File: ExtPho Groove2Hn Page 3 of 3 Accessories

ID Label/Location Info

Rogers Labs, Inc. MIKROTIK 4405 W. 259th Terrace Model: Groove-2Hn FCC ID#: TV7GROOVE-2HN Louisburg, KS 66053 Test #: 110915G SN: 30F501538185 Phone/Fax: (913) 837-3214 Test to: FCC (15.247) Date: November 15, 2011 Revision 1 File: LabelSmpl Groove2Hn Page 1 of 1 Label and Placement Label

Internal Photos

Rogers Labs, Inc. MIKROTIK 4405 W. 259th Terrace Model: Groove-2Hn FCC ID#: TV7GROOVE-2HN Louisburg, KS 66053 Test #: 110915G SN: 30F501538185 Phone/Fax: (913) 837-3214 Test to: FCC (15.247) Date: November 15, 2011 Revision 1 File: IntPho Groove2Hn Page 1 of 2 Internal photographs of equipment under test (inside enclosure) Backside Rogers Labs, Inc. MIKROTIK 4405 W. 259th Terrace Model: Groove-2Hn FCC ID#: TV7GROOVE-2HN Louisburg, KS 66053 Test #: 110915G SN: 30F501538185 Phone/Fax: (913) 837-3214 Test to: FCC (15.247) Date: November 15, 2011 Revision 1 File: IntPho Groove2Hn Page 2 of 2 Shield removed for photograph Backside of Heat Sink removed

RF Exposure Info

Rogers Labs, Inc. MIKROTIK 4405 W. 259th Terrace Model: Groove-2Hn FCC ID#: TV7GROOVE-2HN Louisburg, KS 66053 Test #: 110915G SN: 30F501538185 Phone/Fax: (913) 837-3214 Test to: FCC (15.247) Date: November 14, 2011 Revision 1 File: RFExp Groove2Hn Page 1 of 1

Test Report

NVLAP Lab Code 200087-0 Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: Groove-2Hn SN: 30F501538185 Louisburg, KS 66053 Test #: 110914BA FCC ID#: TV7GROOVE-2HN Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: November 14, 2011 Revision 1 File: MikrotiklsGroove2Hn 110915G TstRpt Page 1 of 46 SUBMITTAL APPLICATION REPORT FOR GRANT OF CERTIFICATION FOR Model: Groove-2Hn 2412-2462 MHz Broadband Digital Transmission System FCC ID: TV7GROOVE-2HN FOR MIKROTIKLS SIA Pernavas 46 Riga, Latvia LV-1009 Test Report Number: 110915G Authorized Signatory: Scot D. Rogers NVLAP Lab Code 200087-0 Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: Groove-2Hn SN: 30F501538185 Louisburg, KS 66053 Test #: 110914BA FCC ID#: TV7GROOVE-2HN Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: November 14, 2011 Revision 1 File: MikrotiklsGroove2Hn 110915G TstRpt Page 2 of 46 Engineering Test Report For Grant of Certification Application FOR CFR 47, PART 15C - Intentional Radiators CFR 47 Paragraph 15.247 License Exempt Intentional Radiator For MIKROTIKLS SIA Pernavas 46 Riga, Latvia LV-1009 Broadband Digital Transmission System Model: Groove-2Hn Frequency Range 2412-2462 MHz FCC ID#: TV7GROOVE-2HN Test Date: September 15, 2011 Certifying Engineer: Scot D. Rogers Rogers Labs, Inc. 4405 West 259 th Terrace Louisburg, KS 66053 Telephone/Facsimile: (913) 837-3214 This report shall not be reproduced except in full, without the written approval of the laboratory. This report must not be used by the client to claim product endorsement by NVLAP, NIST, or any agency of the U.S. Government. ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 Phone / Fax (913) 837-3214 NVLAP Lab Code 200087-0 Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: Groove-2Hn SN: 30F501538185 Louisburg, KS 66053 Test #: 110914BA FCC ID#: TV7GROOVE-2HN Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: November 14, 2011 Revision 1 File: MikrotiklsGroove2Hn 110915G TstRpt Page 3 of 46 Table Of Contents TABLE OF CONTENTS .................................................................................................. 3 FORWARD ..................................................................................................................... 6 OPINION / INTERPRETATION OF RESULTS ............................................................... 6 ENVIRONMENTAL CONDITIONS.................................................................................. 6 EQUIPMENT TESTED .................................................................................................... 6 APPLICATION FOR CERTIFICATION ........................................................................... 7 APPLICABLE STANDARDS & TEST PROCEDURES .................................................. 8 EQUIPMENT FUNCTION AND CONFIGURATION ........................................................ 8 Equipment Configuration.................................................................................................................................... 8 TEST SITE LOCATIONS ................................................................................................ 9 UNITS OF MEASUREMENTS ........................................................................................ 9 TEST PROCEDURES ................................................................................................... 10 AC Line Conducted Emission Test Procedure ................................................................................................ 10 Radiated Emission Test Procedure ................................................................................................................... 10 LIST OF TEST EQUIPMENT ........................................................................................ 11 INTENTIONAL RADIATORS ........................................................................................ 12 Antenna Requirements ...................................................................................................................................... 12 Restricted Bands of Operation .......................................................................................................................... 12 General Radiated Emissions in Restricted Bands Data (General all configurations) ........................................ 13 Harmonic Radiated Emissions in Restricted Bands Data (Omni Directional 15dBi) ........................................ 13 Harmonic Radiated Emissions in Restricted Bands Data (Omni Horizontal 13dBi) ......................................... 14 Harmonic Radiated Emissions in Restricted Bands Data (Sector 17dBi) .......................................................... 14 Harmonic Radiated Emissions in Restricted Bands Data (Panel 20dBi) ........................................................... 15 Harmonic Radiated Emissions in Restricted Bands Data (Dish 24dBi) ............................................................ 15 NVLAP Lab Code 200087-0 Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: Groove-2Hn SN: 30F501538185 Louisburg, KS 66053 Test #: 110914BA FCC ID#: TV7GROOVE-2HN Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: November 14, 2011 Revision 1 File: MikrotiklsGroove2Hn 110915G TstRpt Page 4 of 46 Summary of Results for Radiated Emissions in Restricted Bands ................................................................ 16 AC Line Conducted Emissions Procedure ....................................................................................................... 16 Figure One AC Line Conducted Emissions Line 1............................................................................................ 17 Figure Two AC Line Conducted Emissions Line 2 ........................................................................................... 17 AC Line Conducted Emissions Data (Highest Emissions) .............................................................…

Text truncated - open the document above for the full version.

Test Setup Photos

Rogers Labs, Inc. MIKROTIK 4405 W. 259th Terrace Model: Groove-2Hn FCC ID#: TV7GROOVE-2HN Louisburg, KS 66053 Test #: 110915G SN: 30F501538185 Phone/Fax: (913) 837-3214 Test to: FCC (15.247) Date: November 15, 2011 Revision 1 File: TSup Groove2Hn Page 1 of 6 Test setup photographs AC Line Conducted Emissions Rogers Labs, Inc. MIKROTIK 4405 W. 259th Terrace Model: Groove-2Hn FCC ID#: TV7GROOVE-2HN Louisburg, KS 66053 Test #: 110915G SN: 30F501538185 Phone/Fax: (913) 837-3214 Test to: FCC (15.247) Date: November 15, 2011 Revision 1 File: TSup Groove2Hn Page 2 of 6 Radiated Emissions Omni Directional 15dBi Antenna Rogers Labs, Inc. MIKROTIK 4405 W. 259th Terrace Model: Groove-2Hn FCC ID#: TV7GROOVE-2HN Louisburg, KS 66053 Test #: 110915G SN: 30F501538185 Phone/Fax: (913) 837-3214 Test to: FCC (15.247) Date: November 15, 2011 Revision 1 File: TSup Groove2Hn Page 3 of 6 Omni Directional (hor. polarization) 13dBi Rogers Labs, Inc. MIKROTIK 4405 W. 259th Terrace Model: Groove-2Hn FCC ID#: TV7GROOVE-2HN Louisburg, KS 66053 Test #: 110915G SN: 30F501538185 Phone/Fax: (913) 837-3214 Test to: FCC (15.247) Date: November 15, 2011 Revision 1 File: TSup Groove2Hn Page 4 of 6 Panel 20dBi Rogers Labs, Inc. MIKROTIK 4405 W. 259th Terrace Model: Groove-2Hn FCC ID#: TV7GROOVE-2HN Louisburg, KS 66053 Test #: 110915G SN: 30F501538185 Phone/Fax: (913) 837-3214 Test to: FCC (15.247) Date: November 15, 2011 Revision 1 File: TSup Groove2Hn Page 5 of 6 Sector 17dBi Rogers Labs, Inc. MIKROTIK 4405 W. 259th Terrace Model: Groove-2Hn FCC ID#: TV7GROOVE-2HN Louisburg, KS 66053 Test #: 110915G SN: 30F501538185 Phone/Fax: (913) 837-3214 Test to: FCC (15.247) Date: November 15, 2011 Revision 1 File: TSup Groove2Hn Page 6 of 6 Dish 24dBi

Contact Information

Applicant

Edmunds Zvegincevs(engineer, R&D)
[email protected]+371 67317700Fax: +371 67317701

Test Firm

Rogers Labs, Inc.Scot Rogers
[email protected]913-837-3214Fax: 913-837-3214

Technical Specifications

#Rule PartsFrequency RangePower Output
115C2.41 GHz - 2.46 GHz500.00 mW
Confidentiality
Long Term
Grant Notes
Power listed is conducted. This device must be professionally installed. The antenna(s) used for this transmitter must be fixed-mounted on indoor or outdoor permanent structures with a separation distance of at least 100 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. This transmitter is restricted for use with the specific antenna(s) tested in this application for Certification. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.
