See www.routerboard.com for more information. Contact [email protected] for support questions. 22-Mar-2012 RouterBOARD Metal 5SHPN Quick Setup Guide and Warranty Information The RouterBOARD Metal 5SHPN is a solid, waterproof outdoor device with a high power wireless transmitter (5GHz, 802.11a/n, N-­‐Male antenna connector), and one 10/100 Ethernet connector which supports MDI-­‐X auto detection. The device is packaged with a 24V power adapter, a PoE injector and two mounting loops. First use 1. Connect the antenna to the N-­‐Male connector 2. Use the latches to open the product case, to reveal the Ethernet connector 3. Use the provided round rubber insulator to put on the Ethernet cable, and push it into the case opening, so that the opening is tightly closed. To put the cable though the insulator, you have to put in the cable first, and only then clamp on the Ethernet connector. If the connector is already on the cable, you can cut the insulator on one side, to clamp it around the cable, but this sacrifices waterproofness. 4. The Metal accepts 12-­‐28V Passive PoE from a PoE injector (please compensate voltage for loss due to cable length) 5. The default IP address from Ether1 is 192.168.88.1 for configuration Username is admin and there is no password 6. Depending on the antenna used, you must set its gain in the RouterOS software to ensure that EIRP meets the limit set by authorities. This is done in the Wireless menu. Powering The board accepts powering from the Ethernet port (Passive PoE): • Ethernet port accepts passive Power over Ethernet 12-28V DC. Package contains a 24V adapter and a PoE injector. Maximum power consumption of the device is 12W at 24V. Booting process Initial connection has to be done via the Ethernet cable. Open 192.168.88.1 in your web browser, and choose “Webfig” for browser based configuration or “Winbox” for a Windows utility with the same functions. Username is admin and there is no password. In case IP connection is not available, Winbox can be used to connect to the MAC address of the device. More information here: http://wiki.mikrotik.com/wiki/First_time_startup In case you wish to boot the device from network, for example to use MikroTik Netinstall, hold the RESET button of the device when starting it until the LED light turns off, and Metal will start to look for Netinstall servers. Mounting To tighten the Metal to a pole, use the provided mounting loops. The Metal comes bundled with two plastic and two metallic mounting loops (choose either) -­‐ guide the loops around the Metal though the provided edge markings, and around the pole where it will be mounted. You should avoid connecting a loose Ethernet cable to the Ethernet port -­‐ secure the cable to a wall or the pole, so that the cable weight is not pulling the port. It is recommended to secure the Ethernet cable less than 2m from the Metal device. This is to ensure that the cable doesn't damage the port by its weight, or doesn't fall out. See www.routerboard.com for more information. Contact [email protected] for support questions. 22-Mar-2012 Expansion Slots and Ports • Built in 5GHz 802.11a/n wireless, 1x1 MIMO, station mode (AP mode for Metal A-5SHPN) • One 10/100 Ethernet port, supporting automatic cross/straight cable correction (Auto MDI/X), so you can use either straight or cross-over cable for connecting to other network devices. The Ethernet port accepts 8-30V DC powering from a passive PoE injector. Buttons and Jumpers • RouterOS reset jumper hole (no direct access, board has to be removed from case) – resets RouterOS software to defaults. Must short circuit the metallic sides of the hole (with a screwdriver, for example) and boot the device. Hold screwdriver in place until RouterOS configuration is cleared. • RouterBOOT reset button (access through the door) has two functions: o Hold this button during boot time until LED light starts flashing, release the button to reset RouterOS configuration (same result as with reset hole) o Hold this button during boot time longer, until LED turns off, then release it to make the device look for Netinstall servers. Operating System Support Currently tested operating system is MikroTik RouterOS (starting from version v5.0). Copyright and Trademarks Copyright MikroTikls SIA. This manual contains information protected by copyright law. No part of it may be reproduced or transmitted in any form without prior written permission from the copyright holder. RouterBOARD, RouterOS, RouterBOOT and MikroTik are trademarks of MikroTikls SIA. All trademarks and registered trademarks appearing in this manual are the property of their respective holders. Hardware. MikroTik warrants all RouterBOARD series equipment for the term of fifteen (15) months from the shipping date to be free of defects in materials and workmanship under normal use and service, except in case of damage caused by mechanical, electrical or other accidental or intended damages caused by improper use or due to wind, rain, fire or other acts of nature. To return failed units to MikroTik, you must perform the following RMA (Return Merchandise Authorization) procedure. Follow the instructions below to save time, efforts, avoid costs, and improve the speed of the RMA process. 1. If you have purchased your product from a MikroTik Reseller, please contact the Reseller company regarding all warranty and repair issues, the following instructions apply ONLY if you purchased your equipment directly from MikroTik in Latvia. 2. We do not offer repairs for products that are not covered by warranty. Exceptions can be made for RB1000, RB1100 and RB1200. 3. Out-­‐of-­‐warranty devices and devices not covered by warranty sent to Mikrotikls will be returned to the sender at sender's cost. RMA Instructions are located on our webpage here: http://rma.mikrotik.com Manual. This manual is provided “as is” without a warranty of any kind, expressed or implied, including, but not limited to, the implied warranty o…

Text truncated - open the document above for the full version.

November 23, 2011 Federal Communications Commission Equipment Approval Services Post Office Box 358315 Pittsburgh, Pennsylvania 15215-5315 To Whom It May Concern: Please be advised that SIA "Mikrotikls" has authorized Scot Rogers of Rogers Labs, Inc. to act on behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters and submittals. All acts carried out by Rogers Labs, Inc. on our behalf shall have the same effects as our own. Rogers Labs, Inc. is authorized to receive and exchange data between our company and the Commission. This Authorization is made pursuant to Paragraph 2.911 of FCC Rules CFR 47. This Authorization is in effect until otherwise notified in writing. Name: Edmunds Zvegincevs Title: Project Engineer Signature of applicant: SIA "Mikrotīkls" VAT # LV40003286799 Billing addr.: Aizkraukles iela 23, LV-1006, Rīga Office addr.: Pērnavas iela 46, LV-1009, Rīga Phone: +371 7317700 Fax: +371 7317701

May 24, 2012 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Office of Engineering and Technology Federal Communications Commission Columbia, MD 21046 Applicant: Mikrotikls SIA Pernavas 46 Riga, Latvia LV-1009 Re: Confidentiality for submittal information regarding FCC ID number TV7METL5SHPN PRODUCT: Broadband Digital Transmission System operating under CFR47 part 15.247 Dear Sirs: Mikrotikls SIA requests that the material in the Parts List, Schematics, Block Diagram, and Operational Description be withheld from public disclosure pursuant to Sections 0.457 and 0.459 of the Commission’s Rules following grant of the application. In support of this request, Mikrotikls submits the following: Long Term Confidential Files Include Schematics File Name Conf Schem METL5SHPN.pdf Block diagram File Name Conf BlkDia METL5SHPN.pdf Operational Description File Name Conf OpDes METL5SHPN.pdf 1. Identification of the specific information for which confidential treatment is sought: The materials set forth in the Operational Description, block diagram, and Schematics, which are segregated from the non-confidential exhibits of the application, are those for which confidentiality is sought. 2. Identification of the Commission proceeding in which the information was submitted or a description of the circumstances giving rise to the submission: The proceeding is that involving the application for equipment authorization (certification) under FCC ID No: TV7METL5SHPN 3. Explanation of the degree to which the information is commercial or financial, or contains a trade secret or is privileged: This material includes a detailed theory of operation, circuit diagrams, (schematic diagrams) and any detail Parts List. As such, this material is treated as highly confidential business information. ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 4. Explanation of the degree to which the information concerns a service that is subject to competition: The material for which confidentiality is sought is employed in the design and manufacture of this transmitting equipment that is offered on a highly competitive basis. Customers for this equipment have a variety of competing sources. 5. Explanation of how disclosure of the information could result in substantial competitive harm: Disclosure would, in effect, give away the fruits of the labors of Mikrotik engineering personnel, who have designed the equipment and the manufacturing process. Disclosure would also offer competitors additional unwarranted insight into the state of the product development, thereby allowing competitors an advantage, not available to Mikrotikls SIA 6. Identification of any measures taken by the submitting party to prevent unauthorized disclosure: The information for which confidential treatment is sought is kept confidential by Mikrotikls SIA and not made available to third parties except pursuant to non-disclosure agreements. 7. Identification of whether the information is available to the public and the extent of any previous disclosure of the information to third parties: To the knowledge of those preparing this application, the information has not been disclosed publicly heretofore. While the general theory of operation of this equipment has been the subject of numerous disclosures in industry and standards groups as well as in rule making proceedings of the FCC, the protection sought is narrowly drawn and pertains to certain specific implementations of this radio technology. 8. Justification of the period during which the submitting party asserts that the material should not be available for public disclosure: This material should not be disclosed for at least 25 years. While improvements in design are made relatively frequently, disclosure of the design information would lead to insights into both design and manufacturing techniques that could have an adverse competitive effect for many years to come. As such, it is important that the design not be made available to unauthorized persons who might attempt to use knowledge of the design to compromise the applications for which the equipment will be employed. Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers

May 22, 2012 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Federal Communications Commission Equipment Approval Services P.O. Box 35815 Pittsburgh, PA 15251-3315 Applicant: Mikrotikls SIA Pernavas 46 Riga, Latvia LV-1009 Equipment: FCC ID: TV7METL5SHPN FCC Rules: Part 15.247 Digital Transmission System approval Men: The form 731 and application have been electronically submitted and any attachments will be up loaded to your site to be used in obtaining grant of certification. Permanent Mikrotikls SIA requests that the material in the Schematics, Operational Description, Block diagram, and parts list be withheld from public disclosure pursuant to Sections 0.457 and 0.459 of the Commission’s Rules following grant of the application. Schematics File Name Conf Schem METL5SHPN.pdf Block diagram File Name Conf BlkDia METL5SHPN.pdf Operational Description File Name Conf OpDes METL5SHPN.pdf Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers Rogers Labs, Inc. Enclosures ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 Phone / Fax (913) 837-3214

Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: Metal 5SHPn SN: 315401DD0BF9/128 Louisburg, KS 66053 Test #: 120416M FCC ID#: TV7METL5SHPN Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: May 22, 2012 Revision 1 File: ExtPho METL5SHPN Page 1 of 3 External photographs of equipment under test Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: Metal 5SHPn SN: 315401DD0BF9/128 Louisburg, KS 66053 Test #: 120416M FCC ID#: TV7METL5SHPN Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: May 22, 2012 Revision 1 File: ExtPho METL5SHPN Page 2 of 3 Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: Metal 5SHPn SN: 315401DD0BF9/128 Louisburg, KS 66053 Test #: 120416M FCC ID#: TV7METL5SHPN Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: May 22, 2012 Revision 1 File: ExtPho METL5SHPN Page 3 of 3

Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: Metal 5SHPn SN: 315401DD0BF9/128 Louisburg, KS 66053 Test #: 120416M FCC ID#: TV7METL5SHPN Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: May 22, 2012 Revision 1 File: LabelSmpl METL5SHPN Page 1 of 1 Label and Placement

Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: Metal 5SHPn SN: 315401DD0BF9/128 Louisburg, KS 66053 Test #: 120416M FCC ID#: TV7METL5SHPN Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: May 22, 2012 Revision 1 File: IntPho METL5SHPN Page 1 of 1 Internal photographs of equipment under test (inside enclosure)

RouterBOARD Metal 5SHPn 802.11a/n WLAN Access point Tuning procedure Each units TX and RX functionality is tested and judged with a pass/fail criteria during production. Units meeting the criteria continue through production and others are returned for diagnostics. Mikrotikls SIA, 46 Pernavas str., Riga LV-1009, LatviaPhone +371 67317700, fax +37167317700

Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: Metal-5SHPn FCC ID#: TV7METL5SHPN Louisburg, KS 66053 Test #: 120416M SN: 315401DD0BF9/128 Phone/Fax: (913) 837-3214 Test to: FCC (15.247) Date: May 9, 2012 Revision 1 File: RFExp METL5SHPN Page 1 of 1 MikrotikModel: Metal 5SHPnTest Number:120416M MPE CalculatorMPE uses EIRP for calculation. EIRP is based on TX power added to the antenna gain in dBi. dBi = dB gain compared to an isotropic radiator. S = power density in mW/cm^2 Antenna Gain (dBi)32 Output PowerdBd + 2.17 = dBidBi to dBd2.2 Tx Frequency (MHz)5785Maximum (Watts)1.000000Antenna Gain (dBd)29.83 Cable Loss (dB)0.0(dBm)30.00Antenna minus cable (dBi)32.00 Calculated ERP (mw)961612.278EIRP = Po(dBM) + Gain (dB) Calculated EIRP (mw)1584893.192Radiated (EIRP) dBm62.000 ERP = EIRP - 2.17 dB Occupational Limit Radiated (ERP) dBm59.830 5.00000mW/cm 2 50.00000W/m 2 General Public Limit 1.00000mW/cm 2 10.00000W/m 2 Frequency (MHz)Occupational LimitPublic Limit 300-1,500f/300f/1500 1,500-10,00051 Frequency (MHz)Occupational LimitPublic Limit 300-1,500 (mW/cm2)19.283333333.856666667 300-1,500 (W/m2)192.833333338.56666667 1,500-10,000 (mW/cm2)51 1,500-10,000 (W/m2)5010 EIRPSSDistanceDistanceDistanceDistance milliwatts mW/cm 2 W/m 2 cmmeterinchesFeet 1584893.1920.829208.29203390.003.90153.540.33 1584893.1920.873428.73420380.003.80149.610.32 1584893.1920.921279.21269370.003.70145.670.31 1584893.1920.973169.73162360.003.60141.730.30 1584893.1921.0295710.29566350.003.50137.800.29 1584893.1921.0910210.91019340.003.40133.860.28 1584893.1921.1581411.58143330.003.30129.920.28 1584893.1921.2316612.31658320.003.20125.980.27 1584893.1921.3124013.12402310.003.10122.050.26 1584893.1921.4013514.01353300.003.00118.110.25 1584893.1921.6677316.67726275.002.75108.270.23 1584893.1922.0179520.17949250.002.5098.430.21 1584893.1922.4912924.91295225.002.2588.580.19 1584893.1923.1530431.53045200.002.0078.740.17 1584893.1924.1182641.18263175.001.7568.900.15 1584893.1924.9266349.26633160.001.6062.990.13 1584893.1925.6054156.05413150.001.5059.060.13 Frequency (MHz) Occupational Limit minimum Distance (meters) Occupational Limit minimum Distance (cm / inches) Public Limit minimum distance (meters) Public Limit minimum distance (cm / inches) 300-1,500N/AN/AN/AN/A 1,500-10,0001.60160 / 633.50350 / 138 FCC radio frequency radiation exposure limits per 1.1310 (mW/cm2) FCC radio frequency radiation exposure limits per 1.1310 Power density (S) EIRP -------= mW/cm^2 4 p r^2 r (cm) EIRP (mW)

NVLAP Lab Code 200087-0 Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: Metal 5SHPn SN: 315401DD0BF9/128 Louisburg, KS 66053 Test #: 120416M FCC ID#: TV7METL5SHPN Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: May 22, 2012 Revision 1 File: Mikrotikls Metal 5SHPn TstRpt 120416M Page 1 of 48 SUBMITTAL APPLICATION REPORT FOR GRANT OF CERTIFICATION FOR Model: Metal 5SHPn 5740-5830 MHz Broadband Digital Transmission System FCC ID: TV7METL5SHPN FOR MIKROTIKLS SIA Pernavas 46 Riga, Latvia LV-1009 Test Report Number: 120416M Authorized Signatory: Scot D. Rogers NVLAP Lab Code 200087-0 Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: Metal 5SHPn SN: 315401DD0BF9/128 Louisburg, KS 66053 Test #: 120416M FCC ID#: TV7METL5SHPN Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: May 22, 2012 Revision 1 File: Mikrotikls Metal 5SHPn TstRpt 120416M Page 2 of 48 Engineering Test Report For Application of Grant of Certification FOR CFR 47, PART 15C - Intentional Radiators CFR 47 Paragraph 15.247 License Exempt Intentional Radiator For MIKROTIKLS SIA Pernavas 46 Riga, Latvia LV-1009 Broadband Digital Transmission System Model: Metal 5SHPn Frequency Range 5740-5830 MHz FCC ID#: TV7METL5SHPN Test Date: April 16, 2012 Certifying Engineer: Scot D. Rogers Rogers Labs, Inc. 4405 West 259 th Terrace Louisburg, KS 66053 Telephone/Facsimile: (913) 837-3214 This report shall not be reproduced except in full, without the written approval of the laboratory. This report must not be used by the client to claim product endorsement by NVLAP, NIST, or any agency of the U.S. Government. ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 Phone / Fax (913) 837-3214 NVLAP Lab Code 200087-0 Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: Metal 5SHPn SN: 315401DD0BF9/128 Louisburg, KS 66053 Test #: 120416M FCC ID#: TV7METL5SHPN Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: May 22, 2012 Revision 1 File: Mikrotikls Metal 5SHPn TstRpt 120416M Page 3 of 48 Table Of Contents TABLE OF CONTENTS .................................................................................................. 3 FORWARD ..................................................................................................................... 6 OPINION / INTERPRETATION OF RESULTS ............................................................... 6 ENVIRONMENTAL CONDITIONS.................................................................................. 6 EQUIPMENT TESTED .................................................................................................... 6 APPLICATION FOR CERTIFICATION ........................................................................... 7 APPLICABLE STANDARDS & TEST PROCEDURES .................................................. 8 EQUIPMENT FUNCTION AND CONFIGURATION........................................................ 8 Equipment Configuration.................................................................................................................................... 9 TEST SITE LOCATIONS ................................................................................................ 9 UNITS OF MEASUREMENTS ........................................................................................ 9 TEST PROCEDURES ................................................................................................... 10 AC Line Conducted Emission Test Procedure ................................................................................................ 10 Radiated Emission Test Procedure ................................................................................................................... 10 LIST OF TEST EQUIPMENT ........................................................................................ 11 INTENTIONAL RADIATORS ........................................................................................ 12 Antenna Requirements ...................................................................................................................................... 12 Restricted Bands of Operation .......................................................................................................................... 12 Radiated Emissions in Restricted Bands Data (worst-case) .............................................................................. 12 Harmonic Radiated Emissions in Restricted Bands Data (8.5 dBi Omni) ......................................................... 13 Harmonic Radiated Emissions in Restricted Bands Data (24 dBi Panel) .......................................................... 13 Harmonic Radiated Emissions in Restricted Bands Data (32 dBi Dish) ........................................................... 13 Summary of Results for Radiated Emissions in Restricted Bands ................................................................ 14 NVLAP Lab Code 200087-0 Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: Metal 5SHPn SN: 315401DD0BF9/128 Louisburg, KS 66053 Test #: 120416M FCC ID#: TV7METL5SHPN Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: May 22, 2012 Revision 1 File: Mikrotikls Metal 5SHPn TstRpt 120416M Page 4 of 48 AC Line Conducted Emissions Procedure ....................................................................................................... 14 Figure One AC Line Conducted Emissions Line 1 ........................................................................................... 15 Figure Two AC Line Conducted Emissions Line 2 ........................................................................................... 15 AC Line Conducted Emissions Data (Highest Emissions) ................................................................................ 16 Summary of Results for AC Line Conducted Emissions ................................................................................ 16 General Radiated Emissions Procedure ..................................…
