TV7RB911-2HNDMIMO BROADBAND DIGITAL TRANSMISSION SYSTEM

Mikrotikls SIA

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Apr 03, 2014
Application Purpose: Original Equipment
Date of Application: Apr 03, 2014
Equipment Note: MIMO BROADBAND DIGITAL TRANSMISSION SYSTEM
Frequency Range: 2422.00000000 - 2452.00000000
Company: Mikrotikls SIA
Country: Latvia

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

See www.routerboard.com for more information. Contact [email protected] for support questions. 28-Mar-14 RouterBOARD 91x series Quick Setup Guide and Warranty Information RB91x is a RouterBOARD with a built-‐in 802.11n wireless device and one Ethernet port. Several models are available with 5GHz or 2GHz wireless. First use • Connect antenna cables to the built in Wi-‐Fi connectors • Device accepts 8-‐30V with a passive PoE powered Ethernet cable or with a power connector to the Power Jack Powering The board accepts power with the following modes: • With PoE to Ether1 port. It accepts 8-‐30V DC input (at the board; higher voltage needed to compensate for power loss on long cables; at least 18V suggested) from non-‐standard (passive) Power over Ethernet injectors (no power over data lines). The board does not work with IEEE802.3af compliant 48V power injectors. • Direct input to the power jack 8-‐30V (select models only) Booting process RouterOS is the operating system of all RouterBOARD routers. Please see detailed configuration guide here: http://wiki.mikrotik.com/wiki/Category:Manual#list This device doesn't come fitted with a Serial Port connector, so initial connection has to be done via the Ethernet cable, using the MikroTik Winbox utility. Winbox should be used to connect to the default IP address of 192.168.88.1 with the username admin and no password. In case you wish to boot the device from network, for example to use MikroTik Netinstall, hold the RESET button of the de-‐ vice when starting it until the LED light turns off, and Groove will start to look for Netinstall servers. In case IP connection is not available, Winbox can also be used to connect to the MAC address of the device. More infor-‐ mation here: http://wiki.mikrotik.com/wiki/First_time_startup Extension Slots and Ports • One Gigabit Ethernet port (With Auto MDI/X so you can use either straight or cross-‐over cables for connecting to other network devices). The Ethernet port accepts 8-‐30V DC powering from a passive PoE injector. Built-‐in 802.11b/g/n WiFi card (AR9342) with one or two MMCX connectors • Only RB912UAG-‐2/5HPnD: miniPCI-‐e slot for either a 802.11 Wireless card, or a 3G modem (when a 3G modem is used in miniPCIe slot, USB port will become inactive. In RouterOS you can select which of the 3G modems you want to use, USB or miniPCIe). SIM slot is available for miniPCIe 3G cards. • Only RB912UAG-‐2/5HPnD: USB 2.0 port Buttons and Jumpers • RouterOS reset jumper hole (Reset2 in above image) – resets RouterOS software to defaults. Must short circuit the metallic sides of the hole (with a screwdriver, for example) and boot the device. Hold screwdriver in place until RouterOS configuration is cleared. • Reset button (Reset1 in above image) – Holding this button during boot time will make the RouterBOARD look for Netinstall servers. Release the button after the LED light goes out. See www.routerboard.com for more information. Contact [email protected] for support questions. 28-Mar-14 Operating System Support Currently tested operating system is MikroTik RouterOS (starting from version v6.6q). Copyright and Warranty information Copyright MikroTikls SIA. This document contains information protected by copyright law. No part of it may be reproduced or transmitted in any form without prior written permission from the copyright holder. RouterBOARD, RouterOS, RouterBOOT and MikroTik are trademarks of MikroTikls SIA. All trademarks and registered trademarks appearing in this document are the property of their respective holders. Hardware. MikroTik warrants all RouterBOARD series equipment for the term of twelve (12) months from the shipping date to be free of defects in materials and workmanship under normal use and service, except in case of damage caused by me-‐ chanical, electrical or other accidental or intended damages caused by improper use or due to wind, rain, fire or other acts of nature. To return failed units to MikroTik, you must perform the following RMA (Return Merchandise Authorization) procedure. Fol-‐ low the instructions below to save time, efforts, avoid costs, and improve the speed of the RMA process. 1. If you have purchased your product from a MikroTik Reseller, please contact the Reseller company regarding all warranty and re-‐ pair issues, the following instructions apply ONLY if you purchased your equipment directly from MikroTik in Latvia. 2. We do not offer repairs for products that are not covered by warranty. Exceptions can be made for RB1000 series. 3. Out-‐of-‐warranty devices and devices not covered by warranty sent to Mikrotikls will be returned to the sender at sender's cost. RMA Instructions are located on our webpage here: http://rma.mikrotik.com This document is provided “as is” without a warranty of any kind, expressed or implied, including, but not limited to, the im-‐ plied warranty of merchantability and fitness for a particular purpose. The manufacturer has made every effort to ensure the accuracy of the contents of this document, however, it is possible that it may contain technical inaccuracies, typographical or other errors. No liability is assumed for any inaccuracy found in this publication, nor for direct or indirect, incidental, conse-‐ quential or other damages that may result from such an inaccuracy, including, but not limited to, loss of data or profits. Please report any inaccuracies found to [email protected] See www.routerboard.com for more information. Contact [email protected] for support questions. 28-Mar-14 Federal Communication Commission Interference Statement List of FCC IDs: RB911-‐2Hn, RB911-‐2HnD: TV7RB911-‐2HND; RB911-‐5Hn, RB911-‐5HND: TV7RB911-‐5HND; RB911G-‐ 2HPnD, RB912UAG-‐2HPnD, RB912G-‐2HPnD, RB912UAG-‐2HPnD-‐OUT: TV7RB912G-‐2HPND; RB911G-‐5HPnD, RB912UAG-‐5HPnD, RB912UAG-‐ 5HPnD-‐OUT: TV7RB912G-‐5HPND This equipment has been tested and found to comply with the limits for a Class B digital device,…

Text truncated - open the document above for the full version.

Cover Letter(s)

November 23, 2011 Federal Communications Commission Equipment Approval Services Post Office Box 358315 Pittsburgh, Pennsylvania 15215-5315 To Whom It May Concern: Please be advised that SIA "Mikrotikls" has authorized Scot Rogers of Rogers Labs, Inc. to act on behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters and submittals. All acts carried out by Rogers Labs, Inc. on our behalf shall have the same effects as our own. Rogers Labs, Inc. is authorized to receive and exchange data between our company and the Commission. This Authorization is made pursuant to Paragraph 2.911 of FCC Rules CFR 47. This Authorization is in effect until otherwise notified in writing. Name: Edmunds Zvegincevs Title: Project Engineer Signature of applicant: SIA "Mikrotīkls" VAT # LV40003286799 Billing addr.: Aizkraukles iela 23, LV-1006, Rīga Office addr.: Pērnavas iela 46, LV-1009, Rīga Phone: +371 7317700 Fax: +371 7317701

Cover Letter(s)

April 3, 2014 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Office of Engineering and Technology Federal Communications Commission Columbia, MD 21046 Applicant: Mikrotikls SIA Pernavas 46 Riga, Latvia LV-1009 Re: Confidentiality for submittal information regarding FCC ID number TV7RB911-2HND PRODUCT: Broadband Digital Transmission System operating under CFR47 part 15.247 Dear Sirs: Mikrotikls SIA requests that the material in the Schematics, Block Diagram, and Operational Description be withheld from public disclosure pursuant to Sections 0.457 and 0.459 of the Commission’s Rules following grant of the application. In support of this request, Mikrotikls submits the following: Long Term Confidential Files Include Schematics File Name Conf Schem RB9112HnD.pdf Block diagram File Name Conf BlkDia RB9112HnD.pdf Operational Description File Name Conf OpDes RB9112HnD.pdf 1. Identification of the specific information for which confidential treatment is sought: The materials set forth in the Operational Description, block diagram, and Schematics, which are segregated from the non-confidential exhibits of the application, are those for which confidentiality is sought. 2. Identification of the Commission proceeding in which the information was submitted or a description of the circumstances giving rise to the submission: The proceeding is that involving the application for equipment authorization (certification) under FCC ID No: TV7RB911-2HND 3. Explanation of the degree to which the information is commercial or financial, or contains a trade secret or is privileged: This material includes a detailed theory of operation, circuit diagrams, (schematic diagrams) and any detail Parts List. As such, this material is treated as highly confidential business information. ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 4. Explanation of the degree to which the information concerns a service that is subject to competition: The material for which confidentiality is sought is employed in the design and manufacture of this transmitting equipment that is offered on a highly competitive basis. Customers for this equipment have a variety of competing sources. 5. Explanation of how disclosure of the information could result in substantial competitive harm: Disclosure would, in effect, give away the fruits of the labors of Mikrotik engineering personnel, who have designed the equipment and the manufacturing process. Disclosure would also offer competitors additional unwarranted insight into the state of the product development, thereby allowing competitors an advantage, not available to Mikrotikls SIA 6. Identification of any measures taken by the submitting party to prevent unauthorized disclosure: The information for which confidential treatment is sought is kept confidential by Mikrotikls SIA and not made available to third parties except pursuant to non-disclosure agreements. 7. Identification of whether the information is available to the public and the extent of any previous disclosure of the information to third parties: To the knowledge of those preparing this application, the information has not been disclosed publicly heretofore. While the general theory of operation of this equipment has been the subject of numerous disclosures in industry and standards groups as well as in rule making proceedings of the FCC, the protection sought is narrowly drawn and pertains to certain specific implementations of this radio technology. 8. Justification of the period during which the submitting party asserts that the material should not be available for public disclosure: This material should not be disclosed for at least 25 years. While improvements in design are made relatively frequently, disclosure of the design information would lead to insights into both design and manufacturing techniques that could have an adverse competitive effect for many years to come. As such, it is important that the design not be made available to unauthorized persons who might attempt to use knowledge of the design to compromise the applications for which the equipment will be employed. Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers

Cover Letter(s)

March 28, 2014 Timco Engineering, Inc. 849 NW State Road 45 P.O. Box 370 Newberry, Florida 32669 Re.: Professional Installation Attestation Equipment: FCC: TV7RB911-2HND To Whom It May Concern: MIKROTIK addresses the following items to ensure that the above referenced equipment is professionally installed: 1. The TV7RB911-2HND will only be sold by MIKROTIK or one of its authorized dealers. MIKROTIK and its authorized dealers will be under strict marketing control and will only market and sell the TV7RB911-2HND to professionals. 2. Professional installation is required for the TV7RB911-2HND and will be performed only by someone knowledgeable of its use. MIKROTIK will ensure that the TV7RB911-2HND is only marketed and sold to professionals. 3. The TV7RB911-2HND can be paired with a variety of antennas and cables, the Antenna Gain, Cable Loss, and Output Power fields are provided to the professional installer to assist in meeting regulatory requirements. 4. The TV7RB911-2HND is not sold to the general public and is sold only for industrial or commercial use by professional installers. Sincerely, Edmunds Zvegincevs Engineer Mikrotikls SIA

Cover Letter(s)

April 3, 2014 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Federal Communications Commission Equipment Approval Services P.O. Box 35815 Pittsburgh, PA 15251-3315 Applicant: Mikrotikls SIA Pernavas 46 Riga, Latvia LV-1009 Equipment: FCC ID: TV7RB911-2HND FCC Rules: Part 15.247 Digital Transmission System Men: The form 731 and application have been electronically submitted and any attachments will be up loaded to your site to be used in obtaining grant of certification for Limited Single Module Authorization. Permanent Mikrotikls SIA requests that the material in the Schematics, Block Diagram, and Operational Description be withheld from public disclosure pursuant to Sections 0.457 and 0.459 of the Commission’s Rules following grant of the application. Schematics File Name Conf Schem RB9112HnD.pdf Block diagram File Name Conf BlkDia RB9112HnD.pdf Operational Description File Name Conf OpDes RB9112HnD.pdf Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers Rogers Labs, Inc. Enclosures ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 Phone / Fax (913) 837-3214

External Photos

ID Label/Location Info

Label and Placement

Internal Photos

RF Exposure Info

Test Report

NVLAP Lab Code 200087-0 Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: RB911-2HnD SN: 472901DD0D5/409 Louisburg, KS 66053 Test #: 140324 FCC ID#: TV7RB911-2HND Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: April 2, 2014 Revision 1 File: Mikrotikls RB911 2HnD TstRpt 140324 Page 1 of 47 Submittal Application Report FOR GRANT OF CERTIFICATION FOR Model: RB911-2HnD 2412-2462 MHz Multiple Input Multiple Output Broadband Digital Transmission System FCC ID: TV7RB911-2HND FOR MIKROTIKLS SIA Pernavas 46 Riga, Latvia LV-1009 Test Report Number: 140324 Authorized Signatory: Scot D. Rogers NVLAP Lab Code 200087-0 Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: RB911-2HnD SN: 472901DD0D5/409 Louisburg, KS 66053 Test #: 140324 FCC ID#: TV7RB911-2HND Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: April 2, 2014 Revision 1 File: Mikrotikls RB911 2HnD TstRpt 140324 Page 2 of 47 Engineering Test Report for Grant of Certification Application FOR CFR 47, PART 15C - Intentional Radiators CFR 47 Paragraph 15.247 License Exempt Intentional Radiator For MIKROTIKLS SIA Pernavas 46 Riga, Latvia LV-1009 MIMO Broadband Digital Transmission System Model: RB911-2HnD Frequency Range 2412-2462 MHz FCC ID#: TV7RB911-2HND Test Date: March 24, 2013 Certifying Engineer: Scot D. Rogers Rogers Labs, Inc. 4405 West 259 th Terrace Louisburg, KS 66053 Telephone/Facsimile: (913) 837-3214 This report shall not be reproduced except in full, without the written approval of the laboratory. This report must not be used by the client to claim product endorsement by NVLAP, NIST, or any agency of the U.S. Government. ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 Phone / Fax (913) 837-3214 NVLAP Lab Code 200087-0 Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: RB911-2HnD SN: 472901DD0D5/409 Louisburg, KS 66053 Test #: 140324 FCC ID#: TV7RB911-2HND Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: April 2, 2014 Revision 1 File: Mikrotikls RB911 2HnD TstRpt 140324 Page 3 of 47 Table Of Contents TABLE OF CONTENTS .................................................................................................. 3 REVISIONS ..................................................................................................................... 5 FORWARD ..................................................................................................................... 6 OPINION / INTERPRETATION OF RESULTS ............................................................... 6 EQUIPMENT TESTED .................................................................................................... 6 Equipment Function ............................................................................................................................................ 7 Equipment Configuration.................................................................................................................................... 7 APPLICATION FOR CERTIFICATION ........................................................................... 8 APPLICABLE STANDARDS & TEST PROCEDURES .................................................. 9 EQUIPMENT TESTING PROCEDURES ........................................................................ 9 AC Line Conducted Emission Test Procedure .................................................................................................. 9 Radiated Emission Test Procedure ..................................................................................................................... 9 Diagram 1 Test arrangement for Conducted emissions ..................................................................................... 10 Diagram 2 Test arrangement for radiated emissions of tabletop equipment ...................................................... 11 Diagram 3 Test arrangement for radiated emissions tested on Open Area Test Site (OATS) ........................... 12 TEST SITE LOCATIONS .............................................................................................. 12 LIST OF TEST EQUIPMENT ........................................................................................ 13 UNITS OF MEASUREMENTS ...................................................................................... 14 ENVIRONMENTAL CONDITIONS................................................................................ 14 INTENTIONAL RADIATORS ........................................................................................ 14 Antenna Requirements ...................................................................................................................................... 14 Restricted Bands of Operation .......................................................................................................................... 15 Table 1 General Radiated Emissions in Restricted Bands Data ........................................................................ 15 Table 2 Harmonic Radiated Emissions in Restricted Bands Data (130K-D-1131-150K(WS)) ........................ 16 Table 3 Harmonic Radiated Emissions in Restricted Bands Data (ODH 24-13) ............................................... 16 NVLAP Lab Code 200087-0 Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: RB911-2HnD SN: 472901DD0D5/409 Louisburg, KS 66053 Test #: 140324 FCC ID#: TV7RB911-2HND Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: April 2, 2014 Revision 1 File: Mikrotikls RB911 2HnD TstRpt 140324 Page 4 of 47 Table 4 Harmonic Radiated Emissions in Restricted Bands Data (WLO-2450-15) .......................................... 17 Table 5 Harmonic Radiated Emissions in Restricted Bands Data (SA 24-90-17-WB) ..................................... 17 Table 6 Harmonic Radiated Emissions in Restricted Bands Data (WLP-2450-20) ........................................... 18 Table 7 Harmonic Radiated Emissions in Restricted Bands Data (DC-24-HD-PFIP) ............................…

Text truncated - open the document above for the full version.

Test Setup Photos

Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: RB911-2HnD SN: 472901DD0D5/409 Louisburg, KS 66053 Test #: 140324 FCC ID#: TV7RB911-2HND Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: April 2, 2014 Revision 1 File: TSup RB9112HnD Page 1 of 7 Test setup photographs AC Line Conducted Emissions Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: RB911-2HnD SN: 472901DD0D5/409 Louisburg, KS 66053 Test #: 140324 FCC ID#: TV7RB911-2HND Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: April 2, 2014 Revision 1 File: TSup RB9112HnD Page 2 of 7 Omni Directional, 130K-D-1131-150K(WS) Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: RB911-2HnD SN: 472901DD0D5/409 Louisburg, KS 66053 Test #: 140324 FCC ID#: TV7RB911-2HND Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: April 2, 2014 Revision 1 File: TSup RB9112HnD Page 3 of 7 Omni Directional, WLO-2450-15 Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: RB911-2HnD SN: 472901DD0D5/409 Louisburg, KS 66053 Test #: 140324 FCC ID#: TV7RB911-2HND Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: April 2, 2014 Revision 1 File: TSup RB9112HnD Page 4 of 7 Omni Directional, ODH 24-13 13 Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: RB911-2HnD SN: 472901DD0D5/409 Louisburg, KS 66053 Test #: 140324 FCC ID#: TV7RB911-2HND Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: April 2, 2014 Revision 1 File: TSup RB9112HnD Page 5 of 7 Panel, WLP-2450-20 Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: RB911-2HnD SN: 472901DD0D5/409 Louisburg, KS 66053 Test #: 140324 FCC ID#: TV7RB911-2HND Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: April 2, 2014 Revision 1 File: TSup RB9112HnD Page 6 of 7 Sector, SA-24-90-17-WB Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: RB911-2HnD SN: 472901DD0D5/409 Louisburg, KS 66053 Test #: 140324 FCC ID#: TV7RB911-2HND Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: April 2, 2014 Revision 1 File: TSup RB9112HnD Page 7 of 7 Dish, DC 24-HD-PFIP

Contact Information

Applicant

Edmunds Zvegincevs(Engineer, R&D)

[email protected]+371 67317700Fax: +371 67317701

Test Firm

Rogers Labs, a division of The Compatibility CntrPatrick Powell

[email protected]913-837-3214Fax: 913-837-3214

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
2	15C	2.42 GHz - 2.45 GHz	400.00 mW

Confidentiality

Long Term

Grant Notes

Power listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 100 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has a 20 and 40 MHz bandwidth mode.
