RouterBOARD hAP lite Quick Setup Guide and Warranty Information The hAP lite is a simple home wireless access point, which can be powered with USB power and has four Ethernet ports. It is configured out of the box, you can simply plug in your internet cable and start using wireless internet. We recommend you to set up a password to secure your device, follow these steps Connecting 1.Connect your Internet cable to port 1, and local network PCs to ports 2-4 2.Set your computer IP configuration to automatic (DHCP) 3.Wireless “access point” mode is enabled by default, connect to the wireless network name which starts with “MikroTik”. Log into your router and configure a the Wireless password and router password to secure your wireless network and access to the router 4.Default IP address from the local network is 192.168.88.1, open this address in your web browser to start configuration. The username is admin and there is no password Powering The device accepts powering from the microUSB port. The port itself doesn't function as a standard microUSB port for data, it is only used for power. You can use any standard 0.5-2A USB adapter that usually come with mobile phones. Booting process Initial connection has to be done via the Ethernet cable. Open 192.168.88.1 in your web browser. The username is admin and there is no password. In case IP connection is not available, Winbox can be used to connect to the MAC address of the device. More information here: http://wiki.mikrotik.com/wiki/First_time_startup In case you wish to boot the device from network, for example to use MikroTik Netinstall, hold the RESET button of the device when starting it until the LED light turns off, and unit will start to look for Netinstall servers. Extension Slots and Ports Four individual 10/100 Ethernet ports, supporting automatic cross/straight cable correction (Auto MDI/X), so you can use either straight or cross-over cables for connecting to other network devices. One Integrated Wireless 2.4GHz 802.11b/g/n, 2x2 MIMO with two onboard PIF antennas, max gain 1.5dBi Buttons and Jumpers RouterBOOT reset button (RESET, front panel) has three functions: oHold this button during boot time until LED light starts flashing, release the button to reset RouterOS configuration (total 5 seconds) oKeep holding for 5 more seconds, LED turns solid, release now to turn on CAPs mode (total 10 seconds) oOr Keep holding the button for 5 more seconds until until LED turns off, then release it to make the RouterBOARD look for Netinstall servers (total 15 seconds) Operating System Support Currently tested operating system is MikroTik RouterOS starting from version v6.19 See www.routerboard.com for more information. Contact [email protected] Copyright and Warranty information Copyright MikroTikls SIA. This document contains information protected by copyright law. No part of it may be reproduced or transmitted in any form without prior written permission from the copyright holder. RouterBOARD, RouterOS, RouterBOOT and MikroTik are trademarks of MikroTikls SIA. All trademarks and registered trademarks appearing in this document are the property of their respective holders. Hardware. MikroTik warrants all RouterBOARD series equipment for the term of twelve (12) months from the shipping date to be free of defects in materials and workmanship under normal use and service, except in case of damage caused by mechanical, electrical or other accidental or intended damages caused by improper use or due to wind, rain, fire or other acts of nature. To return failed units to MikroTik, you must perform the following RMA (Return Merchandise Authorization) procedure. Follow the instructions below to save time, efforts, avoid costs, and improve the speed of the RMA process. 1.If you have purchased your product from a MikroTik Reseller, please contact the Reseller company regarding all warranty and repair issues, the following instructions apply ONLY if you purchased your equipment directly from MikroTik in Latvia. 2.MikroTik does not offer repairs for products that are not covered by warranty. Exceptions can be made for: CCR1016-12G, CCR1016-12G-BU, CCR1036-12G-4S, RB1100, RB1100AH, RB1100AHx2, RB1200, RB600, RB600A and RB800 as a paid service (fees apply). 3.Out-of-warranty devices and devices not covered by warranty sent to Mikrotik will be returned to the sender at sender's cost. If the customer has not organized return of such rejected devices within 12 months from the day of arrival, MikroTik has the right to discard them. RMA Instructions are located on our webpage here: http://rma.mikrotik.com This document is provided “as is” without a warranty of any kind, expressed or implied, including, but not limited to, the implied warranty of merchantability and fitness for a particular purpose. The manufacturer has made every effort to ensure the accuracy of the contents of this document, however, it is possible that it may contain technical inaccuracies, typographical or other errors. No liability is assumed for any inaccuracy found in this publication, nor for direct or indirect, incidental, consequential or other damages that may result from such an inaccuracy, including, but not limited to, loss of data or profits. Please report any inaccuracies found to [email protected] See www.routerboard.com for more information. Contact [email protected] CE Declaration of Conformity Full Declaration of Conformity (DoC) may be obtained by visiting this web page: http://routerboard.com/doc/ [EN] EnglishHereby, MIKROTĪKLS SIA declares that this ROUTERBOARD is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. [BG] BulgarianС настоящето, MIKROTĪKLS SIA декларира, че ROUTERBOARD е в съответствие със съществените изисквания и другитеприложими разпоредби на Директива 1999/5/EC. [CZ] CzechMIKROTĪKLS SIA tímto prohlašuje, že ROUTERBOARD splňuje základní požadavky a všechna příslušná ustanoveni Sm…

Text truncated - open the document above for the full version.

Federal Communication Commission Interference Statement (FCC ID: TV7RB941-2ND) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device and its antenna must not be co-located or operation in conjunction with any other antenna or transmitter. IMPORTANT: Exposure to Radio Frequency Radiation. 20 cm minimum distance has to be maintained between the antenna and user. Under such configuration, the FCC radiation exposure limits set forth for an population/uncontrolled environment can be satisfied. Antenna Installation. WARNING: It is installer's responsibility to ensure that when using the authorized antennas in the United States (or where FCC rules apply); only those antennas certified with the product are used. The use of any antenna other than those certified with the product is expressly forbidden in accordance to FCC rules CFR47 part 15.204. The installer should configure the output power level of antennas, according to country regulations and per antenna type. Professional installation is required of equipment with connectors to ensure compliance with health and safety issues. Industry Canada (IC:7442A-9412ND) This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.

November 23, 2011 Federal Communications Commission Equipment Approval Services Post Office Box 358315 Pittsburgh, Pennsylvania 15215-5315 To Whom It May Concern: Please be advised that SIA "Mikrotikls" has authorized Scot Rogers of Rogers Labs, Inc. to act on behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters and submittals. All acts carried out by Rogers Labs, Inc. on our behalf shall have the same effects as our own. Rogers Labs, Inc. is authorized to receive and exchange data between our company and the Commission. This Authorization is made pursuant to Paragraph 2.911 of FCC Rules CFR 47. This Authorization is in effect until otherwise notified in writing. Name: Edmunds Zvegincevs Title: Project Engineer Signature of applicant: SIA "Mikrotīkls" VAT # LV40003286799 Billing addr.: Aizkraukles iela 23, LV-1006, Rīga Office addr.: Pērnavas iela 46, LV-1009, Rīga Phone: +371 7317700 Fax: +371 7317701

February 23, 2015 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Office of Engineering and Technology Federal Communications Commission Columbia, MD 21046 Applicant: Mikrotikls SIA Pernavas 46 Riga, Latvia LV-1009 Re: Confidentiality for submittal information regarding FCC ID number TV7RB941-2ND PRODUCT: Broadband Digital Transmission System Module operating under CFR47 part 15.247 Dear Sirs: Mikrotikls SIA requests that the material in the Schematics, Block Diagram, and Operational Description be withheld from public disclosure pursuant to Sections 0.457 and 0.459 of the Commission’s Rules following grant of the application. In support of this request, Mikrotikls submits the following: Long Term Confidential Files Include Schematics File Name Conf Schem hAP LITE.pdf Block diagram File Name Conf BlkDia hAP LITE.pdf Operational Description File Name Conf OpDes hAP LITE.pdf 1. Identification of the specific information for which confidential treatment is sought: The materials set forth in the Operational Description, block diagram, and Schematics, which are segregated from the non-confidential exhibits of the application, are those for which confidentiality is sought. 2. Identification of the Commission proceeding in which the information was submitted or a description of the circumstances giving rise to the submission: The proceeding is that involving the application for equipment authorization (certification) under FCC ID No: TV7RB941-2ND 3. Explanation of the degree to which the information is commercial or financial, or contains a trade secret or is privileged: This material includes a detailed theory of operation, circuit diagrams, (schematic diagrams) and any detail Parts List. As such, this material is treated as highly confidential business information. ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 4. Explanation of the degree to which the information concerns a service that is subject to competition: The material for which confidentiality is sought is employed in the design and manufacture of this transmitting equipment that is offered on a highly competitive basis. Customers for this equipment have a variety of competing sources. 5. Explanation of how disclosure of the information could result in substantial competitive harm: Disclosure would, in effect, give away the fruits of the labors of Mikrotikls SIA engineering personnel, who have designed the equipment and the manufacturing process. Disclosure would also offer competitors additional unwarranted insight into the state of the product development, thereby allowing competitors an advantage, not available to Mikrotikls SIA. 6. Identification of any measures taken by the submitting party to prevent unauthorized disclosure: The information for which confidential treatment is sought is kept confidential by Mikrotikls SIA and not made available to third parties except pursuant to non-disclosure agreements. 7. Identification of whether the information is available to the public and the extent of any previous disclosure of the information to third parties: To the knowledge of those preparing this application, the information has not been disclosed publicly heretofore. While the general theory of operation of this equipment has been the subject of numerous disclosures in industry and standards groups as well as in rule making proceedings of the FCC, the protection sought is narrowly drawn and pertains to certain specific implementations of this radio technology. 8. Justification of the period during which the submitting party asserts that the material should not be available for public disclosure: This material should not be disclosed for at least 25 years. While improvements in design are made relatively frequently, disclosure of the design information would lead to insights into both design and manufacturing techniques that could have an adverse competitive effect for many years to come. As such, it is important that the design not be made available to unauthorized persons who might attempt to use knowledge of the design to compromise the applications for which the equipment will be employed. Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers

February 23, 2015 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Federal Communications Commission Equipment Approval Services P.O. Box 35815 Pittsburgh, PA 15251-3315 Applicant: Mikrotikls SIA Pernavas 46 Riga, Latvia LV-1009 Equipment: FCC ID: TV7RB941-2ND FCC Rules: Part 15.247 Digital Transmission System modular Authorization Men: The form 731 and application have been electronically submitted and any attachments will be provided to your site to be used in processing for and obtaining grant of authorization. Permanent Confidential Requested Mikrotikls SIA requests that the material in the Parts List, Schematics, Block Diagram, and Operational Description be withheld from public disclosure pursuant to Sections 0.457 and 0.459 of the Commission’s Rules following grant of the application. In support of this request, Mikrotikls SIA submits the following files to hold in long-term confidential status. Schematics File Name Conf Schem hAP LITE.pdf Block diagram File Name Conf BlkDia hAP LITE.pdf Operational Description File Name Conf OpDes hAP LITE.pdf Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers Rogers Labs, Inc. Enclosures ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 Phone / Fax (913) 837-3214

Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: hAP Lite SN: 541A01DD504D/448 FCC ID#: TV7RB941-2ND Louisburg, KS 66053 Test #: 150210 IC: 7442A-9412ND Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: February 23, 2015 Revision 1 File: ExtPho hAP Lite Page 1 of 3 External photographs of equipment under test Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: hAP Lite SN: 541A01DD504D/448 FCC ID#: TV7RB941-2ND Louisburg, KS 66053 Test #: 150210 IC: 7442A-9412ND Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: February 23, 2015 Revision 1 File: ExtPho hAP Lite Page 2 of 3 Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: hAP Lite SN: 541A01DD504D/448 FCC ID#: TV7RB941-2ND Louisburg, KS 66053 Test #: 150210 IC: 7442A-9412ND Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: February 23, 2015 Revision 1 File: ExtPho hAP Lite Page 3 of 3

Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: hAP Lite SN: 541A01DD504D/448 FCC ID#: TV7RB941-2ND Louisburg, KS 66053 Test #: 150210 IC: 7442A-9412ND Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: February 23, 2015 Revision 1 File: LabelSmpl hAP Lite Page 1 of 1 Label and Placement

Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: hAP Lite SN: 541A01DD504D/448 FCC ID#: TV7RB941-2ND Louisburg, KS 66053 Test #: 150210 IC: 7442A-9412ND Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: February 23, 2015 Revision 1 File: IntPho hAP Lite Page 1 of 1 Internal photographs of equipment under test

Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: hAP Lite SN: 541A01DD504D/448 FCC ID#: TV7RB941-2ND Louisburg, KS 66053 Test #: 150210 IC: 7442A-9412ND Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: February 23, 2015 Revision 1 File: RFExp hAP Lite Page 1 of 1

NVLAP Lab Code 200087-0 Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: hAP Lite FCC ID#: TV7RB941-2ND Louisburg, KS 66053 Test #: 150210 IC: 7442A-9412ND Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: February 26, 2015 Revision 1 File: Mikrotikls hAP Lite TstRpt 150210 Page 1 of 32 SUBMITTAL APPLICATION REPORT FOR GRANT OF CERTIFICATION FOR Model: hAP Lite 2412-2462 MHz Broadband Digital Transmission System FCC ID: TV7RB941-2ND IC: 7442A-9412ND FOR MIKROTIKLS SIA Pernavas 46 Riga, Latvia LV-1009 Test Report Number: 150210 Authorized Signatory: Scot D. Rogers NVLAP Lab Code 200087-0 Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: hAP Lite FCC ID#: TV7RB941-2ND Louisburg, KS 66053 Test #: 150210 IC: 7442A-9412ND Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: February 26, 2015 Revision 1 File: Mikrotikls hAP Lite TstRpt 150210 Page 2 of 32 Engineering Test Report for Grant of Certification Application FOR CFR 47, PART 15C - Intentional Radiators CFR 47 Paragraph 15.247 and Industry Canada RSS-210 License Exempt Digital Transmission System For MIKROTIKLS SIA Pernavas 46 Riga, Latvia LV-1009 Broadband Digital Transmission System Model: hAP Lite Frequency Range 2412-2462 MHz FCC ID#: TV7RB941-2ND IC 7442A-9412ND Test Date: February 10, 2015 Certifying Engineer: Scot D. Rogers Rogers Labs, Inc. 4405 West 259 th Terrace Louisburg, KS 66053 Telephone/Facsimile: (913) 837-3214 This report shall not be reproduced except in full, without the written approval of the laboratory. This report must not be used by the client to claim product certification, approval or endorsement by NVLAP, NIST, or any agency of the Federal Government. ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 Phone / Fax (913) 837-3214 NVLAP Lab Code 200087-0 Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: hAP Lite FCC ID#: TV7RB941-2ND Louisburg, KS 66053 Test #: 150210 IC: 7442A-9412ND Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: February 26, 2015 Revision 1 File: Mikrotikls hAP Lite TstRpt 150210 Page 3 of 32 Table Of Contents TABLE OF CONTENTS .................................................................................................. 3 REVISIONS ..................................................................................................................... 4 FORWARD ..................................................................................................................... 5 OPINION / INTERPRETATION OF RESULTS ............................................................... 5 EQUIPMENT TESTED .................................................................................................... 5 APPLICATION FOR CERTIFICATION ........................................................................... 6 EQUIPMENT FUNCTION AND CONFIGURATION........................................................ 7 Equipment Configuration.................................................................................................................................... 7 APPLICABLE STANDARDS & TEST PROCEDURES .................................................. 8 EQUIPMENT TESTING PROCEDURES ........................................................................ 8 AC Line Conducted Emission Test Procedure .................................................................................................. 8 Radiated Emission Test Procedure ..................................................................................................................... 8 Diagram 1 Test arrangement for Conducted emissions ....................................................................................... 9 Diagram 2 Test arrangement for radiated emissions of tabletop equipment ...................................................... 10 Diagram 3 Test arrangement for radiated emissions tested on Open Area Test Site (OATS) ........................... 11 TEST SITE LOCATIONS .............................................................................................. 11 LIST OF TEST EQUIPMENT ........................................................................................ 12 UNITS OF MEASUREMENTS ...................................................................................... 13 ENVIRONMENTAL CONDITIONS................................................................................ 13 INTENTIONAL RADIATORS ........................................................................................ 13 Antenna Requirements ...................................................................................................................................... 13 Restricted Bands of Operation .......................................................................................................................... 13 Table 1 General Radiated Emissions in Restricted Bands Data ........................................................................ 14 Table 2 Harmonic Radiated Emissions in Restricted Bands Worst-case ........................................................... 15 Summary of Results for Radiated Emissions in Restricted Bands ................................................................ 15 NVLAP Lab Code 200087-0 Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: hAP Lite FCC ID#: TV7RB941-2ND Louisburg, KS 66053 Test #: 150210 IC: 7442A-9412ND Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: February 26, 2015 Revision 1 File: Mikrotikls hAP Lite TstRpt 150210 Page 4 of 32 AC Line Conducted Emissions Procedure ....................................................................................................... 16 Figure 1 AC Line Conducted Emissions Line 1 ................................................................................................ 17 Figure 2 AC Line Conducted Emissions Line 2 ................................................................................................ 17 Table 3 AC Line Conducted Emissio…
