Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
See www.routerboard.com for more information. Contact [email protected] for support questions. 5-SEP-2011 RouterBOARD SXT G-5HnD Quick Setup Guide and Warranty Information The RouterBOARD SXT G-5HnD comes as a complete set, and includes a built in 802.11n dual chain wireless device, and a dual polarization 16dBi antenna. It has one Gigabit Ethernet connector which supports MDI-X auto detection. First use 1. Connect an Ethernet cable to the port behind the small plastic door 2. The SXT accepts 24V Passive PoE from the supplied PoE injector 3. The default IP address from LAN is 192.168.88.1 for configuration 4. Username is admin and there is no password Powering The board accepts powering from the Ethernet port (Passive PoE) 8-30V DC. Package contains a 24V adapter. Booting process RouterOS is the operating system of all RouterBOARD routers. Please see detailed configuration guide here: http://wiki.mikrotik.com/wiki/Category:Manual This device doesn't come fitted with a Serial Port connector, so initial connection has to be done via the Ethernet cable, using the MikroTik Winbox utility. Winbox should be used to connect to the default IP address of 192.168.88.1 with the username admin and no password. In case IP connection is not available, Winbox can also be used to connect to the MAC address of the device. More information here: http://wiki.mikrotik.com/wiki/First_time_startup In case you wish to boot the device from network, for example to use MikroTik Netinstall, hold the RESET button of the device when start- ing it until the LED LD600 light turns off (behind the small door), and SXT will start to look for Netinstall servers. Mounting With the clip pointed forward, slide the mounting bracket into the rail on the bottom of the case, until the clip clicks into place. The SXT comes bundled with a hose clamp - guide the clamp through the opening in the bracket and around the pole where it will be mounted. Tighten the hose clamp screw when alignment is complete. Two screw holes are provided as additional security against accidental bracket movement. The SXT device has a sliding door, behind which the Ethernet port and the reset jumpers are located. This door can be also secured shut with a screw in the provided screw hole. Buttons and Jumpers RouterOS reset jumper hole (access through the plastic door) – resets RouterOS software to defaults. Must short cir- cuit the metallic sides of the hole (with a screwdriver, for example) and boot the device. Hold screwdriver in place until RouterOS configuration is cleared. RouterBOOT reset button (access through the plastic door) has two functions: Hold this button during boot time until LED light starts flashing, release the button to reset RouterOS configuration (same result as with reset hole) Hold this button during boot time longer, until LED turns off, and then release it to make the device look for Netinstall servers. See www.routerboard.com for more information. Contact [email protected] for support questions. 5-SEP-2011 Operating System Support Currently tested operating system is MikroTik RouterOS (starting from version v5). Copyright and Warranty Information Copyright and Trademarks. Copyright MikroTikls SIA. This manual contains information protected by copyright law. No part of it may be reproduced or transmitted in any form without prior written permission from the copyright holder. RouterBOARD, RouterOS, RouterBOOT and MikroTik are trademarks of MikroTikls SIA. All trademarks and registered trademarks appearing in this manual are the property of their respective holders. Hardware. MikroTikls SIA warrants all RouterBOARD series equipment for the term of fifteen (15) months from the shipping date to be free of defects in materials and workmanship under normal use and service, except in case of damage caused by mechanical, electrical or other accidental or intended damages caused by improper use or due to wind, rain, fire or other acts of nature. If you have purchased your product from a MikroTik Reseller, please contact the Reseller company regarding all warranty and repair issues, the following instructions apply ONLY if you purchased your equipment directly from MikroTik Latvia To return failed unit or units to MikroTikls you must perform the following RMA (Return Material Authorization) procedure. Follow the instructions below to save time, efforts, avoid costs, and improve the speed of the RMA process. Take into account that all goods have one year warranty. Instructions are located on our webpage here: http://rma.mikrotik.com Manual. This manual is provided “as is” without a warranty of any kind, expressed or implied, including, but not limited to, the implied warranty of merchantability and fitness for a particular purpose. The manufacturer has made every effort to ensure the accuracy of the contents of this manual; however, it is possible that it may contain technical inaccuracies, typographical or other errors. No liability is as- sumed for any inaccuracy found in this publication, nor for direct or indirect, incidental, consequential or other damages that may result from such an inaccuracy, including, but not limited to, loss of data or profits. Please report any inaccuracies found to sup- [email protected] See www.routerboard.com for more information. Contact [email protected] for support questions. 5-SEP-2011 Federal Communication Commission Interference Statement (FCC ID: TV7SXTG-5HND) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installa- tion. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular inst…
Text truncated - open the document above for the full version.
SIA "Mikrotīkls" Aizkraukles iela 23, Rīga, LV-1006, Latvia Phone: +371 67317700 Fax: +371 67317701 September 4, 2008 Federal Communications Commission Equipment Approval Services Post Office Box 358315 Pittsburgh, Pennsylvania 15215-5315 To Whom It May Concern: Please be advised that SIA "Mikrotikls" has authorized Scot Rogers of Rogers Labs, Inc. to act on behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters and submittals. All acts carried out by Rogers Labs, Inc. on our behalf shall have the same effects as our own. Rogers Labs, Inc. is authorized to receive and exchange data between our company and the Commission. This Authorization is made pursuant to Paragraph 2.911 of FCC Rules CFR 47. This Authorization is in effect until otherwise notified in writing. Āris Jurkāns engineer, R&D SIA "Mikrotikls"
November 3, 2011 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Office of Engineering and Technology Federal Communications Commission Columbia, MD 21046 Applicant: Mikrotikls SIA Pernavas 46 Riga, Latvia LV-1009 Re: Confidentiality for submittal information regarding FCC ID number TV7SXTG-5HND PRODUCT: Broadband wireless Digital Transmission System operating under CFR47 part 15.247 Dear Sirs: Mikrotikls SIA requests that the material in the Schematic, block diagram, and Operational Description be withheld from public disclosure Pursuant to Sections 0.457 & 0.459 of the Commission’s Rules following grant of the application. In support of this request, MIKROTIK submits the following: Long Term Confidential Files Include Schematics File Name Conf Schem SXTG5HND.pdf Block diagram File Name Conf BlkDia SXTG5HND.pdf Operational Description File Name Conf OpDes SXTG5HND.pdf 1. Identification of the specific information for which confidential treatment is sought: The materials set forth in the Operational Description, block diagram, and Schematics, which are segregated from the non-confidential exhibits of the application, are those for which confidentiality is sought. 2. Identification of the Commission proceeding in which the information was submitted or a description of the circumstances giving rise to the submission: The proceeding is that involving the application for equipment authorization (certification) under FCC ID No: TV7SXTG-5HND 3. Explanation of the degree to which the information is commercial or financial, or contains a trade secret or is privileged: This material includes a detailed theory of operation, circuit diagrams, (schematic diagrams) and any detail Parts List. As such, this material is treated as highly confidential business information. ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 4. Explanation of the degree to which the information concerns a service that is subject to competition: The material for which confidentiality is sought is employed in the design and manufacture of this transmitting equipment that is offered on a highly competitive basis. Customers for this equipment have a variety of competing sources. 5. Explanation of how disclosure of the information could result in substantial competitive harm: Disclosure would, in effect, give away the fruits of the labors of Mikrotikls engineering personnel, who have designed the equipment and the manufacturing process. Disclosure would also offer competitors additional unwarranted insight into the state of the product development, thereby allowing competitors an advantage, not available to Mikrotikls SIA 6. Identification of any measures taken by the submitting party to prevent unauthorized disclosure: The information for which confidential treatment is sought is kept confidential by Mikrotikls SIA and not made available to third parties except pursuant to non-disclosure agreements. 7. Identification of whether the information is available to the public and the extent of any previous disclosure of the information to third parties: To the knowledge of those preparing this application, the information has not been disclosed publicly heretofore. While the general theory of operation of this equipment has been the subject of numerous disclosures in industry and standards groups as well as in rule making proceedings of the FCC, the protection sought is narrowly drawn and pertains to certain specific implementations of this radio technology. 8. Justification of the period during which the submitting party asserts that the material should not be available for public disclosure: This material should not be disclosed for at least 25 years. While improvements in design are made relatively frequently, disclosure of the design information would lead to insights into both design and manufacturing techniques that could have an adverse competitive effect for many years to come. As such, it is important that the design not be made available to unauthorized persons who might attempt to use knowledge of the design to compromise the applications for which the equipment will be employed. Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers
Mikrotikls SIA 46 Pernavas str., Riga LV-1009, LATVIA Tel: +371 6 7317700Fax:+371 6 7317701 DoC Attestation Letter Date:2011/11/15 We Mikrotikls SIA, as the grantee of this project FCC ID:TV7SXTG-5HND, would like to declare that the composite portion catagorized as computer peripheral has been authorized under the Declaration of Conformity procedures. Regards, FCC Grantee contract person information. Applicant's company name : Mikrotikls SIA Applicant's company address : 46 Pernavas str., Riga LV-1009, LATVIA Signature : Job Tittle and Dept. : Āris Jurkāns / Engineer, R&D E-Mail : [email protected] Tel. : +371 6 7317700
November 3, 2011 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Federal Communications Commission Equipment Approval Services P.O. Box 35815 Pittsburgh, PA 15251-3315 Applicant: Mikrotikls SIA Pernavas 46 Riga, Latvia LV-1009 Equipment: FCC ID: TV7SXTG-5HND FCC Rules: Broadband wireless Digital Transmission System operating under CFR47 part 15.247 Gentlemen: The form 731 and application have been electronically submitted and any attachments will be up loaded to your web site to be used in obtaining a grant of certification. Permanent Mikrotikls SIA requests that the material in the following files be withheld from public disclosure in accordance with Sections 0.457 and 0.459 of the Commission’s Rules, 47 C.F.R. following grant of the application. Schematics File Name Conf Schem SXTG5HND.pdf Block diagram File Name Conf BlkDia SXTG5HND.pdf Operational Description File Name Conf OpDes SXTG5HND.pdf Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers Rogers Labs, Inc. Enclosures ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 Phone / Fax (913) 837-3214
Rogers Labs, Inc. MIKROTIK 4405 W. 259th Terrace Model: SXTG-5HnD FCC ID#: TV7SXTG-5HnD Louisburg, KS 66053 Test #: 110914A SN: 308F01DDB8D Phone/Fax: (913) 837-3214 Test to: FCC (15.247) Date: November 3, 2011 Revision 1 File: ExtPho SXTG5HND Page 1 of 2 External photographs of equipment under test Rogers Labs, Inc. MIKROTIK 4405 W. 259th Terrace Model: SXTG-5HnD FCC ID#: TV7SXTG-5HnD Louisburg, KS 66053 Test #: 110914A SN: 308F01DDB8D Phone/Fax: (913) 837-3214 Test to: FCC (15.247) Date: November 3, 2011 Revision 1 File: ExtPho SXTG5HND Page 2 of 2
Rogers Labs, Inc. MIKROTIK 4405 W. 259th Terrace Model: SXTG-5HnD FCC ID#: TV7SXTG-5HnD Louisburg, KS 66053 Test #: 110914A SN: 308F01DDB8D Phone/Fax: (913) 837-3214 Test to: FCC (15.247) Date: November 3, 2011 Revision 1 File: LabelSmpl SXTG5HND Page 1 of 1 ID and Placement Label Placement
Rogers Labs, Inc. MIKROTIK 4405 W. 259th Terrace Model: SXTG-5HnD FCC ID#: TV7SXTG-5HnD Louisburg, KS 66053 Test #: 110914A SN: 308F01DDB8D Phone/Fax: (913) 837-3214 Test to: FCC (15.247) Date: November 3, 2011 Revision 1 File: IntPho SXTG5HND Page 1 of 3 Internal photographs of equipment under test PCB without shield Rogers Labs, Inc. MIKROTIK 4405 W. 259th Terrace Model: SXTG-5HnD FCC ID#: TV7SXTG-5HnD Louisburg, KS 66053 Test #: 110914A SN: 308F01DDB8D Phone/Fax: (913) 837-3214 Test to: FCC (15.247) Date: November 3, 2011 Revision 1 File: IntPho SXTG5HND Page 2 of 3 Back side of EUT PCB Rogers Labs, Inc. MIKROTIK 4405 W. 259th Terrace Model: SXTG-5HnD FCC ID#: TV7SXTG-5HnD Louisburg, KS 66053 Test #: 110914A SN: 308F01DDB8D Phone/Fax: (913) 837-3214 Test to: FCC (15.247) Date: November 3, 2011 Revision 1 File: IntPho SXTG5HND Page 3 of 3 PCB with shield
RouterBOARD SXT G-5HnD 802.11a/n WLAN router Tuning procedure Each units TX and RX functionality is tested and judged with a pass/fail criteria during production. Units meeting the criteria continue through production and others are returned for diagnostics.
Rogers Labs, Inc. MIKROTIK 4405 W. 259th Terrace Model: SXTG 5HnD FCC ID#: TV7SXTG-5HnD Louisburg, KS 66053 Test #: 110914A SN: 308F01DDB8D Phone/Fax: (913) 837-3214 Test to: FCC (15.247) Date: October 31, 2011 Revision 1 File: RFExp SXTG5HnD Page 1 of 1
NVLAP Lab Code 200087-0 Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: SXTG-5HnD SN: 308F01DDB8D Louisburg, KS 66053 Test #: 110914BA FCC ID#: TV7SXTG-5HND Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: October 31, 2011 Revision 1 File: Mikrotikls SXTG5HnD 110914A TstRpt Page 1 of 41 SUBMITTAL APPLICATION REPORT FOR GRANT OF CERTIFICATION FOR Model: SXTG 5HnD 5745-5825 MHz MIMO Broadband Digital Transmission System FCC ID: TV7SXTG-5HND FOR MIKROTIKLS SIA Pernavas 46 Riga, Latvia LV-1009 Test Report Number: 110914A Authorized Signatory: Scot D. Rogers NVLAP Lab Code 200087-0 Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: SXTG-5HnD SN: 308F01DDB8D Louisburg, KS 66053 Test #: 110914BA FCC ID#: TV7SXTG-5HND Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: October 31, 2011 Revision 1 File: Mikrotikls SXTG5HnD 110914A TstRpt Page 2 of 41 Engineering Test Report For Grant of Certification Application FOR CFR 47, PART 15C - Intentional Radiators CFR 47 Paragraph 15.247 License Exempt Intentional Radiator For MIKROTIKLS SIA Pernavas 46 Riga, Latvia LV-1009 MIMO Broadband Digital Transmission System Model: SXTG 5HnD Frequency Range 5745-5825 MHz FCC ID#: TV7SXTG-5HND Test Date: September 14, 2011 Certifying Engineer: Scot D. Rogers Rogers Labs, Inc. 4405 West 259 th Terrace Louisburg, KS 66053 Telephone/Facsimile: (913) 837-3214 This report shall not be reproduced except in full, without the written approval of the laboratory. This report must not be used by the client to claim product endorsement by NVLAP, NIST, or any agency of the U.S. Government. ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 Phone / Fax (913) 837-3214 NVLAP Lab Code 200087-0 Rogers Labs, Inc. Mikrotikls SIA 4405 W. 259th Terrace Model: SXTG-5HnD SN: 308F01DDB8D Louisburg, KS 66053 Test #: 110914BA FCC ID#: TV7SXTG-5HND Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247) Date: October 31, 2011 Revision 1 File: Mikrotikls SXTG5HnD 110914A TstRpt Page 3 of 41 Table Of Contents TABLE OF CONTENTS .................................................................................................. 3 FORWARD ..................................................................................................................... 5 OPINION / INTERPRETATION OF RESULTS ............................................................... 5 ENVIRONMENTAL CONDITIONS.................................................................................. 5 EQUIPMENT TESTED .................................................................................................... 5 APPLICATION FOR CERTIFICATION ........................................................................... 6 APPLICABLE STANDARDS & TEST PROCEDURES .................................................. 7 EQUIPMENT FUNCTION AND CONFIGURATION ........................................................ 7 Equipment Configuration.................................................................................................................................... 8 TEST SITE LOCATIONS ................................................................................................ 8 UNITS OF MEASUREMENTS ........................................................................................ 8 TEST PROCEDURES ..................................................................................................... 9 AC Line Conducted Emission Test Procedure .................................................................................................. 9 Radiated Emission Test Procedure ..................................................................................................................... 9 LIST OF TEST EQUIPMENT ........................................................................................ 10 INTENTIONAL RADIATORS ........................................................................................ 11 Antenna Requirements ...................................................................................................................................... 11 Restricted Bands of Operation .......................................................................................................................... 11 General Radiated Emissions in Restricted Bands Data ..................................................................................... 12 Harmonic Radiated Emissions in Restricted Bands Data .................................................................................. 12 Summary of Results for Radiated Emissions in Restricted Bands ................................................................ 13 AC Line Conducted Emissions Procedure ....................................................................................................... 13 Figure One AC Line Conducted Emissions Line 1............................................................................................ 14 Figure Two AC Line Conducted Emissions Line 2 ........................................................................................... 14 AC Line Conducted Emissions Data (Highest Emissions) ................................................................................ 15 Summary of Results for AC Line Conducted Emissions ................................................................................ 16 General Radiated Emissions Procedure ........................................................................................................... 16 Figure Three General Radiated Emissions taken at 1 meter in screen room ..................................................... 17 Figure Four General Radiated Emissions taken at 1 meter in screen room ....................................................... 17 Figure Five General Radiated Emissions taken at 1 meter in screen room ........................................................ 18 Figure Six General Radiated Emissions taken at 1 meter in screen room .............................…
Text truncated - open the document above for the full version.
Rogers Labs, Inc. MIKROTIK 4405 W. 259th Terrace Model: SXTG-5HnD FCC ID#: TV7SXTG-5HnD Louisburg, KS 66053 Test #: 110914A SN: 308F01DDB8D Phone/Fax: (913) 837-3214 Test to: FCC (15.247) Date: November 3, 2011 Revision 1 File: TSup SXTG5HND Page 1 of 2 Test setup photographs AC Line Conducted Emissions Rogers Labs, Inc. MIKROTIK 4405 W. 259th Terrace Model: SXTG-5HnD FCC ID#: TV7SXTG-5HnD Louisburg, KS 66053 Test #: 110914A SN: 308F01DDB8D Phone/Fax: (913) 837-3214 Test to: FCC (15.247) Date: November 3, 2011 Revision 1 File: TSup SXTG5HND Page 2 of 2 Radiated Emissions
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 2 | 15C | 5.75 GHz - 5.82 GHz | 400.00 mW |
