TW5GD76152.4GHz Digital Solution Wireless Remote Pan/Tilt Camera Kit

Shenzhen Gospell Smarthome Electronic Co., Ltd.
2.4GHz Digital Solution Wireless Remote Pan/Tilt Camera Kit - FCC ID TW5GD7615 - Shenzhen Gospell Smarthome Electronic Co., Ltd.
Click to zoom

Application Details

Equipment Class
DSS - Part 15 Spread Spectrum Transmitter
Date of Grant
Sep 07, 2010
Application Purpose
Original Equipment
Date of Application
Sep 02, 2010
Equipment Note
2.4GHz Digital Solution Wireless Remote Pan/Tilt Camera Kit
Frequency Range
2417.62500000 - 2464.87500000
Company
Shenzhen Gospell Smarthome Electronic Co., Ltd.
Country
China

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Declaration of Conformity Hereby, ShenZhen Gospell Smarthome Electronic Co., Ltd., declares that this device is in compliance with the essential requirem ents and other relevant provisions of Directive 1999/5/EC. FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communicatio ns. However, there is no guarantee that interference will not occur in a particular inst allation. If this equipment does cause harmful interference to radio or television reception, which ca n be determined by turning the equipment of f and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. To assure continued compliance, any changes or modifications no t expressly approved by the party responsible for compliance cou ld void the user’s authority to operate this equipment. (Example- use only shielded interfac e cables when connecting to computer or peripheral devices). Radiation Exposure Statement This equipment complies with FCC RF radiation exposure limits se t forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body and must not be co-located or operating in conjunction with any other antenna or transmitter. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, incl uding interference that may cause undesired operation. Caution! The manufacturer is not responsible for any radio or TV interferen ce caused by unauthorized modifications to this equipment. Su ch modifications could void the user authority to operate the equipment. The product will not hold to the ears during to the operation .

External Photos

Neutron Engineering Inc. Project No.: 1006C257A Page 2 of 12 1006C257A 1006C257A 1006C257A 1006C257A 1006C257A 1006C257A 1006C257A 1006C257A 1006C257A 1006C257A Neutron Engineering Inc. Project No.: 1006C257A Page 2 of 12 1006C257A 1006C257A 1006C257A 1006C257A 1006C257A 1006C257A 1006C257A 1006C257A 1006C257A 1006C257A

Internal Photos

Neutron Engineering Inc. Project No.: 1006C257A Page 3 of 12 1006C257A 1006C257A Neutron Engineering Inc. Project No.: 1006C257A Page 3 of 12 1006C257A 1006C257A Neutron Engineering Inc. Project No.: 1006C257A Page 4 of 12 1006C257A 1006C257A Neutron Engineering Inc. Project No.: 1006C257A Page 4 of 12 1006C257A 1006C257A Neutron Engineering Inc. Project No.: 1006C257A Page 5 of 12 1006C257A 1006C257A Neutron Engineering Inc. Project No.: 1006C257A Page 5 of 12 1006C257A 1006C257A Neutron Engineering Inc. Project No.: 1006C257A Page 6 of 12 1006C257A 1006C257A Neutron Engineering Inc. Project No.: 1006C257A Page 6 of 12 1006C257A 1006C257A Neutron Engineering Inc. Project No.: 1006C257A Page 7 of 12 1006C257A 1006C257A Neutron Engineering Inc. Project No.: 1006C257A Page 7 of 12 1006C257A 1006C257A Neutron Engineering Inc. Project No.: 1006C257A Page 8 of 12 1006C257A 1006C257A Neutron Engineering Inc. Project No.: 1006C257A Page 8 of 12 1006C257A 1006C257A Neutron Engineering Inc. Project No.: 1006C257A Page 9 of 12 1006C257A Neutron Engineering Inc. Project No.: 1006C257A Page 10 of 12 1006C257A 1006C257A Neutron Engineering Inc. Project No.: 1006C257A Page 10 of 12 1006C257A 1006C257A Neutron Engineering Inc. Project No.: 1006C257A Page 11 of 12 1006C257A 1006C257A Neutron Engineering Inc. Project No.: 1006C257A Page 11 of 12 1006C257A 1006C257A Neutron Engineering Inc. Project No.: 1006C257A Page 12 of 12 1006C257A 1006C257A Neutron Engineering Inc. Project No.: 1006C257A Page 12 of 12 1006C257A 1006C257A

RF Exposure Info

RF Exposure Statement RF exposure evaluations are based on extremity SAR evaluation. According to KDB 447498, item 4), C), iii). The SAR limit is 1000/sqrt (2.4G) = 645 mW. The measured peak output power is 29.6 mW < 645 mW Therefore, no SAR evaluation is needed.

Test Report

Neutron Engineering Inc. Report No.: NEI-FCCP-2-1006C257A Page 2 of 57 Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C., or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Neutron Engineering Inc. Report No.: NEI-FCCP-2-1006C257A Page 3 of 57 Table of Contents Page 1 . CERTIFICATION 6 2 . SUMMARY OF TEST RESULTS 7 2.1 TEST FACILITY 8 2.2 MEASUREMENT UNCERTAINTY 8 3 . GENERAL INFORMATION 9 3.1 GENERAL DESCRIPTION OF EUT 9 3.2 DESCRIPTION OF TEST MODES 11 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 11 3.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 12 3.5 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 13 4 . EMC EMISSION TEST 14 4.1 CONDUCTED EMISSION MEASUREMENT 14 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 14 4.1.2 MEASUREMENT INSTRUMENTS LIST AND SETTING 14 4.1.3 TEST PROCEDURE 15 4.1.4 DEVIATION FROM TEST STANDARD 15 4.1.5 TEST SETUP 15 4.1.6 EUT OPERATING CONDITIONS 15 4.1.7 TEST RESULTS 16 4.2 RADIATED EMISSION MEASUREMENT 18 4.2.1 RADIATED EMISSION LIMITS 18 4.2.2 MEASUREMENT INSTRUMENTS LIST ANS SETTING 19 4.2.3 TEST PROCEDURE 20 4.2.4 DEVIATION FROM TEST STANDARD 20 4.2.5 TEST SETUP 21 4.2.6 EUT OPERATING CONDITIONS 21 4.2.7 TEST RESULTS (BETWEEN30 – 1000 MHZ) 22 4.2.8 TEST RESULTS (ABOVE 1000 MHZ) 24 5 . NUMBER OF HOPPING CHANNEL 36 5.1 APPLIED PROCEDURES / LIMIT 36 5.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 36 5.1.2 TEST PROCEDURE 36 5.1.3 DEVIATION FROM STANDARD 36 5.1.4 TEST SETUP 36 5.1.5 EUT OPERATION CONDITIONS 36 5.1.6 TEST RESULTS 37 Neutron Engineering Inc. Report No.: NEI-FCCP-2-1006C257A Page 4 of 57 Table of Contents Page 6 . AVERAGE TIME OF OCCUPANCY 38 6.1 APPLIED PROCEDURES / LIMIT 38 6.1.1 MEASUREMENT INSTRUMENTS LIST 38 6.1.2. TEST PROCEDURES 38 6.1.3. TEST SETUP LAYOUT 38 6.1.4. TEST DEVIATION 38 6.1.5. EUT OPERATION DURING TEST 38 6.1.6. RESULTS OF OCCUPIED BANDWIDTH AND SPREAD-SPECTRUM BANDWIDTH 39 7 . HOPPING CHANNEL SEPARATION MEASUREMENT 41 7.1 APPLIED PROCEDURES / LIMIT 41 7.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 41 7.1.2 TEST PROCEDURE 41 7.1.3 DEVIATION FROM STANDARD 41 7.1.4 TEST SETUP 41 7.1.5 EUT OPERATION CONDITIONS 41 7.1.6 TEST RESULTS 42 8 . BANDWIDTH TEST 43 8.1 APPLIED PROCEDURES / LIMIT 43 8.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 43 8.1.2 TEST PROCEDURE 43 8.1.3 DEVIATION FROM STANDARD 43 8.1.4 TEST SETUP 43 8.1.5 EUT OPERATION CONDITIONS 43 8.1.6 TEST RESULTS 44 9 . PEAK OUTPUT POWER TEST 46 9.1 APPLIED PROCEDURES / LIMIT 46 9.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 46 9.1.2 TEST PROCEDURE 46 9.1.3 DEVIATION FROM STANDARD 46 9.1.4 TEST SETUP 46 9.1.5 EUT OPERATION CONDITIONS 46 9.1.6 TEST RESULTS 47 10 . ANTENNA CONDUCTED SPURIOUS EMISSION 49 10.1 APPLIED PROCEDURES / LIMIT 49 10.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 49 10.1.2 TEST PROCEDURE 49 10.1.3 DEVIATION FROM STANDARD 49 10.1.4 TEST SETUP 49 Neutron Engineering Inc. Report No.: NEI-FCCP-2-1006C257A Page 5 of 57 Table of Contents Page 10.1.5 EUT OPERATION CONDITIONS 49 10.1.6 TEST RESULTS 50 11 . EUT TEST PHOTO 56 Neutron Engineering Inc. Report No.: NEI-FCCP-2-1006C257A Page 6 of 57 1. CERTIFICATION E q u i p m e n t : 2.4GHz Digital Solution Wireless Remote Pan/Tilt Camera Kit Brand Name : GOSCAM Model Name : GD7615 A p p l i c a n t : ShenZhen Gospell Smarthome Electronic Co., Ltd. Factory : ShenZhen Gospell Smarthome Electronic Co., Ltd. Address : F01-04/Block A,fenghuanggang first industrial park,south 1st road of baotian,xixiang street,baoan district,shenzhen city,P.R.china Date of Test : Aug. 10, 2010 ~ Aug. 29, 2010 T e s t I t e m : ENGINEERING SAMPLE Standards : FCC Part15, Subpart C(15.247) / ANSI C63.4 : 2003 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCP-2-1006C257A) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of NVLAP and TAF according to the ISO-17025 quality assessment standard and technical standard(s). Test result included in this report is only for the Monitor Sample part of the product. Neutron Engineering Inc. Report No.: NEI-FCCP-2-1006C257A Page 7 of 57 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247 (d) Antenna conducted Spurious EmissionPASS 15.247 (a)(1) Hopping Channel Separation PASS 15.247 (b)(1) Peak Output Power PASS 15.209/15.247 (d) Radiated Sp…

Text truncated - open the document above for the full version.

Test Setup Photos

Neutron Engineering Inc. Report No.: NEI-FCCP-2-1006C257A Page 54 of 55 11. EUT TEST PHOTO Conducted Measurement Photos Neutron Engineering Inc. Report No.: NEI-FCCP-2-1006C257A Page 54 of 55 11. EUT TEST PHOTO Conducted Measurement Photos Neutron Engineering Inc. Report No.: NEI-FCCP-2-1006C257A Page 55 of 55 Radiated Measurement Photos Neutron Engineering Inc. Report No.: NEI-FCCP-2-1006C257A Page 55 of 55 Radiated Measurement Photos

Contact Information

Applicant

Richie Xiao(Certified Engineer)
[email protected]+755-26716688Fax: +755-26716099

Technical Contact

Neutron Engineering Inc.Cathy Wang
[email protected]+886-769-83183000

No.3,Jinshagang 1st Rd, ShiXia,Dalang Town · Dongguan · China

Non-Technical Contact

Neutron Engineering Inc.Cathy Wang
[email protected]+886-769-83183000

Test Firm

BTL Inc.Daisy Dai
[email protected]008676983183000Fax: 0086 769 83196000

Technical Specifications

#Rule PartsFrequency RangePower Output
115C2.42 GHz - 2.46 GHz29.60 mW
Confidentiality
Long Term
Grant Notes
Power listed is peak conducted.
