TWNZF01-DWireless module

ZF01-D Wireless Module User guide Figure 1. ZF01-D wireless module z Interface & Cable： channel setting switch P C Antenna LED Sign I n t e r f a c e I n t e r f a c e cable Figure 2. ZF01-D RS-422 Interface & Cable . channel setti ng switch PC Antenna LED Sign Int erface Interface cable Figure 3. ZF01-D RS-232 Interface & Cable USB channel setting switc h PC Antenna LED Sign Interface Interface cable VCC D- D+ GND Figure 4. ZF 01-D USB In terface & C able channel setti ng switch PC Antenna LED Sign Int erface Interface cable Figure 5. ZF 01-D TTL In terface & C able Main Technical Specifications： RF channels(MHz) 433.050,432. 700,433.310 ,433.540,43 4.050,434.3 10,434.610, 434.910 modulation mode GFSK baud rate 9600bps Interface data format UART ,8E1/8N1 data format Power supply DC 3.6V---5V overall dimensions70 X 45 X 17 mm z Communication Application： Figure6. ZF01-D wireless communication application diagram Channel setting There is a channel setting switch as shown in Figure 2, defined as A,B,C respectively， so there are 8 channels can be set . Channel A2 A1 A0 Freq. 0 OFF OFF OFF 433.050MHz 1 OFF OFF ON 432.700MHz 2 OFF ON OFF 433.310MHz 3 OFF ON ON 433.540MHz 4 ON OFF OFF 434.050MHz 5 ON OFF ON 434.310MHz 6 ON ON OFF 434.610MHz 7 ON ON ON 434.910MHz Wireless communication channel setting PC LED Sign Interface Interface PC LED Sign Interface Interface TTL RF MCU RS422 USB RS232 TTL RF MCU RS422 USB RS232 z FCC Notices 1. The manufacturer is not responsible for any radio or TV Interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment. 2. This device complies with Part 15 of the FCC Rules. (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.

Pro-Lite, Inc. AGENCY AUTHORIZATION LETTER Date: 2010-10-21 FCC ID: TWNZF01-D To whom it may concern: We, the undersigned, hereby authorize SHENZHEN HUATONGWEI INTERNATIONAL INSPECTION CO., LTD of China to act on our behalf, as our agent in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification, Any act carried out by SHENZHEN HUATONGWEI INTERNATIONAL INSPECTION CO., LTD within the scope of this authorization shall have the same effects as our own. This authorization shall expire 6 months from original date. If you have any questions regarding the authorization, please don’t hesitate to contact us. Sincerely, Print Name: Andy Kaoh Title: General Manager Tel: 714-668-9988 Fax: 714-668-9898 E-mail: [email protected] Company Name: Pro-Lite, Inc.

Pro-Lite, Inc. Request for Confidentiality Date: 2010-10-21 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: TWNZF01-D Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this application as outlined below: Exhibit: File Name: Schematic TWNZF01-D_Schematic.pdf Theory of Operation TWNZF01-D _Theory of Operation.pdf Block Diagram TWNZF01-D _Block Diagram.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might to harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the grant for this application. Sincerely, Print Name: Andy Kaoh Title: General Manager Tel: 714-668-9988 Fax: 714-668-9898 E-mail: [email protected] Company Name: Pro-Lite, Inc.

TTL and RS232 I/O port RS422 I/O port USB I/O port

Label and label location

Internal Photos TTL and RS232 I/O port RSS232 port and cable TTL port and cable RS422 I/O port USB I/O port

FCC TEST REPORT 47 CFR FCC Part 15 Subpart C & 15.231 FCC ID .............................................: TWNZF01-D Report Reference No......................: WE10090038 Compiled by ( position+printed name+signature)..: File administrators Wenliang Li Supervised by ( position+printed name+signature)..: Test Engineer Xiankun Ding Approved by ( position+printed name+signature)..: Manager Jimmy Li Date of issue.....................................: Nov 03, 2010 Testing Laboratory Name..............: Shenzhen Huatongwei International Inspection Co., Ltd Address ............................................: Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Applicant’s name............................: Pro-Lite, Inc. Address ............................................: 3505 Cadillac Ave. Building D Manufacturer’s name.....................: NINGBO YOUWON TECHNOLOGY ELECTRONICS CO., LTD Address ............................................: #928, XUEYUAN ROAD, LUGANG VILLAGE, GAOQIAO TOWN, NINGBO Test specification: Standard ...........................................: 47 CFR FCC Part 15 Subpart C & 15.231 ANSI C63.4: 2009 TRF Originator..................................: Shenzhen Huatongwei International Inspection CO., Ltd Master TRF.......................................: Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader’s interpretation of the reproduced material due to its placement and context. Equipment Under Test...................: Wireless Module Trade Mark .......................................: / Model/Type reference.......................: ZF01-D Listed Models ..................................: / Result................................................: Complied V1.0 Page 2 of 43 Report No.: WE10090038 FCC ID: TWNZF01-D Shenzhen Huatongwei International Inspection Co., Ltd T E S T R E P O R T Test Report No. : WE10090038 Nov 03, 2010 Date of issue Equipment under Test : Wireless Module Model /Type : ZF01-D Listed Models : / Applicant : Pro-Lite, Inc. Address : 3505 Cadillac Ave. Building D Manufacturer : NINGBO YOUWON TECHNOLOGY ELECTRONICS CO., LTD Address : #928, XUEYUAN ROAD, LUGANG VILLAGE, GAOQIAO TOWN, NINGBO SUMMARY OF STANDARDS AND RUSELT No. Test Item Test Standards and Procedure Result 1 AC Conducted Emission FCC Subpart 15C§15.207 Complied 2 Radiated Emission FCC Subpart 15C§15.209 FCC Subpart 15C§15.231(e) Complied 3 Deactivation Time FCC Subpart 15C§15.231(e) Complied 4 20dB Bandwidth FCC Subpart 15C§15.231(c) Complied 5 Antenna Requirement FCC Subpart 15C§15.203 Complied NOTE: 1) The detailed test rusult please see section 4. 2) The test report merely corresponds to the test sample. 3) It is not permitted to copy extracts of these test result without the written permission of the test laboratory. V1.0 Page 3 of 43 Report No.: WE10090038 FCC ID: TWNZF01-D Shenzhen Huatongwei International Inspection Co., Ltd Contents 1. TEST STANDARDS .................................................................. 4 2. SUMMARY............................................................................. 5 2.1. General Remarks 5 2.2. Equipment Under Test Power Supply 5 2.3. S Short description of the Equipment under Test (EUT) 5 2.4. EUT operation mode 5 2.5. Related Submittal(s) / Grant (s) 5 2.6. Modifications 5 2.7. Configuration of Tested System 6 3. TEST ENVIRONMENT............................................................... 7 3.1. Address of the test laboratory 7 3.2. Test Facility 7 3.3. Environmental conditions 8 3.4. Statement of the measurement uncertainty 8 3.5. Equipments Used during the Test 9 4. TEST CONDITIONS AND RESULTS ............................................ 10 4.1. AC Conducted Emission 10 4.2. Radiated Emission 13 4.3. Deactivation Time 20 4.4. 20dB Bandwidth 24 4.5. Antenna Requirement 27 5. TEST SETUP PHOTOS OF THE EUT .......................................... 28 6. EXTERNAL AND INTERNAL PHOTOS OF THE EUT ....................... 30 V1.0 Page 4 of 43 Report No.: WE10090038 FCC ID: TWNZF01-D Shenzhen Huatongwei International Inspection Co., Ltd 1. TEST STANDARDS The tests were performed according to following standards: 47 CFR FCC Part 15 Subpart C & 15.231 – Intentional Radiators & Periodic operation in the band 40.66–40.70 MHz and above 70 MHz ANSI C63.4: 2009 – American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40GHz ANSI C63.10: 2009 – American National Standard for Teating Unlicensed Wireless Devices V1.0 Page 5 of 43 Report No.: WE10090038 FCC ID: TWNZF01-D Shenzhen Huatongwei International Inspection Co., Ltd 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : Sep 20, 2010 Testing commenced on : Sep 20, 2010 Testing concluded on : Oct 14, 2010 2.2. Equipment Under Test Power Supply Power supply voltage : ○ 120V / 60 Hz ○ 115V / 60Hz ○ 12 V DC ○ 24 V DC ● Other (specified in blank below) DC 5V from PC 2.3. S Short description of the Equipment under Test (EUT) Product Name : Wireless Module Model Number : ZF01-D Operation Frequency : 433.05MHz,432.70MHz,433.31MHz 433.54MHz,434.05MHz,434.31MHz 434.61MHz,434.91MHz Modulation Technology : GFSK Transmitter Type : Periodic Transmitter Sample Type : Prototype I/O Port : USB, RS232, RS422, TTL For more details, refer to the user’s manual of the EUT. Remark: The EUT has been tested with 4 different ports, and the worst case is EUT with USB port. And the data recorded in this report is the worst case test data. 2.4. EUT operation mode The EUT has been tested under typical operating condition. 2…

Text truncated - open the document above for the full version.

AC conducted emission test photo Radiated emission test photo
