FCC ID: U2M-9603H Report No.: RF990204L16 Operational Description This device is a Wireless 11N USB Adapter, which operates in the 2.4GHz frequency spectrum with throughput of up to 150Mbps which OFDM technique will be applied. If the signal to noise radio is too poor which could not support 150Mbps, the 11Mbps data rate with DSSS technique will be applied. The transmitter of the EUT is powered by 5Vdc from a host equipment The antenna is Dipole antenna with R-SMA antenna connector. The other instruction, please have a look at the users manual.
Report No.: SA990204L16 Report Format Version 3.0.1 1 RF EXPOSURE REPORT REPORT NO.: SA990204L16 MODEL NO.: EUB9603H FCC ID: U2M-9603H ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: Senao Networks, Inc. ADDRESS: 3F, No. 529, Chung Cheng Rd., Hsintien, Taipei, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien 244, Taiwan, R.O.C. Report No.: SA990204L16 Report Format Version 3.0.1 2 1. RF EXPOSURE LIMIT LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 2. MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r2) where Pd = power density in mW/cm2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 3. CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. 4. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER FREQUENCY BAND (MHz) MAX POWER (dBm) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 2412-2462 28.9 5 20 0.488 1.00
Report No.: RF990204L16 1 Report Format Version 3.0.1 FCC TEST REPORT REPORT NO.: RF990204L16 MODEL NO.: EUB9603H RECEIVED: Feb. 04, 2010 TESTED: Feb. 05 ~ Feb. 09, 2010 ISSUED: Feb. 11, 2010 APPLICANT: Senao Networks, Inc. ADDRESS: 3F, No. 529, Chung Cheng Rd., Hsintien, Taipei, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien 244, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 67 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF990204L16 2 Report Format Version 3.0.1 TABLE OF CONTENTS 1. CERTIFICATION .................................................................................................... 4 2. SUMMARY OF TEST RESULTS............................................................................ 5 2.1 MEASUREMENT UNCERTAINTY ......................................................................... 5 3. GENERAL INFORMATION .................................................................................... 6 3.1 GENERAL DESCRIPTION OF EUT....................................................................... 6 3.2 DESCRIPTION OF TEST MODES......................................................................... 7 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST.................................................... 7 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL......................... 8 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ...................................... 10 3.4 DESCRIPTION OF SUPPORT UNITS................................................................. 10 4. TEST TYPES AND RESULTS .............................................................................. 11 4.1 RADIATED EMISSION MEASUREMENT ............................................................ 11 4.1.1 LIMITS OF RADIATED EMISSION MEASUREMENT ......................................... 11 4.1.2 TEST INSTRUMENTS ......................................................................................... 12 4.1.3 TEST PROCEDURES .......................................................................................... 13 4.1.4 DEVIATION FROM TEST STANDARD ................................................................ 13 4.1.5 TEST SETUP ....................................................................................................... 14 4.1.6 EUT OPERATING CONDITIONS......................................................................... 14 4.1.7 TEST RESULTS ................................................................................................... 15 4.2 CONDUCTED EMISSION MEASUREMENT ....................................................... 28 4.2.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT .................................... 28 4.2.2 TEST INSTRUMENTS ......................................................................................... 28 4.2.3 TEST PROCEDURES .......................................................................................... 29 4.2.4 DEVIATION FROM TEST STANDARD ................................................................ 29 4.2.5 TEST SETUP ....................................................................................................... 30 4.2.6 EUT OPERATING CONDITIONS......................................................................... 30 4.2.7 TEST RESULTS ................................................................................................... 31 4.3 6dB BANDWIDTH MEASUREMENT ................................................................... 33 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT................................................. 33 4.3.2 TEST INSTRUMENTS ......................................................................................... 33 4.3.3 TEST PROCEDURE ............................................................................................ 33 4.3.4 DEVIATION FROM TEST STANDARD ................................................................ 33 4.3.5 TEST SETUP ....................................................................................................... 34 4.3.6 EUT OPERATING CONDITIONS......................................................................... 34 4.3.7 TEST RESULTS ................................................................................................... 35 Report No.: RF990204L16 3 Report Format Version 3.0.1 4.4 MAXIMUM OUTPUT POWER.............................................................................. 39 4.4.1 LIMITS OF MAXIMUM OUTPUT POWER MEASUREMENT .............................. 39 4.4.2 INSTRUMENTS ................................................................................................... 39 4.4.3 TEST PROCEDURES .......................................................................................... 39 4.4.4 DEVIATION FROM TEST STANDARD ................................................................ 39 4.4.5 TEST SETUP ....................................................................................................... 40 4.4.6 EUT OPERATING CONDITIONS......................................................................... 40 4.4.7 TEST RESULTS ................................................................................................... 41 4.5 POWER SPECTRAL DENSITY MEASUREMENT .............................................. 42 4.5.1 LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT ............................ 42 4.5.2 TEST INSTRUMENTS .......................................................................................โฆ
