U2M-SR7260Wireless concurrent dual band Gigabit Router 300N

Senao Networks, Inc.
Wireless concurrent dual band Gigabit Router 300N - FCC ID U2M-SR7260 - Senao Networks, Inc.
Click to zoom

Application Details

Equipment Class
NII - Unlicensed National Information Infrastructure TX
Date of Grant
Aug 16, 2011
Application Purpose
Original Equipment
Date of Application
Aug 16, 2011
Equipment Note
Wireless concurrent dual band Gigabit Router 300N
Frequency Range
5180.00000000 - 5240.00000000
Company
Senao Networks, Inc.
Country
Taiwan

Documents & Files

Select a file to view

Users Manual

↗

Attestation Statements

↗

Cover Letter(s)

↗
↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

Operational Description

↗

RF Exposure Info

↗

Test Report

↗
↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Wireless concurrent dual band Gigab it Router 300N 2 1. Introduction....................................... ................................................... ................................................... ....................7 1.1. Package Contents................................... ................................................... ................................................... ...7 1.2. System Requirements................................ ................................................... ................................................... 7 1.3. Introduction ....................................... ................................................... ................................................... ......... 8 1.4. LED Overview (need modify to 2.4G and 5G’s) ........ ................................................... ....................................9 1.5. Before you Begin ................................... ................................................... ................................................... .. 10 2. Configure PC/Laptop Network Interface .............. ................................................... ..................................................1 1 2.1. Windows XP/Vista................................... ................................................... ................................................... . 11 2.2. Windows 7 .......................................... ................................................... ................................................... ..... 14 2.3. Apple Mac OS X ..................................... ................................................... ................................................... . 15 3. Setup your Router .................................. ................................................... ................................................... ............17 4. Manually enter Setup Wizard........................ ................................................... ................................................... ......20 5. System............................................. ................................................... ................................................... ...................33 5.1. Status............................................. ................................................... ................................................... .......... 33 5.2. LAN (Local Area Network) ........................... ................................................... ............................................... 37 5.3. DHCP............................................... ................................................... ................................................... ........ 41 5.4. Schedule ........................................... ................................................... ................................................... ....... 44 5.5. Log................................................ ................................................... ................................................... ........... 46 5.6. Monitor............................................ ................................................... ................................................... ......... 47 5.7. Language........................................... ................................................... ................................................... ...... 48 6. Internet ........................................... ................................................... ................................................... ....................49 6.1. Status............................................. ................................................... ................................................... .......... 49 3 6.2. Dynamic IP Address (DHCP) .......................... ................................................... ............................................ 50 6.3. Static IP Address .................................. ................................................... ................................................... ... 52 6.4. PPP over Ethernet (PPPoE) .......................... ................................................... ............................................. 53 6.5. Point-to-Point Tunneling Protocol (PPTP)........... ................................................... ........................................ 55 7. Wireless 2.4G ...................................... ................................................... ................................................... ...............57 7.1. Basic .............................................. ................................................... ................................................... .......... 57 7.2. Advanced........................................... ................................................... ................................................... ...... 60 7.3. Security........................................... ................................................... ................................................... ......... 62 7.4. Filter............................................. ................................................... ................................................... ............ 68 7.5. Wi-Fi Protected Setup (WPS) ........................ ................................................... ............................................. 69 7.6. Client List ........................................ ................................................... ................................................... ......... 73 8. Wireless 5G ........................................ ................................................... ................................................... ................74 8.1. Basic .............................................. ................................................... ................................................... ....…

Text truncated - open the document above for the full version.

External Photos

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3

Internal Photos

Page 4 Page 5 Page 6 Page 7 Page 8 Page 9 Page 10 Page 11

Operational Description

FCC ID: U2M-SR7260 Report No.: RF110311C20 Operational Description This device is a Wireless Router 300N, which operates in both of the 5GHz and 2.4GHz bands; the maximum data rate could be up to 300Mbps which OFDM technique. If the signal to noise radio is too poor which could not support 300Mbps, the 11Mbps data rate with DSSS technique will be applied. The transmitter of the EUT is powered by the 12Vdc POE. The antenna are PIFA & PCB antennas with IPEX antenna connector. The other instruction, please have a look at the users manual. FCC 15.407(c) states: The device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude the transmission of control or signaling information or the use of repetitive codes used by certain digital technologies to complete frame or burst intervals. Applicants shall include in their application for equipment authorization a description of how this requirement is met” Data transmission is always initiated by software, which is then pass down through the MAC, through the digital and analog baseband, and finally to the RF chip. Several special packets (ACKs, CTS, PSPoll, etc...) are initiated by the MAC. There are the only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on only while one of the aforementioned packets are being transmitted.

RF Exposure Info

Report No.: SA110311C20 Report Format Version 4.0.0 1 RF EXPOSURE REPORT REPORT NO.: SA110311C20 MODEL NO.: ESR7750G, SR7260, WBR4200RGN, WLR-5000 v1 001, WL-370 v1 001, WBR-5050 FCC ID: U2M-SR7260 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: Senao Networks, Inc. ADDRESS: 3F, No. 529, Chung Cheng Rd., Hsintien, Taipei, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien 244, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 6 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced, except in full, without the written approval of our laboratory. The client should not use it to claim product, certification, approval, or endorsement by any government agency. The test results in the report only apply to the tested sample. Report No.: SA110311C20 Report Format Version 4.0.0 2 TABLE OF CONTENTS RELEASE CONTROL RECORD ............................................................................................. 3 1. CERTIFICATION .......................................................................................................... 4 2. RF EXPOSURE............................................................................................................ 5 2.1 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE)...................................... 5 2.2 MPE CALCULATION FORMULA ................................................................................. 5 2.3 CLASSIFICATION ........................................................................................................ 5 2.4 CALCULATION RESULT OF MAXIMUM CONDUCTED POWER............................... 6 Report No.: SA110311C20 Report Format Version 4.0.0 3 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED Original release NA Apr. 13, 2011 Report No.: SA110311C20 Report Format Version 4.0.0 4 1. CERTIFICATION PRODUCT: Wireless concurrent dual band Gigabit Router 300N MODEL NO.: ESR7750G, SR7260, WBR4200RGN, WLR-5000 v1 001, WL-370 v1 001, WBR-5050 BRAND: EnGenius, Senao Networks, Sitecom, LG-ERICSSON APPLICANT: Senao Networks, Inc. TEST SAMPLE: ENGINEERING SAMPLE TESTED: Mar. 25 ~ Apr. 08, 2011 STANDARDS: FCC Guidelines for Human Exposure IEEE C95.1 The above equipment (Model: WLR-5000 v1 001) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE:Apr. 13, 2011 Ivy Lin / Specialist APPROVED BY : , DATE:Apr. 13, 2011 Gary Chang / Assistant Manager Report No.: SA110311C20 Report Format Version 4.0.0 5 2. RF EXPOSURE 2.1 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 2.2 MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r2) where Pd = power density in mW/cm2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 2.3 CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA110311C20 Report Format Version 4.0.0 6 2.4 CALCULATION RESULT OF MAXIMUM CONDUCTED POWER FREQUENCY BAND (MHz) MAX POWER (dBm) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 2412-2462 26.7 4.5 20 0.262 1 5180-5240 15.7 5.0 20 0.023 1 5745-5825 23.5 5.0 20 0.141 1

Test Report

Report No.: RF110311C20 1 Report Format Version 4.0.0 FCC TEST REPORT (15.247) REPORT NO.: RF110311C20 MODEL NO.: ESR7750G (refer to item 3.1 for more details) FCC ID: U2M-SR7260 RECEIVED: Mar. 11, 2011 TESTED: Mar. 25 ~ Apr. 08, 2011 ISSUED: Apr. 13, 2011 APPLICANT: Senao Networks, Inc. ADDRESS: 3F, No. 529, Chung Cheng Rd., Hsintien, Taipei, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien 244, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 138 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product, certification, approval or endorsement by TAF or any government agency. The test results in the report only apply to the tested sample. Report No.: RF110311C20 2 Report Format Version 4.0.0 TABLE OF CONTENTS RELEASE CONTROL RECORD.............................................................................................. 5 1. CERTIFICATION........................................................................................................... 6 2. SUMMARY OF TEST RESULTS .................................................................................. 7 2.1 MEASUREMENT UNCERTAINTY................................................................................ 7 3. GENERAL INFORMATION ........................................................................................... 8 3.1 GENERAL DESCRIPTION OF EUT ............................................................................. 8 3.2 DESCRIPTION OF TEST MODES ............................................................................. 10 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST ........................................................ 11 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ............................. 12 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ............................................ 16 3.4 DESCRIPTION OF SUPPORT UNITS ....................................................................... 16 4. TEST TYPES AND RESULTS (FOR 2.4GHz BAND)................................................. 17 4.1 RADIATED EMISSION MEASUREMENT .................................................................. 17 4.1.1 LIMITS OF RADIATED EMISSION MEASUREMENT................................................ 17 4.1.2 TEST INSTRUMENTS................................................................................................ 18 4.1.3 TEST PROCEDURES ................................................................................................ 19 4.1.4 DEVIATION FROM TEST STANDARD....................................................................... 19 4.1.5 TEST SETUP.............................................................................................................. 20 4.1.6 EUT OPERATING CONDITIONS ............................................................................... 20 4.1.7 TEST RESULTS ......................................................................................................... 21 4.2 CONDUCTED EMISSION MEASUREMENT ............................................................. 35 4.2.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT........................................... 35 4.2.2 TEST INSTRUMENTS................................................................................................ 35 4.2.3 TEST PROCEDURES ................................................................................................ 36 4.2.4 DEVIATION FROM TEST STANDARD....................................................................... 36 4.2.5 TEST SETUP.............................................................................................................. 37 4.2.6 EUT OPERATING CONDITIONS ............................................................................... 37 4.2.7 TEST RESULTS ......................................................................................................... 38 4.3 6dB BANDWIDTH MEASUREMENT.......................................................................... 40 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT ....................................................... 40 4.3.2 TEST INSTRUMENTS................................................................................................ 40 4.3.3 TEST PROCEDURE................................................................................................... 40 4.3.4 DEVIATION FROM TEST STANDARD....................................................................... 40 4.3.5 TEST SETUP.............................................................................................................. 41 4.3.6 EUT OPERATING CONDITIONS ............................................................................... 41 4.3.7 TEST RESULTS ......................................................................................................... 42 4.4 MAXIMUM OUTPUT POWER .................................................................................... 46 Report No.: RF110311C20 3 Report Format Version 4.0.0 4.4.1 LIMITS OF MAXIMUM OUTPUT POWER MEASUREMENT..................................... 46 4.4.2 INSTRUMENTS .......................................................................................................... 46 4.4.3 TEST PROCEDURES ................................................................................................ 46 4.4.4 DEVIATION FROM TEST STANDARD....................................................................... 47 4.4.5 TEST SETUP.............................................................................................................. 47 4.4.6 EUT OPERATING CONDITIONS ...............................…

Text truncated - open the document above for the full version.

Test Report

Report No.: RF110311C20-1 1 Report Format Version 4.0.0 FCC TEST REPORT (15.407) REPORT NO.: RF110311C20-1 MODEL NO.: ESR7750G (refer to item 3.1 for more details) FCC ID: U2M-SR7260 RECEIVED: Mar. 11, 2011 TESTED: Mar. 29 ~ Apr. 08, 2011 ISSUED: Apr.13, 2011 APPLICANT: Senao Networks, Inc. ADDRESS: 3F, No. 529, Chung Cheng Rd., Hsintien, Taipei, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien 244, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 79 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product, certification, approval or endorsement by TAF or any government agency. The test results in the report only apply to the tested sample. Report No.: RF110311C20-1 2 Report Format Version 4.0.0 TABLE OF CONTENTS RELEASE CONTROL RECORD.............................................................................................. 4 1. CERTIFICATION........................................................................................................... 5 2. SUMMARY OF TEST RESULTS .................................................................................. 6 2.1 MEASUREMENT UNCERTAINTY................................................................................ 6 3. GENERAL INFORMATION ........................................................................................... 7 3.1 GENERAL DESCRIPTION OF EUT ............................................................................. 7 3.2 DESCRIPTION OF TEST MODES ............................................................................... 9 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST .......................................................... 9 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ............................. 10 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ............................................ 12 3.4 DESCRIPTION OF SUPPORT UNITS ....................................................................... 12 4. TEST TYPES AND RESULTS .................................................................................... 13 4.1 RADIATED EMISSION MEASUREMENT .................................................................. 13 4.1.1 LIMITS OF RADIATED EMISSION MEASUREMENT................................................ 13 4.1.2 LIMITS OF UNWANTED EMISSION OUT OF THE RESTRICTED BANDS .............. 13 4.1.3 TEST INSTRUMENTS................................................................................................ 14 4.1.4 TEST PROCEDURES ................................................................................................ 15 4.1.5 DEVIATION FROM TEST STANDARD....................................................................... 15 4.1.6 TEST SETUP.............................................................................................................. 16 4.1.7 EUT OPERATING CONDITION.................................................................................. 16 4.1.8 TEST RESULTS ......................................................................................................... 17 4.2 CONDUCTED EMISSION MEASUREMENT ............................................................. 26 4.2.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT........................................... 26 4.2.2 TEST INSTRUMENTS................................................................................................ 26 4.2.3 TEST PROCEDURES ................................................................................................ 27 4.2.4 DEVIATION FROM TEST STANDARD....................................................................... 27 4.2.5 TEST SETUP.............................................................................................................. 28 4.2.6 EUT OPERATING CONDITIONS ............................................................................... 28 4.2.7 TEST RESULTS ......................................................................................................... 29 4.3 MAXIMUM CONDUCTED OUTPUT POWER MEASUREMENT ............................... 31 4.3.1 LIMITS OF MAXIMUM CONDUCTED OUTPUT POWER MEASUREMENT............. 31 4.3.2 TEST INSTRUMENTS................................................................................................ 31 4.3.3 TEST PROCEDURE................................................................................................... 32 4.3.4 DEVIATION FROM TEST STANDARD....................................................................... 32 4.3.5 TEST SETUP.............................................................................................................. 32 4.3.6 EUT OPERATING CONDITIONS ............................................................................... 32 4.3.7 TEST RESULTS ......................................................................................................... 33 Report No.: RF110311C20-1 3 Report Format Version 4.0.0 4.4 PEAK POWER EXCURSION MEASUREMENT ........................................................ 37 4.4.1 LIMITS OF PEAK POWER EXCURSION MEASUREMENT...................................... 37 4.4.2 TEST INSTRUMENTS................................................................................................ 37 4.4.3 TEST PROCEDURE................................................................................................... 37 4.4.4 DEVIATION FROM TEST STANDARD....................................................................... 38 4.4.5 TEST SETUP.............................................................................................................. 38 4.4.6 EUT OPERATING CONDIT…

Text truncated - open the document above for the full version.

Test Setup Photos

1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST 2 RADIATED EMISSION TEST

Contact Information

Applicant

Iris Chang
[email protected]886-3-3289289Fax: 886-3-3961112

Technical Contact

Bureau Veritas CPS (H.K.) Ltd. Taoyuan BranchGary Chang
[email protected]886-3-3183232

No. 19, Hwa Ya 2nd Rd., Kwei Shan Hsiang · Taoyuan Hsien · Taiwan

Non-Technical Contact

Bureau Veritas CPS (H.K.) Ltd. Taoyuan BranchNatacha Chen
[email protected]886-3-3183232

Test Firm

Bureau Veritas CPS (H.K.) Ltd. Taoyuan BranchRichard Chen
[email protected]886-3-3183232Fax: 886-3-2115834

Technical Specifications

#Rule PartsFrequency RangePower Output
115E5.18 GHz - 5.24 GHz37.00 mW
Confidentiality
Long Term
Grant Notes
Power listed is the maximum combined conducted output power. End-users and responsible parties must be provided with operating and installation instructions to ensure RF exposure compliance. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Operations in the 5.15-5.25GHz band are restricted to indoor usage only.
