U2ZZW5301Wireless Lighting Control

pg. 1 Wireless Lighting Control Keypad Controller Model 45631 User’s manual This device provides control of 4 groups and 4 scenes. Up to 32 Z-Wave devices can be included in each of the groups and scenes. It is a secondary controller only and cannot function as a primary controller. BUTTON LAYOUT NOTE: This product can be operated in one Z-Wave network with Z-Wave certified devices from other manufacturers and/or other applications. The different listening nodes within the network may act as repeaters regardless of vendor. For best results, please read and perform all the remaining instructions before using the controller. Keep this manual for future reference. Z-WAVE TERMINOLOGY Primary Controller: This is the main device used to set up and control your Z-Wave network. There can only be one primary controller and it must be used to add or delete devices. A primary controller can be a portable device like a hand-held remote, a static controller (permanently installed & never moved), a Z-Wave enabled PC or a Z-Wave enabled Ethernet router/bridge/gateway. Turns selected group or scene Turns selected group or scene Press & Release to change to Group mode Press & Release to change to Scene mode After entering SETUP mode, use to add devices to a group or scene After entering SETUP mode, use to remove devices from a group or scene Multi-color LED ( Green/Orange/Red) (behind bezel). Visible only when the device is in setup mode Amber LEDs behind buttons provide visual feedback pg. 2 Secondary Controller: The Z-Wave network supports multiple controllers so the residents can use additional Z-Wave remotes throughout the home. A secondary controller can not be used to add or delete devices. Slave: Devices within the Z-Wave network are either controllers or slaves. Most AC powered slaves also function as repeaters in the network, and when required, relay the command signals to the destination device. Battery powered devices like motion detectors are typically asleep and do not function as repeaters. Home Control Network: Your controllers and every Z-Wave device you have added with the primary controller are linked together into a wireless network. Each device in your network has a unique address assigned to it and cannot be activated by your neighbor’s Z-Wave controller. Light/Node/Device: Node is the technical term used to describe a Z-Wave device in your home control network. Please note that the terms “Node”, “Device” and “Light” all refer to an individual Z-Wave enabled device and are interchangeable within the context of these instructions. Group: Groups can also be thought of as an area or zone. Multiple Z-Wave devices can be turned ON or OFF with a single command when they are placed into a Group. One example would be grouping your porch light, exterior garage lights and patio lights together so that they could all be turned ON if you hear a strange sound in the middle of the night. Scene: Scenes are normally activity based lighting schemes. A scene lets you establish preset brightness levels for multiple Z-Wave controlled lights and then control them with one command. This is ideal for mood or task lighting. Scene 1 could be the family room lights set to dim for watching TV. Scene 2 could have the same lights set to a different brightness level for other activities like reading or entertaining. Include / Exclude: Include and exclude are the formal terms used to describe adding, removing or deleting devices to or from the control network or groups and scenes. Replicate: This is the Z-Wave term for copying or transferring the Z-Wave network data to a new controller. This process is also used to update secondary controllers after changes have been made to the control network with the primary controller. BATTERIES Two CR2032 batteries are pre-installed in the unit. Be sure to remove the insulating tabs before trying to program and use the device. Battery Use and Safety - Use only fresh batteries of the required size and recommended type. - Replace both batteries at the same time! Do not mix old and new batteries or different types of batteries. - Dispose of old batteries promptly and properly. Do not burn or bury them. - Replace fully discharged batteries immediately pg. 3 To Install Batteries: 1. Insert a flat-blade screwdriver into the small slot at the bottom of the faceplate and twist gently to remove the faceplate from the device. 2. Remove the small screw from the battery retainer door. Pull out on the top of the door (it is hinged at the bottom). 3. Slide the batteries out of the holder 4. Install new batteries in the correct orientation based on the “+” & “-“ polarity markings 5. Hold the batteries in place (pushing them toward the center of the unit) and close the battery door making sure that the ends of the retainer door fit over the batteries. Please note that the battery retainer door hinges at the bottom and can lock in the open position. You may need to pull or lift it gently to close it. 6. Reinstall the retainer screw and faceplate INSERT PICTURES & CALLOUTS DETAILING BATTERY INSTALLATION & POLARITY MARKINGS Battery Life: This device is just like any universal A/V remote control; the more you use it, the shorter the battery life. Under normal operating conditions, the batteries should last for approximately one year. LED indicators behind the Group/Scene control buttons will blink when one of the buttons is pressed. The brightness of the blinking LED will diminish as the batteries are depleted. A very dim LED will provide a visual indication that the batteries need to be replaced. Network, Group & Scene programming will be retained while changing batteries. Please note: Using this device to control Groups and Scenes containing large numbers of Z-Wave devices will be more demanding on the batteries than smaller Groups and Scenes, resulting in shorter battery life. ! WARNING RISK OF FIRE RISK OF ELECTRICAL SHOCK RISK OF BURNS Controlling Appliances: Exercise extreme caution when u…

Text truncated - open the document above for the full version.

SheenwayAsia Limited Rm 1313, 13/F, Austin Tower, 22-26 Austin Avenue, TsimShaTsui, Kowloon, Hong Kong Tel: (852)-2722-6692Fax: (852)- 2722- 7793 Federal Communications Commission 7435 Oa kland, Mills Road Columbia, MD 21046 Dear Sir/Madam, This is written to authorize Ms.Josephine Yeung to act on my behalf for the FCC application. Yours truly, Arthury Chau Director of Marketing and Product Development

Sheenway Asia Ltd Room 1313, 13/F, Austin Tower, Tsim Sha Tsui, Kowloon. Tel: (86-755)82374246 Fax: (86-755)82375277 Email: [email protected] ; [email protected] Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concernΚ This is to serve as proper written authorization thatShenzhen academy of metrology and Quality inspection longzhu road Shenzhen Guangdong china, will act as our representative in all matters relating to FCC applications for equipment approval. If you have any questions regarding our applications for equipment approval, please contact Shenzhen academy of metrology and quality inspection Respectfully, Effective DatesΚ (Josephone) From Project Engineer DATEΚ

Sheenway Asia Ltd Room 1313, 13/F, Austin Tower, Tsim Sha Tsui, Kowloon. Tel: (86-755)82374246 Fax: (86-755)82375277 Email: [email protected] ; [email protected] Federal Communications Commission 7435 Okland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with section 0.457(d)(2)(i) pertaining to confidential material. Sheenway Asia Ltd would like the following documents regarding this submission for FCC ID: U2ZZW5301 to be kept confidential. 1. schematics 2. block diagram 3. operation description the above documents contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want the documents to be accessible to general public. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, --------------------------------------------------- Project Engineer company: Sheenway Asia Ltd Tel: (86-755)82374246 Fax: (86-755)82375277 E-mail: [email protected] ; [email protected]

External photo page 1 of 1 Photo 1 Appearance of EUT Photo 2 Appearance of EUT

Internal photo Page 1/3 Photo 1 Inside of EUT Photo 2 Inside of EUT Internal photo Page 2/3 Photo 3 Inside of EUT Photo 4 Inside of EUT Internal photo Page 3/3 Photo 5 Antenna

FCC TEST REPORT For Group and Scene Controller Model Number: 45631, ZW5301 FCC ID: U2ZZW5301 Report Number : WT108000792 Test Laboratory : Shenzhen Academy of Metrology and Quality Inspection National Testing Center for Digital Electronic Products Site Location : Bldg. Metrology and Quality Inspection, Longzhu Road, Shenzhen, Guangdong, China Tel : 0086-755-26941599 Fax : 0086-755-26941545 Web : www.smq.com.cn Report No.: WT108000792 Page 2/17 Test report declaration Applicant : SHEENWAY ASIA LTD. Address : Room 1313, 13/F., Austin Tower, Tsim Sha Tsui, Kowloon, Hong Kong. Manufacturer : SHEENWAY ASIA LTD. Address : Room 1313, 13/F., Austin Tower, Tsim Sha Tsui, Kowloon, Hong Kong. Factory : KONIG ELECTRONIC (HUIZHOU) LTD. Address : 2-Plant, East Lake Side, QingTang, Lian He Village, Shui Kou, Hui Cheng District, Huizhou, GuangDong, China. EUT Description : Group and Scene Controller Model No : 45631, ZW5301 FCC ID : U2ZZW5301 Test Standards: FCC Part 15 15.249 The EUT described above is tested by Shenzhen Academy of Metrology and Quality Inspection EMC Laboratory to determine the maximum emissions from the EUT. Shenzhen Academy of Metrology and Quality Inspection EMC Laboratory is assumed full responsibility for the accuracy of the test results. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (2003) and the energy emitted by the sample EUT tested as described in this report is in compliance with FCC Rules Part 15.249. The test report is valid for above tested sample only and shall not be reproduced in part without written approval of the laboratory. Project Engineer: Date: Mar.22,2010 (Ryan Chen) Checked by: Date: Mar.22,2010 (Dewelly Yang) Approved by: Date: Mar.22,2010 (Peter Lin) Report No.: WT108000792 Page 3/17 TABLE OF CONTENTS TEST REPORT DECLARATION........................................................................................................2 1. TEST RESULTS SUMMARY...................................................................................................4 2. GENERAL INFORMATION......................................................................................................5 2.1. Report information..........................................................................................................5 2.2. Laboratory Accreditation and Relationship to Customer.........................................5 2.3. Measurement Uncertainty.............................................................................................6 3. PRODUCT DESCRIPTION.......................................................................................................7 3.1. EUT Description..............................................................................................................7 3.2. Related Submittal(s) / Grant (s)...................................................................................7 3.3. Block Diagram of EUT Configuration..........................................................................7 3.4. Operating Condition of EUT..........................................................................................7 3.5. Special Accessories.......................................................................................................8 3.6. Equipment Modifications...............................................................................................8 3.7. Support Equipment List.................................................................................................8 3.8. Test Conditions...............................................................................................................8 4. TEST EQUIPMENT USED........................................................................................................9 5. CONDUCTED DISTURBANCE TEST..................................................................................10 5.1. Test Standard and Limit..............................................................................................10 5.2. Test Procedure.............................................................................................................10 5.3. Test Arrangement.........................................................................................................10 5.4. Test Data.......................................................................................................................10 6. RADIATED DISTURBANCE TEST.......................................................................................11 6.1. Test Standard and Limit..............................................................................................11 6.2. Test Procedure.............................................................................................................11 6.3. Test Arrangement.........................................................................................................11 6.4. Test Data.......................................................................................................................12 7. OCCUPIED BANDWIDTH......................................................................................................14 7.1. Test Standard and Limit..............................................................................................14 7.2. Test Procedure.............................................................................................................14 7.3. Test Arrangement.........................................................................................................14 7.4. Test Data.......................................................................................................................14 8. BAND EDGE.............................................................................................................................15 8.1. Test Standard and Limit.....................................…

Text truncated - open the document above for the full version.

Test setup photo Page 1/1 Photo 1 Radiated Disturbance Test Photo 2 Radiated Disturbance Test
