MAX Series User Manual Pepwave Products: MAX 700 / HD2 / HD2 IP67 / HD2 Mini / HD2 MBX / HD Dome / HD Dome Pro / HD4 / HD4 MBX / MBX Mini / HD4 IP67 / Transit / Transit Duo / Transit 5G / Transit Core / Transit Mini / Transit Pro E / Transit Pro / BR1 Classic / BR1 MK2 / BR1 Slim / BR1 ENT / BR1 M2M / / BR1 Mini (HW2) / BR1 Mini (HW3) / BR1 Mini Core / BR1 ESN / BR1 Pro LTE / BR1 Pro (CAT-20) / BR1 Pro 5G / BR2 Pro / BR1 IP55 / BR1 IP67 / BR2 IP55 / On-The-Go / HD2 with MediaFast / HD4 with MediaFast / SpeedFusion Engine / UBR LTE / UBR Plus / PDX Pepwave Firmware 8.2.1 November 2022 COPYRIGHT & TRADEMARKS Specifications are subject to change without notice. Copyright © 2021 Peplink Pepwave Ltd. All Rights Reserved. Pepwave and the Pepwave logo are trademarks of Peplink International Ltd. Other brands or products mentioned may be trademarks or registered trademarks of their respective owners. Table of Contents Introduction and Scope 8 Glossary 9 1 Product Features 10 1.1 Supported Network Features 10 1.2 Other Supported Features 13 2 Pepwave MAX Mobile Router Overview 14 2.1 MAX 700 14 2.2 MAX HD2 16 2.3 MAX HD2 IP67 18 2.4 MAX HD2 mini 19 2.5 MAX HD Dome 20 2.6 MAX HD Dome Pro 22 2.7 MAX Transit / MAX Transit Duo (CAT-12) 24 2.8 MAX Transit (CAT-18) 26 2.9 MAX Transit 5G 28 2.10 MAX Transit Mini 29 2.11 MAX Transit Pro E 30 2.12 MAX Transit Core 31 2.13 MAX Transit Pro 33 2.14 MAX BR1 ESN 35 2.15 MAX HD2 and HD4 with MediaFast 36 2.16 MAX HD4 38 2.17 MAX HD4 MBX (CAT-12) 40 2.18 MAX HD2/4 MBX (CAT-20) 42 2.19 MAX HD2/4 MBX (5G) 44 2.20 MAX MBX Mini 46 2.21 MAX HD4 IP67 48 2.22 MAX BR1 Classic 49 2.23 MAX BR1 MK2 50 2.24 MAX BR1 Slim 52 2.25 MAX BR1 Mini (HW2) 53 2.26 MAX BR1 Mini (HW3) 55 2.27 MAX BR1 Mini Core 56 https://www.peplink.com 2 Copyright @ 2021 Peplink 2.28 MAX BR1 M2M 57 2.29 MAX BR1 ENT 58 2.30 MAX BR1 Pro 59 2.31 MAX BR1 Pro (CAT-20) 60 2.32 MAX BR1 Pro 5G 62 2.33 MAX BR2 Pro 64 2.34 MAX Hotspot 65 2.35 MAX BR1 IP55 66 2.36 MAX BR2 IP55 68 2.37 MAX BR1 IP67 69 2.38 MAX On-The-Go 70 2.39 SpeedFusion Engine 71 2.40 UBR LTE 71 2.41 UBR Plus 73 2.42 PDX 74 3 Advanced Feature Summary 75 3.1 Drop-in Mode and LAN Bypass: Transparent Deployment 75 3.2 QoS: Clearer VoIP 75 3.3 Per-User Bandwidth Control 76 3.4 High Availability via VRRP 76 3.5 USB Modem and Android Tethering 77 3.6 Built-In Remote User VPN Support 77 3.7 SIM-card USSD support 78 3.8 KVM Virtualization 78 3.9 DPI Engine 79 3.10 NetFlow 79 3.11 Wi-Fi Air Monitoring 79 3.12 SP Default Configuration 79 3.13 Peplink Relay 80 3.14 DNS over HTTPS (DoH) 80 3.15 Peplink InTouch 80 4 Installation 81 4.1 Preparation 81 4.2 Constructing the Network 81 4.3 Configuring the Network Environment 82 5 Mounting the Unit 83 https://www.peplink.com 3 Copyright @ 2021 Peplink 5.1 Wall Mount 83 5.2 Car Mount 83 5.3 IP67 Installation Guide 83 5.4 PDX Accessory Kit Installation Guide 84 6 Connecting to the Web Admin Interface 91 7 SpeedFusion Connect 93 7.1 Activate SpeedFusion Connect Service 93 7.2 Enable SpeedFusion Connect 94 7.3 Connect Clients to Cloud 101 7.4 Link Wi-Fi to Cloud 102 7.5 Optimize Cloud Application 104 8 Configuring the LAN Interface(s) 105 8.1 Basic Settings 105 8.2 Port Settings 117 8.3 Captive Portal 118 9 Configuring the WAN Interface(s) 121 9.1 Ethernet WAN 123 9.2 Cellular WAN 133 9.3 Wi-Fi WAN 137 9.4 WAN Connection Settings (Common) 141 9.5 WAN Health Check 142 9.6 Bandwidth Allowance Monitoring 145 9.7 Additional Public IP address 146 9.8 Dynamic DNS Settings 146 10 Advanced Wi-Fi Settings 148 11 MediaFast Configuration 152 11.1 Setting Up MediaFast Content Caching 152 11.2 Scheduling Content Prefetching 154 11.3 Viewing MediaFast Statistics 156 12 ContentHub 156 12.1 Configuring the ContentHub 157 12.2 Configure a website for ContentHub 157 12.3 Configure an application for ContentHub 159 https://www.peplink.com 4 Copyright @ 2021 Peplink 13 Docker 161 14 KVM 162 15 Bandwidth Bonding SpeedFusionTM / PepVPN 164 15.1 PepVPN 164 15.2 The Pepwave Router Behind a NAT Router 173 16 IPsec VPN 174 16.1 IPsec VPN Settings 175 16.2 GRE Tunnel 179 17 Outbound Policy 181 17.1 Outbound Policy 182 17.2 Adding Rules for Outbound Policy 183 18 Port Forwarding 193 18.1 UPnP / NAT-PMP Settings 195 19 NAT Mappings 195 20 QoS 197 20.1 User Groups 198 20.2 Bandwidth Control 199 20.3 Application 199 21 Firewall 201 21.1 Outbound and Inbound Firewall Rules 203 21.2 Content Blocking 207 22 Routing Protocols 210 22.1 OSPF & RIPv2 210 22.2 BGP 212 23 Remote User Access 217 23.1 L2TP with IPsec 217 23.2 OpenVPN 217 23.3 PPTP 218 23.4 Authentication Methods 218 24 Miscellaneous Settings 220 24.1 High Availability 220 24.2 Certificate Manager 223 https://www.peplink.com 5 Copyright @ 2021 Peplink 24.3 Service Forwarding 224 24.4 Service Passthrough 227 24.5 UART 228 24.6 GPS Forwarding 230 24.7 Ignition Sensing 232 Ignition Sensing installation 232 GPIO Menu 233 24.8 NTP Server 234 24.9 Grouped Networks 236 24.10 Remote SIM Management 237 24.11 SIM Toolkit 238 25 AP 240 25.1 AP Controller 241 25.2 Wireless SSID 241 25.3 Wireless Mesh 246 25.4 Settings 246 26 AP Controller Status 253 26.1 Info 253 26.2 Access Point (Usage) 255 26.3 Wireless SSID 256 26.4 Mesh / WDS 258 26.5 Wireless Client 259 26.6 Nearby Device 261 26.7 Event Log 261 27 Toolbox 262 28 System Settings 262 28.1 Admin Security 263 28.2 Firmware 267 28.3 Time 269 28.4 Schedule 270 28.5 Email Notification 271 28.6 Event Log 272 28.7 SNMP 275 28.8 SMS Control 277 28.9 InControl 278 https://www.peplink.com 6 Copyright @ 2021 Peplink 28.10 Configuration 279 28.11 Feature Add-ons 279 28.12 Reboot 280 29 Tools 280 29.1 Ping 280 29.2 Traceroute Test 282 29.3 PepVPN Test 282 29.4 Wake-on-LAN 282 29.5 CLI (Command Line Interface Support) 283 30 Status 283 30.1 Device 283 30.2 GPS Data 285 30.3 Active Sessions 287 30.4 Client List 289 30.5 WINS Client 290 30.6 UPnP / NAT-PMP 290 30.7 OSPF & RIPv2 291 30.8 BGP 291 30.9 SpeedFusion Status 292 30.10 Event Log 294 31 WAN Quality 295 32 …

Text truncated - open the document above for the full version.

IPsec NAT-T This field is for enabling the support of IPsec NAT-T passthrough. UDP ports 500, 4500, and 10000 are monitored by default. You may add more custom data ports that your IPsec system uses by checking Define custom ports . If the VPN contains IPsec site-to-site VPN traffic, check Route IPsec Site-to-Site VPN and choose the WAN connection to route the traffic to. https://www.peplink.com 228 Copyright @ 2021 Peplink 24.5 UART Selected Pepwave MAX routers feature a RS-232 serial interface on the built-in terminal block. The RS-232 serial interface can be used to connect to a serial device and make it accessible over an TCP/IP network. The serial interface can be enabled and parameters can be set on the web admin page under Advanced > UART . Make sure they match the serial device you are connecting to. https://www.peplink.com 229 Copyright @ 2021 Peplink There are 4 pins i.e. TX, RX, RTS, CTS on the terminal block for serial connection and they correspond to the pins in a DB-9 connector as follows: DB-9 Pepwave MAX Terminal Block Pin 1 – Pin 2 Rx (rated -+25V) Pin 3 Tx (rated -+12V) Pin 4 – Pin 5 – Pin 6 – Pin 7 RTS Pin 8 CTS Pin 9 – The RS232 serial interface is not an isolated RS232. External galvanic isolation may be added if required. Be sure to check whether your serial cable is a null modem cable, commonly known as crossover cable, or a straight through cable. If in doubt, swap Rx and Tx, and RTS and CTS, at the other end and give it another go. Once connected, your serial device should be accessible on your Pepwave MAX router LAN IP address at the specified TCP port. https://www.peplink.com 230 Copyright @ 2021 Peplink 24.6 GPS Forwarding Using the GPS forwarding feature, some Pepwave routers can automatically send GPS reports to a specified server. To set up GPS forwarding, navigate to Advanced>GPS Forwarding . GPS Forwarding Enable Check this box to turn on GPS forwarding. Server Enter the name/IP address of the server that will receive GPS data. Also specify a port number, protocol ( UDP or TCP ), and a report interval of between 1 and 10 seconds. Click to save these settings. GPS Report Format Choose from NMEA or TAIP format for sending GPS reports. NMEA Sentence Type If you’ve chosen to send GPS reports in NMEA format, select one or more sentence types for sending the data ( GPRMC , GPGGA , GPVTG , GPGSA , and GPGSV ). Vehicle ID The vehicle ID will be appended in the last field of the NMEA sentence. Note that the NMEA sentence will become customized and non-standard. TAIP Sentence Type/TAIP ID (optional) If you’ve chosen to send GPS reports in TAIP format, select one or more sentence types for sending the data ( PV—Position / Velocity Solution and CP—Compact Velocity Solution ). You can also optionally include an ID number in the TAIP ID field. https://www.peplink.com 231 Copyright @ 2021 Peplink 24.7 Ignition Sensing Ignition Sensing detects the ignition signal status of a vehicle it is installed in. This feature allows the cellular router to start up or shut down when the engine of that vehicle is started or turned off. The time delay setting between ignition off and power down of the router is a configurable setting, which allows the router to stay on for a period of time after the engine of a vehicle is turned off. Ignition Sensing installation Functoin Colour Wire I/O optional * Brown IGN I/P connected to positive feed on the ignition ** Orange DC IN - connected to permanent negative feed (ground) Black DC IN + connected to permanent positive feed (power) Red * Currently not functional; will be used for additional features in future firmware. ** Connecting IGN I/P is optional and is needed only if the Ignition Sensing feature is configured. https://www.peplink.com 232 Copyright @ 2021 Peplink Connectivity diagram for devices with 4-pin connector Connectivity diagram for devices with terminal block connection https://www.peplink.com 233 Copyright @ 2021 Peplink GPIO Menu Note: This feature is applicable for certain models that come with a GPIO interface. Ignition Sensing options can be found in Advanced > GPIO. The configurable option for Ignition Input is Delay; the time in seconds that the router stays powered on after the ignition is turned off. The O/P (connected to the I/O pin on a 4 pin connector) can be configured as a digital input, a digital output, or an analog input. Digital Input - the connection supports input sensing; it reads the external input and determines if the settings should be 'High' (on) or 'Low' (off). Digital Output - when there is a healthy WAN connection, the output pin is marked as 'High' (on). Otherwise, it will be marked as 'Low' (off). Note: The Digital Output state (on/off) upon rebooting the device may vary depending on the model, eg. MAX BR1 MK2 = Persistent; MAX Transit Mini with ContentHub = Reset to default, etc . Analog Input - to be confirmed. In most cases, it should read the external input and determine the voltage level. https://www.peplink.com 234 Copyright @ 2021 Peplink 24.8 NTP Server Pepwave routers can now serve as a local NTP server. Upon start up, it is now able to provide connected devices with the accurate time, precise UTC from either an external NTP server or via GPS and ensuring that connected devices always receive the correct time. Compatible with: BR1 ENT, BR1 Pro CAT-20/5G, 700 HW3, HD2/4, Transit NTP Server setting can be found via: Advanced>Misc. Settings>NTP Server Time Settings can be found at System>Time>Time Settings https://www.peplink.com 235 Copyright @ 2021 Peplink 24.9 Grouped Networks Advanced > Grouped Networks allows to configure destination networks in grouped format. Select Add group to create a new group with single IPaddresses or subnets from different VLANs. The created network groups can be used in outbound policies, firewall rules. https://www.peplink.com 236 Copyright @ 2021 Peplink 24.10 Remote SIM Management The Remote SIM management is accessible via Advanced > Misc Settings > Remo…

Text truncated - open the document above for the full version.
