  3. UAG-T3E

UAG-T3ET3E

AwarePoint Corporation
T3E - FCC ID UAG-T3E - AwarePoint Corporation
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Dec 21, 2011
Application Purpose
Original Equipment
Date of Application
Dec 21, 2011
Equipment Note
T3E
Frequency Range
2405.00000000 - 2480.00000000
Company
AwarePoint Corporation
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗
↗
↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

Operational Description

↗

RF Exposure Info

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

600 W Broadway Ave., Suite 250 San Diego, CA 92101 Tel: (858) 345-5000 Fax: (619) 230-8886 Awarepoint Corporation Confidential and Proprietary Tag Model T3E User’s Manual November 02, 2011 600 W Broadway Ave., Suite 250 San Diego, CA 92101 Tel: (858) 345-5000 Fax: (619) 230-8886 Awarepoint Corporation Confidential and Proprietary Introduction Safety and Regulatory Information FCC ID: UAG-T3E This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this Device may not cause harmful interference and (2) this Device must accept any interference received, including Interference that may cause undesired operation. CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Warnings • This product is for indoor use only. • This product is only to be installed by factory trained Awarepoint personnel. • Do not open the product as there are no user serviceable parts inside and this product is powered at all times. • Do not use unit if the case is cracked or worn. Product Description The Tag is a wireless device that is located so as to provide environmental information such as the temperature of a refrigeration unit or the humidity of a space The Tags transmits short messages periodically that include the ID of the device as well as environmental sample data which are received by the Awarepoint sensors. The sensors relay the ID and sample data messages to the bridges via the mesh network created by the plurality of sensors. The bridge communicates with the tags on its wireless link via the sensors. The bridges communicate with the Awarepoint server over an ethernet Interface. Tags, sensors and bridges also periodically check the server for updated configuration information or firmware updates. The tag works with other Awarepoint products as shown in the diagram below. 600 W Broadway Ave., Suite 250 San Diego, CA 92101 Tel: (858) 345-5000 Fax: (619) 230-8886 Awarepoint Corporation Confidential and Proprietary AwarePoint Receiver Corporate LAN AwarePoint Bridge AwarePoint Tag AwarePoint Server PC Running Management Console PC Running Dashboard AwarePoint Receiver AwarePoint Receiver Figure 1: Awarepoint Tracking System Product Illustration Figure 2: Tag, with temperature probe 600 W Broadway Ave., Suite 250 San Diego, CA 92101 Tel: (858) 345-5000 Fax: (619) 230-8886 Awarepoint Corporation Confidential and Proprietary Installation Pre-Installation Prior to installing the tag, the Awarepoint server, bridges, and sensors must be correctly installed. Attaching the tag to an asset To attach a tag to an asset, you will need to know the asset’s type, and optionally manufacturer, model, and serial number. 1. You can use zip ties or double sided tape to attach the tag to the asset. 2. In the system manager, create a new asset type if one does not exist already. 3. In the system manager, create a new asset with the specified manufacturer, model, and unique ID. 4. Drag the tag’s MAC address onto the newly created asset. 5. Click Apply

Cover Letter(s)

Northwest EMC TCB Compliance Opinion Rev. 7/1/10 AWAR0013 Information about the Applicant Grantee (Company Name) Awarepoint Corporation FCC Contact Person Brian Lee Address 600 W. Broadway Suite 250 City, State, Zip San Diego, CA 92101 Job Number AWAR0013 Model T3x FCC ID UAG-T3E Agent John Taylor Approval Type Original Equipment Class DTS Digital Transmission System Rule Part 15.247 (15C) Overview The Tag is a wireless device that is located so as to provide environmental information such as the temperature of a refrigeration unit or the humidity of a space. The Tag transmits short messages periodically that include the ID of the device as well as environmental sample data which are received by the Awarepoint sensors. The sensors relay the ID and sample data messages to the bridges via the mesh network created by the plurality of sensors. The bridge communicates with the tags on its wireless link via the sensors. The bridges communicate with the Awarepoint server over an ethernet Interface. Confidentiality requested for allowed files. Request is properly addressed and referenced. Recommendation All items have been resolved and completed to my satisfaction; therefore I recommend this application for approval. Signature Dave Tolman, TCB Committee 12/21/2011

Cover Letter(s)

600 W Broadway Ave., Suite 250 San Diego, CA 92101 Tel: (858) 345-5000 Fax: (619) 230-8886 Awarepoint Corporation P a g e | 1 December 14, 2011 Re: Request for application examination for Awarepoint Tag model T3E Applicant: Awarepoint Corporation Application Examiner, Awarepoint Corporation is submitting this application for the original certification their model T3E radio transceiver, FCC ID: UAG-T3E. The technical report and exhibits demonstrate compliance with FCC rules 47 CFR 15.209 as a low frequency transmitter and 15.247 as a DTS transmitter. The 15.209 transmitter has been verified per 15.201(a). Your efforts in reviewing this application are greatly appreciated. Best regards, John Taylor Senior Sustaining Engineer Tel: (858) 775-1711 Fax: (858) 777-5626

Cover Letter(s)

600 W Broadway Ave., Suite 250 San Diego, CA 92101 Tel: (858) 345-5000 Fax: (619) 230-8886 Awarepoint Corporation P a g e | 1 November 02, 2011 Re: Request of Confidentiality for Awarepoint model T3E Applicant: Awarepoint Corporation Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying as outlined below: • Schematics • Block Diagram • Operating Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this Application. Best regards, John Taylor Senior Sustaining Engineer Tel: (858) 775-1711 Fax: (858) 777-5626

External Photos

600 W Broadway Ave., Suite 250 San Diego, CA 92101 Tel: (858) 345-5000 Fax: (619) 230-8886 T3E TAG EXTERNAL CONFIGURATION (This view is not at the same scale) 600 W Broadway Ave., Suite 250 San Diego, CA 92101 Tel: (858) 345-5000 Fax: (619) 230-8886 T3E TAG FCC LABELING

ID Label/Location Info

600 W Broadway Ave., Suite 250 San Diego, CA 92101 Tel: (858) 345-5000 Fax: (619) 230-8886 T3E TAG FCC LABELING

Internal Photos

600 W Broadway Ave., Suite 250 San Diego, CA 92101 Tel: (858) 345-5000 Fax: (619) 230-8886 T3E TAG PWB CONFIGURATION 600 W Broadway Ave., Suite 250 San Diego, CA 92101 Tel: (858) 345-5000 Fax: (619) 230-8886 T3E TAG PWB CONFIGURATION WITH BATTERIES INSTALLED 600 W Broadway Ave., Suite 250 San Diego, CA 92101 Tel: (858) 345-5000 Fax: (619) 230-8886 T3E TAG INTERNAL CONFIGURATION PWB in housing with circuit shield plate removed and probe attached. PWB in housing with circuit shield plate installed and probe attached.

Operational Description

Integrated Antenna and RF Solutions 1 Product Specification FE010315-N Mica 2.4 GHz SMD Antenna Part No. A5645 Product Specification 1 Features • Designed for 2.4 GHz applications: Bluetooth ® , Wi-Fi ® (802.11b/g), ZigBee ® , etc., as well as 2.3 GHz WiMAX ™ , 2.5 GHz WiMAX ™ and WiBro • Easy to integrate • Designed for use with the ground plane extended beneath the antenna • High efficiency • Light weight • Intended for SMD mounting • Supplied in tape on reel 2 Description Mica is intended for use with all 2.4 GHz applications. The antenna uses a ground plane in order to radiate efficiently and the ground plane must extend underneath the antenna itself. 3 Applications • Mobile phones • PDAs • PNDs • Headsets • PMPs / MP3s • Laptops • PC-Cards • Sensors • Automotive Mica 2.4 GHz SMD Antenna Part No. A5645 4 Part number Mica: A5645 150 5 General data Product name Mica 2.4 GHz Part Number A5645 Frequency 2.4 – 2.5 GHz Polarization Linear Operating temperature -40 ºC to +85 ºC Impedance with matching 50 Ω Weight 0.5 g Antenna type SMD Dimensions 20.5 x 3.6 x 3.3 [mm] 6 Electrical characteristics Typical performanceConditions Peak gain 1.8 dBi Average gain -1.9 dBi Average efficiency 65% Maximum Return Loss -11 dB Maximum VSWR 1.8:1 All data measured on Antenova’s reference board, part number A5645-U1 Data given for the 2.4 – 2.5 GHz frequency range Integrated Antenna and RF Solutions 2 Product Specification FE010315-N Mica 2.4 GHz SMD Antenna Part No. A5645 7 Electrical performance 7-1 Return Loss 2200 23002400250026002700 -40 -30 -20 -10 0 ∇ ∇ [MHz] [dB] mtool5 7-2 VSWR 2200 23002400250026002700 1 2 3 4 5 ∇ ∇ [MHz] mtool5 Integrated Antenna and RF Solutions 3 Product Specification FE010315-N Mica 2.4 GHz SMD Antenna Part No. A5645 7-3 Antenna patterns Z X Y -15 -35 dBi 5 XZ plane XY plane ZY plane Patterns show combined polarisations measured on reference board A5645-U1 Integrated Antenna and RF Solutions 4 Product Specification FE010315-N Mica 2.4 GHz SMD Antenna Part No. A5645 8 Antenna dimensions L W H Length Width Height 20.5 ± 0.2 3.6 ± 0.2 3.3 ± 0.2 Dimensions in mm 9 Antenna footprint Mica (Part No: A5645) CAD files of the antenna footprint are available from Antenova on request. Please contact [email protected] for further details. I S K J L M O 3.2 ± 0.11.2 ± 0.1 1.0 ± 0.15.5 ± 0.17.7 ± 0.1≥ 0.4 ± 0.10.2 ± 0.1 Dimensions in mm Integrated Antenna and RF Solutions 5 Product Specification FE010315-N Mica 2.4 GHz SMD Antenna Part No. A5645 10 Electrical interface 10-1 Transmission lines • All transmission lines should be designed to have a characteristic impedance of 50 Ω • The length of the transmission lines should be kept to a minimum • Any other parts of the RF system like transceivers, power amplifiers, etc, should also be designed to have an impedance of 50 Ω Once the material for the PCB has been chosen (PCB thickness and dielectric constant), a coplanar transmission line can easily be designed using any of the commercial software packages for transmission line design. For the chosen PCB thickness, copper thickness and substrate dielectric constant, the program will calculate the appropriate transmission line width and gaps on either side of the track so the characteristic impedance of the coplanar transmission line is 50 Ω. 10-2 Matching circuit The antenna requires a matching circuit that must be optimized for each customer’s product. The matching circuit will require up to three components and the following pad layout should be designed into the device so the correct circuit can be installed: Antenna feed pad indicated. All other pads should be connected to ground. In addition to the matching circuit, a separate DC blocking capacitor will also be required between the radio and the antenna matching circuit. Note: The component values for the matching circuit will vary depending on the size of the PCB and surrounding components. The impedance of the antenna should be measured before selecting suitable matching components. Antenova offers this service on request. Contact [email protected] for further information. Integrated Antenna and RF Solutions 6 Product Specification FE010315-N Mica 2.4 GHz SMD Antenna Part No. A5645 10-3 Antenna placement Antenova strongly recommends placing the antenna near the edge of the board. Maximum antenna performance is achieved by placing the antenna towards one of the corners of the PCB and with the feed point of the antenna as close to same corner of the PCB as possible. 10-4 Reference board The reference board has been designed for evaluation purposes of Mica 2.4 GHz and it includes a SMA female connector Dimensions in mm To order a reference board contact [email protected] Integrated Antenna and RF Solutions 7 Product Specification FE010315-N Mica 2.4 GHz SMD Antenna Part No. A5645 Integrated Antenna and RF Solutions 8 Product Specification FE010315-N 11 Soldering This antenna is suitable for lead free soldering. The reflow profile should be adjusted to suit the device, oven and solder paste, while observing the following conditions: - The maximum temperature should not exceed 240 ºC - However for lead free soldering, a maximum temperature of 255 ºC for no more than 20 seconds is permitted. - The antenna should not be exposed to temperatures exceeding 120 ºC more than 3 times during the soldering process. 12 Hazardous material regulation conformance The antenna has been tested to conform to RoHS requirements. A certificate of conformance is available from Antenova’s website. 13 Packaging 13-1 Optimal storage conditions for packaged reels Temperature -10ºC to 40ºC Humidity Less than 75% RH Shelf Life 18 Months Storage place Away from corrosive gas and direct sunlight Packaging Reels should be stored in unopened sealed manufacturer’s plastic packaging. Note: Storage of open reels of antennas is not recommended due to possible oxidization of pads on antennas. If short term storage is necessary, then it is highly recommended that the bag contain…

Text truncated - open the document above for the full version.

RF Exposure Info

Awarepoint Corporation T3E Tag Device Report No. AWAR0013.2 Report Prepared By www.nwemc.com 1-888-EMI-CERT © 2011 Northwest EMC, Inc 22975 NW Evergreen Parkway Suite 400 Hillsboro, Oregon 97124 Certificate of Evaluation Evaluation Date: December 13, 2011 Awarepoint Corporation Model: T3E Tag Device Emissions Test Description Specification Test Method Pass/Fail RF Exposure FCC 15.247(i): 2011 OET Bulletin 65, Supplement C Ed 01-01 Pass Modifications made to the product See the Modifications section of this report Approved By: Don Facteau, IS Manager This report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government of the United States of America. Product compliance is the responsibility of the client, therefore the tests and equipment modes of operation represented in this report were agreed upon by the client, prior to testing. This Report may only be duplicated in its entirety. The results of this test pertain only to the sample(s) tested. The specific description is noted in each of the individual sections of the test report supporting this certificate of test. Northwest EMC Revision History Revision 05/05/03 Revision Number Description Date Page Number 00 None Accreditations and Authorizations FCC Accredited by NVLAP for performance of FCC radio, digital, and ISM device testing. Our Open Area Test Sites, certification chambers, and conducted measurement facilities have been fully described in reports filed with the FCC and accepted by the FCC in letters maintained in our files. Northwest EMC has been accredited by ANSI to ISO / IEC Guide 65 as a product certifier. We have been designated by the FCC as a Telecommunications Certification Body (TCB). This allows Northwest EMC to certify transmitters to FCC specifications in accordance with 47 CFR 2.960 and 2.962. NVLAP Northwest EMC, Inc. is accredited under the National Voluntary Laboratory Accreditation Program (NVLAP) for satisfactory compliance with the requirements of ISO/IEC 17025 for Testing Laboratories. NVLAP is administered by the National Institute of Standards and Technology (NIST), an agency of the U.S. Commerce Department. The NVLAP accreditation encompasses Electromagnetic Compatibility Testing in accordance with the European Union EMC Directive 2004/108/EC, and ANSI C63.4. Additionally, Northwest EMC is accredited by NVLAP to perform radio testing in accordance with the European Union R&TTE Directive 1999/5/EEC, the requirements of FCC, and the RSS radio standards for Industry Canada. Industry Canada Accredited by NVLAP for performance of Industry Canada RSS and ICES testing. Our Open Area Test Sites and certification chambers comply with RSS-Gen, Issue 2 and have been filed with Industry Canada and accepted. Northwest EMC has been accredited by ANSI to ISO / IEC Guide 65 as a product certifier. We have been designated by NIST and recognized by Industry Canada as a Certification Body (CB) per the APEC Mutual Recognition Arrangement (MRA). This allows Northwest EMC to certify transmitters to Industry Canada technical requirements. (Site Filing Numbers - Hillsboro: 2834D-1, 2834D-2, Sultan: 2834C-1, Irvine: 2834B-1, 2834B-2, Brooklyn Park: 2834E-1) CAB Designated by NIST and validated by the European Commission as a Conformity Assessment Body (CAB) to conduct tests and approve products to the EMC directive and transmitters to the R&TTE directive, as described in the U.S. - EU Mutual Recognition Agreement. Australia/New Zealand The National Association of Testing Authorities (NATA), Australia has been appointed by the ACA as an accreditation body to accredit test laboratories and competent bodies for EMC standards. Accredited test reports or assessments by competent bodies must carry the NATA logo. Test reports made by an overseas laboratory that has been accredited for the relevant standards by an overseas accreditation body that has a Mutual Recognition Agreement (MRA) with NATA are also accepted as technical grounds for product conformity. The report should be endorsed with the respective logo of the accreditation body (NVLAP). Accreditations and Authorizations VCCI Accepted as an Associate Member to the VCCI, Acceptance No. 564. Conducted and radiated measurement facilities have been registered in accordance with Regulations for Voluntary Control Measures, Article 8. (Registration Numbers. - Hillsboro: C-1071, R-1025, G-84, C-2687, T- 1658, and R-2318, Irvine: R-1943, G-85, C-2766, and T-1659, Sultan: R-871, G-83, C-1784, and T-1511, Brooklyn Park: R-3125, G-86, G-141, C-3464, and T-1634). BSMI Northwest EMC has been designated by NIST and validated by C-Taipei (BSMI) as a CAB to conduct tests as described in the APEC Mutual Recognition Agreement (US0017). GOST Northwest EMC, Inc. has been assessed and accredited by the Russian Certification bodies Certinform VNIINMASH, CERTINFO, SAMTES, and Federal CHEC, to perform EMC and Hygienic testing for Information Technology Products. As a result of their laboratory assessment, they will accept test results from Northwest EMC, Inc. for product certification KCC Northwest EMC, Inc is a CAB designated by MRA partners and recognized by Korea. (Assigned Lab Numbers: Hillsboro: US0017, Irvine: US0158, Sultan: US0157, Brooklyn Park: US0175) VIETNAM Vietnam MIC has approved Northwest EMC as an accredited test lab. Per Decision No. 194/QD-QLCL (dated December 15, 2009), Northwest EMC test reports can be used for Vietnam approval submissions. SCOPE For details on the Scopes of our Accreditations, please visit: http://www.nwemc.com/accreditations/ Northwest EMC Locations Oregon Labs EV01-EV12 22975 NW Evergreen Pkwy Suite 400 Hillsboro, OR 97124 (503) 844-4066 California Labs OC01-OC13 41 Tesla Irvine, CA 92618 (949) 861-8918 Minnesota Labs MN01-MN08 9349 W Broadway Ave. Brooklyn Park, MN 55445 (763) 425-2281 Washington Labs SU01-SU07 14128 339 th Ave. SE Sultan, WA 98294 (360) 793-8675 New York Labs WA01-WA04 49…

Text truncated - open the document above for the full version.

Test Report

Awarepoint Corporation T3E Report No. AWAR0013 Report Prepared By www.nwemc.com 1-888-EMI-CERT © 2011 Northwest EMC, Inc 22975 NW Evergreen Parkway Suite 400 Hillsboro, Oregon 97124 Certificate of Test Last Date of Test: October 14, 2011 Awarepoint Corporation Model: T3E Emissions Test Description Specification Test Method Pass/Fail Occupied Bandwidth FCC 15.247:2011 ANSI C63.10:2009 Pass Output Power FCC 15.247:2011 ANSI C63.10:2009 Pass Band Edge Compliance FCC 15.247:2011 ANSI C63.10:2009 Pass Power Spectral Density FCC 15.247:2011 ANSI C63.10:2009 Pass Spurious Radiated Emissions FCC 15.247:2011 ANSI C63.10:2009 Pass Modifications made to the product See the Modifications section of this report Test Facility The measurement facility used to collect the data is located at: Northwest EMC, Inc. 41 Tesla Ave. Irvine, CA 92618 Phone: (503) 844-4066 Fax: 844-3826 This site has been fully described in a report filed with and accepted by the FCC (Federal Communications Commission) and Industry Canada (Site filing #2834B-1). Approved By: Don Facteau, IS Manager NVLAP Lab Code: 200676-0 This report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government of the United States of America. Product compliance is the responsibility of the client, therefore the tests and equipment modes of operation represented in this report were agreed upon by the client, prior to testing. This Report may only be duplicated in its entirety. The results of this test pertain only to the sample(s) tested. The specific description is noted in each of the individual sections of the test report supporting this certificate of test. Northwest EMC Revision History Revision 06/29/09 Barometric Pressure The recorded barometric pressure has been normalized to sea level. Revision Number Description Date Page Number 00 None Accreditations and Authorizations FCC Accredited by NVLAP for performance of FCC radio, digital, and ISM device testing. Our Open Area Test Sites, certification chambers, and conducted measurement facilities have been fully described in reports filed with the FCC and accepted by the FCC in letters maintained in our files. Northwest EMC has been accredited by ANSI to ISO / IEC Guide 65 as a product certifier. We have been designated by the FCC as a Telecommunications Certification Body (TCB). This allows Northwest EMC to certify transmitters to FCC specifications in accordance with 47 CFR 2.960 and 2.962. NVLAP Northwest EMC, Inc. is accredited under the National Voluntary Laboratory Accreditation Program (NVLAP) for satisfactory compliance with the requirements of ISO/IEC 17025 for Testing Laboratories. NVLAP is administered by the National Institute of Standards and Technology (NIST), an agency of the U.S. Commerce Department. The NVLAP accreditation encompasses Electromagnetic Compatibility Testing in accordance with the European Union EMC Directive 2004/108/EC, and ANSI C63.4. Additionally, Northwest EMC is accredited by NVLAP to perform radio testing in accordance with the European Union R&TTE Directive 1999/5/EEC, the requirements of FCC, and the RSS radio standards for Industry Canada. Industry Canada Accredited by NVLAP for performance of Industry Canada RSS and ICES testing. Our Open Area Test Sites and certification chambers comply with RSS-Gen, Issue 2 and have been filed with Industry Canada and accepted. Northwest EMC has been accredited by ANSI to ISO / IEC Guide 65 as a product certifier. We have been designated by NIST and recognized by Industry Canada as a Certification Body (CB) per the APEC Mutual Recognition Arrangement (MRA). This allows Northwest EMC to certify transmitters to Industry Canada technical requirements. (Site Filing Numbers - Hillsboro: 2834D-1, 2834D-2, Sultan: 2834C-1, Irvine: 2834B-1, 2834B-2, Brooklyn Park: 2834E-1) CAB Designated by NIST and validated by the European Commission as a Conformity Assessment Body (CAB) to conduct tests and approve products to the EMC directive and transmitters to the R&TTE directive, as described in the U.S. - EU Mutual Recognition Agreement. Australia/New Zealand The National Association of Testing Authorities (NATA), Australia has been appointed by the ACA as an accreditation body to accredit test laboratories and competent bodies for EMC standards. Accredited test reports or assessments by competent bodies must carry the NATA logo. Test reports made by an overseas laboratory that has been accredited for the relevant standards by an overseas accreditation body that has a Mutual Recognition Agreement (MRA) with NATA are also accepted as technical grounds for product conformity. The report should be endorsed with the respective logo of the accreditation body (NVLAP). Accreditations and Authorizations VCCI Accepted as an Associate Member to the VCCI, Acceptance No. 564. Conducted and radiated measurement facilities have been registered in accordance with Regulations for Voluntary Control Measures, Article 8. (Registration Numbers. - Hillsboro: C-1071, R-1025, G-84, C-2687, T- 1658, and R-2318, Irvine: R-1943, G-85, C-2766, and T-1659, Sultan: R-871, G-83, C-3265, and T-1511, Brooklyn Park: R-3125, G-86, G-141, C-3464, and T-1634). BSMI Northwest EMC has been designated by NIST and validated by C-Taipei (BSMI) as a CAB to conduct tests as described in the APEC Mutual Recognition Agreement (US0017). GOST Northwest EMC, Inc. has been assessed and accredited by the Russian Certification bodies Certinform VNIINMASH, CERTINFO, SAMTES, and Federal CHEC, to perform EMC and Hygienic testing for Information Technology Products. As a result of their laboratory assessment, they will accept test results from Northwest EMC, Inc. for product certification KCC Northwest EMC, Inc is a CAB designated by MRA partners and recognized by Korea. (Assigned Lab Numbers: Hillsboro: US0017, Irvine: US0158, Sultan: US0157, Brooklyn Park: US0175) VIETNAM Vietnam MIC has approved Northwest EMC as an…

Text truncated - open the document above for the full version.

Test Setup Photos

NORTHWEST EMC IMG_0114.JPG IMG_0115.JPG Occupied Bandwidth XMit 2011.01.21 NORTHWEST EMC IMG_0116.JPG Occupied Bandwidth XMit 2011.01.21 NORTHWEST EMC HFB01 (X).JPG HFB02 (X).JPG Output Power PSA-ESCI 2011.07.20 NORTHWEST EMC HFB03 (X).JPG HFB04 (X).JPG Output Power PSA-ESCI 2011.07.20 NORTHWEST EMC HFB01 (X).JPG HFB02 (X).JPG Band Edge Compliance XMit 2010.01.14 NORTHWEST EMC HFB03 (X).JPG HFB04 (X).JPG Band Edge Compliance XMit 2010.01.14 NORTHWEST EMC HFB01 (X).JPG HFB02 (X).JPG Power Spectral Density XMit 2010.01.14 NORTHWEST EMC HFB03 (X).JPG HFB04 (X).JPG Power Spectral Density XMit 2010.01.14 NORTHWEST EMC IMG_0927.JPG IMG_0921.JPG Spurious Radiated Emissions PSA-ESCI 2011.07.26 NORTHWEST EMC IMG_0923.JPG Spurious Radiated Emissions PSA-ESCI 2011.07.26

Contact Information

Applicant

John Taylor(Senior Sustaining Engineer)
[email protected]8583455000Fax: 6192308886

Test Firm

Northwest EMC, Inc.Greg Kiemel
[email protected]503-844-4066Fax: 503-844-3826

Technical Specifications

#Rule PartsFrequency RangePower Output
115C2.40 GHz - 2.48 GHz559.00 µW
Confidentiality
Long Term
Grant Notes
Output power is listed is EIRP. The antenna(s) used for this transmitter must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures.
