UB9HL-355VKXVHF AMATEUR RADIO AMPLIFIER

FCC PART 97 AMATEUR RADIO TEST REPORT Applicant TOKYO HY-POWER LABS, INC. Address 1- 1 HATANAKA 3-CHOME NIIZA SAITAMA 352-0012 JAPAN FCC ID UB9HL-355VKX Model Number HL-355VKX Product Description VHF AMATEUR RADIO AMPLIFIER Date Sample Received 4/25/2013 Date Tested 4/29/2013 Tested By Nam Nguyen Approved By Mario de Aranzeta Report Number 698AUT13TestReport.doc Test Results PASS FAIL THE ATTACHED REPORT SHALL NOT BE REPRODUCED EXCEPT IN FULL WITHOUT THE WRITTEN APPROVAL OF TIMCO ENGINEERING, INC. 849 NW State Road 45 Newberry, FL 32669 USA Phone: 888.472.2424 or 352.472.5500 Fax: 352.472.2030 Email: [email protected] Website: www.timcoengr.com Certificate # 0955-01 Certificate # 0955-01 APPLICANT: TOKYO HY-POWER LABS, INC. FCC ID: UB9HL-355VKX REPORT: T\TOKYO_UB9\698AUT13\698AUT13TestReport.doc Page 2 of 16 TABLE OF CONTENT STATEMENT OF COMPLIANCE .............................................................................................. 3 GENERAL INFORMATION ...................................................................................................... 4 EMC EQUIPMENT LIST .......................................................................................................... 6 TEST PROCEDURES: ............................................................................................................. 7 RF POWER OUTPUT .............................................................................................................. 8 IN BAND GAIN ....................................................................................................................... 9 OUT OF BAND GAIN ............................................................................................................ 12 DURING THE BAND FROM 26 TO 28 MHz ........................................................................ 12 DURING THE BAND FROM 20 TO 200 MHz ...................................................................... 13 FIELD STRENGTH OF SPURIOUS EMISSIONS ..................................................................... 14 POWER LINE CONDUCTED INTERFERENCE ....................................................................... 15 FCC EXPOSURE INFORMATION .......................................................................................... 16 Certificate # 0955-01 APPLICANT: TOKYO HY-POWER LABS, INC. FCC ID: UB9HL-355VKX REPORT: T\TOKYO_UB9\698AUT13\698AUT13TestReport.doc Page 3 of 16 STATEMENT OF COMPLIANCE This equipment has been tested in accordance with the standards identified in the referenced test report. To the best of my knowledge and belief, these tests were performed using the measurement procedures described in this report and demonstrate that the equipment complies with the appropriate standards. No modifications were made to the equipment during testing in order to demonstrate compliance with these standards. I attest that the necessary measurements were made by me or under my supervision, at TIMCO ENGINEERING, INC. located at 849 N.W. State Road 45, Newberry, Florida 32669 USA. Authorized by: Nam Nguyen Signature: Function: Testing Tech/Project Manager Date: May 1, 2013 Authorized by: Signature: Mario de Aranzeta C.E.T. Compliance Engineer/ Lab. Supervisor Date: Certificate # 0955-01 APPLICANT: TOKYO HY-POWER LABS, INC. FCC ID: UB9HL-355VKX REPORT: T\TOKYO_UB9\698AUT13\698AUT13TestReport.doc Page 4 of 16 GENERAL INFORMATION DUT Specification The test results relate only to the items tested. DUT Description VHF AMATEUR RADIO AMPLIFIER FCC ID UB9HL-355VKX Model Number HL-355VKX Serial Number N/A Operating Frequency 144 to 148 MHz Type of Emission J3E Modulation FM, SSB DUT Power Source 240 VAC/50– 60Hz; 120 VAC/50-60Hz DC Power (13.8 VDC) Battery Operated Exclusively Test Item Prototype Pre-Production Production Type of Equipment Fixed Mobile Portable Antenna Connector N connector Supporting Peripheral Equipment XPR 4550 Mobile Radio FCC ID: ABZ99FT4080 Model: XPR 4550 Manufacture: Motorola Certificate # 0955-01 APPLICANT: TOKYO HY-POWER LABS, INC. FCC ID: UB9HL-355VKX REPORT: T\TOKYO_UB9\698AUT13\698AUT13TestReport.doc Page 5 of 16 Test Facility: The test sites used by Timco Engineering Inc. for radiated and conducted emission data are located at 849 NW State Road 45 Newberry, FL 32669 USA. Test Condition: The DUT was tested in the laboratory in an environment with normal temperature and humidity. The temperature was 26ºC with a relative humidity of 50%. Modification to the DUT: No modification was made to the DUT during testing. Test Exercise (e.g software description, test signal, etc.): The DUT was placed in continuous transmit mode of operation. Applicable Standards: TIA 603 & ANSI C63.4 – 2003 FCC CFR 47 Part 97 FCC CRF 47 Part 15 Other information: The amplifier is capable of operation in the amateur radio 2 meter band (144-148 MHz). The amplifier is NOT capable of operation on any frequency or frequencies between 26 MHz and 28 MHz as marketed. 1. The amplifier requires 50 Watts of drive to obtain full output power. Reduction in RF input power reduces the output power as shown on Page 8. 2. The gain of the amplifier is under 15 dB and under all conditions. 3. The amplifier in the off or standby state does not amplify and merely passes through the exciter energy to the antenna port. The spurious emissions of the transceiver were unaffected. Certificate # 0955-01 APPLICANT: TOKYO HY-POWER LABS, INC. FCC ID: UB9HL-355VKX REPORT: T\TOKYO_UB9\698AUT13\698AUT13TestReport.doc Page 6 of 16 EMC EQUIPMENT LIST Device Manufacturer Model Serial Number Cal/Char Date Due Date 3-Meter Semi- Anechoic Chamber Panashield N/A N/A 12/31/11 12/31/13 AC Voltmeter HP 400FL 2213A14499 6/12/11 6/12/13 Hygro- Thermometer Extech 445703 0602 6/15/11 6/15/13 Digital Multimeter Fluke FLUKE-77 35053830 9/9/11 9/9/13 DC Power Supply Astron VS-50M 9001191 01/19/13 01/19/15 Power Meter Boonton Electronics 4531 11793 1/9/13 1/9/15 Sensor Boonton 51072A 34647 01/19/13 01/19/15 Signal Generator H…

Text truncated - open the document above for the full version.
