UC3M3152G400RF 2.4G Optical Mouse

Intech Electronics Corp. Hall B3, Guan-Lan Industrial Park, Golf Blvd., Guan-Lan, Shenzhen, China Antenna description M-315 uses PCB antenna ,the PCB antenna with a maximum gain of 0 dBi.

1 Lucy Tsai From:zhou aven [[email protected]] Sent:Thursday, March 20, 2008 6:22 PM To:Lucy Tsai Cc:aven. zhou Subject:Re: FW: Intech Electronics Corp., FCC ID: UC3M3152G400, Assessment NO.: AN08T7725, Notice#1 Attachments:RF Module schematics.pdf; SZ080202B01-RP_0319.pdf; UserManual_revised 01.pdf Dear Lucy, Good day! The attached are the three documents for the RF Module schematics , user mauna and test report. By the way, I would like to know the status of AN08T7716. 2008/3/18, Lucy Tsai <[email protected]>: Hi Aven, Please address following issues. Q#1: Please provide an updated user manual to include 15.19, 15.21 and 15.105 statement and user information. Q#2: The schematic provided doesn't include RF portion. Please provide. Q#3: The fundamental and some harmonics test result in test report are incorrect. Please check if the calculation formula is correct and do the necessary revise. Hi Miro, Again, please help to check if Aven has receive the email and forward to her if necessary, thank you. Best Regards, Lucy The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 30 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender.

Reference No.: Report No.: SZ080202B01-RP FCC ID : UC3M3152G400 Page 1 / 27 FCC TEST REPORT for RF 2.4G Optical Mouse MODEL: M-315 Test Report Number: SZ080202B01-RP Issued for Intech Electronics Corp. Hall B3,Yuan-Hu Industry Park, Golf Blvd., Song-Yuan Village, Guan-Lan, Shenzhen, China Issued by: COMPLIANCE CERTIFICATION SERVICES (SHENZHEN) INC. (aka Compliance Engineering Service (China)) NO. 5, JINAO INDUSTRIAL PARK, NO. 35 JUKENG ROAD, DASHUIKENG VILLAGE, GUANLAN TOWN, BAOAN DISTRICT, SHENZHEN, CHINA TEL: 86-755-28055000 FAX: 86-755-28055221 Issued Date: February 18, 2008 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by TAF, A2LA, NVLAP, NIST or any government agencies. The test results in the report only apply to the tested sample. Reference No.: Report No.: SZ080202B01-RP FCC ID : UC3M3152G400 Page 2 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Revision History Rev. Issue Date Revisions Effect Page Revised By 00 February 18, 2008 Initial Issue ALL Clinton Kao Reference No.: Report No.: SZ080202B01-RP FCC ID : UC3M3152G400 Page 3 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. TABLE OF CONTENTS 1 TEST CERTIFICATION ................................................................................................. 4 2 EUT DESCRIPTION....................................................................................................... 5 3 TEST METHODOLOGY................................................................................................. 6 3.1. DESCRIPTION OF TEST MODES ...................................................................................... 6 4 TEST METHODOLOGY................................................................................................. 7 4.1. EUT EXERCISE ...................................................................................................................7 4.2. FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS ........................................... 7 5 INSTRUMENT CALIBRATION ...................................................................................... 8 6 SETUP OF EQUIPMENT UNDER TEST ....................................................................... 8 6.1. DESCRIPTION OF SUPPORT UNITS................................................................................. 8 6.2. CONFIGURATION OF SYSTEM UNDER TEST ................................................................. 8 7 FACILITIES AND ACCREDITATIONS .......................................................................... 9 7.1. FACILITIES .......................................................................................................................... 9 7.2. ACCREDITATIONS ............................................................................................................. 9 7.3. MEASUREMENT UNCERTAINTY....................................................................................... 9 8 FCC PART 15.249 REQUIREMENTS ......................................................................... 10 8.1. BAND EDGES MEASUREMENT....................................................................................... 10 8.2. POWER LINE CONDUCTED EMISSIONS MEASUREMENT........................................... 16 8.3. SPURIOUS EMISSIONS MEASUREMENT....................................................................... 19 APPENDIX II PHOTOGRAPHS OF THE TEST CONFIGURATION ............................... 27 Reference No.: Report No.: SZ080202B01-RP FCC ID : UC3M3152G400 Page 4 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 1 TEST CERTIFICATION Product: RF 2.4G Optical Mouse Model: M-315 Brand: N/A Tested: February 02-18, 2008 Applicant: Intech Electronics Corp. Hall B3,Yuan-Hu Industry Park, Golf Blvd., Song-Yuan Village, Guan-Lan, Shenzhen, China Manufacturer: Intech Electronics Corp. Hall B3,Yuan-Hu Industry Park, Golf Blvd., Song-Yuan Village, Guan-Lan, Shenzhen, China APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance noted DEVIATION FROM APPLICABLE STANDARD None We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 15.207, 15.209, 15.249. The test results of this report relate only to the tested sample EUT identified in this report. Approved by: Reviewed by: Clinton Kao Manager Compliance Certification Service Inc. Vincent Yao Assistant manager Compliance Certification Service Inc. Reference No.: Report No.: SZ080202B01-RP FCC ID : UC3M3152G400 Page 5 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 2 EUT DESCRIPTION Product RF 2.4G Optical Mouse Trade Name N/A Model Number M-315 Model Discrepancy N/A Serial Number N/A Power Supply TX: DC 3V Powered by the battery Frequency Range 2403 ~ 2478MHz Transmit Power 92.64 dBuV/m (Max.) Modulation Technique GFSK Number of Channels 125 Channel (but number of the useful channel is 12 channels) Antenna Specification PCB antenna with 0 dBi gain (Max) Note: 1. The sample selected for test was engineering sample that approximated to production product and was provided by manufacturer. 2. This submittal(s) (test report) is intended for FCC ID: UC3M3152G400 fili…

Text truncated - open the document above for the full version.

Reference No.: Report No.: SZ080202B01-RP FCC ID : UC3M3152G400 Page 27 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. APPENDIX II PHOTOGRAPHS OF THE TEST CONFIGURATION Radiated Emissions Setup Photos
