UC3R0902GU400USB Receiver

Battery Cover(1) AA Battery (2) USB Receiver (3) System Compatibility PC running Windows XP/XP64/Vista/Mac OS X Installation (1) Open the battery cover at the bottom of the mouse. (2) Insert the battery in the right direction. The battery is 3V( 1*AA size Battery) (3) Turn on the computer and plug in the receiver into the computers USB port. It will automatically detect the product and assign an appropriate driver. (4) When the connection is established, you will see the blinking of the LED light from the bottom of the mouse. 2.4GHz Optical Mouse 1 0 0 0 D P I W i r e l e s s FCC Certifications Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment.

Authorization Letter We, (the approval holder) Company name Intech Electronics Corp. Addresss Hall B3,Yuan-hu Industrial Park,Golf Road,Song-Yuan Village Guan-Lan, City Shenzhen Country China declare that the following representative (agent): Name (person) Bovey.yang Company name NTEK Testing Technology Co., Ltd. Addresss 1/F, Building E, Fenda Science Park Sanwei Community, Xixiang Street, Baoan District City Shenzhen Country China is hereby authorized to apply the following equipment for certification on our behalf: Product Description Dongle Type or Model(s) R09 Tradename or Brand(s) N/A We also authorize BZT - TCP Certification GmbH (Ms.Wanida Patthanveorj) to process this application. Attestation: City and Country: Date: Name: (this must be a person) Function:Signature: (or official company stamp) Shenzhen Guangdong 2011/9/2 Haijun Zhang Manager

FCC Confidentiality Request To the FCC and FCC TCB handling this application for certification Pursuant to 47 CFR Section 0.459(a) & (b), we, (the applicant / grantee) Company name Intech Electronics Corp. Addresss Hall B3,Yuan-hu Industrial Park,Golf Road,Song-Yuan Village Guan-Lan, City Shenzhen Country China request non-disclosure and confidential treatment for our certification under: Grantee Code Product Number FCC ID: UC3 R0902G400 of the following materials submitted within this certification application: (please cross what is applicable, or add other documents) x Operational Description x Block Diagrams x Schematics Diagrams Bill of Materials Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. We understand that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Attestation: City and Country: Date: Name: (this must be a person) Function:Signature: (or official company stamp) Shenzhen Guangdong 2011/9/2 Haijun Zhang Manager

Ersteller: D. Brandhorst Revision: 00 Erstelldatum: 07.03.2008 Datum: 00.00.00 Seite 1 von 1 PHOENIX TEST-LAB GmbH Product Certification Königswinkel 10 D 32825 Blomberg Date: 2011-9-02 FCC ID: UC3R0902G400 Subject: Attestation Letter “Declaration of Conformity” Dear Sirs, Our products with the above FCC ID are defined as composite device. The transmitter is authorized under the “Certification” procedure. The device is also defined as “PC Periphery” acc to §15.101 Equipment authorization of unintentional radiators, where we hereby declare, that we apply and follow the “Declaration of Conformity” procedure. If you have any questions, please feel free to contact me at the address shown below. Yours sincerely, Signatory Name Haijun Zhang Position Manager CompanyAdress Hall B3,Yuan-hu Industrial Park,Golf Road,Song-Yuan Village Guan-Lan, S henzhen, China TEL 86-75 5-27997268 FAX 86-755-27997273

R09(Dongle):

Dongle:

Page 1 of 31 Report No.: NTEK-2011DG0829343F ` FCC RADIO TEST REPORT Report Reference No. ............... : NTEK-2011DG0829343F Compiled by (+ signature) ........... Jim He Approved by (+ signature) ........... Bovey Yang Applicant’s name ........................... : Intech Electronics Corp. Address ...................................... : Hall B3,Yuan-hu Industrial Park,Golf Road,Song-Yuan Village Guan-Lan,ShenzhenCity,GuangDong Province,China,P.R.C. Manufacture's Name ...................... : Intech Electronics Corp. Address ...................................... : Hall B3,Yuan-hu Industrial Park,Golf Road,Song-Yuan Village Guan-Lan,ShenzhenCity,GuangDong Province,China,P.R.C. Test specification: Standard ..................................... : FCC Part15.249 Test procedure ............................... : ANSI C63.4-2003 Test item description Product name ........................ : Dongle FCC ID UC3R0902G400 Trademark ............................ : Model and/or type reference : R09 Rating(s) ................................ : DC 5V from PC Testing Laboratory information: Testing Laboratory Name ..... : NTEK Testing Technology Co., Ltd Address ................................ : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao ＇an District, Shenzhen P.R. China. This device described above has been tested by NTEK Testing Technology Co., Ltd, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK Testing Technology Co., Ltd, this document may be altered or revised by NTEK Testing Technology Co., Ltd, personal only, and shall be noted in the revision of the documen Testing .................................................... : Date of receipt of test item ...................... : 26 Aug. 2011 Date (s) of performance of tests ............. : 26 Aug. 2011 ~02 Sep. 2011 Date of Issue ........................................... : 02 Sep. 2011 Test Result ............................................... : Pass Page 2 of 31 Report No.: NTEK-2011DG0829343F ` Table of Contents Page 1 . SUMMARY OF TEST RESULTS 3 1.1 MEASUREMENT UNCERTAINTY 4 2 . GENERAL INFORMATION 5 2.1 GENERAL DESCRIPTION OF EUT 5 2.2 DESCRIPTION OF TEST MODES 7 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 8 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 9 3 . TEST RESULT 11 3.1 ANTENNA REQUIREMENT 11 3.1.1 STANDARD REQUIREMENT 11 3.1.2 EUT ANTENNA 11 3.2 COND UCTED EMISSION MEASUREMENT 12 3.2.1 POWER LINE CONDUCTED EMISSION LIMITS 12 3.2.2 TEST PROCEDURE 13 3.2.3 DEVIATION FROM TEST STANDARD 13 3.2.4 TEST SETUP 13 3.2.5 TEST RESULT 13 3.3 RADIATED EMISSION MEASUREMENT 14 3.3.1 RADIATED EMISSION LIMITS 14 3.3.2 TEST PROCEDURE 15 3.3.3 DEVIATION FROM TEST STANDARD 15 3.3.4 TEST SETUP 16 3.3.5 TEST RESULTS (BLOW 30MHZ) 18 3.3.6 TEST RESULTS (BETWEEN 30 – 1000 MHZ) 19 3.3.7 TEST RESULTS (ABOVE 1000 MHZ) 21 4 . BANDWIDTH TEST 27 4.1 TEST PROCEDURE 27 4.2 DEVIATION FROM STANDARD 27 4.3 TEST SETUP 27 4.4 TEST RESULTS 28 5 . EUT TEST PHOTO 31 6 . APPENDIX-Photographs of EUT Constructional Details Page 3 of 31 Report No.: NTEK-2011DG0829343F ` 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15, Subpart C (15.249) & RSS-Gen Issue 3 & RSS-210 Issue 8 Standard Section Test Item Judgment Remark 15.207 Conducted Emission N/A Note(1) 15.203 Antenna Requirement Pass 15.249 Radiated Spurious Emission Pass 15.249 Occupied Bandwidth Pass NOTE: (1) ” N/A” denotes test is not applicable in this Test Report. Page 4 of 31 Report No.: NTEK-2011DG0829343F ` 1.1 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 Radiated Emission Test ±3.17dB 3 RF power,conducted ±0.16dB 4 Spurious emissions,conducted ±0.21dB 5 All emissions,radiated(<1G) ±4.68dB 6 All emissions,radiated(>1G) ±4.89dB Page 5 of 31 Report No.: NTEK-2011DG0829343F ` 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Dongle Trade Name N/A Model Name R09 OEM Brand/Model Name N/A Model Difference N/A Product Description The EUT is a Dongle Operation Frequency: 2403~2478 MHz Channel Number 20 Modulation Type: GFSK Antenna Designation: PCB antenna Antenna Gain(Peak) 0 dBi Bit Rate of Transmission 1Mbps RF output Power: -2.19dBm Channel List Please refer to the Note 2. Power Source DC Voltage supplied from PC Power Rating DC 5V from PC Connecting I/O Port(s) Please refer to the User's Manual Products Covered N/A EUT Modification(s) N/A Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. Page 6 of 31 Report No.: NTEK-2011DG0829343F ` 2. Channel List Group Frequency (MHz) Frequency (MHz) Frequency (MHz) Frequency (MHz) Frequency (MHz) 01 2403 2478 2453 2413 2466 02 2404 2474 2444 2424 2464 03 2405 2475 2445 2415 2465 04 2406 2476 2436 2456 2416 3. Table for Filed Antenna Ant . Brand Model Name Antenna Type Connector Gain (dBi) NOTE 1 N/A N/A PCB Antenna NA 0 Antenna Page 7 of 31 Report No.: NTEK-2011DG0829343F ` 2.2 DESCRIPTION OF TEST MODES To investigate the maximum EMI emission characteristics generates from EUT, the test system was pre-scanning tested base on the consideration of following EUT operation mode or test configuration mode which possible have effect on EMI emission level. Each of these EUT operation mode(s) or test configuration mode(s) mentioned above was evaluated respectively. Pretest Mode Description Mode 1 2403MHz Mode 2 2453MHz Mode 3 2478MHz For Conducted Emission Final Test Mode Description - “N/A” denotes test is not applicable in this Test Report For Radiated Emission …
