UCS86295081Cow activity meter system

DeLaval International AB

Click to zoom

Application Details

Equipment Class: DSR - Part 15 Remote Control/Security Device Transceiver
Date of Grant: Feb 18, 2015
Application Purpose: Original Equipment
Date of Application: Feb 18, 2015
Equipment Note: Cow activity meter system
Frequency Range: 417.00000000 - 418.80000000
Company: DeLaval International AB
Country: Sweden

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

DeLaval activity meter system Instruction Book © DeLaval 2014.87224201 2014-02-17, Version 4Original instruction EC Declaration of Conformity - DeLaval activity meter system......................................................5 Safety precautions..............................................................................................................................7 nDeLaval activity meter system nDeLaval activity meter AM2 nDeLaval activity receiver AR2 1 Foreword...........................................................................................................................7 2 Disclaimer.........................................................................................................................7 3 Note to operator................................................................................................................7 4 FCC and IC compliance statement...................................................................................7 4.1 Information to user............................................................................................8 General description.............................................................................................................................9 nDeLaval activity meter system nDeLaval activity meter AM2 nDeLaval activity receiver AR2 1 Introduction.......................................................................................................................9 2 Parts of the DeLaval activity meter system.....................................................................10 3 Functional overview........................................................................................................11 4 Features of the DeLaval activity meter AM2...................................................................11 5 Features of the DeLaval activity receiver AR2................................................................12 6 Co-existence and compatibility with the previous generation activity meter system....... 13 7 Environmental specification............................................................................................14 Installation..........................................................................................................................................15 nDeLaval activity meter system nDeLaval activity meter AM2 nDeLaval activity receiver AR2 1 Mounting the DeLaval activity meter on the neckband with B-transponder ...................15 1.1 Assembling of the neckband without number plates....................................... 17 1.2 Assembling of the neckband with number plates............................................ 22 2 Mounting the DeLaval activity meter on the neckband without B-transponder .............27 2.1 Assembling the neckband without number plates........................................... 28 2.2 Assembling of the neckband with number plates............................................ 33 Start up...............................................................................................................................................36 nDeLaval activity meter system nDeLaval activity meter AM2 nDeLaval activity receiver AR2 1 Farm management system start up................................................................................36 2 DeLaval activity meter AM2 start up...............................................................................36 2.1 Manual activation............................................................................................37 2.2 Automatic activation........................................................................................38 3 Matching activity meter ID number to cow number.........................................................38 4 Confirmation of AM2 start up..........................................................................................39 5 Operation........................................................................................................................39 DeLaval activity meter system Table of contents © DeLaval 2014. 2014-02-17, Version 43 (44)87224201 Troubleshooting................................................................................................................................40 nDeLaval activity meter system nDeLaval activity meter AM2 nDeLaval activity receiver AR2 1 General...........................................................................................................................40 2 DeLaval activity receiver AR2 LED indicators.................................................................41 DeLaval activity meter system Table of contents © DeLaval 2014. 2014-02-17, Version 44 (44)87224201 EC Declaration of Conformity Name of product:DeLaval activity meter system Type:DeLaval activity receiver AR2 DeLaval activity meter AM2 Report No.80009746 The product complies with requirements of the following directives: Radio and Telecommunication Terminal Equipment Directive - 1999/5/EC Harmonised standards which have been used: EN 301 489-3 V1.4.1: 2002 EN 300 220-2 V2.4.1: 2012 Other technical standards and specifications used: Tumba 2013-08-30Signed: Name:Jan Ove Nilsson Position:Vice president Department:BA Capital Goods Contact:Wiveca Sveen P.O. Box 39 SE 147 21 TUMBA Sweden Name and address of manufacturer: DeLaval International AB P.O. Box 39 SE 147 21 TUMBA Sweden © DeLaval 2014. 2014-02-17, Version 45 (44)87224201 © DeLaval 2014. 2014-02-17, Version 46 (44)87224201 Safety precautions DeLaval activity meter system DeLaval activity meter AM2 DeLaval activity receiver AR2 1 Foreword Read carefully before using the product! For best possible performance, continuous sat- isfactory safe operation, read and understand these instructions thoroughly before operating your equipment. 2 Disclaimer The information, instructions and parts listed are applicable and current on the date when issued. DeLaval reserves the right to make changes wi…

Text truncated - open the document above for the full version.

Cover Letter(s)

RF MCU 3V LITHIUM BATTERY INTEGRATED PCB ANTENNA CRYSTAL 30 MHZ DeLaval activity meter AM2 block diagram FILTER 131/134 KHZ DETECTOR ACCELEROMETER RF TRANSCEIVER MCU INT OSC CRYSTAL 32 KHZ I2C DELAVAL INTERNATIONAL AB MS MEP AK 2014-08-18 1.1 1.7 1.8 1.5 1.6 1.4 1.3 1.2 1.2

Test Report

DELTA Development Technology AB Finnslätten Elektronikgatan 47 721 36 Västerås Sweden Tel. 021-31 44 80 Fax 021-31 44 81 [email protected] www.delta-dt.se Bankgiro 5534-7728 VAT SE 556556207001 DELTA Development Technology AB is a subsidiary company of DELTA DELTA Test Report TEST Reg. no. 19 TEST REPORT issued by an Accredited Testing Laboratory Th e r e p or t m us t n o t b e r e pr od uc e d, ex c e pt i n f ul l , wi t h o ut t h e wr i tt e n a p pr ov al o f DE L TA . Thi s r e p or t i s i s s u e d u nd er t h e r ul es of DA N A K ( D ani s h A c c r edi ta ti o n) an d I LA C ( In t er n a ti o n al L ab or at or y A c c r e di t ati o n Co o p er ati on ) i nc l u di ng i ts M RA ( M ut u al Re c o g ni ti on A r r a n gem e nt) . F ur t h er i nf or m ati o n c a n b e fo u n d a t ww w .d a n ak . dk a n d w ww .i l ac . or g. Th e r e p or t m us t n o t b e r e pr od uc e d, ex c e pt i n f ul l , wi t h o ut t h e wr i tt e n a p pr ov al o f DE L TA . EMC_RepGen MAIN TEMPLATEV.93/2013-05-31 Thi s r e p or t i s i s s u e d u nd er t h e r ul es of S W E DA C ( S w e di s h A c c r e di t ati o n) a n d I LA C ( In t er n a ti o n al L ab or at or y A c c r e di t ati o n Co o p er ati on ) i nc l u di ng i ts M RA ( M ut u al Re c o g ni ti on A r r a n gem e nt) . F ur t h er i nf or m ati o n c a n b e fo u n d a t ww w .s w e d ac .s e a n d w ww .i l ac .or g. Th e r e p or t m us t n o t b e r e pr od uc e d, ex c e pt i n f ul l , wi t h o ut t h e wr i tt e n a p pr ov al o f DE L TA . Emission test to FCC requirements of DeLaval Activity meter AM2 Performed for DeLaval International AB REC-E703572_3 Rev. C Projec t no.: E703572 Page 1 of 34 including 1 annex. 06 February 2015 REC-E703572 _3 Rev. C DELTA-E703572 Page 2 of 34 LAJ Title Emission test to FCC requirements of DeLaval Activity meter AM2 Test object DeLaval Activity meter AM2 Report no. REC-E703572_3 Rev C FCC-/IC ID. FCC ID UCS86295081 / IC 6576A-86295081 Test period 04 June 2013 to 28 June 2013 and 19 June 2014 Client DeLaval International AB Gustav De Lavals väg 15 147 41 Tumba Sweden Contact person Anders kvist E-mail: [email protected] Manufacturer DeLaval International AB Specifications FCC:47 CFR Part 15, subpart C IC RSS-GEN, issue 4, IC RSS-210, issue 8 Results The test object was found to be in compliance with the specifications, as listed in Section 1 Test personnel Lars Johnsson Test site(s) Date 06 February 2015 Project Manager Lars Johnsson DELTA Responsible Ulf Bjerke. Technical manager DELTA REC-E703572 _3 Rev. C DELTA-E703572 Page 3 of 34 LAJ Table of contents Page 1. Summary of tests 4 2. Test object(s) and auxiliary equipment 5 2.1 Test object(s) 6 2.2 Auxiliary equipment 8 3. General test conditions 14 3.1 Test setup during test 14 3.2 Description and intended use of test object 14 3.2.1 Operation mode 14 3.2.2 Test modes during emission tests 15 3.3 Modifications of the test object 16 3.4 Test sequence 16 4. Test results 17 4.1 Measurement of radiated spurious emission. 17 4.2 Measurement of peak output field strength of fundamental 22 4.3 Measurement of occupied bandwidth 27 4.4 Periodic operation 29 5. National registrations and accreditations 30 5.1 SWEDAC Accreditation 30 5.2 FCC Registrations 30 5.3 IC Registrations 30 6. List of instruments 31 7. Revision 32 Annex 1 Device list from DeLaval International AB. 33 REC-E703572 _3 Rev. C DELTA-E703572 Page 4 of 34 LAJ 1. Summary of tests Tests Test methods Results Measurement of radio frequency voltage on mains ANSI C63.4:2009 FCC CFR 47, Part 15, Subpart C clause 15.207 IC RSS Gen, Issue 4, section 7.2.4 Passed Measurement of radio frequency electromagnetic field ANSI C63.4:2009 FCC CFR 47, Part 15, Subpart C clause 15.209 IC RSS Gen, Issue 4, section 7.2.5 Passed Measurement of occupied bandwidth FCC CFR 47, Part 15, Subpart C clause 15.231c IC RSS 210, Issue 8, A1.1 Passed Measurement of peak output field strength of fundamental FCC CFR 47, Part 15, Subpart C clause 15.231b IC RSS 210, Issue 8, A1.3 Passed Periodic operation FCC CFR 47, Part 15, Subpart C clause 15.231a IC RSS 210, Issue 8, A1.1.1 Passed Conclusion The test object(s) mentioned in this report meet(s) the requirements of the standard(s) stated below. FCC:47 CFR Part 15, subpart C IC RSS-GEN, issue 4 IC RSS-210, issue 8 The test results relate only to the object(s) tested. REC-E703572 _3 Rev. C DELTA-E703572 Page 5 of 34 LAJ 2. Test object(s) and auxiliary equipment Photo 2.1.1 Test object; activity meter (AM). Photo 2.1.2 Test objects 2.1.4 activity meters REC-E703572 _3 Rev. C DELTA-E703572 Page 6 of 34 LAJ 2.1 Test object(s) Test object details can be seen in Annex 1. The system consists of an Activity meter (AM2) that is placed around the neck of the cow. The activity meter contains a sensor which detects the cow’s movements. The movements are registered and transmitted to the Activity receiver (AR2) every hour. The system helps to detect cows in heat by the fact that cows are more active than usual during the pre-heat and heat period. Common information FCC ID AM2 UCS86295081 IC AM2 6576A-86295081 Manufacturer DeLaval International AB Supply voltage 2.2-3.3VDC (internal battery on activity meter) Hardware version See Annex 1 Test object 2.1.1 Name of test object AM2 (3 pieces) Model / type 418MHz Part no. 86295081 Serial no. 0x70707A 0x70707B 0x70707C Ch2 417.99 MHz Ch0 417.33 MHz Ch1 417.66 MHz Comment Used during measurement of Radiated spurious emission. Received Date: 2013-06-04 Status: Prototype REC-E703572 _3 Rev. C DELTA-E703572 Page 7 of 34 LAJ Test object 2.1.2 Name of test object AM2 Model / type 418MHz Part no. 86295081 Serial no. 2347 For reference, TX level 3, 417.99 MHz 2472 For reference, TX level 4, 417.66 MHz 2032 Test object, TX level 5, 417.33 MHz Comment Used during measurement of peak output field strength Received Date: 2014-06-19 Status: Prototype REC-E703572 _3 Rev. C DELTA-E703572 Page 8 of 34 LAJ Radio parameters. Operating freq…

Text truncated - open the document above for the full version.

Test Setup Photos
