Technical Specifications
| # | Rule Parts | Frequency Range | Power Output | Emission | Tolerance |
|---|
| 2 | 24E | 1.85 GHz - 1.91 GHz | 180.00 mW | 4M17F9W | 21
Hz |
Modular TypeSingle Modular ApprovalConfidentialityLong Term Grant NotesSingle Modular Approval. Power out is conducted at the antenna terminal. ERP for
part 22 is 21.18 dBm and EIRP for part 24 is 21.57 dBm. This device is to be used
only for mobile and fixed application. The antenna(s) used for this transmitter must
be installed to provide a separation distance of at least 20 cm from all persons. End-
Users must be provided with transmitter operation conditions for satisfying RF
exposure compliance. OEM integrators must ensure that the end user has no
manual instructions to remove or install the SIM5320ALD module. For mobile and fixed
operating configurations the antenna gain, including cable loss, must not exceed 1
dBi at 1900 MHz and 1 dBi at 850 MHz as defined in 2.1091 for satisfying RF
exposure compliance. Under no condition may an antenna gain be used that would
exceed the 7W erp Part 22 and the 2W eirp Part 24 power limits. The Grantee is
responsible for providing the documentation required for modular use. This device
contains GSM/WCDMA functions that are not operational in U.S. Territories. This
filing is only applicable for 850 MHz Cell and 1900 MHz PCS operations.
This module can only be used with a host antenna circuit trace layout design in strict compliance with the OEM instructions provided.
