UFW-ALADDINSK2Ground penetrating radar

Tot pag. N°. = 32 - PRO/010/M1 Rev 3 - INGEGNERIA DEI SISTEMI S.p.A. Rev. 1.2 Protocol: MN/2005/038 “ALADDIN SK2” STRUCTURE KIT USER MANUAL Pisa, 28/06/2006 “ALADDIN SK2 ” STRUCTURE KIT User Manual IDS Ingegneria Dei Sistemi S.p.A. Protocol: MN/2005/038 - Rev. 1.2 “ALADDIN SK2 ” STRUCTURE KIT User Manual 2 / 32 Document Evolution Revision Date Reason of change Rev. 1.0 19/12/2005 First Edition Rev. 1.1 28/06/2006 Upgrade of the survey kit Rev. 1.2 25/07/2006 FCC information included Versions covered by this document K2 01.01.000, 01.02.000, 01.02.002. GRED 3D 01.00.000, 01.00.001, 01.00.002, 01.03.016 Disclaimer IDS will not be held responsible for the consequences of an improper use of the equipment IDS will not be responsible for the consequences caused by the improper use of the software. Contacts IDS Ingegneria dei Sistemi S.p.A. – GeoRadar Division Via Sterpulino, 20 56121 Ospedaletto (PISA) - ITALIA Tel: +39.050.967111 Fax: +39.050.967121 [email protected] Customer Care Department: [email protected] Tel.: +39.050.967122 Sales & Marketing: [email protected] Tel.: +39.050.967123/24 IDS Ingegneria Dei Sistemi S.p.A. Protocol: MN/2005/038 - Rev. 1.2 “ALADDIN SK2 ” STRUCTURE KIT User Manual 3 / 32 IMPORTANT NOTE FOR THE US CUSTOMERS In the US this unit operates under FCC rules Part 15. According to these rules, the system includes a manually operated switch (“dead-man switch”) that causes the transmitter to cease operation within 10 seconds of being released by the operator. The use of this switch is further explained in this manual; specific instructions for operating a system sold in the US are identified by the following label This equipment complies with part 15 of the FCC rules. Any changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment. IDS Ingegneria Dei Sistemi S.p.A. Protocol: MN/2005/038 - Rev. 1.2 “ALADDIN SK2 ” STRUCTURE KIT User Manual 4 / 32 INDEX 1. INTRODUCTION.......................................................................................................6 1.1 Purpose.................................................................................................................6 1.2 Field of application...............................................................................................6 1.3 Reference ..............................................................................................................6 1.3.1 Referenced Documents............................................................................6 1.4 Acronyms and Definitions.....................................................................................6 1.4.1 Acronyms.................................................................................................6 1.4.2 Definitions................................................................................................6 1.5 How to use this manual.........................................................................................7 2. SYSTEM COMPONENTS.........................................................................................8 3. HOW TO SET UP THE SYSTEM.............................................................................9 3.1 Opening the case...................................................................................................9 3.2 Connecting up the system ...................................................................................13 3.2.1 How to assemble the frame to the antenna ............................................13 3.2.2 How to assemble the metric wheel to the frame....................................14 3.2.3 Assembly of the slide on the frame........................................................14 3.2.4 How to assemble the fork and the handle on the frame.........................15 3.3 Cable connection of the system...........................................................................15 3.3.1 Complete list of cables...........................................................................15 3.4 Technical advice.................................................................................................20 4. HOW TO USE THE SYSTEM.................................................................................21 4.1 Main functions ....................................................................................................21 4.2 Work procedure using the Aladdin system .........................................................25 4.2.1 "Automatic" mode..................................................................................25 4.2.2 “Manual” Mode......................................................................................29 4.2.3 “Manual (no check)” Mode....................................................................30 PICTURES INDEX FIG. 2-1 – “ALADDIN SK2” STRUCTURES KIT..................................................................8 FIG. 3-1 – OPENING THE CASE...........................................................................................9 FIG. 3-2 – REMOVING THE BATTERY..............................................................................9 FIG. 3-3 – REMOVING THE DAD AND THE ANTENNA TROLLEY.................................10 IDS Ingegneria Dei Sistemi S.p.A. Protocol: MN/2005/038 - Rev. 1.2 “ALADDIN SK2 ” STRUCTURE KIT User Manual 5 / 32 FIG. 3-4 – REMOVING THE BIPOLAR ANTENNA............................................................10 FIG. 3-5 – BOTTOM SECTION...........................................................................................11 FIG. 3-6 – UPPER SECTION..............................................................................................11 FIG. 3-7 – INSERTING THE SUPPORT LEGS.....................................................................12 FIG. 3-8 – FIXING THE WORKTABLE...............................................................................12 FIG. 3-9 – FINAL SET-UP OF THE WOR…

Text truncated - open the document above for the full version.

INGEGNERIA DEI SISTEMI S.p.A. PISA Headquarters Via Livornese, 1019 - 56010 PISA (Italy) Tel. +39.050.3124.1 - Fax +39.050.3124.201 e-mail: [email protected] www.ids-spa.it PISA Headquarters Via Livornese, 1019 56010 PISA (Italy) Tel. +39.050.3124.1 Fax +39.050.3124.201 e-mail: [email protected] PISA Branch Office Via Sterpulino, 20 56121 PISA (Italy) Tel. +39.050.9671.11 Fax +39.050.9671.21 e-mail: [email protected] ROMA Branch Office Via Flaminia, 330 00196 ROMA (Italy) Tel. +39.06.326483.1 Fax +39.06.36002447 e-mail: [email protected] VARESE Branch Office Via Vittorio Veneto, 12 21040 MORAZZONE (Italy) Tel. +39.0332.462502 Fax +39.0332.460549 e-mail: [email protected] Capitale Sociale 520.000 Euro i.v. – C.C.I.A.A. Pisa, R.E.A. n° 77042 - C.F. 00672210507 – P. IVA (VAT) IT 00672210507 2006-07-26 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: UFW-ALADDINSK2 Product Name: ALADDIN SK2 Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: Schematics AD SECTION.PDF ANTENNA CONNECTOR BOARD.PDF AUDIO SECTION.PDF CONNECTION BOX.PDF CONNECTOR SECTION.PDF CONNECTORS.PDF MICROCONTROLLER & PLD SECTION.PDF MICROCONTROLLER SECTION.PDF MULTIPLEXER SECTION.PDF POWER SUPPLY BOARD.PDF POWERSUPPLY SECTION.PDF REMOTE_CONTROL SECTION.PDF RX BOARD.PDF TEST_POINT.PDF TIMING SECTION.PDF TRIGGER_AMPLIFIER.PDF TX BOARD.PDF Technical TECHNICAL DESCRIPTION OF THE UNIT.PDF ALADDIN INTERNAL PICTURES.PDF These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 26 Day of July 20 06 By: Guido Manacorda Signature Printed Title: Engineering Manager On behalf of : IDS Ingegneria dei Sistemi SpA Telephone: +39 050 967125

EXTERNAL PICTURES

1.5” 3” FCC ID: UFW-ALADDINSK2 This device complies with Part 15 of the Rules. Operation is subject to the two conditions: (1) this device may not harmful interference, and (2) this device accept any interference received, interference that may cause undesired operation.

Nemko Test Report: 6L0165RUS1rev2 Applicant: IDS Ingegneria dei Sistemi SpA via Stuperlino 20 Pisa Italy Equipment Under Test: Aladdin SK2 (E.U.T.) In Accordance With: FCC Part 15, Subpart F, 15.509 UltraWideband Operation Ground Penetrating Radar Tested By: Nemko USA Inc. 802 N. Kealy Lewisville, Texas 75057-3136 Authorized By: Kevin Rose Wireless Engineer Date: July 31, 2006 Total number of pages:31 Nemko USA, Inc. FCC PART 15, SUBPART F TRANSMITTERS TEST REPORT NO 6L0165RUS1REV2.: EQUIPMENT: Aladdin SK2 Page 2 of 31 Table Of Contents Section 1. Summary Of Test Results ............................................................................3 Section 2. General Equipment Specification ...............................................................5 Section 3. Pulse Repition Frequency ............................................................................7 Section 4. Radiated Emissions ......................................................................................9 Section 6. Highest Radiated Emission (f M ) ..................................................................25 Section 7.Test Equipment List ......................................................................................28 ANNEX A TEST DIAGRAMS ....................................................................................29 Nemko USA, Inc. FCC PART 15, SUBPART F TRANSMITTERS TEST REPORT NO 6L0165RUS1REV2.: EQUIPMENT: Aladdin SK2 Page 3 of 31 Section 1. Summary Of Test Results Manufacturer: IDS Ingegneria dei Sistemi SpA Model No.: Aladdin SK2 Serial No.: 10 General: All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with FCC Part 15.509. All tests were conducted using measurement procedure ANSI C63.4-2003. Radiated Emissions were made on an open area test site. with a 4 foot by 4foot by 4foot dry sand pit New Submission Production Unit Class II Permissive Change Pre-Production Unit This test report relates only to the item(s) tested. The following deviations from, additions to, or exclusions from the test specifications have been made. See “ Summary of Test Data”. Nemko USA Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko USA Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. Nemko USA, Inc. FCC PART 15, SUBPART F TRANSMITTERS TEST REPORT NO 6L0165RUS1REV2.: EQUIPMENT: Aladdin SK2 Page 4 of 31 Summary Of Test Data NAME OF TEST PARA. NO. RESULT Conducted Emissions 15.207 NA Pulse Repetition Frequency 15.509 Complies Definition of UWB 15.203(a)/15.209(a) Complies Radiated Emissions 15.509(d) Complies Radiated Emissions 15.509(e) Complies Peak Emission at f M 15.509(f) Complies The digital circuit portion of the EUT has been tested and verified to comply with FCC Part 15, Subpart B, Footnotes For N/A’s: EUT is a 12Vdc power device Test Conditions: The tests were performed with the EUT transmitting while on a pit filled with dry sand approximately 1 meter by 1 meter by 50 cm deep. Nemko USA, Inc. FCC PART 15, SUBPART F TRANSMITTERS TEST REPORT NO 6L0165RUS1REV2.: EQUIPMENT: Aladdin SK2 Page 5 of 31 Section 2. General Equipment Specification Frequency Range: Single Operating Frequency(ies) of Sample: 2151 to 2538 MHz (10 dB BW) Tunable Bands: Single 10 dB Occupied Bandwidth: 2.7 GHz User Frequency Adjustment: None Integral Antenna Yes No Nemko USA, Inc. FCC PART 15, SUBPART F TRANSMITTERS TEST REPORT NO 6L0165RUS1REV2.: EQUIPMENT: Aladdin SK2 Page 6 of 31 Description of Device Tested Ground Penetrating Radar Bipolar Antenna System System Diagram Refer to separate exhibit. Nemko USA, Inc. FCC PART 15, SUBPART F TRANSMITTERS TEST REPORT NO 6L0165RUS1REV2.: EQUIPMENT: Aladdin SK2 Page 7 of 31 Section 3. Pulse Repetition Frequency NAME OF TEST: Pulse Repetition Frequency PARA. NO.: 15.509 TESTED BY: David Light DATE:15 June 2006 Test Results: Complies. See attached graph(s). Measurement Data: See attached graph(s). Method of Measurement: (Procedure ANSI C63.4-2003) General: All measurements are traceable to national standards. These tests were conducted using measurement procedures of ANSI C63.4-2003. Nemko USA, Inc. FCC PART 15, SUBPART F TRANSMITTERS TEST REPORT NO 6L0165RUS1REV2.: EQUIPMENT: Aladdin SK2 Page 8 of 31 Nemko USA, Inc. FCC PART 15, SUBPART F TRANSMITTERS TEST REPORT NO 6L0165RUS1REV2.: EQUIPMENT: Aladdin SK2 Page 9 of 31 Section 4. Radiated Emissions NAME OF TEST: Radiated Emissions PARA. NO.: 15.509(d)&(e) TESTED BY: David Light DATE: 16 June 2006 Minimum Standard: Para no. 15.509 Limits below 960 MHz (15.209 and 15.509): Frequency (MHz) Field Strength Limits (microvolts/m) Measuring RBW Distance (Meters) 0.009-0.490 0.490-1.705 1.705-30.0 30-88 88-216 216-960 2400/F(kHz) 24000/F(kHz) 30 100 150 200 1 kHz 10 kHz 10 kHz 100 kHz 100 kHz 100 kHz 300 30 30 3 3 3 Limits above 960 MHz (15.509) Frequency (MHz) E.I.R.P. (dBm) Measuring RBW Distance (Meters) 960-1610 1610-1990 1990-3100 3100-10600 Above 10600 1164-1240 159-1610 -65.3 -53.3 -51.3 -41.3 -51.3 -75.3 -75.3 1 MHz 1 MHz 1 MHz 1 MHz 1 MHz 1 kHz 1 kHz 3 3 3 3 3 3 3 E.I.R.P limits converted to field strength during measurements per 15.521(g) Maximizing Emission Levels: The emissions were scanned from 30 MHz to 15000 MHz. For measurements below 960 MHz the emissions were made using a PEAK detector RBW=VBW=100 kHz For Frequency above 960 MHz and outside the below frequency bands, the emissions were measured using RMS detector, RBW=1MHz, VBW=3MHz For frequencies fall inside 1164-1240 and 1559-1610 MHz, the emissions were measured using EMI RMS Detect…

Text truncated - open the document above for the full version.
