UFW-HI-MODGround Penetrating Radar

T ot pag. N°. = 41 - P RO/010/M1 Rev 4 - INGEGNERIA DEI SISTEMI S.p.A. Rev. 1.0 Protocol: MN/2009/056 “RIS Hi-Mod System Installation Guide and User Manual Pisa, August 2009 RIS Hi-Mod - Installation Guide and User Manual IDS Ingegneria Dei Sist emi S.p.A. P rot ocol: MN/2009/056 - Rev. 1.0 RIS Hi-Mod - Installation Guide and User Manual 2 / 41 Document Evolution Revision Date Reason for change Rev. 1.0 August 2009 First edition OUR CONTACTS IDS Ingegneria dei Sistemi S .p.A. – GeoRadar Division Via Sterp ulino, 20 56121 Osp edaletto (PISA) - ITALIA Tel: +39.050.967111 Fax: +39.050.967121 inforis@ids-sp a.it Customer Care department: customercare. gp r@ids-sp a.it Tel.: +39.050.967122 S ales & Marketing department: sales.gp r@ids-sp a.it Tel.: +39.050.967123/24/43 IDS Ingegneria Dei Sist emi S.p.A. P rot ocol: MN/2009/056 - Rev. 1.0 RIS Hi-Mod - Installation Guide and User Manual 3 / 41 DISCLAIMER IDS WILL NOT BE HELD RESPONSIBLE FOR THE CONSEQUENCES OF AN IMPROPER USE OF THE EQUIPM ENT AND/OR THE SOFTWARE. THIS SOFTWARE MAY INCLUDE AUTOMATED DATA PROCESSING AND ANALYSIS TOOLS. WHILE EVER Y EFFORT IS M ADE TO ENSURE THE ACCURACY OF THE INFORMATION PROVIDED BY THOSE TOOLS, THEY M UST NOT BE INTENDED AS A SUBSTITUTE FOR INTELLIGENT ANALYSIS; RATHER, THEY HAVE TO BE INTENDED AS AN ADVISOR AND THE USER MUST NOT COM PLETELY RELY ON THE RESULTS PROVIDED BY THEM TO GIVE THE COM PLETE ANSWER. IDS INGEGNERIA DEI SISTEM I SPA ASSUM ES NO LIABILITY FOR ANY DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES OR INJURIES CAUSED BY SUCH RELIANCE ON THE ACCURACY, RELIABILITY, OR TIM ELESS OF THE INFORM ATION PROVIDED BY THOSE TOOLS. ANY PERSON OR ENTITY WHO RELIES ON INFORM ATION OBTAINED FROM THE AUTOMATED DATA PROCESSING/ANALYSI S TOOLS ONLY, DOES SO AT HIS OR HER OWN RISK IDS Ingegneria Dei Sist emi S.p.A. P rot ocol: MN/2009/056 - Rev. 1.0 RIS Hi-Mod - Installation Guide and User Manual 4 / 41 SAFETY INFORMATION The equipment conforms to the following requirements set by EC regulat ions, including subsequent modifications, and to the legis lat ion set by the member states that implement these regulations: 1999/05/EEC Radio Directive Warning: this equipment is destined for use in industrial environments (Class A apparatus). In residential, commercial and light industry environments, this apparatus may generate radio interference: in this case, the user may be required to operate while taking appropriate countermeasures. The apparatus is sensitive to the presence of external electromagnetic fields, which may reduce its performance. IDS Ingegneria Dei Sist emi S.p.A. P rot ocol: MN/2009/056 - Rev. 1.0 RIS Hi-Mod - Installation Guide and User Manual 5 / 41 IMPORTANT NO TE FOR THE US CUS TO MERS FCC ID: UFW-Hi-Mo d T his device complies with part 15 of the FCC Rules: Operation is subject to the following conditions: 1. T his device may not cause harmful interference, and 2. T his device must accept any interferen ce received, Including interferen ce that may cause undesired operation Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Operation o f this device is restri cted to law en forcem ent, fire and res cue o ffi cials, scientifi c res earch institutes, commercial mining companies, and construction companies. Operation by any other party is a violation of 47 U.S.C. § 301 and could subject the operator to serious legal penalties. Coordination Requirements. (a) UWB imaging systems require coordination through the FCC befo re th e equipment may b e used. T he operator shall comply with any constraints on equipment usage resulting from this coordination. (b) T he users of UWB imaging devices shall supply detailed operational areas to the FCC Office o f Engineering and T echnology who sh all coordin ate this in fo rmation with the Federal Gov ernment through the National T elecommunications and In form ation Administration. T he inform ation provided by the UWB operator sh all include the name, address and other p ertinent contact info rmation o f the user, the desired geographical area o f op eration, and the FCC ID number and other nomen clature o f th e UWB device. T his material shall be submitted to the following address: Frequency Coordination Branch., OET Federal Communications Commission 445 12th Street, SW Washington, D.C. 20554 ATTN: UWB Coordination (d) Users o f authorized, coordinated UWB systems may transfer them to other qualified users and to different locations upon coordination o f ch ange o f ownership or lo cation to the FCC and coordination with existing authorized operations. (e) T he NT IA/FCC coordination report shall include any needed constraints that apply to day-to-d ay operations. Such constraints could specify prohibited areas o f operations or areas located near authorized radio stations for whi ch additional coordin ation is required befo re op eration o f the UWB equipment. If additional local coordination is required, a local coordination contact will be provided. (f) T he coordination of routine UWB operations shall not take longer than 15 business days from the receipt of the coordination requ est by NT IA. Special temporary operations may be handled with an exp edited turn- around time when circumstances warrant. T he operation o f UWB systems in emergency situations involving the safety o f li fe or p roperty m ay occur without coordination p rovided a noti fication p rocedu re, similar to that contained in CFR47 Section 2.405(a)-(e), is followed by the UWB equipment user. Notice: Use of this device as a wall imaging system is prohibited by FCC regulations. IDS Ingegneria Dei Sist emi S.p.A. P rot ocol: MN/2009/056 - Rev. 1.0 RIS Hi-Mod - Installation Guide and User Manual 6 / 41 ! WARNING CLEANING INFORMATION Before cleaning any external parts of the apparatus, make sure that all cables have been disconnected, including the power supply ca…

Text truncated - open the document above for the full version.

RIS Hi-Mod EXTERNAL PICTURES RIS Hi-Mod 1 antenna configuration RIS Hi-Mod 2 antennas configuration RIS Hi-Mod 3 antennas configuration RIS Hi-Mod 4 antennas configuration (full configuration)

Digital Antenna Driver (D.A.D.) Unit: external picture Fig. 1: DAD external picture

1.5” 3” FCC ID: UFW-Hi-Mod This device complies with Part 15 of the Rules. Operation is subject to the two conditions: (1) this device may not harmful interference, and (2) this device accept any interference received, interference that may cause undesired operation.

TT&T Laboratory Test Report No. ARSJ00105 Date 2009-09-30 page 2 of 39 T ELECOMMUNICATIONS & T ELEMATICS FOR T RANSPORTS L ABORATORY CONTENTS 1 Introduction .........................................................................................1-3 1.1 Scope .................................................................................................1-3 1.2 Test specifications, methods & procedures.........................................1-3 2 General Description of Equipment under Test..................................2-4 2.1 Applicant .............................................................................................2-4 2.2 Manufacturer.......................................................................................2-4 2.3 Equipment classification .....................................................................2-4 2.4 Basic description of equipment under test ..........................................2-5 2.5 Feature of equipment under test .........................................................2-5 2.6 Models and Variants ...........................................................................2-6 3 Test Configuration of Equipment under Test ....................................3-7 3.1 EUT Operating test conditions ............................................................3-7 3.2 EUT Configurations ............................................................................3-7 3.3 Description of support equipment .......................................................3-7 4 General Test Set-Up ............................................................................4-8 4.1 Environmental conditions ....................................................................4-8 4.2 Description..........................................................................................4-8 4.3 Drawings.............................................................................................4-9 5 Summary Of Test Results ................................................................. 5-10 6 Measurements and Tests Data ......................................................... 6-11 7 Technical Documentation ................................................................. 7-34 8 Photographic Documentation........................................................... 8-35 8.1 EUT Identification ............................................................................. 8-35 8.2 Test set-up........................................................................................ 8-36 9 Measurement Uncertainty................................................................. 9-38 9.1 Radiated Emission Measurement Uncertainty from 30 to 1000 MHz 9-38 9.2 Radiated Emission Measurement Uncertainty above 1000 MHz ....... 9-38 10 List Of Measuring Equipment And Calibration Information ......... 10-39 TT&T Laboratory Test Report No. ARSJ00105 Date 2009-09-30 page 3 of 39 T ELECOMMUNICATIONS & T ELEMATICS FOR T RANSPORTS L ABORATORY 1 INTRODUCTION 1.1 Scope Obtain FCC Certification Authorization with the requirement of Title 47 of the Code of Federal Regulations Part 15 subpart F. 1.2 Test specifications, methods & procedures Publication Year Title 47 CFR Part 15 2008 Radio Frequency Device ANSI C63.4 2004 Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz FCC Order, ET Docket No. 98- 153 (FCC 02-48) 2002 Revision of Part 15 of the Commission’s Rules Regarding Ultra-Wideband Transmission Systems KDB Publication No. 393764 2007 UWB Compliance Measurements TT&T Laboratory Test Report No. ARSJ00105 Date 2009-09-30 page 4 of 39 T ELECOMMUNICATIONS & T ELEMATICS FOR T RANSPORTS L ABORATORY 2 GENERAL DESCRIPTION OF EQUIPMENT UNDER TEST 2.1 Applicant NAME IDS INGEGNERIA DEI SISTEMI S.p.A. ADDRESS Via Livornese, 1019 – I-56122 PISA COUNTRY ITALY 2.2 Manufacturer NAME IDS INGEGNERIA DEI SISTEMI S.p.A. ADDRESS Via Sterpulino, 20 – I-56121 PISA COUNTRY ITALY 2.3 Equipment classification According to the definition 15.503 EUT is a Ground penetrating radar (GPR) system so it shall fulfil provisions of 47 CFR Part 15 Subpart F – Ultra Wideband Operation– and Section 15.509. TT&T Laboratory Test Report No. ARSJ00105 Date 2009-09-30 page 5 of 39 T ELECOMMUNICATIONS & T ELEMATICS FOR T RANSPORTS L ABORATORY 2.4 Basic description of equipment under test Parameters Value Type of equipment Ground penetrating radar (GPR) system Model RIS Hi-Mod FCC ID UFW-Hi-Mod Trade Name IDS INGEGNERIA DEI SISTEMI S.p.A. General Overview The RIS Hi-Mod system is a Ground penetrating radar (GPR) system, i.e., according to the FCC definition, A field disturbance sensor that is designed to operate only when in contact with, or within one meter of, the ground for the purpose of detecting or obtaining the images of buried objects or determining the physical properties within the ground. The energy from the GPR is intentionally directed down into the ground for this purpose. The RIS Hi-Mod product includes: • Up to 4 antennas (each one including two transmitting and two receiving dipoles) • The control unit (hereinafter referred as D.A.D – Digital Antenna Driver) that is linked to a laptop computer for storing the collected data 2.5 Feature of equipment under test Parameters Value Power supply type DC 12 V battery supplied Operating frequency 81,5 to 613,5 MHz (10 dB Bandwidth) Channel Spacing Not applicable Pulse Repetition Frequency (PRF) 200 KHz Antenna description Integral permanently attached Antenna Type Dipole TT&T Laboratory Test Report No. ARSJ00105 Date 2009-09-30 page 6 of 39 T ELECOMMUNICATIONS & T ELEMATICS FOR T RANSPORTS L ABORATORY 2.6 Models and Variants Model RIS Hi-Mod Description The RIS Hi-Mod product includes: Up to 4 antennas (each one including two transmitting and two receiving dipoles) and The control unit (hereinafter referred as D.A.D – Digital Antenna Driver) that is linked to a laptop computer for storing the col…

Text truncated - open the document above for the full version.

Test set-up below 960 MHz Test set-up above 960 MHz
