UFW-HR2000NAGround Penetrating Radar

IDS Ingegneria Dei Sistemi S.p.A. N doc:MN/2011/004 - Rev. 1.1 Hi-Pave – User Manual Config.: Hi-Pave-PRCS-OUT-MN 1 / 19 Tutte le informazioni sono di proprietà IDS. Tutti i diritti riservati. All information contained in this document is property of IDS. All rights reserved - PRO/010/M1 Rev 4 - INGEGNERIA DEI SISTEMI S.p.A. Rev. 1.1 N°doc:MN/2011/004 Config.: Hi-Pave-PRCS-OUT-MN Hi-Pave System Assembly User Manual Hi-Pave – User Manual Pisa, December 2011 IDS Ingegneria Dei Sistemi S.p.A. N doc:MN/2011/004 - Rev. 1.1 2 / 19 Tutte le informazioni sono di proprietà IDS. Tutti i diritti riservati. All information contained in this document is property of IDS. All rights reserved KEYWORDS: HI-PAVE, ENCODER, ANTENNA, FRAME SUMMARY: This manual explains the procedure of assembling the Hi-Pave GPR system in all its parts. Document Evolution Revision Date Reason of change Rev. 1.0 18/02/2011 First Edition Rev. 1.1 2/12/2011 FCC/IC Information added Versions covered by this document Contacts IDS Ingegneria dei Sistemi S.p.A. – GeoRadar Division Via Enrica Calabresi, 20 56121 Montacchiello (PISA) - ITALIA Tel: +39.050.3124350 Fax: +39.050.3124205 [email protected] Customer Care department: [email protected] Tel.: +39.050.3124 355/356 Sales & Marketing department: [email protected] Tel.: +39.050.3124352 IDS Ingegneria Dei Sistemi S.p.A. N doc:MN/2011/004 - Rev. 1.1 3 / 19 Tutte le informazioni sono di proprietà IDS. Tutti i diritti riservati. All information contained in this document is property of IDS. All rights reserved Disclaimer IDS WILL NOT BE HELD RESPONSIBLE FOR THE CONSEQUENCES OF AN IMPROPER USE OF THE EQUIPMENT AND/OR THE SOFTWARE. THIS SOFTWARE MAY INCLUDE AUTOMATED DATA PROCESSING AND ANALYSIS TOOLS. WHILE EVERY EFFORT IS MADE TO ENSURE THE ACCURACY OF THE INFORMATION PROVIDED BY THOSE TOOLS, THEY MUST NOT BE INTENDED AS A SUBSTITUTE FOR INTELLIGENT ANALYSIS; RATHER, THEY HAVE TO BE INTENDED AS AN ADVISOR AND THE USER MUST NOT COMPLETELY RELY ON THE RESULTS PROVIDED BY THEM TO GIVE THE COMPLETE ANSWER. IDS INGEGNERIA DEI SISTEMI SPA ASSUMES NO LIABILITY FOR ANY DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES OR INJURIES CAUSED BY SUCH RELIANCE ON THE ACCURACY, RELIABILITY, OR TIMELESS OF THE INFORMATION PROVIDED BY THOSE TOOLS. ANY PERSON OR ENTITY WHO RELIES ON INFORMATION OBTAINED FROM THE AUTOMATED DATA PROCESSING/ANALYSIS TOOLS ONLY, DOES SO AT HIS OR HER OWN RISK IDS Ingegneria Dei Sistemi S.p.A. N doc:MN/2011/004 - Rev. 1.1 4 / 19 Tutte le informazioni sono di proprietà IDS. Tutti i diritti riservati. All information contained in this document is property of IDS. All rights reserved SAFETY INFORMATION The equipment conforms to the following requirements set by EC regulations, including subsequent modifications, and to the legislation set by the member states that implement these regulations: 1999/05/EEC Radio Directive Warning: this equipment is destined for use in industrial environments (Class A apparatus). In residential, commercial and light industry environments, this apparatus may generate radio interference: in this case, the user may be required to operate while taking appropriate countermeasures. The apparatus is sensitive to the presence of external electromagnetic fields, which may reduce its performance. IDS Ingegneria Dei Sistemi S.p.A. N doc:MN/2011/004 - Rev. 1.1 5 / 19 Tutte le informazioni sono di proprietà IDS. Tutti i diritti riservati. All information contained in this document is property of IDS. All rights reserved IMPORTANT NOTE FOR THE US CUSTOMERS FCC ID: UFW-HR2000NA This device complies with part 15 of the FCC Rules: Operation is subject to the following conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, Including interference that may cause undesired operation Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Operation of this device is restricted to law enforcement, fire and rescue officials, scientific research institutes, commercial mining companies, and construction companies. Operation by any other party is a violation of 47 U.S.C. § 301 and could subject the operator to serious legal penalties. Coordination Requirements. (a) UWB imaging systems require coordination through the FCC before the equipment may be used. The operator shall comply with any constraints on equipment usage resulting from this coordination. (b) The users of UWB imaging devices shall supply detailed operational areas to the FCC Office of Engineering and Technology who shall coordinate this information with the Federal Government through the National Telecommunications and Information Administration. The information provided by the UWB operator shall include the name, address and other pertinent contact information of the user, the desired geographical area of operation, and the FCC ID number and other nomenclature of the UWB device. This material shall be submitted to the following address: Frequency Coordination Branch., OET Federal Communications Commission 445 12th Street, SW Washington, D.C. 20554 ATTN: UWB Coordination (d) Users of authorized, coordinated UWB systems may transfer them to other qualified users and to different locations upon coordination of change of ownership or location to the FCC and coordination with existing authorized operations. (e) The NTIA/FCC coordination report shall include any needed constraints that apply to day-to-day operations. Such constraints could specify prohibited areas of operations or areas located near authorized radio stations for which additional coordination is required before operation of the UWB equipment. If additional local coordination is required, a local coordination contact will be provided. (f) The coordination of routine UWB operations shall not take longer than 15 business days from the receipt of the …

Text truncated - open the document above for the full version.

INGEGNERIA DEI SISTEMI S.p.A. PISA Headquarters Via E. Calabresi, 24 – Loc. Montacchiello 56121 Pisa (Italy) Tel. +39.050.3124.1 - Fax +39.050.3124.201 e-mail: [email protected] www.idscompany.it PISA Headquarters Via E. Calabresi ,24 – Loc. Montacchiello 56121 PISA (Italy) Tel. +39.050.3124.1 Fax +39.050.3124.201 e-mail: [email protected] ROMA Branch Office Via Flaminia, 1068 00189 ROMA (Italy) Tel. +39.06.33217.11 Fax +39.06.33217.402 e-mail: [email protected] Capitale Sociale 7.500.000 Euro i.v. – C.C.I.A.A. Pisa, R.E.A. n° 77042 - C.F. 00672210507 – P. IVA (VAT) IT 00672210507 Share Capital 7.500.000 euro fully paid – registered at the Pisa Chamber of Commerce, R.E.A. n. 77042 – Tax number and VAT code (IT) 00672210507 e-mail (PEC): [email protected] 2012, February the 9th Mrs. Evelyn Cherry Office of Engineering and Technology Federal Communications Commission 445 12th Street SW Washington DC 20554 Re: Certification Application FCC ID UFW-HR2000NA Dear Mrs.Cherry: The above-referenced application, filed by IDS Ingegneria dei Sistemi SpA, Inc., seeks certification for a ground-penetrating radar (GPR) device. The application shows compliance with the Commission's Rules and does not require waivers. When submitting the application, we have requested that certain photographs showing the interior of the devices be withheld from public disclosure. The Commission has previously granted confidentiality under similar conditions to several applications concerning these GPR devices: e.g. FCC ID QF750400 EA640311 FCC ID QF762000 EA291754 FCC ID QF75103A EA870041 FCC ID QLA250MHZ EA586775 FCC ID QLAMID EA364767 FCC ID QLA500MHZ EA369105 FCC ID QLA800MHZ EA813498 FACTUAL BASIS FOR CONFIDENTIALITY REQUEST In the original request for Confidentiality, we have pointed out that these photographs showing the interior of the device contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Particularly, the antenna pictured in the document “HR2000NA internal pictures.pdf” is a sealed and potted unit that cannot be opened after manufacturing without destroying the contents. INGEGNERIA DEI SISTEMI S.p.A. The unit will not be made available for sale to the general public. Marketing will be limited to law enforcement, fire fighting, emergency rescue, scientific research, commercial mining, and construction pursuant to CFR 47, Part 15, Subpart F, 15.509 In the message sent on 20012, February the 8 th (Correspondence Reference Number: 41167), You are objecting that internal photos of a consumer device may be held confidential when the circuit board is enclosed in epoxy or in a material that would destroy the circuit board if removed or if the device is sealed and disassembly would destroy the product (Ref. FCC Publication No.726920 D02 Confidentiality Procedures dated 12/21/2011). On this respect, we are submitting, as a separate exhibit, a revised version of the file “HR2000NA internal pictures.pdf”, including the pictures of the potted circuit boards and the material used for potting those boards (polyurethane resin). Respectfully submitted Guido Manacorda Georadar Division Engineering Manager IDS Ingegneria Dei Sistemi S.p.A Pisa Headquarters: Via Enrica Calabresi, 24 - 56121 Pisa - Italy - Pisa Phone: +39 050 31 24 (1) ext. 363 Fax: +39 050 31 24 205

Digital Antenna Driver (D.A.D.) Unit: external picture Fig. 1: DAD external picture

EXTERNAL PICTURES

1.5” 3” FCC ID: UFW-HR2000NA ED9GEMINIB This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

IMQ S.p.A. con socio unico Via Quintiliano, 43 20138 MILANO - I LAB N° 0121 Signatory of EA, IAF and ILAC Mutual Recognition Agreements Test Report No. ARSL00296/2 Date: 2011-12-21 Page 2 of 44 Mod. TRF 1792ACC /0 T TT T ELECOMMUNICATIONS ELECOMMUNICATIONS ELECOMMUNICATIONS ELECOMMUNICATIONS & && & T TT T EL ELEL EL EMATICS FOR EMATICS FOR EMATICS FOR EMATICS FOR T TT T RANSPORTS RANSPORTSRANSPORTS RANSPORTS L LL L ABORATORY ABORATORYABORATORY ABORATORY 1. GENERAL DATA SAMPLE Samples received on 2011-11-29 (item sent and sampling by applicant) IMQ reference samples BEM 61894 Samples tested No. 1 Object under analysis recognition Not carried out Except where stated, characteristics of products were taken from client description and were not verified by the laboratory TEST LOCATION Testing dates 2011-11-29 ÷ 2011-11-30 Testing laboratory. IMQ S.p.A. - Via Quintiliano, 43 – I-20138 Milano Testing site Viale Lombardia, 20 – I-20021 Bollate (MI) ENVIRONMENTAL CONDITIONING Parameter Measured Ambient Temperature 0 ÷ 10 °C Relative Humidity 60 ÷ 75 % Atmospheric Pressure 900 ÷ 1000 mbar IMQ S.p.A. con socio unico Via Quintiliano, 43 20138 MILANO - I LAB N° 0121 Signatory of EA, IAF and ILAC Mutual Recognition Agreements Test Report No. ARSL00296/2 Date: 2011-12-21 Page 3 of 44 Mod. TRF 1792ACC /0 T TT T ELECOMMUNICATIONS ELECOMMUNICATIONS ELECOMMUNICATIONS ELECOMMUNICATIONS & && & T TT T EL ELEL EL EMATICS FOR EMATICS FOR EMATICS FOR EMATICS FOR T TT T RANSPORTS RANSPORTSRANSPORTS RANSPORTS L LL L ABORATORY ABORATORYABORATORY ABORATORY 2. REFERENCE DOCUMENT DOCUMENT DATE TITLE 47 CFR Part 15 2008 Radio Frequency Device ANSI C63.4 2009 Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz ANSI C63.10 (*) 2009 American National Standard for Testing Unlicensed Wireless Devices FCC Order, ET Docket No. 98-153 (FCC 02-48) (*) 2002 Revision of Part 15 of the Commission’s Rules Regarding Ultra-Wideband Transmission Systems KDB Publication No. 393764 (*) 2007 UWB Compliance Measurements (*) not accredited by ACCREDIA IMQ S.p.A. con socio unico Via Quintiliano, 43 20138 MILANO - I LAB N° 0121 Signatory of EA, IAF and ILAC Mutual Recognition Agreements Test Report No. ARSL00296/2 Date: 2011-12-21 Page 4 of 44 Mod. TRF 1792ACC /0 T TT T ELECOMMUNICATIONS ELECOMMUNICATIONS ELECOMMUNICATIONS ELECOMMUNICATIONS & && & T TT T EL ELEL EL EMATICS FOR EMATICS FOR EMATICS FOR EMATICS FOR T TT T RANSPORTS RANSPORTSRANSPORTS RANSPORTS L LL L ABORATORY ABORATORYABORATORY ABORATORY 3. UNIT UNDER TEST (EUT) DETAILS GENERAL DATA Model HR2000NA FCC ID UFW-HR2000NA Manufacturer IDS INGEGNERIA DEI SISTEMI S.p.A. Via E. Calabresi, 20 – I-56121 PISA EUT classification Ground penetrating radar (GPR) General overwiew The HR2000NA system is a Ground penetrating radar (GPR) system, i.e., according to the FCC definition, a field disturbance sensor that is designed to operate within one meter from the ground for the purpose of measuring pavement thickness, detecting or obtaining the images of buried objects or determining the physical properties within the ground. The energy from the GPR is intentionally directed down into the ground for this purpose. The HR2000NA product includes • The HR2000NA antenna (including one couple of transmitting and receiving dipoles) • The control unit (hereinafter referred as D.A.D – Digital Antenna Driver) that is linked to a laptop computer for storing the collected data . Power supply type DC 12 V battery supplied Operating frequency 963,12 ÷ 2853 MHz (10 dB Bandwidth) Channel Spacing Not applicable Pulse Repetition Frequency (PRF) 400 KHz Antenna description Integral permanently attached Antenna Type Dipole IMQ S.p.A. con socio unico Via Quintiliano, 43 20138 MILANO - I LAB N° 0121 Signatory of EA, IAF and ILAC Mutual Recognition Agreements Test Report No. ARSL00296/2 Date: 2011-12-21 Page 5 of 44 Mod. TRF 1792ACC /0 T TT T ELECOMMUNICATIONS ELECOMMUNICATIONS ELECOMMUNICATIONS ELECOMMUNICATIONS & && & T TT T EL ELEL EL EMATICS FOR EMATICS FOR EMATICS FOR EMATICS FOR T TT T RANSPORTS RANSPORTSRANSPORTS RANSPORTS L LL L ABORATORY ABORATORYABORATORY ABORATORY 4. TEST CONFGURATION OF UNIT UNDER TEST EUT CONFIGURATION The Equipment under test was powered with a battery and placed directly on the dry sand with no ground plane under it. STATE OF THE EUT DURING TESTS Ref. Mode Description #1 Operating Continuous transmission with the antenna fitted in a manner typical of normal indented use. SUPPORT EQUIPMENT Defined as equipment needed for correct operation or loading of the EUT, but not considered as tested: Equipment Manufacturer Model None / / EUT TECHNICAL DOCUMENTATION Document Reference DAD & antenna block diagrams / User Manual Protocol: MN/2011/0004 rev. 1.1 Technical description of the system Technical description of the unit - HR2000NA IMQ S.p.A. con socio unico Via Quintiliano, 43 20138 MILANO - I LAB N° 0121 Signatory of EA, IAF and ILAC Mutual Recognition Agreements Test Report No. ARSL00296/2 Date: 2011-12-21 Page 6 of 44 Mod. TRF 1792ACC /0 T TT T ELECOMMUNICATIONS ELECOMMUNICATIONS ELECOMMUNICATIONS ELECOMMUNICATIONS & && & T TT T EL ELEL EL EMATICS FOR EMATICS FOR EMATICS FOR EMATICS FOR T TT T RANSPORTS RANSPORTSRANSPORTS RANSPORTS L LL L ABORATORY ABORATORYABORATORY ABORATORY 5. TEST SET-UP DESCRIPTION Type of test facilities Open Area Test Site (OATS) The test site is flat and the level area is clear of overhead wires and reflecting structures, it is sufficiently large to permit measuring antenna placement at specified distance. Adequate spacing distance is assured between the EUT and measuring antenna to any adjacent large reflecting structures. Test distance • 3 meters measuring distance. • 1 meter above 960 MHz for measurement to device not placed on the ground plane with the antenna pointed in the direction of the radiating head. Ground plane Galvanized sheet steel soldered panels is installed on the fl…

Text truncated - open the document above for the full version.
