UFW-SRS-FW400Ground Penetrating Radar

INGEGNERIA DEI SISTEMI S.p.A. Rev. 1.2 Protocol: MN/2009/030 Safe Rail System User Guide Signature Date Compiled by Valt er Baroncini Controlled by St efania Bracciali Approved by Laura Della Maggiore Authorised by Guido Manacorda August 2009 IDS Ingegneria Dei Sist emi S.p.A. P rot ocol: MN/2009/030 - Rev. 1.2 Safe Rail System Data Acquisition Software 2 / 76 Document Evolution Revision Date Reason for modifica tion Rev. 1.0 M arch 2009 First edition Rev. 1.1 July 2009 Add of M echanical kit Rev 1.2 August 2009 FCC information added SW Versions covered by this document 01.03.001, 01.06.001, 01.07.006, 01.07.007. OUR CONTACTS IDS Ingegneria dei Sistemi S .p.A. – GeoRadar Division Via Sterp ulino, 20 56121 Osp edaletto (PISA) - ITALIA Tel: +39.050.967111 Fax: +39.050.967121 inforis@ids-sp a.it Customer Care department: customercare. gp r@ids-sp a.it Tel.: +39.050.967122 S ales & Marketing department: sales.gp r@ids-sp a.it Tel.: +39.050.967123/24/43 IDS Ingegneria Dei Sist emi S.p.A. P rot ocol: MN/2009/030 - Rev. 1.2 Safe Rail System Data Acquisition Software 3 / 76 DISCLAIMER IDS WILL NOT BE HELD RESPONSIBLE FOR THE CONSEQUENCES OF AN IMPROPER USE OF THE EQUIPM ENT AND/OR THE SOFTWARE. THIS SOFTWARE MAY INCLUDE AUTOMATED DATA PROCESSING AND ANALYSIS TOOLS. WHILE EVER Y EFFORT IS M ADE TO ENSURE THE ACCURACY OF THE INFORMATION PROVIDED BY THOSE TOOLS, THEY M UST NOT BE INTENDED AS A SUBSTITUTE FOR INTELLIGENT ANALYSIS; RATHER, THEY HAVE TO BE INTENDED AS AN ADVISOR AND THE USER MUST NOT COM PLETELY RELY ON THE RESULTS PROVIDED BY THEM TO GIVE THE COM PLETE ANSWER. IDS INGEGNERIA DEI SISTEM I SPA ASSUM ES NO LIABILITY FOR ANY DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES OR INJURIES CAUSED BY SUCH RELIANCE ON THE ACCURACY, RELIABILITY, OR TIM ELESS OF THE INFORM ATION PROVIDED BY THOSE TOOLS. ANY PERSON OR ENTITY WHO RELIES ON INFORM ATION OBTAINED FROM THE AUTOMATED DATA PROCESSING/ANALYSI S TOOLS ONLY, DOES SO AT HIS OR HER OWN RISK IDS Ingegneria Dei Sist emi S.p.A. P rot ocol: MN/2009/030 - Rev. 1.2 Safe Rail System Data Acquisition Software 4 / 76 SAFETY INFORMATION The equipment conforms to the following requirements set by EC regulat ions, including subsequent modifications, and to the legis lation set by the member states that implement these regulations: 1999/05/EEC Radio Directive Warning: this equipment is destined for use in industrial environments (Class A apparatus). In residential, commercial and light industry environments, this apparatus may generate radio interference: in this case, the user may be required to operate while taking appropriate countermeasures. The apparatus is sensitive to the presence of external electromagnetic fields, which may reduce its performance. IDS Ingegneria Dei Sist emi S.p.A. P rot ocol: MN/2009/030 - Rev. 1.2 Safe Rail System Data Acquisition Software 5 / 76 IMPORTANT NO TE FOR THE US CUS TO MERS FCC ID: UFW-S RS -FW400 This device complies with part 15 of the FCC Rules: Operation is subject to the following conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, Including interference that may cause undesired operation Warning: Changes or modifications to this unit not expressly appro ved by the pa rty responsible for compliance could void the user’s authority to operate the equipment. Operation of this device is restricted to law enforcement, fire and rescue officials, scientific research institutes, commercial mining companies, and construction companies. Operation by any other party is a violation of 47 U.S.C. § 301 and could subject the operator to serious legal penalties. Coordination Requirements (a) UWB imaging systems require coordination through the FCC before the equipment may be used. The operator shall comply with any constraints on equipment usage resulting from this coordination. (b) The users of UWB imaging devices shall supply detailed operational areas to the FCC Office of Engineering and Technology who shall coordinate this information with the Federal Government through the National Telecommunications and Information Administration. The information provided by the UWB operator shall include the name, address and other pertinent contact information of the user, the desired geographical area of operation, and the FCC ID number and other nomenclature of the UWB device. This material shall be submitted to the following address: Frequency Coordination Branch., OET Federal Communications Commission 445 12th Street, SW Washington, D.C. 20554 ATTN: UWB Coordination (d) Users of authorized, coordinated UWB systems may transfer them to other qualified users and to different locations upon coordination of change of ownership or location to the FCC and coordination with existing authorized operations. (e) The NTIA/FCC coordination report shall include any needed constraints that apply to day-to-day operations. Such constraints could specify prohibited areas of operations or areas located near authorized radio stations for which additional coordination is required before operation of the UWB equipment. If additional local coordination is required, a local coordination contact will be provided. (f) The coordination of routine UWB operations shall not take longer than 15 business days from the receipt of the coordination request by NTIA. Special temporary operations may be handled with an expedited turn-around time when circumstances warrant. The operation of UWB systems in emergency situations involving the safety of life or property may occur without coordination provided a notification procedure, similar to that contained in CFR47 Section 2.405(a)- (e), is followed by the UWB equipment user. Notice: Use of this device as a wall imaging system is prohibited by FCC regulations. In this manual, instructions that specifically apply to the version of the system dedicated to the US market, are identified by the following label IDS Ingegneria Dei Sist emi S.p.…

Text truncated - open the document above for the full version.

INGEGNERIA DEI SISTEMI S.p.A. PISA Branch Office Via Sterpulino, 20 - 56121 PISA (Italy) Tel. +39.050.9671.11 - Fax +39.050.9671.21 e-mail: [email protected] www.idscompany.it PISA Headquarters Via Livornese, 1019 56122 PISA (Italy) Tel. +39.050.3124.1 Fax +39.050.3124.201 e-mail: [email protected] PISA Branch Office Via Sterpulino, 20 56121 PISA (Italy) Tel. +39.050.9671.11 Fax +39.050.9671.21 e-mail: [email protected] ROMA Branch Office Via Flaminia, 1068 00189 ROMA (Italy) Tel. +39.06.332173.11 Fax +39.06.33217.402 e-mail: [email protected] VARESE Branch Office Via Vittorio Veneto, 12 21040 MORAZZONE (Italy) Tel. +39.0332.462502 Fax +39.0332.460549 e-mail: [email protected] Capitale Sociale 5.000.000 Euro i.v. – C.C.I.A.A. Pisa, R.E.A. n° 77042 - C.F. 00672210507 – P. IVA (VAT) IT 00672210507 2009-08-10 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: UFW-SRS-FW400 Product Name: SRS-FW400 Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: Schematics (AS02635_rev01) Antenna multiplexer board.pdf Power supply high voltage monitor.pdf (AS02665_A) Antenna connector board.pdf Power supply high voltage section -70 VDC.pdf (AS02851_A) Transmitter for HF dipole.PDF Power supply high voltage section +150 VDC.pdf (AS02853_A) Receiver for HF or LF dipole.PDF Power supply low voltage section.pdf timing circuit control section - CPLD.pdf timing circuit control section - CPU section.pdf DAD functional scheme.pdf timing circuit front end.pdf ADC analog to digital conversion circuit.pdf timing circuit Static RAM.pdf DAD service interface.pdf timing circuit.pdf PC interface LAN - WLAN.pdf trigger amplifier board.pdf Technical TECHNICAL DESCRIPTION OF THE UNIT-SRS-FW400.pdf SRS-FW400 antenna internal pictures.pdf DAD internal pictures.pdf These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 10 Day of August 20 09 By: Guido Manacorda Signature Printed Title: Engineering Manager On behalf of : IDS Ingegneria dei Sistemi SpA Telephone: +39 050 967125

Digital Antenna Driver (D.A.D.) Unit: external picture Fig. 1: DAD external picture

SRS-FW400 EXTERNAL PICTURES SRS-FW400 antenna (top view) SRS-FW400 antenna (front view) SRS-FW400 antenna (side view)

1.5” 3” FCC ID: UFW-SRS-FW400 This device complies with Part 15 of the Rules. Operation is subject to the two conditions: (1) this device may not harmful interference, and (2) this device accept any interference received, interference that may cause undesired operation.

Digital Antenna D river (D.A.D.) Unit: internal pictures Fig. 1: DAD internal pictures showing the main board and connector panels WLAN Radio M odule FCC ID: R68M TCHDRCT Trigger amp lifier board M ain Board Front Connector Panel (lap top side) Rear Connector p anel (antenna side) Fig. 2: Front connector panel Fig. 3: Rear connector panel Fig. 4: D.A.D. main board (component side) Fig. 5: D.A.D. main board (bottom side)

SRS-FW400: internal pictures Fig. 1: Internal view of the antenna once the top cover has been unscrewed and lifted Fig. 2: Antenna connector board (top side) Fig. 3: Antenna connector board (back side) Fig. 4: Internal view of the antenna once the top cover has been removed: top side Fig. 5: Antenna multiplexer board (top side) Fig. 6: Antenna multiplexer board (back side) Fig. 7: SRS-FW400 antenna (bottom view) Fig. 8: SRS-FW400 antenna (side view) Transmitting dipole Receiving dipole Fig. 9: SRS-FW400 antenna internal view with transmitting and receiving dipoles removed Fig. 10: on the left receiver (dipole and RX electronics with shield), on the right transmitter (dipole and TX electronics with shield) Fig. 11: Receiver board (front side) Fig. 12: Receiver board (back side) Fig. 13: Transmitter board (front side) Fig. 14: Transmitter board (back side)

NOTICE: The results of tests and checks reported in this Test Report refer exclusively to the samples tested and described in the Report itself. This report shall not be reproduced partially or in its entirety without the written approval of IMQ S.p.A. IMQ S.p.A. - Via Quintiliano, 43 – I-20138 MILANO Telecommunications & Telematics for Transports Lab. TEST REPORT Ref. No. ARSJ00120 Date: 2009-09-30 Measurements performed in accordance with: FCC Rules : Code of Federal Regulations (CFR) no. 47 PART 15 – RADIO FREQUENCY DEVICES PRODUCT : Ground penetrating radar TESTED MODEL : SRS-FW400 FCC ID : UFW-SRS-FW400 APPLICANT : IDS INGEGNERIA DEI SISTEMI S.p.A. Via Livornese, 1019 – I-56122 PISA MANUFACTURER : IDS INGEGNERIA DEI SISTEMI S.p.A. Via Sterpulino, 20 – I-56121 PISA TRADEMARK : IDS INGEGNERIA DEI SISTEMI S.p.A OTHER INFORMATION Testing dates : 2009-08-26 ÷ 2009-08-28 B.E.M. No. (IMQ ref.) : 50614 Tested samples No. : 1 Testing Laboratory : IMQ S.p.A. Via Quintiliano, 43 I-20138 MILANO Testing site : Viale Lombardia, 20 – I-20021 Bollate Tested by : R. Torri Signature: Date : 2009-09-30 Checked by: R. Colombo (EMC and R&TTE Lab. Deputy) Signature: Date : 2009-09-30 Revision Sheet Release No. Date Revision Description Rev. 0 2009-09-30 First edition T ELECOMMUNICATIONS & T ELEMATICS FOR T RANSPORTS L ABORATORY TT&T Laboratory Test Report No. ARSJ00120 Date 2009-09-30 page 2 of 39 T ELECOMMUNICATIONS & T ELEMATICS FOR T RANSPORTS L ABORATORY CONTENTS 1 Introduction .........................................................................................1-3 1.1 Scope .................................................................................................1-3 1.2 Test specifications, methods & procedures.........................................1-3 2 General Description of Equipment under Test..................................2-4 2.1 Applicant .............................................................................................2-4 2.2 Manufacturer.......................................................................................2-4 2.3 Equipment classification .....................................................................2-4 2.4 Basic description of equipment under test ..........................................2-5 2.5 Feature of equipment under test .........................................................2-5 2.6 Models and Variants ...........................................................................2-6 3 Test Configuration of Equipment under Test ....................................3-7 3.1 EUT Operating test conditions ............................................................3-7 3.2 EUT Configurations ............................................................................3-7 3.3 Description of support equipment .......................................................3-7 4 General Test Set-Up ............................................................................4-8 4.1 Environmental conditions ....................................................................4-8 4.2 Description..........................................................................................4-8 4.3 Drawings.............................................................................................4-9 5 Summary Of Test Results ................................................................. 5-10 6 Measurements and Tests Data ......................................................... 6-11 7 Technical Documentation ................................................................. 7-34 8 Photographic Documentation........................................................... 8-35 8.1 EUT Identification ............................................................................. 8-35 8.2 Test set-up........................................................................................ 8-36 9 Measurement Uncertainty................................................................. 9-38 9.1 Radiated Emission Measurement Uncertainty from 30 to 1000 MHz 9-38 9.2 Radiated Emission Measurement Uncertainty above 1000 MHz ....... 9-38 10 List Of Measuring Equipment And Calibration Information ......... 10-39 TT&T Laboratory Test Report No. ARSJ00120 Date 2009-09-30 page 3 of 39 T ELECOMMUNICATIONS & T ELEMATICS FOR T RANSPORTS L ABORATORY 1 INTRODUCTION 1.1 Scope Obtain FCC Certification Authorization with the requirement of Title 47 of the Code of Federal Regulations Part 15 subpart F. 1.2 Test specifications, methods & procedures Publication Year Title 47 CFR Part 15 2008 Radio Frequency Device ANSI C63.4 2004 Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz FCC Order, ET Docket No. 98- 153 (FCC 02-48) 2002 Revision of Part 15 of the Commission’s Rules Regarding Ultra-Wideband Transmission Systems KDB Publication No. 393764 2007 UWB Compliance Measurements TT&T Laboratory Test Report No. ARSJ00120 Date 2009-09-30 page 4 of 39 T ELECOMMUNICATIONS & T ELEMATICS FOR T RANSPORTS L ABORATORY 2 GENERAL DESCRIPTION OF EQUIPMENT UNDER TEST 2.1 Applicant NAME IDS INGEGNERIA DEI SISTEMI S.p.A. ADDRESS Via Livornese, 1019 – I-56122 PISA COUNTRY ITALY 2.2 Manufacturer NAME IDS INGEGNERIA DEI SISTEMI S.p.A. ADDRESS Via Sterpulino, 20 – I-56121 PISA COUNTRY ITALY 2.3 Equipment classification According to the definition 15.503 EUT is a Ground penetrating radar (GPR) system so it shall fulfil provisions of 47 CFR Part 15 Subpart F – Ultra Wideband Operation– and Section 15.509. TT&T Laboratory Test Report No. ARSJ00120 Date 2009-09-30 page 5 of 39 T ELECOMMUNICATIONS & T ELEMATICS FOR T RANSPORTS L ABORATORY 2.4 Basic description of equipment under test Parameters Value Type of equipment Ground penetrating radar (GPR) system Model SRS-FW400 FCC ID UFW-SRS-FW400 Trade Name IDS INGEGNERIA DEI SISTEMI S.p.A. General Overview The SRS-FW400 system is a Ground penetrating radar (GPR) system, i.e., according to the FCC…

Text truncated - open the document above for the full version.

Test set-up below 960 MHz Test set-up above 960 MHz
