UI6-ZRFVitalilty Wireless RF Module (ZRF)

Vigil Vitality Wireless Module - Manual Vitality Wireless Module (ZRF) Manual Vigil Health Solutions Inc. dedicated to improving seniors' quality of life through creative technology. Page 1 of 3 Revised: 2013-04-25 Vigil Health Solutions Inc. 2102 - 4464 Markham Street * Victoria, BC * Canada * V8Z 7X8. Phone: (250) 383.6900 * (877) 850.1122 Fax: (250) 383.6999 Web: www.vigil.com © Vigil Health Solutions Inc. Description The Vigil Vitality Wireless Module (ZRF) is used to receive handle wireless communication and I/O control on Vigil Vitality Wireless devices. The Vitality Wireless Module operates on the 2.4GHz IEEE 802.15.4 wireless platform. Host board provides power and external I/O to Vitality wireless module. Instructions 1. ZRF solders directly on host board. Please check land pattern of ZRF. 2. Ensure power supply does not exceed 3.6V. Figure 1. ZRF Pinout Vigil Vitality Wireless Module - Manual Vitality Wireless Module (ZRF) Manual Vigil Health Solutions Inc. dedicated to improving seniors' quality of life through creative technology. Page 2 of 3 Revised: 2013-04-25 Vigil Health Solutions Inc. 2102 - 4464 Markham Street * Victoria, BC * Canada * V8Z 7X8. Phone: (250) 383.6900 * (877) 850.1122 Fax: (250) 383.6999 Web: www.vigil.com © Vigil Health Solutions Inc. Specifications PHYSICAL ELECTRICAL Height 46mm (1.81") Operating Voltage 2-3.6V DC Width 32mm (1.25") Input Voltage 3.3V Depth 5.5mm (0.21") Standing Current 8mA, 28.5mA burst Enclosure Material N/A Shield thickness 0.016 inch thick Mounting Method Soldering Shield material Brass, nickel plated Temperature Ratings Operating: 0°C to 50°C (32°F to 122°F) Storage/ Transport: -55°C to 85°C (-67°F to 185°F) FCC/IC Statements FCC ID UI6-ZRX  This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.  Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.  To Comply with FCC/IC RF exposure limits for general population/uncontrolled exposure, the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. IC: 6706A-ZRX  This Device complies with Industry Canada License-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.  Cet appareil est conforme avec les norme(s) exemption de licences RSS d’Industrie Canada. Opération est sujet au deux conditions suivantes. (1) Cet appareil ne peut causer d'interférences, et (2) cet appareil doit accepter toute interférence, y compris les interférences qui peuvent causer un mauvais fonctionnement de l'appareil. OEM Responsibilities to comply with FCC and Industry Canada Regulations The ZRF Module has been certified for integration into products only by OEM integrators under the following conditions: 1. The antenna(s) must be installed such that a minimum separation distance of 20cm is maintained between the radiator (antenna) and all persons at all times. 2. The transmitter module must not be co-located or operating in conjunction with any other antenna or transmitter. As long as the two conditions above are met, further transmitter testing will not be required. However, the OEM integrator is still responsible for testing their end-product for any additional compliance requirements required with this module installed (for example, digital device emissions, PC peripheral requirements, etc.). IMPORTANT NOTE: In the event that these conditions cannot be met (for certain configurations or co-location with another transmitter), then the FCC and Industry Canada authorizations are no longer considered valid and the FCC ID and IC Certification Number cannot be used on the final Do not mount Wireless Devices using ZRF on or near metal objects (HVAC, I Beams, etc) or electrical devices (motors, high voltage switching, etc) as they can interfere with the wireless signals Vigil Vitality Wireless Module - Manual Vitality Wireless Module (ZRF) Manual Vigil Health Solutions Inc. dedicated to improving seniors' quality of life through creative technology. Page 3 of 3 Revised: 2013-04-25 Vigil Health Solutions Inc. 2102 - 4464 Markham Street * Victoria, BC * Canada * V8Z 7X8. Phone: (250) 383.6900 * (877) 850.1122 Fax: (250) 383.6999 Web: www.vigil.com © Vigil Health Solutions Inc. product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC and Industry Canada authorization. End Product Labelling The ZRF Module is labelled with its own FCC ID and IC Certification Number. If the FCC ID and IC Certification Number are not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. In that case, the final end product must be labelled in a visible area with the following: “Contains Transmitter Module FCC ID: UI6-ZRF” “Contains Transmitter Module IC: 6706A-ZRF” or “Contains FCC ID: UI6-ZRF” “Contains IC: 6706A-ZRF” The OEM of the ZRF Module must only use the approved antenna(s) listed above, which have been certified with this module. The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module or change RF related parameters in the user manual of the end product. The user manual for the end product must include the following information in a prominent location: “To comply with F…

Text truncated - open the document above for the full version.

EXTERNAL PHOTOS Company Name Vigil Health Solutions Inc Model # ZRF FCC ID # UI6‐ZRF IC # 6706A‐ZRF Page 1 of 2 EXTERNAL PHOTOS Company Name Vigil Health Solutions Inc Model # ZRF FCC ID # UI6‐ZRF IC # 6706A‐ZRF Page 2 of 2

INTERNAL PHOTOS Company Name Vigil Health Solutions Inc Model # ZRF FCC ID # UI6‐ZRF IC # 6706A‐ZRF Page 1 of 1

Prepared For: Vigil Health Solutions, Inc. Name: Vitality Wireless RF Module Report: TR 313025A FCCICTX A Model: ZRF LSR: C-1651 Serial: N/A (engineering sample) Page 32 of 33 Appendix F – RF Exposure Assessment The following MPE calculations are based on a measured conducted RF power of 18.47dBm as presented to the antenna. The peak gain of this antenna, based on field strength measurements over a conducting ground plane is 0.3 dBi.

W66 N220 Commerce Court ● Cedarburg, WI 53012 USA ● Phone: 262.375.4400 ● Fax: 262.375.4248 ● www.lsr.com Prepared For: Vigil Health Solutions, Inc. Name: Vitality Wireless RF Module Report: TR 313025A FCCICTX A Model: ZRF LSR: C-1651 Serial: N/A (engineering sample) Page 1 of 33 i. Title Page ENGINEERING TEST REPORT # 313025 A LSR Job #: C-1651 Compliance Testing of: Vitality Wireless RF Module (ZRF) Test Date(s): April 25, May 7-9 and 20, 2013 Prepared For: Vigil Health Solutions, Inc. Attn: Jason Cai / Steven Smith 2102-4464 Markham St. Victoria, British Columbia Canada V8Z 7X8 This Test Report is issued under the Authority of: Adam Alger, EMC Engineer Signature: Date: 6-11-13 Test Report Reviewed by: Shane Rismeyer, EMC Engineer Signature: Date: 6-3-13 Report by: Adam Alger, EMC Engineer Signature: Date: 5-28-13 This Test Report may not be reproduced, except in full, without written approval of LS Research, LLC. Prepared For: Vigil Health Solutions, Inc. Name: Vitality Wireless RF Module Report: TR 313025A FCCICTX A Model: ZRF LSR: C-1651 Serial: N/A (engineering sample) Page 2 of 33 ii. Table of Contents Table of Contents i. Title Page ................................................................................................................................... 1 ii. Table of Contents ....................................................................................................................... 2 iii. LS Research, LLC ...................................................................................................................... 3 1.0 Summary of Test Report ............................................................................................................ 4 2.0 Test Facilities ............................................................................................................................. 4 3.0 Client Information ...................................................................................................................... 5 3.1 Equipment Under Test (EUT) Information ................................................................................ 5 3.2 Product Description ................................................................................................................... 5 3.3 Modifications Incorporated In the EUT for Compliance Purposes ........................................... 5 4.0 Conditions of Test ...................................................................................................................... 5 5.0 Additional Information .............................................................................................................. 6 6.0 Test Equipment .......................................................................................................................... 6 7.0 Conformance Summary ............................................................................................................. 6 Appendix A – Test Equipment ............................................................................................................. 7 Appendix B – Test Data ........................................................................................................................ 8 B.1 – RF Conducted Emissions ........................................................................................................ 8 B.2 – Radiated Emissions ............................................................................................................... 19 Appendix C - Uncertainty Summary .................................................................................................. 29 Appendix D - References .................................................................................................................... 30 Appendix E – Duty Cycle ................................................................................................................... 31 Appendix F – RF Exposure Assessment ............................................................................................. 32 Prepared For: Vigil Health Solutions, Inc. Report: TR 313025A FCCICTX A LSR: C-1651 iii. LS Research, LLC As an EMC Testing Laboratory, our Accreditation and Assessments are recognized through the following: A2LA – American Association for Laboratory Accreditation Accreditation based on ISO/IEC 17025: 2005 A2LA Certificate Number: 1255.01 Federal Communications Commission (FCC) Listing of 3 Meter Semi-Anechoic Chamber based on FCC Registration Number: 90756 Industry Canada On file, 3 Meter Semi- Anechoic Chamber based on RSS File Number: IC 3088-A On file, 3 and 10 Meter OATS based on RSS File Number: IC 3088 U. S. Conformity Assessment Body (CAB) Validation Validated by the European Commission as a U. S. Competent Body operating under the U. S./EU, Mutual Recognition Agreement (MRA) operating under the European Union Electromagnetic Compatibility 10.2). Date of Validation: January 16, 2001 Validated by the European Commission as a U.S. Notified Body operating under the U.S. /EU, Mutual Recognition Agreement (MRA) operating under the European Union Telecommunication Equipment Date of Validation: November 20, 2002 Notified Body Identification Number: 1243 Name: Vitality Wireless RF Module Model: ZRF Serial: N/A (engineering sample) Page 3 of 33 LS Research, LLC in Review As an EMC Testing Laboratory, our Accreditation and Assessments are recognized through the for Laboratory Accreditation Accreditation based on ISO/IEC 17025: 2005 with Electrical (EMC) Scope of A2LA Certificate Number: 1255.01 Federal Communications Commission (FCC) – USA Anechoic Chamber based on Title 47 CFR – Part 2.948 FCC Registration Number: 90756 Anechoic Chamber based on RSS-212 – Issue 1 On file, 3 and 10 Meter OATS based on RSS-212 – Issue 1 S. Conformity Assessment Body (CAB) Validation Validated by the European Commission as a U. S. Competent Body operating under the U. S./EU, Mutual Recognition Agreement (MRA) operati…

Text truncated - open the document above for the full version.

TEST SETUP PHOTOS Company Name Vigil Health Solutions Inc Model # ZRF FCC ID # UI6‐ZRF IC # 6706A‐ZRF Page 1 of 2 TEST SETUP PHOTOS Company Name Vigil Health Solutions Inc Model # ZRF FCC ID # UI6‐ZRF IC # 6706A‐ZRF Page 2 of 2
