UTCAP400E-001AP400E: DECT 6.0 Base Station for external antennas and optional G.729 compression module

AP400 - All Types Installation Manual Issue: May 2012 AP400 – All Types Installation Manual Page 1 of 34 © NEC Nederland B.V. 2012 © NEC Nederland B.V. 2012 Page 2 of 34 AP400 – All Types Installation Manual A publication of NEC Nederland B.V. HILVERSUM, THE NETHERLANDS Date: May 2012 Great care has been taken to ensure that the information contained in this handbook is accurate and complete. Should any errors or omissions be discovered or should any user wish to make a suggestion for improving this handbook, he is invited to send the relevant details to: NEC Nederland B.V. P.O. BOX 32 1200 JD HILVERSUM THE NETHERLANDS  NEC Nederland B.V., 2012 All rights are reserved. Reproduction in whole or in part is prohibited without written consent of the copyright owner. AP400 – All Types Installation Manual Page 3 of 34 © NEC Nederland B.V. 2012 Regulatory information European Union Declaration of Conformity Hereby, “NEC Unified Solutions”, declares that this “AP400” is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.  http://www.nec-unified.com/doc PRODUCT DISPOSAL INFORMATION (EN) For countries in the European Union The symbol depicted here has been affixed to your product in order to inform you that electrical and electronic products should not be disposed of as municipal waste. Electrical and electronic products including the cables, plugs and accessories should be disposed of separately in order to allow proper treatment, recovery and recycling. These products should be brought to a designated facility where the best available treatment, recovery and recycling techniques is available. Separate disposal has significant advantages: valuable materials can be re-used and it prevents the dispersion of unwanted substances into the municipal waste stream. This contributes to the protection of human health and the environment. Please be informed that a fine may be imposed for illegal disposal of electrical and electronic products via the general municipal waste stream. In order to facilitate separate disposal and environmentally sound recycling arrangements have been made for local collection and recycling. In case your electrical and electronic products need to be disposed of please refer to your supplier or the contractual agreements that your company has made upon acquisition of these products. At www.nec-unified.com/weee you can find information about separate disposal and environmentally sound recycling. For countries outside the European Union Disposal of electrical and electronic products in countries outside the European Union should be done in line with the local regulations. If no arrangement has been made with your supplier, please contact the local authorities for further information. © NEC Nederland B.V. 2012 Page 4 of 34 AP400 – All Types Installation Manual Exposure to Radio Frequency (RF) Signals - All Countries: This device with internal antennas must provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. AP400 – All Types Installation Manual Page 5 of 34 © NEC Nederland B.V. 2012 Regulatory information United States This device contains functions which are not operational in US territories This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:  Reorient or relocate the equipment.  Increase the separation between the equipment and receiver.  Consult the dealer or an experienced radio/TV technician for help.” Privacy of communications may not be ensured when using this equipment. © NEC Nederland B.V. 2012 Page 6 of 34 AP400 – All Types Installation Manual Exposure to Radio Frequency (RF) Signals: This base station is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the OET Bulletin 65 Supplement C. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on the safety standards previously set by international standards bodies. These standards include a substantial safety margin designed to assure the safety of all persons, regardless of age and health. This device with internal antennas must provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Regulatory information Canada This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applic…

Text truncated - open the document above for the full version.

Federal Communications Commission Date: 2011-12-09 Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Request for Confidentiality NEC Nederland B.V. FCC ID: UTCAP400E-001 FCC Part 15 Certification Dear sir or madam, In accordance with 0.457 and 0.459 of CFR 47, NEC Nederland B.V. hereby request infinite confidentiality of the following files and contents for the subject application: - Schematic diagrams - Bill of materials and parts - Detailed Block diagrams - Detailed Operational/Functional Description These documents contain detailed system and equipment descriptions and related information about the product which NEC Nederland B.V. considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. Infinite confidentiality is also requested for the listed installation manual, because it contains information which should only be available to qualified and trained personnel. Since the design of this product is a basis from which future technological products will evolve, NEC Nederland B.V. considers that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, Name: F. Dosil Title: Advisor regulatory compliance Company: NEC Nederland B.V. NEC Nederland B.V. Anton Philipsweg, 1223 KZ Hilversum, P.O.Box32, 1200 JD Hilversum, The Netherlands Phone: +31 (0)35 689 91 11, Fax: +31 (0)35 689 14 50 www.nec-unified.com

FCC ID: UTCAP400E-001 Project no.: 176720 Page 1 of 3 EXTERNAL PHOTOS – AP400E AP400E – Outdoor Box FCC ID: UTCAP400E-001 Project no.: 176720 Page 2 of 3 AP400E with External Antenna

FCC ID: UTCAP400-001 Project no.: 176720 Page 1 of 2 INTERNAL PHOTOS – AP400E FCC ID: UTCAP400-001 Project no.: 176720 Page 2 of 2 FCC ID: UTCAP400-001 Project no.: 176720 Page 3 of 3 G.729 Daughterboard

FCC ID: UTCAP400E-001 MPE Calculation for FCC Uncontrolled Environment Formula from page 18 of OET Bulletin 65, Edition 97 -01 where: S = power density P = power input to the antennaG = power gain of the antenna in the direction of i nterest relative to an isotropic radiator R = distance to the center of radiation of the ante nna Source Based Time Averaged Duty Cycle is 100% in ca lculation below Maximum peak output power at antenna input terminal : 15.35 (dBm) Maximum peak output power at antenna input terminal : 0.034 (W) Maximum antenna gain: 8.00 (dBi) Maximum antenna gain: 6.310 (numeric) Prediction distance: 20 (cm) Prediction frequency: 1925 (MHz) Time Averaged Duty Cycle 100 % MPE limit for uncontrolled exposure at prediction f requency: 10.00 (W/m^2) Power density at prediction frequency: 0.0430 (mW/cm^2) Power density at prediction frequency: 0.430 (W/m^2) Maximum allowable antenna gain: 21.66 (dBi) Margin of Compliance: 13.66 (dB) 2 4 R PG S π =

Nemko AS, Gaustadalléen 30, P.O.Box 73 Blindern, NO-0314 Oslo Norway T +47 22 96 03 30 F +47 22 96 05 50 Enterprise number NO974404532 Visiting address: Nemko Kjeller, Instituttveien 6, P.O.Box 96, NO-2027 Kjeller Norway T +47 64 84 57 00 F +47 64 84 57 05 Test report no. : 176720-4 Item tested : AP400E Type of equipment : UPCS Base FCC ID : UTCAP400E-001 IC : 140Q-AP400E01 Client : NEC Nederland B.V. FCC Part 15, subpart D Isochronous UPCS Device 1920 - 1930 MHz Industry Canada RSS-213, Issue 2 2 GHz Licence-exempt Personal Communications Service Devices (LE-PCS) 20 April 2012 Authorized by : .............................................. G. Suhantakumar Technical Verificator TEST REPORT FCC part 15D Report no.: 176720-4 FCC ID: UTCAP400E-001 Nemko AS, N-2007 Kjeller Page 2 (47) CONTENTS 1 GENERAL INFORMATION ............................................................................................................... 3 1.1 Testhouse Info ................................................................................................................................... 3 1.2 Client Information .............................................................................................................................. 3 1.3 Manufacturer (if other than client) ...................................................................................................... 3 2 TEST INFORMATION ....................................................................................................................... 4 2.1 Tested Item........................................................................................................................................ 4 2.2 Description of Tested Device ............................................................................................................. 4 2.3 Exposure Evaluation .......................................................................................................................... 4 2.4 Test Environment .............................................................................................................................. 5 2.5 Test Period ........................................................................................................................................ 5 2.6 Test Engineer(s) ................................................................................................................................ 5 2.7 Test Equipment ................................................................................................................................. 5 2.8 Other Comments ............................................................................................................................... 5 3 TEST REPORT SUMMARY .............................................................................................................. 6 3.1 General .............................................................................................................................................. 6 3.2 Test Summary ................................................................................................................................... 7 4 TEST RESULTS ................................................................................................................................ 8 4.1 Power Line Conducted Emissions ..................................................................................................... 8 4.2 Coordination with fixed microwave .................................................................................................. 10 4.3 Digital Modulation Techniques ........................................................................................................ 10 4.4 Labeling Requirements ................................................................................................................... 10 4.5 Antenna Requirement...................................................................................................................... 11 4.6 Channel Frequencies ...................................................................................................................... 11 4.7 Automatic Discontinuation of Transmission .................................................................................... 12 4.8 Peak Power Output ......................................................................................................................... 13 4.9 Emission Bandwidth B ..................................................................................................................... 16 4.10 Power Spectral Density ................................................................................................................... 19 4.11 In-Band Unwanted Emissions, Conducted ...................................................................................... 22 4.12 Out-of-band Emissions, Conducted................................................................................................. 24 4.13 Carrier Frequency Stability .............................................................................................................. 30 4.14 Frame Repetition Stability ............................................................................................................... 31 4.15 Frame Period and Jitter ................................................................................................................... 31 4.16 Monitoring Threshold, Least Interfered Channel ............................................................................. 33 4.17 Threshold Monitoring Bandwidth ..................................................................................................... 35 4.18 Reaction Time and Monitoring Interval ............................................................................................ 36 4.19 Time and Spectrum Window Access Procedure ...........................................................................…

Text truncated - open the document above for the full version.

FCC Part 15D – Compliance Information fcc - ap400e part 15d declarations.docx 8-Dec-2006 page 1 (4) rev.1.4 EUT AND PRODUCT INFORMATION Type of Equipment UPCS (DECT 6.0) Applicant Name NEC Nederland B.V. Address Anton Philipsweg 1, 1223 KZ Hilversum, The Netherlands Contact F. Dosil ([email protected]) FP PP Repeater EUT Type/System FCC ID UTCAP400E-001 Model name AP400E HW Version V2 Rev E SW Version TBD Max antenna Gain 8 dBi Can the EUT be Initiating Device YES YES YES Does the EUT transmit signaling channels YES YES YES Max number of slots in use simultaneously 24 Test standard: FCC part 15D Other: Industry Canada RSS-213, Issue 2 Frequency Band 1921.536 – 1928.448 MHz # of RF Channels 5 Frame Period 10 ms Max. Burst length 420 us Min. Burst Length 83 uS # of Logical Channels 60 (12 duplex channels per RF carrier) Operating Mode Simplex Duplex FCC Part 15D – Compliance Information fcc - ap400e part 15d declarations.docx 8-Dec-2006 page 2 (4) rev.1.4 ANTENNAS Base (FP) Antenna Type Internal External 1 Dual slant monopole 2 3 4 Does RX and TX use the same antenna(s)? Yes No Handset (PP) Antenna Type Internal External 1 2 Does RX and TX use the same antenna(s)? Yes No ANTENNA DIVERSITY Antenna Diversity Supported TX RX Base (FP) 1 2 3 4 Handset (PP) 1 2 VOLTAGE AND TEMPERATURE RANGES VOLTAGES FP PP Repeater Nominal Voltage 48V Cut-Off Voltage (if applicable) 36V POWER SOURCE Type Manufacturer Base or Repeater PoE (Power Over Ethernet) Not included in product Handset (PP) (charger) Data Connections PSTN Others (please specify) Ethernet FCC Part 15D – Compliance Information fcc - ap400e part 15d declarations.docx 8-Dec-2006 page 3 (4) rev.1.4 ANCILLARY EQUIPMENT Description Type Manufacturer HOST DEVICE Description Type Manufacturer ADDITIONAL INFORMATION FCC Part 15D – Compliance Information fcc - ap400e part 15d declarations.docx 8-Dec-2006 page 4 (4) rev.1.4 MANUFACTURERS DECLARATIONS FCC part 15.323 (c)(5) No device or group of co-operating devices located within 1m of each other shall during any frame period occupy more than 6 MHz of aggregate bandwidth, or alternatively, more than one third of the time and spectrum windows defined by the system. Applicant Agrees Yes No FCC part 15.323 (c)(10) The applicant hereby declares that the system in this application does use the criteria of (c)(10) of this section. Applicant Agrees Yes No FCC part 15.323 (c)(11) The applicant hereby declares that system in this application does not use the criteria of (c)(11) of this section. Applicant Agrees Yes No FCC part 15.323 (c)(12) The provisions of (c)(10) or (c)(11) of this section shall not be used to extend the range of spectrum occupied over space or time for the purpose of denying fair access to spectrum to other devices. Applicant Agrees Yes No FCC part 15.307 (b) The Applicant is a participating member of UTAM, Inc. and will provide an affidavit from UTAM, Inc. certifying this. Confirmed By Applicant Yes No ADDITIONAL REMARKS: DECLARED BY: Date 2011 May 25 th Name F. Dosil Signature

FCC ID: UTCAP400E-001 Project no.: 176720 Page 1 of 1 PHOTOS OF TEST SET-UP –AP400E Power-line Conducted Emissions Test Set-up
