TEST REPORT Report No. : AJ005664-001 Date : 2007 April 19 Page 1 of 13 FCC ID: UU7DCTX2 This document shall not be reproduced except in full or with written approval by the laboratory. CMA Industrial Development Foundation Limited Room 1302, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com Application No. : LJ205863(2) Client : FORMATION LTD. SUITE 915-918, 9/F., CORPORATION SQUARE 8 LAM LOK STREET, KOWLOON BAY, KOWLOON, HONG KONG. Sample Description : One(1) submitted sample(s) stated to be Outdoor Sensor of Model No. FX5500 Radio Frequency : 433.920MHz Transmitter Rating : 2 x 1.5V AA size batteries No. of submitted sample : Two (2) piece(s) *** Date Received : 2007 March 16 Test Period : 2007 March 16 β 2007 March 28 Test Requested : FCC Part 15 Certification. Test Method : 47 CFR Part 15 (10-1-05 Edition) ANSI C63.4 β 2003 Test Result : See attached sheet(s) from page 2 to 13. Conclusion : The submitted sample was found to comply with requirement of FCC Part 15 Subpart C. For and on behalf of CMA Industrial Development Foundation Limited Authorized Signature : ____________________________________________________ Danny Chui Deputy Manager - EL. Division TEST REPORT Report No. : AJ005664-001 Date : 2007 April 19 Page 2 of 13 FCC ID: UU7DCTX2 This document shall not be reproduced except in full or with written approval by the laboratory. CMA Industrial Development Foundation Limited Room 1302, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com Table of Contents 1 General Information............................................................................................................................. 3 1.1 General Description ..................................................................................................................... 3 1.2 Location of the test site ................................................................................................................ 4 1.3 List of measuring equipment........................................................................................................ 5 2 Description of the radiated emission test ............................................................................................. 6 2.1 Test Procedure ............................................................................................................................. 6 2.2 Test Result ................................................................................................................................... 6 2.3 Radiated Emission Measurement Data ........................................................................................ 7 3 Description of the Line-conducted Test............................................................................................. 10 3.1 Test Procedure ........................................................................................................................... 10 3.2 Test Result ................................................................................................................................. 10 3.3 Graph and Table of Conducted Emission Measurement Data ................................................... 10 4 Photograph ......................................................................................................................................... 11 4.1 Photographs of the Test Setup for Radiated Emission and Conduction Emission..................... 11 4.2 Photographs of the External and Internal Configurations of the EUT....................................... 11 5 Supplementary document................................................................................................................... 12 5.1 Bandwidth .................................................................................................................................. 12 5.2 Duty cycle .................................................................................................................................. 12 5.3 Transmission period ................................................................................................................... 12 6 Appendices......................................................................................................................................... 13 TEST REPORT Report No. : AJ005664-001 Date : 2007 April 19 Page 3 of 13 FCC ID: UU7DCTX2 This document shall not be reproduced except in full or with written approval by the laboratory. CMA Industrial Development Foundation Limited Room 1302, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com 1 General Information 1.1 General Description The equipment under test (EUT) is a transmitter. It operates at 433.920MHz and the oscillation of radio control is generated by a crystal. The EUT is power by 2 x 1.5V AA size batteries. There are single switch inside the battery cover for select different channel (CH1, CH2 and CH3), and the LCD display will show the temperature states. All data will transmit to receiver through radio frequency. The difference in between CH1 β CH3 is modulation code signal. The brief circuit description is listed as follows: - U1 and its associated circuit act as Microcontroller. - X1 and its associated circuit act as an oscillator for U1. - Q2, X2 and its associated circuit act as an oscillator for radio transmission. - Q3 and its associated circuit act as RF amplifier. TEST REPORT Report No. : AJ005664-001 Date : 2007 April 19 Page 4 of 13 FCC ID: UU7DCTX2 This document shall not be reproduced except in full or with written approval by the laboratory. CMA Industrial Development Foundation Limited Room 1302, Yan Hing Cenβ¦
Text truncated - open the document above for the full version.
Job No. WF-EL-EMC-15 Edition 1 2006 April 12 Page of Bandwidth Plot Bandwidth 1
Job No. WF-EL-EMC-15 Edition 1 2006 April 12 Page of Duty Cycle Duty Cycle 1 Duty Cycle 2
Job No. WF-EL-EMC-15 Edition 1 2006 April 12 Page of Transmission Period Transmission Cycle 1 Transmission Cycle 2
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15.231(e) | 434 MHz - 434 MHz | - |
