UU8-S160Lighting Speaker with stand PEANUTS

Para limpiar el juguete, utilice únicamente un paño suave humedecido en agua. No utilice ningún producto detergente. No exponga el juguete a la acción directa de los rayos del sol ni a ninguna otra fuente de calor. No mojar el juguete. No desmonte o deje caer el juguete. Nota: Conserve este manual de instrucciones ya que contiene informaciones de importancia. Este producto está cubierto por nuestra garantía de 3 meses. Para cualquier reclamación bajo la garantía o petición de servicio post venta deberá dirigirse a su revendedor y presentar su comprobante de compra. Nuestra garantía cubre los defectos de material o montaje que sean imputables al fabricante, con la excepción de todo aquel deterioro que sea consecuencia de la no observación de las indicaciones indicadas en el manual de instrucciones, o de toda intervención impro cedente sobre este aparato (como por ejemplo el desmontaje, exposición al calor o a la humedad...). Se recomienda conservar el embalaje para cualquier referencia futura. En nuestro constante afán de superación, podemos proceder a la modificación de los colores y detalles del producto mostrado en el embalaje. ADVERTENCIA! No conviene para niños menores de 36 meses. Partes pequeñas. Peligro de atragantamiento. Cuerda larga. Peligro de estrangulamiento. Referencia: S160_09series Diseñado y desarrollado en Europa – Fabricado en China, Shantou ©Lexibook® Para cualquier solicitud de soporte técnico, reclamo o servicio postventa: - Visite nuestro sitio web en https://www.lexibook.com/contact-us y complete el formulario de contacto. - O envíenos un correo electrónico directamente a: [email protected]. Las pilas no recargables no deben ser recargadas. Las pilas recargables deben ser retiradas del producto antes de ser cargadas. Las pilas recargables solo deben cargarse bajo la supervisión de un adulto. No mezcle pilas viejas y nuevas, pilas de diferentes marcas o distintos tipos de pila, como alcalinas, de carbono-zinc o recargables. Solo deben utilizarse pilas del mismo tipo o equivalente al recomendado. Asegúrese de que las pilas estén colocadas correctamente, de acuerdo con la polaridad (+ y -). Las pilas agotadas deben ser retiradas del producto. Los terminales de alimentación no deben cortocircuitarse. No tirar las pilas al fuego. Retirar las pilas si no se va a utilizar el producto durante un largo periodo de tiempo. Las pilas no deben exponerse a calor excesivo, como el producido por la luz solar, el fuego o similares. Non-rechargeable batteries are not to be recharged. Rechargeable batteries are to be removed from the product before being charged. Rechargeable batteries are only to be charged under adult supervision. Do not mix old and new batteries, different brands or types of batteries, such as alkaline, carbon-zinc, or rechargeable batteries. Only batteries of the same or equivalent type as recommended are to be used. Ensure the batteries are installed correctly according to polarity (+ and -). Exhausted batteries are to be removed from the product. The supply terminals are not to be short circuited. Do not throw batteries into a fire. Remove the batteries if you are not going to use the product for a long period of time. Batteries shall not be exposed to excessive heat such as sunshine, fire or the like. Les piles non rechargeables ne doivent pas être rechargées. Les piles rechargeables doivent être retirées du produit avant d’être rechargées. Les piles rechargeables ne doivent être rechargées que sous la surveillance d’un adulte. Ne mélangez pas des piles anciennes et neuves, ni des piles de marques ou de types différents, telles que les piles alcalines, carbone-zinc ou rechargeables. Seules des piles du même type ou d’un type équivalent à celui recommandé doivent être utilisées. Assurez-vous que les piles sont correctement installées en respectant la polarité (+ et -). Les piles usagées doivent être retirées du produit. Les bornes d’alimentation ne doivent pas être court- circuitées. Ne jetez pas les piles au feu. Retirez les piles si vous ne comptez pas utiliser le produit pendant une longue période. Les piles ne doivent pas être exposées à une chaleur excessive, telle que la lumière du soleil, le feu ou autre. Only use a soft, slightly damp cloth to clean the unit. Do not use detergent. Do not expose the unit to direct sunlight or any other heat source. Do not immerse the unit in water. Do not dismantle or drop the unit. Do not try to twist or bend the unit. Note: Please keep this instruction manual, it contains important information. This product is covered by our 3-month warranty. For any claim under the warranty or after sale service, please contact your distributor and present a valid proof of purchase. Our warranty covers any manufacturing material and workmanship defect, with the exception of any deterioration arising from the non-observance of the instruction manual or from any careless action implemented on this item (such as dismantling, exposition to heat and humidity, etc.). It is recommended to keep the packaging for any further reference. In a bid to keep improving our services, we could implement modification on the colours and the details of the product shown on the packaging. WARNING! Not suitable for children under 36 months. Small parts. Choking hazard. Long cord. Strangulation hazard. w w w . l e x i b o o k . c o m Lighting Speaker with stand PEANUTS S160PN_09 Instruction manual Manual de instrucciones Mode d’emploi FRANÇAIS ENGLISH ESPAÑOL Lors du déballage, assurez-vous d’avoir tous les éléments suivants : 2 x Microphones / 1 x Enceinte / 1 x Tube / 1 x Pied / 1 x Manuel d’instruction ATTENTION:Les éléments d’emballage tels que films plastiques, rubans adhésifs, étiquettes et rubans de fixation métalliques ne font pas partie de ce jouet et doivent être enlevés par raison de sécurité avant toute utilisation par un enfant. ATTENTION : D’importantes interférences électromagnétiques ou des décharges électrostatiques peuvent provoquer un…

Text truncated - open the document above for the full version.

Lexibook America Covered Equipment Certification Attestation Letter 5/26/2026 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: UU8-S160 Lexibook America (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. Lexibook America (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Lexibook America (“the applicant”) certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Signed: Printed name: Terry Tang Title: Managing Director Company Name: Lexibook America Date: 5/26/2026

Lexibook America Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 4/13/2026 U.S. Agent Designation Lexibook America acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: UU8-S160): Name and company of U.S. agent: Physical U.S. address of agent: FRN of U.S. agent: Email address of U.S. agent: Lexibook America C/O Pramex International, 1251 Avenue of the Americas, 3rd Fl., New York, 10020 United States 0036338390 [email protected] Lexibook America acknowledges their obligation to accept service of process on behalf of Lexibook America. Lexibook America with the FRN 0036338390 accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. Sincerely, Signature Terry Tang Managing Director Lexibook America 48_[model] US_Agent_2.911(d)(7) - U, V05

Lexibook America DATE: May 26, 2026 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Shenzhen Tongzhou Testing Co.,Ltd. (1st Floor, Building 1, Haomai High-tech Park, Huating Road 387, Dalang Street, Longhua, Shenzhen, China) to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with Lexibook America (C/O Pramex International, 1251 Avenue of the Americas, 3rd Fl.,New York 10020, United States) <Signature> Name: Terry Tang Title: Managing Director Applicant Company: Lexibook America

Date: May 26, 2026 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Compliance Testing, LLC to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). Sincerely, <Signature> Name: Terry Tang Title: Managing Director Company: Lexibook America

DATE: May 26, 2026 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: UU8-S160 Product Name: Lighting Speaker with stand PEANUTS Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) • Schematics • Block diagram • Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. <Signature> Name: Terry Tang Title: Managing Director Company: Lexibook America

Report No.: TZ0035260345PH02 Page 1 of 4 Exterior Photographs of EUT Figure 1 Figure 2 Report No.: TZ0035260345PH02 Page 2 of 4 Figure 3 Figure 4 Report No.: TZ0035260345PH02 Page 3 of 4 Figure 5 Figure 6 Report No.: TZ0035260345PH02 Page 4 of 4 Figure 7

The size of the label is 15mm*10mm with White forecolor. The size of the logo is 5mm*5mm. FCC ID: UU8-S160

Report No.: TZ0035260345PH03 Page 1 of 3 Interior Photographs of EUT Figure 1 Figure 2 Report No.: TZ0035260345PH03 Page 2 of 3 Figure 3 Figure 4 Bluetooth Antenna Report No.: TZ0035260345PH03 Page 3 of 3 Figure 5

Shenzhen Tongzhou Testing Co.,Ltd FCC ID: UU8-S160 This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 1 of 2 RADIO FREQUENCY EXPOSURE Limit According to section B.4 of 447498 D04 Interim General RF Exposure Guidance v01 SAR-based thresholds are derived based on frequency, power, and separation distance of the RF source. The formula defines the thresholds in general for either available maximum time-averaged power or maximum time-averaged ERP, whichever is greater. If the ERP of a device is not easily determined, such as for a portable device with a small form factor, the applicant may use the available maximum time-averaged power exclusively if the device antenna or radiating structure does not exceed an electrical length of λ/4. As for devices with antennas of length greater than λ/4 where the gain is not well defined, but always less than that of a half-wave dipole (length λ/2), the available maximum time-averaged power generated by the device may be used in place of the maximum time-averaged ERP, where that value is not known. The separation distance is the smallest distance from any part of the antenna or radiating structure for all persons, during operation at the applicable ERP. In the case of mobile or portable devices, the separation distance is from the outer housing of the device where it is closest to the antenna. The SAR-based exemption formula of § 1.1307(b)(3)(i)(B), repeated here as Formula (B.2), applies for single fixed, mobile, and portable RF sources with available maximum time-averaged power or effective radiated power (ERP), whichever is greater, of less than or equal to the threshold Pth (mW). This method shall only be used at separation distances from 0.5 cm to 40 cm and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by Formula (B.2). Where and f is in GHz, d is the separation distance (cm), and ERP 20cm is per Formula (B.1). Shenzhen Tongzhou Testing Co.,Ltd FCC ID: UU8-S160 This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 2 of 2 Results RF Exposure at Separation distance (cm): 0.5 Mode Antenna Frequency [MHz] Conducted Power [dBm] Manufacturing tolerance Antenna Gain [dBi] Max of ERP and Conducted Power including Tune Up SAR-based exemption threshold Pth [mW] Target Power [dBm] Tolerance ±[dB] [dBm] [mW] DH5 Ant1 2402 0.42 0 1 0 1 1.26 2.79 DH5 Ant1 2441 0.3 0 1 0 1 1.26 2.75 DH5 Ant1 2480 -0.26 -1 1 0 0 1.00 2.72 2DH5 Ant1 2402 1.13 0.5 1 0 1.5 1.41 2.79 2DH5 Ant1 2441 1.04 0.5 1 0 1.5 1.41 2.75 2DH5 Ant1 2480 0.44 0 1 0 1 1.26 2.72 Max of ERP and Conducted Power including Tune Up (dBm) = Max Conducted Tune Up Power(dBm) and Max Conducted Tune Up Power(dBm) + Antenna Gain(dBi)-2.15), whichever is greater. The Maximum Erp is used for Routine Evaluation Exemption according to B.4 of 447498 D04 Interim General RF Exposure Guidance v01. So, the SAR evaluation is not required.

Report No.: TZ0035260345FRF01 Page 1 of 32 This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Tongzhou Testing Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Tongzhou Testing Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. The test report apply only to the specific sample(s) tested under stated test conditions. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. TEST REPORT Report Number : TZ0035260345FRF01 Product Name : Lighting Speaker with stand PEANUTS Model/Type reference : S160PN_09 FCC ID : UU8-S160 Prepared for : Lexibook America C/O Pramex International, 1251 Avenue of the Americas, 3rd Fl.,New York 10020, United States Prepared By : Shenzhen Tongzhou Testing Co.,Ltd. 1st Floor, Building 1, Haomai High-tech Park, Huating Road 387, Dalang Street, Longhua, Shenzhen, China Standards : FCC CFR Title 47 Part 15C, ANSI C63.10-2020+Cor. 1-2023 Date of Test : 2026-04-23 ~ 2026-05-09 Date of Issue : 2026-05-09 Prepared by : Nancy Li Reviewed by : Allen Lai Approved by : Max Zhang (Authorized Officer) Report No.: TZ0035260345FRF01 Page 2 of 32 ** Report Revise Record ** Report Version Revise Time Issued Date Valid Version Notes V1.0 / 2026-05-09 Valid Initial release Report No.: TZ0035260345FRF01 Page 3 of 32 TABLE OF CONTENTS 1. G E N E R A L I N F O R M A T I O N ........................................................ 4 1.1. Client Information ................................................................................................................... 4 1.2. Description of Device (EUT) ................................................................................................... 4 1.3. Wireless Function Tested in this Report .............................................................................. 4 1.4. EUT configuration ................................................................................................................... 5 1.5. Description of Test Facility .................................................................................................... 5 1.6. Statement of the Measurement Uncertainty ......................................................................... 5 1.7. Measurement Uncertainty ...................................................................................................... 6 1.8. Description of Test Modes ..................................................................................................... 6 1.9. Frequency of Channels .......................................................................................................... 6 2. T E S T M E T H O D O L O G Y ............................................................ 7 2.1. EUT Configuration .................................................................................................................. 7 2.2. EUT Exercise ........................................................................................................................... 7 2.3. Test Sample ............................................................................................................................. 7 3. S Y S T E M T E S T C O N F I G U R A T I O N .............................................. 8 3.1. Justification ............................................................................................................................. 8 3.2. EUT Exercise Software ........................................................................................................... 8 3.3. Special Accessories ............................................................................................................... 8 3.4. Block Diagram/Schematics .................................................................................................... 8 3.5. Equipment Modifications ....................................................................................................... 8 3.6. Test Setup ................................................................................................................................ 8 4. S U M M A R Y O F T E S T R E S U L T S ................................................. 9 5. M E A S U R E M E N T R E S U L T S ...................................................... 10 5.1. Maximum Peak Conducted Output Power ......................................................................... 10 5.2. Frequency Separation and 20 Db Bandwidth .................................................................... 11 5.3. Number of Hopping Frequency ........................................................................................... 12 5.4. Time of Occupancy (Dwell Time) ......................................................................................... 13 5.5. Conducted Spurious Emissions and Band Edges Test .................................................... 15 5.6. Restricted Band Emission Limit .......................................................................................... 16 5.7. AC Power line conducted emissions .................................................................................. 25 5.8. Band-edge measurements for radiated emissions ........................................................... 26 5.9. Pseudorandom frequency hopping sequence ................................................................... 29 5.10. Antenna requirement ............................................................................................................ 30 6. S U M M A R Y O F T E S T E Q U I P M E N T ............................................ 31 7. T E S T S E T U P P H O T O G R A P H S ................................................. 32 8. E X T E R N A L P H O T O S O F T H E E U T ............................................…

Text truncated - open the document above for the full version.

V . S .W . R < 1.4 Polarization Type V ertical & Horizontal Frequenc Range2400 ~ 2500GHz Input Impendence(ohm)50 Efficiency (dB) 6 0.2 % 6 0.2 % Maximum Power (dBm) 1.6 8(XZ-plane) Gain (dBi) 0.0 (Peak Gain XZ-plane) Peak EIRP(dBm)1.2 Tot. Rad. Pwr. (dBm)-1.2 (Input pwr – loss pwr) Antenna Product Specification Quick Reference Date Antenna module on the system board Ant. Port Input Pwr. (dBm)0 (Typ. BT class 2 output power) Directivity (dBi) 0 (all direction antenna) Minimum Power (dBm ) -3.83(XZ-plane) Avg. Power (dBm)-0.48(XY-plane) All the technical data and information contained herein are subject to change without prior notice Antenna Layout & module on the system board Antenna Gain Gain Table Unit in dBi @2.44GHzXY-planeXZ-planeYZ-plane Efficiency PeakAvg. Peak Avg. Peak Avg. Module Board -1.68 -1.35 -0. 0 -3.83 - 1.11 -2.99 Address Manufacture SHANTOU CHENGHAI AOQI TOY FACTORY LONGTIAN DEZHENG ROAD NORTH INDUSTRIAL ZONE, GUANGYI STREET, CHENGHAI DISTRICT, SHANTOU CITY Ret urn Loss The Environment of Antenna Radiation Pattern 3D radiation pattern diagram XY-planeXZ-planeYZ-plane

Appendix Test Data of the Report No.: TZ0035260345FRF01 Page 1 of 38 Appendix Test Data for BT(BDR/EDR) (Conducted Measurement) Product Name: Lighting Speaker with stand PEANUTS Trade Mark: / Test Model: S160PN_09 FCC ID: UU8-S160 Environmental Conditions Temperature: 23.5°C Relative Humidity: 58% ATM Pressure: 100.0 kPa Test Engineer: Allen Lai Supervised by: Max Zhang NOTE N/A Appendix A: 20dB Emission Bandwidth Test Result Test Mode Antenna Frequency [MHz] 20db EBW [MHz] FL [MHz] FH [MHz] Limit [MHz] Verdict DH5 Ant1 2402 1.035 2401.622 2402.657 --- --- DH5 Ant1 2441 1.041 2440.619 2441.660 --- --- DH5 Ant1 2480 1.056 2479.613 2480.669 --- --- 2DH5 Ant1 2402 1.356 2401.469 2402.825 --- --- 2DH5 Ant1 2441 1.329 2440.478 2441.807 --- --- 2DH5 Ant1 2480 1.329 2479.481 2480.810 --- --- Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0035260345FRF01 Page 2 of 38 Test Graphs DH5-Ant1-2402 DH5-Ant1-2441 Appendix Test Data of the Report No.: TZ0035260345FRF01 Page 3 of 38 DH5-Ant1-2480 2DH5-Ant1-2402 Appendix Test Data of the Report No.: TZ0035260345FRF01 Page 4 of 38 2DH5-Ant1-2441 2DH5-Ant1-2480 Appendix Test Data of the Report No.: TZ0035260345FRF01 Page 5 of 38 Appendix B: Occupied Channel Bandwidth Test Result Test Mode Antenna Frequency [MHz] OCB [MHz] FL [MHz] FH [MHz] Limit [MHz] Verdict DH5 Ant1 2402 0.94580 2401.6604 2402.6062 --- --- DH5 Ant1 2441 0.95481 2440.6578 2441.6126 --- --- DH5 Ant1 2480 0.97135 2479.6542 2480.6255 --- --- 2DH5 Ant1 2402 1.2177 2401.5320 2402.7497 --- --- 2DH5 Ant1 2441 1.2161 2440.5341 2441.7502 --- --- 2DH5 Ant1 2480 1.2329 2479.5304 2480.7633 --- --- Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0035260345FRF01 Page 6 of 38 Test Graphs DH5-Ant1-2402 DH5-Ant1-2441 Appendix Test Data of the Report No.: TZ0035260345FRF01 Page 7 of 38 DH5-Ant1-2480 2DH5-Ant1-2402 Appendix Test Data of the Report No.: TZ0035260345FRF01 Page 8 of 38 2DH5-Ant1-2441 2DH5-Ant1-2480 Appendix Test Data of the Report No.: TZ0035260345FRF01 Page 9 of 38 Appendix C: Maximum peak conducted output power Test Result Test Mode Antenna Frequency [MHz] Conducted Peak Power [dBm] Conducted Limit [dBm] Verdict DH5 Ant1 2402 0.42 ≤30 PASS DH5 Ant1 2441 0.30 ≤30 PASS DH5 Ant1 2480 -0.26 ≤30 PASS 2DH5 Ant1 2402 1.13 ≤20.97 PASS 2DH5 Ant1 2441 1.04 ≤20.97 PASS 2DH5 Ant1 2480 0.44 ≤20.97 PASS Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0035260345FRF01 Page 10 of 38 Test Graphs DH5-Ant1-2402-PASS DH5-Ant1-2441-PASS Appendix Test Data of the Report No.: TZ0035260345FRF01 Page 11 of 38 DH5-Ant1-2480-PASS 2DH5-Ant1-2402-PASS Appendix Test Data of the Report No.: TZ0035260345FRF01 Page 12 of 38 2DH5-Ant1-2441-PASS 2DH5-Ant1-2480-PASS Appendix Test Data of the Report No.: TZ0035260345FRF01 Page 13 of 38 Appendix D: Carrier frequency separation Test Result Test Mode Antenna Frequency [MHz] Result [MHz] Limit [MHz] Verdict DH5 Ant1 Hop 1.13 ≥1.056 PASS 2DH5 Ant1 Hop 1 ≥0.904 PASS Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0035260345FRF01 Page 14 of 38 Test Graphs DH5-Ant1-Hop-PASS 2DH5-Ant1-Hop-PASS Appendix Test Data of the Report No.: TZ0035260345FRF01 Page 15 of 38 Appendix E: Time of occupancy Test Result Test Mode Antenna Frequency [MHz] Burst Width [ms] TotalHops [Num] Result [s] Limit [s] Verdict DH5 Ant1 Hop 2.878 120 0.345 ≤0.4 PASS 2DH5 Ant1 Hop 2.883 100 0.288 ≤0.4 PASS Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0035260345FRF01 Page 16 of 38 Test Graphs DH5-Ant1-Hop-PASS Appendix Test Data of the Report No.: TZ0035260345FRF01 Page 17 of 38 2DH5-Ant1-Hop-PASS Appendix Test Data of the Report No.: TZ0035260345FRF01 Page 18 of 38 Appendix F: Number of hopping channels Test Result Test Mode Antenna Frequency [MHz] Result [Num] Limit [Num] Verdict DH5 Ant1 Hop 79 ≥15 PASS 2DH5 Ant1 Hop 79 ≥15 PASS Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0035260345FRF01 Page 19 of 38 Test Graphs DH5-Ant1-Hop-PASS 2DH5-Ant1-Hop-PASS Appendix Test Data of the Report No.: TZ0035260345FRF01 Page 20 of 38 Appendix G: Band edge measurements Test Result Test Mode Antenna Ch.Name Frequency [MHz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict DH5 Ant1 Low 2402 -0.13 -45.25 ≤-20.13 PASS DH5 Ant1 High 2480 -0.95 -46.01 ≤-20.95 PASS DH5 Ant1 Low Hop_2402 -0.38 -45.98 ≤-20.38 PASS DH5 Ant1 High Hop_2480 -1.14 -46.32 ≤-21.14 PASS 2DH5 Ant1 Low 2402 -0.21 -45.45 ≤-20.21 PASS 2DH5 Ant1 High 2480 -2.59 -48 ≤-22.59 PASS 2DH5 Ant1 Low Hop_2402 -3.40 -47.35 ≤-23.4 PASS 2DH5 Ant1 High Hop_2480 -0.87 -47.6 ≤-20.87 PASS Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0035260345FRF01 Page 21 of 38 Test Graphs DH5-Ant1-2402-PASS DH5-Ant1-2480-PASS Appendix Test Data of the Report No.: TZ0035260345FRF01 Page 22 of 38 DH5-Ant1-Hop_2402-PASS DH5-Ant1-Hop_2480-PASS Appendix Test Data of the Report No.: TZ0035260345FRF01 Page 23 of 38 2DH5-Ant1-2402-PASS 2DH5-Ant1-2480-PASS Appendix Test Data of the Report No.: TZ0035260345FRF01 Page 24 of 38 2DH5-Ant1-Hop_2402-PASS 2DH5-Ant1-Hop_2480-PASS Appendix Test Data of the Report No.: TZ0035260345FRF01 Page 25 of 38 Appendix H: Conducted Spurious Emission Test Result Test Mode Antenna Frequency [MHz] Freq. Range [MHz] Ref. Level [dBm] Result [dBm] Limit [dBm] Verdict DH5 Ant1 2402 0~Reference -0.77 -0.77 --- PASS DH5 Ant1 2402 30~1000 -0.77 -62.28 ≤-20.77 PASS DH5 Ant1 2402 1000~26500 -0.77 -37.92 ≤-20.77 PASS DH5 Ant1 2441 0~Reference -0.63 -0.63 --- PASS DH5 Ant1 2441 30~1000 -0.63 -63.12 ≤-20.63 PASS DH5 Ant1 2441 1000~26500 -0.63 -37.47 ≤-20.63 PASS DH5 Ant1 2480 0~Reference -1.30 -1.30 --- PASS DH5 Ant1 2480 30~1000 -1.30 -62.18 ≤-21.3 PASS DH5 Ant1 2480 1000~26500 -1.30 -37.94 ≤-21.3 PASS 2DH5 Ant1 2402 0~Reference -1.66 -1.66 --…

Text truncated - open the document above for the full version.

Report No.: TZ0035260345PH01 Page 1 of 1 Test Setup Photos of the EUT Radiated Emission Below 1GHz Radiated Emission Above 1GHz
