ViewPoint Essentials Sensor User Manual Document No. DS-VP-ESS-S-MNL August 12, 2022 Rev. DRAFT VP Essentials Sensor User Manual (Rev. A) 2 Mesa Labs, Inc. 12100 W. 6th Avenue Lakewood, CO 80228 USA Tel: 303-565-2724 monitoring.mesalabs.com [email protected] Contents 1.0 Introduction ...................................................................................................................................... 4 2.0 Regulatory Compliance ..................................................................................................................... 5 2.1 United States FCC .......................................................................................................................... 5 2.2 Industry Canada ............................................................................................................................ 6 3.0 Reference Documents ....................................................................................................................... 6 4.0 VP Essentials Sensor Models ............................................................................................................. 7 5.0 Needed Infrastructure ...................................................................................................................... 7 6.0 Features ............................................................................................................................................ 8 6.1 User Interface ............................................................................................................................... 8 6.2 Inputs .......................................................................................................................................... 10 7.0 Installing and Configuring ............................................................................................................... 11 7.1 Opening Enclosure ...................................................................................................................... 11 7.2 Inserting Batteries ....................................................................................................................... 12 7.3 Physically Installing ..................................................................................................................... 12 7.4 Startup ........................................................................................................................................ 13 7.5 Configuring .................................................................................................................................. 13 7.5.1 Connect Configuration Cable (Phono Stereo Connector) ................................................... 13 7.5.2 3-Pin Configuration Cable (option) ..................................................................................... 14 7.5.3 VPx Configuration Utility ..................................................................................................... 14 7.6 Shipping ....................................................................................................................................... 15 7.7 Log Term Storage ........................................................................................................................ 15 8.0 Sensor Modes ................................................................................................................................. 15 8.1 Fast Transmit Mode .................................................................................................................... 15 9.0 New Battery .................................................................................................................................... 16 10.0 Specs ............................................................................................................................................... 16 11.0 Probe List ........................................................................................................................................ 17 11.1 DS-VP-ESS-900-S-TEMP - VP Essentials 900MHz Temperature Sensor ...................................... 17 11.2 DS-VP-ESS-900-S-HUMI - VP Essentials 900MHz Humidity Sensor ............................................. 17 12.0 Accessory List .................................................................................................................................. 17 13.0 CheckPoint G4 Compatibility .......................................................................................................... 17 14.0 Troubleshooting .............................................................................................................................. 19 15.0 Revisions ......................................................................................................................................... 21 VP Essentials Sensor User Manual (Rev. A) 3 Mesa Labs, Inc. 12100 W. 6th Avenue Lakewood, CO 80228 USA Tel: 303-565-2724 monitoring.mesalabs.com [email protected] Figures 2-1 VP Essentials Product Label .................................................................................................................... 5 Table 3-1 Reference Documents ................................................................................................................... 6 Tables 4-1 VP Essentials Sensor Models ....................................................................................................... 7 Tables 5-1 Needed Infrastructure ................................................................................................................. 7 6-1 VP Essentials Sensor – Illustrating Position of Push Button and LED ..................................................... 8 Tables 6-1 Sensor Query Actions .................................................................................................................. 8 Tables 6-2 Changing Sensor Operating …

Text truncated - open the document above for the full version.

INSERT PEM_PKB-440 B 3.91 E .69 C 3.24 D 1.09 A 1.730±.020 K .782 L .668±.008 A J .067 DETAIL A SCALE 2 : 1 NOTES: FOR INSPECTION ONLY, PART FILES DO NOT MATCH AS MOLDED PART1. LETTERS LEADING THE DIMENSIONS ARE FOR EASE OF INSPECTION2. MATERIAL: FR3010-013689 PC/ABS WHITE3. PRESS IN INSERT PEM_PKB-440, WITH SCREW 440_250_SS_BO_91249A1054. REVISIONS REV.DESCRIPTIONDATEDRAWN AINITIAL RELEASE5/20/2022TH BADDED MODEL INFORMATION7/22/2022TH D C B A A B C D 1 2 3 4 5 6 7 8 8 7 6 5 4 3 2 1 DATEDRAWN MATERIAL: DWG NO. TITLE: REVISION SHEET 1 OF 2SIZE:SCALE:1:1 FINISH: ABS CM-000731 Essentials Sensor Enclosure - Back 12100 West 6th Avenue Lakewood, CO 80228 These drawings and specifications are the property of Mesa Laboratories, Inc. and shall not be reproduced, copied, or used for manufacture or sale of apparatus, in whole or in part, without the written approval of Mesa Laboratories, Inc UNLESS OTHERWISE SPECIFIED: DIMENSIONS ARE INCHES .X 0.030 .XX 0.010 .XXX 0.005 CORNER BREAK (EXTERNAL) (DEBURR) R.002 TO R.020 (OR EQUIVALENT) FILLET RADII (INTERNAL R.002 TO R.020) : 0.5 B 7/22/2022 T HAROVER B G .80 F 3.00 H 1.280±.015 I .28±.02 D C B A A B C D 1 2 3 4 5 6 7 8 8 7 6 5 4 3 2 1 DWG NO. TITLE: REVISION SHEET 2 OF 2SIZE:SCALE:2:1 CM-000731 Essentials Sensor Enclosure - Back 12100 West 6th Avenue Lakewood, CO 80228 B B FCC ID: UUYESS900 IC ID: 6891A-ESS900 For the product number and FCC/IC identifies, VP Essentials DS-VP-ESS-900-S does not use a stick on label but has this information embedded on part of the back enclosure. This information is part of the mold that produces the back enclosure.

= where: S = transmitter operating variables: must be blank if dB values are entered P = = 11.855 (dBm) - or - (mW) 7 G = = 5.42 (dBi) - or - (numeric gain) R = = (cm) ( PG)/(4*R 2 *  ) = (mW/cm 2 ) 15.32851206 3.48337 20 (mw) (gain) (cm) ()/(4**  3 ) = (mW/cm 2 ) ()/( ) = (mW/cm 2 ) S 5026.548246 POWER DENSITY ESTIMATIONS BASED ON POWER OUTPUT, ANTENNA GAIN, AND DISTANCE FROM ANTENNA maximum power density (mW/cm 2 ) (mW/cm 2 ) ) = 2 *  / 20 ( ( P G ) / ( 4 R 2  ) power input to the antenna --------------------------------- >> gain of the antenna - worst case -------------------------- >> distance to the center of the radiation of the antenna -- >> 3.1 53.39492736 0.010623 SSS 53.39492736 ) 400 (4*

Report Number: B20822D1 FCC Part 15 Subpart B and C; FCC 15.247; RSS-247; and RSS-GEN Test Report 900 MHz Sensor Model: Essentials; Part Number: DS-VP-ESS-900-S Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 23 FCC PART 15, SUBPART B and C; FCC 15.247; RSS-247 and RSS-GEN TEST REPORT For 900 MHz SENSOR Model: ESSENTIALS Part Number: DS-VP-ESS-900-S Prepared for MESA LABORATORIES, INC. 12100 WEST 6 TH AVENUE LAKEWOOD, COLORADO 80228 Prepared by: ____________________ JAMES ROSS Approved by: ____________________ KYLE FUJIMOTO COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: SEPTEMBER 16, 2022 REPORT APPENDICES TOTAL BODY A B C D E PAGES 23 2 2 2 11 80 120 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B20822D1 FCC Part 15 Subpart B and C; FCC 15.247; RSS-247; and RSS-GEN Test Report 900 MHz Sensor Model: Essentials; Part Number: DS-VP-ESS-900-S Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 23 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 5 1. PURPOSE 6 1.1 Decision Rule & Risk 7 2. ADMINISTRATIVE DATA 8 2.1 Location of Testing 8 2.2 Traceability Statement 8 2.3 Cognizant Personnel 8 2.4 Date Test Sample was Received 8 2.5 Disposition of the Test Sample 8 2.6 Abbreviations and Acronyms 8 3. APPLICABLE DOCUMENTS 9 4. DESCRIPTION OF TEST CONFIGURATION 10 4.1 Description of Test Configuration – Emissions 10 4.1.1 Cable Construction and Termination 11 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 12 5.1 EUT and Accessory List 12 5.2 Emissions Test Equipment 13 6. TEST SITE DESCRIPTION 14 6.1 Test Facility Description 14 6.2 EUT Mounting, Bonding and Grounding 14 6.3 Measurement Uncertainty 14 7. CHARACTERISTICS OF THE TRANSMITTER 15 7.1 Channel Number and Frequencies 15 7.2 Antenna 15 8. TEST PROCEDURES 16 8.1 RF Emissions 16 8.1.1 Conducted Emissions Test 16 8.1.2 Radiated Emissions Test 17 8.1.3 RF Emissions Test Results 18 8.1.4 Sample Calculations 19 8.2 20 dB Bandwidth 20 8.3 Peak Output Power 20 8.4 RF Antenna Conducted Test 20 8.5 RF Band Edges 21 8.6 Carrier Frequency Separation 21 8.7 Number of Hopping Frequencies 21 8.8 Average Time of Occupancy Test 21 8.9 Fundamental Field Strength (Duty Cycle Calculations) 22 8.10 Variation of the Input Power 22 8.11 99% Bandwidth 23 9. CONCLUSIONS 23 Report Number: B20822D1 FCC Part 15 Subpart B and C; FCC 15.247; RSS-247; and RSS-GEN Test Report 900 MHz Sensor Model: Essentials; Part Number: DS-VP-ESS-900-S Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 23 LIST OF APPENDICES APPENDIX TITLE A Laboratory Accreditations and Recognitions B Modifications to the EUT C Models Covered Under This Report D Diagrams and Charts  Test Setup Diagrams  Antenna and Effective Gain Factors E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Conducted Emissions Test Setup 2 Layout of the Semi-Anechoic Test Chamber LIST OF TABLES TABLE TITLE 1 Radiated Emission Results Report Number: B20822D1 FCC Part 15 Subpart B and C; FCC 15.247; RSS-247; and RSS-GEN Test Report 900 MHz Sensor Model: Essentials; Part Number: DS-VP-ESS-900-S Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 23 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. The client must not use this report to claim product certification, approval or endorsement by NVLAP, NIST or any agency of the U.S. government. Device Tested: 900 MHz Sensor Models: Essentials P/N: DS-VP-ESS-900-S S/N: N/A Product Description: The EUT a battery powered general purpose 902-928 MHz logging sensor measuring temperature, humidity, and discrete inputs . The integrated MCU/radio clocks are: 32.768 kHz and 48 MHz. The dimensions of the EUT is 4.4" (H) x 2.15" (W) x 1.2" (L). Modifications: The EUT was not modified to meet the specifications. Customer: Mesa Laboratories, Inc. 12100 West 6th Avenue Lakewood, Colorado 80228 Test Dates: August 17, 18 and 20, 2022 Test Specifications covered by accreditation: Test Specifications: Emissions requirements CFR Title 47, Part 15, Subpart B; and Subpart C, Sections 15.205, 15.209, and 15.247; RSS-247 and RSS-GEN Test Procedures: ANSI C63.4 and ANSI C63.10 Test Deviations: The test procedure was not deviated from during the testing. Report Number: B20822D1 FCC Part 15 Subpart B and C; FCC 15.247; RSS-247; and RSS-GEN Test Report 900 MHz Sensor Model: Essentials; Part Number: DS-VP-ESS-900-S Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 23 SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions, 150 kHz – 30 MHz Thi…

Text truncated - open the document above for the full version.

Report Number: B20822D2 FCC Part 15 Subpart B and C; FCC 15.247; RSS-247; and RSS-GEN Test Report 900 MHz Sensor Model: Essentials; Part Number: DS-VP-ESS-900-S Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 23 FCC PART 15, SUBPART B and C; FCC 15.247; RSS-247 and RSS-GEN TEST REPORT For 900 MHz SENSOR Model: ESSENTIALS Part Number: DS-VP-ESS-900-S Prepared for MESA LABORATORIES, INC. 12100 WEST 6 TH AVENUE LAKEWOOD, COLORADO 80228 Prepared by: ____________________ JAMES ROSS Approved by: ____________________ KYLE FUJIMOTO COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: SEPTEMBER 16, 2022 REPORT APPENDICES TOTAL BODY A B C D E PAGES 23 2 2 2 11 76 116 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B20822D2 FCC Part 15 Subpart B and C; FCC 15.247; RSS-247; and RSS-GEN Test Report 900 MHz Sensor Model: Essentials; Part Number: DS-VP-ESS-900-S Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 23 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 5 1. PURPOSE 6 1.1 Decision Rule & Risk 7 2. ADMINISTRATIVE DATA 8 2.1 Location of Testing 8 2.2 Traceability Statement 8 2.3 Cognizant Personnel 8 2.4 Date Test Sample was Received 8 2.5 Disposition of the Test Sample 8 2.6 Abbreviations and Acronyms 8 3. APPLICABLE DOCUMENTS 9 4. DESCRIPTION OF TEST CONFIGURATION 10 4.1 Description of Test Configuration – Emissions 10 4.1.1 Cable Construction and Termination 11 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 12 5.1 EUT and Accessory List 12 5.2 Emissions Test Equipment 13 6. TEST SITE DESCRIPTION 14 6.1 Test Facility Description 14 6.2 EUT Mounting, Bonding and Grounding 14 6.3 Measurement Uncertainty 14 7. CHARACTERISTICS OF THE TRANSMITTER 15 7.1 Channel Number and Frequencies 15 7.2 Antenna 15 8. TEST PROCEDURES 16 8.1 RF Emissions 16 8.1.1 Conducted Emissions Test 16 8.1.2 Radiated Emissions Test 17 8.1.3 RF Emissions Test Results 18 8.1.4 Sample Calculations 19 8.2 20 dB Bandwidth 20 8.3 Peak Output Power 20 8.4 RF Antenna Conducted Test 20 8.5 RF Band Edges 21 8.6 Carrier Frequency Separation 21 8.7 Number of Hopping Frequencies 21 8.8 Average Time of Occupancy Test 21 8.9 Fundamental Field Strength (Duty Cycle Calculations) 22 8.10 Variation of the Input Power 22 8.11 99% Bandwidth 23 9. CONCLUSIONS 23 Report Number: B20822D2 FCC Part 15 Subpart B and C; FCC 15.247; RSS-247; and RSS-GEN Test Report 900 MHz Sensor Model: Essentials; Part Number: DS-VP-ESS-900-S Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 23 LIST OF APPENDICES APPENDIX TITLE A Laboratory Accreditations and Recognitions B Modifications to the EUT C Models Covered Under This Report D Diagrams and Charts  Test Setup Diagrams  Antenna and Effective Gain Factors E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Conducted Emissions Test Setup 2 Layout of the Semi-Anechoic Test Chamber LIST OF TABLES TABLE TITLE 1 Radiated Emission Results Report Number: B20822D2 FCC Part 15 Subpart B and C; FCC 15.247; RSS-247; and RSS-GEN Test Report 900 MHz Sensor Model: Essentials; Part Number: DS-VP-ESS-900-S Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 23 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. The client must not use this report to claim product certification, approval or endorsement by NVLAP, NIST or any agency of the U.S. government. Device Tested: 900 MHz Sensor Models: Essentials P/N: DS-VP-ESS-900-S S/N: N/A Product Description: The EUT a battery powered general purpose 902-928 MHz logging sensor measuring temperature, humidity, and discrete inputs . The integrated MCU/radio clocks are: 32.768 kHz and 48 MHz. The dimensions of the EUT is 4.4" (H) x 2.15" (W) x 1.2" (L). Modifications: The EUT was not modified to meet the specifications. Customer: Mesa Laboratories, Inc. 12100 West 6th Avenue Lakewood, Colorado 80228 Test Dates: August 18, 19, 20 and 22, 2022 Test Specifications covered by accreditation: Test Specifications: Emissions requirements CFR Title 47, Part 15, Subpart B; and Subpart C, Sections 15.205, 15.209, and 15.247; RSS-247 and RSS-GEN Test Procedures: ANSI C63.4 and ANSI C63.10 Test Deviations: The test procedure was not deviated from during the testing. Report Number: B20822D2 FCC Part 15 Subpart B and C; FCC 15.247; RSS-247; and RSS-GEN Test Report 900 MHz Sensor Model: Essentials; Part Number: DS-VP-ESS-900-S Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 23 SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions, 150 kHz – 30 MHz…

Text truncated - open the document above for the full version.

Antenna Gain for FCC ID: UUYESS900, IC: 6891A-ESS900 The antenna gain is 5.42 dBi. This is based on the largest field strength to conducted power output differential. The highest differential was for the middle channel of the G4 configuration which had a conducted output power of 11.255 dBm and a field strength of 111.87 dBuV/m at 3 meters. Expected field strength with a 0 dBi antenna = 11.255 dBm + 95.2 = 106.455 dBuV/m Antenna gain = 111.87 dBuV/m (measured) – 106.455 dBuV/m (theoretical assuming 0 dBi gain) = 5.42 dBi
