UUYVPFLXAP900 MHz Access Point

Hardware User Manual ViewPoint Access Point Mesa Laboratories, Inc. Document Number: DS-VP-900-AP-MNL Document Revision: A Revision Date: Author (Group): Mesa Laboratories, Inc. Product Group: Continuous Monitoring – Hardware Document Type: User Manual Product/System Name: ViewPoint Access Point Document Number: DS-900-AP-MNL Document Revision: A Revision Date: Mesa Laboratories, Inc. – 12100 West 6 th Ave. Lakewood, CO 80228 – Phone 303.987.8000 Page 2 of 14 Revision History This document is revision-controlled, and a formal revision history will be maintained herein. All changes to the approved document must be dated, reviewed, and approved by designated representatives via Mesa Laboratories, Inc. (MLI) document and revision control system(s) and in accordance with all applicable Standard Operating Procedures (SOP). REV DATE CHANGE SUMMARY AUTHOR A Initial Release Z. Sparks Product Group: Continuous Monitoring – Hardware Document Type: User Manual Product/System Name: ViewPoint Access Point Document Number: DS-900-AP-MNL Document Revision: A Revision Date: Mesa Laboratories, Inc. – 12100 West 6 th Ave. Lakewood, CO 80228 – Phone 303.987.8000 Page 3 of 14 Product Disclaimer Mesa Laboratories, Inc., herein referred to as MLI, is not liable for any damage or damages, of any kind, including, but not limited to direct, indirect, punitive, and consequential damages, that may occur from the proper or improper installation, use, or operation, normal or otherwise, of MLI equipment, product(s), materials, or services. The contents of this document are for informational purposes only, and may not be reproduced, redistributed, copied, modified, altered, sold, published, distributed, or broadcast in anyway without the expressed written consent of MLI. This document is not an expressed or implied warranty or agreement, and MLI makes no representation or warranties, of any kind, expressed or implied, unless otherwise specified in writing. The installation, use, and operation of MLI equipment, product(s), materials, or services are solely at the risk of the end-user. Product Group: Continuous Monitoring – Hardware Document Type: User Manual Product/System Name: ViewPoint Access Point Document Number: DS-900-AP-MNL Document Revision: A Revision Date: Mesa Laboratories, Inc. – 12100 West 6 th Ave. Lakewood, CO 80228 – Phone 303.987.8000 Page 4 of 14 Table of Contents 1. Regulatory Compliance ....................................................................................................................... 5 1.1. FCC Notice .................................................................................................................................. 5 1.1.1. RF Exposure Notice ...................................................................................................... 5 1.2. Industry Canada ......................................................................................................................... 5 1.2.1. Radiation Exposure Notice: .......................................................................................... 6 2. Introduction ........................................................................................................................................ 6 2.1. System Description ..................................................................................................................... 6 3. Getting Started .................................................................................................................................... 7 3.1. Equipment Details ...................................................................................................................... 7 3.2. Indicator LEDs ............................................................................................................................ 8 3.3. Configuration ............................................................................................................................. 9 3.3.1. Generation Configuration ............................................................................................ 9 3.3.2. Access Point Configuration Utility ............................................................................... 9 3.4. Installation ............................................................................................................................... 12 4. Contact Information .......................................................................................................................... 12 5. Figures List ........................................................................................................................................ 13 Product Group: Continuous Monitoring – Hardware Document Type: User Manual Product/System Name: ViewPoint Access Point Document Number: DS-900-AP-MNL Document Revision: A Revision Date: Mesa Laboratories, Inc. – 12100 West 6 th Ave. Lakewood, CO 80228 – Phone 303.987.8000 Page 5 of 14 1. Regulatory Compliance 1.1. FCC Notice The ViewPoint Access Point complies with CFR Title 47 Part 15 (FCC) requirements. The Access Point operation was verified through testing to not cause harmful interference and accepts any interference received, including but not limited to interference that may cause undesired operation. Th Access Point has been tested and found to comply with the limits for Class A digital device pursuant to CFR Title 47 Part 15 (FCC) requirements. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause interference to radio communications. Operation of this equipment in a residential area is likely to cause interference in which case the user will be required to correct the interference at his own expense. The end user is cautioned that chang…

Text truncated - open the document above for the full version.

Top View of the EUT - External Antenna Enclosure Bottom View of the EUT - External Antenna Enclosure Side View #1 of the EUT - External Antenna Enclosure Side View #2 of the EUT - External Antenna Enclosure Side View #3 of the EUT - External Antenna Enclosure Side View #4 of the EUT - External Antenna Enclosure

Top View of the EUT - Internal Antenna Enclosure Bottom View of the EUT - Internal Antenna Enclosure Side View #1 of the EUT - Internal Antenna Enclosure Side View #2 of the EUT -Internal Antenna Enclosure Side View #3 of the EUT -Internal Antenna Enclosure Side View 4 of the EUT -Internal Antenna Enclosure

The FCC label will be affixed to the back panel of the Access Point using a permanent acrylic based adhesive.

Top View of the RF Board Top View of the RF Board - View #2 Bottom View of the RF Board Inside View of the EUT Top View of the PCB for the EUT Top View of the PCB - Closeup #1 Top View of the PCB - Closeup #2 Top View of the PCB - Closeup #3 Top View of the PCB - Closeup #4 Top View of the PCB - Closeup #5 Top View of the PCB - Closeup #6 Bottom View of the PCB with RF Board Bottom View of the PCB with No RF Board Bottom View of the PCB - Closeup #1 Bottom View of the PCB - Closeup #2 Bottom View of the PCB - Closeup #3 Bottom View of the PCB - Closeup #4 View of the Small Board - Top Side View of the Large Board - Top Side

= where: S = transmitter operating variables: must be blank if dB values are entered P = = 10.488 (dBm) - or - (mW) 7 G = = 5.4 (dBi) - or - (numeric gain) R = = (cm) ( PG)/(4*R 2 *  ) = (mW/cm 2 ) 11.18922482 3.46737 20 (mw) (gain) (cm) ()/(4**  3 ) = (mW/cm 2 ) ()/( ) = (mW/cm 2 ) S 5026.548246 POWER DENSITY ESTIMATIONS BASED ON POWER OUTPUT, ANTENNA GAIN, AND DISTANCE FROM ANTENNA maximum power density (mW/cm 2 ) (mW/cm 2 ) ) = 2 *  / 20 ( ( P G ) / ( 4 R 2  ) power input to the antenna --------------------------------- >> gain of the antenna - worst case -------------------------- >> distance to the center of the radiation of the antenna -- >> 3.1 38.79716573 0.007718 SSS 38.79716573 ) 400 (4*

Report Number: B30619D1 FCC Part 15 Subpart B and C; FCC 15.247; RSS-247; and RSS-GEN Test Report 900 MHz Access Point Model: ViewPoint Access Point 1.1 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 L ake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 24 FCC PART 15, SUBPART B and C; FCC 15.247; RSS-247 and RSS-GEN TEST REPORT For 900 MHz ACCESS POINT Model: VIEWPOINT ACCESS POINT 1.1 HVIN: DS-VP-900-AP Prepared for MESA LABORATORIES, INC. 12100 WEST 6 TH AVENUE LAKEWOOD, COLORADO 80228 Prepared by: ____________________ Approved by: ____________________ -$0(65266 COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: JULY 8, 2023 REPORT APPENDICES TOTAL BODY A B C D E PAGES 24 2 2 2 31 174 235 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. .</()8-,0272 Report Number: B30619D1 FCC Part 15 Subpart B and C; FCC 15.247; RSS-247; and RSS-GEN Test Report 900 MHz Access Point Model: ViewPoint Access Point 1.1 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 24 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 5 1. PURPOSE 6 1.1Decision Rule & Risk 7 2. ADMINISTRATIVE DATA 8 2.1 Location of Testing 8 2.2 Traceability Statement 8 2.3 Cognizant Personnel 8 2.4 Date Test Sample was Received 8 2.5 Disposition of the Test Sample 8 2.6 Abbreviations and Acronyms 8 3. APPLICABLE DOCUMENTS 9 4. DESCRIPTION OF TEST CONFIGURATION 10 4.1 Description of Test Configuration – Emissions 10 4.1.1 Cable Construction and Termination 11 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 12 5.1EUT and Accessory List 12 5.2 Emissions Test Equipment 13 6. TEST SITE DESCRIPTION 14 6.1 Test Facility Description 14 6.2 EUT Mounting, Bonding and Grounding 14 6.3 Measurement Uncertainty 14 7. CHARACTERISTICS OF THE TRANSMITTER 15 7.1 Channel Number and Frequencies 15 7.2 Antenna Gain 15 8. TEST PROCEDURES 16 8.1 RF Emissions 16 8.1.1 Conducted Emissions Test 16 8.1.2 Radiated Emissions Test 17 8.1.3 RF Emissions Test Results 18 8.1.4 Sample Calculations 20 8.2 20 dB Bandwidth 21 8.3 Peak Output Power 21 8.4 RF Antenna Conducted Test 21 8.5 RF Band Edges 22 8.6 Carrier Frequency Separation 22 8.7 Number of Hopping Frequencies 22 8.8 Average Time of Occupancy Test 22 8.9 Fundamental Field Strength (Duty Cycle Calculations) 23 8.10 Variation of the Input Power 23 8.11 99% Bandwidth 24 9. CONCLUSIONS 24 Report Number: B30619D1 FCC Part 15 Subpart B and C; FCC 15.247; RSS-247; and RSS-GEN Test Report 900 MHz Access Point Model: ViewPoint Access Point 1.1 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 24 LIST OF APPENDICES APPENDIX TITLE A Laboratory Accreditations and Recognitions B Modifications to the EUT C Models Covered Under This Report D Diagrams and Charts xTest Setup Diagrams xAntenna and Effective Gain Factors E Data Sheets LIST OF FIGURES FIGURETITLE 1 Conducted Emissions Test Setup 2 Layout of the Semi-Anechoic Test Chamber LIST OF TABLES TABLETITLE 1 Conducted Emission Results 2 Radiated Emission Results Report Number: B30619D1 FCC Part 15 Subpart B and C; FCC 15.247; RSS-247; and RSS-GEN Test Report 900 MHz Access Point Model: ViewPoint Access Point 1.1 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 24 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. The client must not use this report to claim product certification, approval or endorsement by NVLAP, NIST or any agency of the U.S. government. Device Tested: 900 MHz Access Point Models: ViewPoint Access Point 1.1 HVIN: DS-VP-900-AP S/N: B6900004 Product Description: Line powered general purpose 902-928 MHz Access Point that communicates with 902-928 MHz wireless sensors which measure environmental conditions. The integrated MCU/radio clocks are: 32.768 kHz and 48 MHz. The dimensions of the EUT are 5.25" (L) x 5.25" (W) x 1.75" (H). Modifications: The EUT was not modified to meet the specifications. Customer: Mesa Laboratories, Inc. 12100 West 6th Avenue Lakewood, Colorado 80228 Test Dates: June 6, 7, 8, 16, and 19, 2023 Test Specifications covered by accreditation: Test Specifications : Emissions requirements CFR Title 47, Part 15, Subpart B; and Subpart C, Sections 15.205, 15.207, 15.209, and 15.247; RSS-247 and RSS-GEN Test Procedures: ANSI C63.4 and ANSI C63.10 Test Deviations: The test procedure was not deviated from during the testing. Report Number: B30619D1 FCC Part 15 Subpart B and C; FCC 15.247; RSS-247; and RSS-GEN Test Report 900 MHz Access Point Model: ViewPoint Access Point 1.1 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive New bury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pas…

Text truncated - open the document above for the full version.

Report Number: B30619D1 FCC Part 15 Subpart B and C; FCC 15.247; RSS-247; and RSS-GEN Test Report 900 MHz Access Point Model: ViewPoint Access Point 1.1 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page E1 APPENDIX E DATA SHEETS Report Number: B30619D1 FCC Part 15 Subpart B and C; FCC 15.247; RSS-247; and RSS-GEN Test Report 900 MHz Access Point Model: ViewPoint Access Point 1.1 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page E2 RADIATED EMISSIONS DATA SHEETS Report Number: B30619D1 FCC Part 15 Subpart B and C; FCC 15.247; RSS-247; and RSS-GEN Test Report 900 MHz Access Point Model: ViewPoint Access Point 1.1 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page E3 Report Number: B30619D1 FCC Part 15 Subpart B and C; FCC 15.247; RSS-247; and RSS-GEN Test Report 900 MHz Access Point Model: ViewPoint Access Point 1.1 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page E4 The frequencies that were over the Class B limit were then retested to the Class A limits shown on the next page with the transmit function disabled because the EUT is a Class A device. Report Number: B30619D1 FCC Part 15 Subpart B and C; FCC 15.247; RSS-247; and RSS-GEN Test Report 900 MHz Access Point Model: ViewPoint Access Point 1.1 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page E5 Report Number: B30619D1 FCC Part 15 Subpart B and C; FCC 15.247; RSS-247; and RSS-GEN Test Report 900 MHz Access Point Model: ViewPoint Access Point 1.1 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page E6 Report Number: B30619D1 FCC Part 15 Subpart B and C; FCC 15.247; RSS-247; and RSS-GEN Test Report 900 MHz Access Point Model: ViewPoint Access Point 1.1 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page E7 The frequencies that were over the Class B limit were then retested to the Class A limits shown on the next page with the transmit function disabled because the EUT is a Class A device. Report Number: B30619D1 FCC Part 15 Subpart B and C; FCC 15.247; RSS-247; and RSS-GEN Test Report 900 MHz Access Point Model: ViewPoint Access Point 1.1 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page E8 Report Number: B30619D1 FCC Part 15 Subpart B and C; FCC 15.247; RSS-247; and RSS-GEN Test Report 900 MHz Access Point Model: ViewPoint Access Point 1.1 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page E9 Report Number: B30619D1 FCC Part 15 Subpart B and C; FCC 15.247; RSS-247; and RSS-GEN Test Report 900 MHz Access Point Model: ViewPoint Access Point 1.1 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page E10 The frequencies that were over the Class B limit were then retested to the Class A limits shown on the next page with the transmit function disabled because the EUT is a Class A device. Report Number: B30619D1 FCC Part 15 Subpart B and C; FCC 15.247; RSS-247; and RSS-GEN Test Report 900 MHz Access Point Model: ViewPoint Access Point 1.1 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page E11 Report Number: B30619D1 FCC Part 15 Subpart B and C; FCC 15.247; RSS-247; and RSS-GEN Test Report 900 MHz Access Point Model: ViewPoint Access Point 1.1 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page E12 Report Number: B30619D1 FCC Part 15 Subpart B and C; FCC 15.247; RSS-247; and RSS-GEN Test Report 900 MHz Access Point Model: ViewPoint Access Point 1.1 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page E13 The frequencies that were over the Class B limit were then retested to the Class A limits shown on the next page with the transmit function disabled because the EUT is a Class A device. Report Number: B30619D1 FCC Part 15 Subpart B and C; FCC 15.247; RSS-247; and RSS-GEN Test Report 900 MHz Access Point Model: ViewPoint Access Point 1.1 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lak…

Text truncated - open the document above for the full version.

Mesa Laboratories, Inc. – 12100 West 6 th Ave. Lakewood, CO 80228 – Phone 303.987.8000 Page 1 of 1 ViewPoint Access Point Internal Antenna Technical Description: 1. Construction: Quarter Wavelength. Printed board trace. 2. Type of Antenna: Inverted-F 3. Connector Type: Antenna is permanently connected to both the ground plane and a feed point that has been tuned for a 50 Ohm impedance. 4. Mounting: Antenna design is printed directly onto the circuit board. 5. Gain (dBi): + 5.4 dBi

W1063.B (2/14)1 pulseelectronics.com/products/antennas Wireless External Antenna for 900 MHz Applications Pulse Part Number W1063 San Diego, CA 858 674 8100 Vancouver, WA 360 944 7551Europe 49 7032 7806 0Asia 86 755 33966678North Asia 886 3 4356768China 86 512 6807 9998 D R A F T Part Number Frequency [MHz] Gain [dBi] Impedance [Nom]VSWRPolarizationRadiationColor W1063868 - 9283.050 Ω<2.5VerticalOmniBlack Features -Ideal for lower frequency wireless applications in the ISM 900 MHz band -Omni-directional radiation pattern provides broad 360° coverage -One-eighth wavelength dipole configuration -Connection and color options easily integrate with OEM designs -Black Connector -Reverse SMA Male Weight. . . . . . . . . . . . . . . . . . . . . . .25.6 grams Carton . . . . . . . . . . . . . . . . . 20/bag, 500/carton Dimensions [in / mm] Unless otherwise specified, all tolerances are ± .010 / 0.25 Electrical Specifications @ 25 ºC Note: This part number is lead-free and RoHS compliant. No additional suffix or identifier is required 2 pulseelectronics.com/products/antennas Wireless External Antenna for 900 MHz Applications Pulse Part Number W1063 W1063.B (2/14)2 pulseelectronics.com/products/antennas 2 pulseelectronics.com/products/antennas For More Information Pulse Worldwide Headquarters 12220 World Trade Drive San Diego, CA 92128 U.S.A. Tel: 858 674 8100 Fax: 858 674 8262 Larsen Brand Antennas 3611 NE 112th Avenue Vancouver, WA 98682 USA Tel: 360 944 7551 Fax: 369 944 7556 Europe Headquarters Pulse GmbH & Do, KG Zeppelinstrasse 15 Herrenberg Germany Tel: 49 7032 7806 0 Fax: 49 7032 7806 135 Asia Headquarters B402, Shenzhen Academy of Aerospace Technology Bldg. 10th Kejinan Road, High-Tech Zone Nanshan District, Shenzen, PR China 518057 Tel: 86 755 33966678 Fax: 86 755 33966700 Pulse North Asia 3F, No. 198, Zhongyuan Road Zhongli City, Taoyuan County 320 Taiwan R. O. C. Tel: 886 3 4356768 Fax: 886 3 4356823 Pulse (Suzhou) Wireless Products Co, Inc. 99 Huo Ju Road, (#29 Bldg, 4th Phase) Suzhou New District Science & Tech Industrial Park Jiangsu Province, Suzhou 215009 PR China Tel: 86 512 6807 9998 Fax: 86 512 6809 8023 Performance warranty of products offered on this data sheet is limited to the parameters specified. Data is subject to change without notice. Other brand and product names mentioned herein may be trademarks or registered trademarks of their respective owners. © Copyright, 2014. Pulse Electronics, Inc. All rights reserved. D R A F T Application Notes Omni-directional antennas provide a uniform, donut- shaped, 360 ̊ radiation pattern. The omni-directional pattern is suitable for point-to-multipoint broadcasting in all directions. The antenna is primarily used for WLAN applications. However, it can also be used for a variety of other applications within the specified frequency range. When used as an access point, the antenna is ideally located at the center of the coverage Horizontal Position Gain Performance W1063 Vertical Position

FRONT VIEW MESA LABORATORIES, INC. 900 MHz ACCESS POINT MODEL: VIEW POINT ACCESS POINT 1.1 EXTERNAL POWER – INTERNAL ANTENNA FCC SUBPART B AND C; RSS-GEN and RSS-247 – RADIATED EMISSIONS – BELOW 1 GHz PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS REAR VIEW MESA LABORATORIES, INC. 900 MHz ACCESS POINT MODEL: VIEWPOINT ACCESS POINT 1.1 EXTERNAL POW ER – INTERNAL ANTENNA FCC SUBPART B AND C; RSS-GEN and RSS-247 – RADIATED EMISSIONS – BELOW 1 GHz PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS FRONT VIEW MESA LABORATORIES, INC. 900 MHz ACCESS POINT MODEL: VIEWPOINT ACCESS POINT 1.1 EXTERNAL POWER – INTERNAL ANTENNA FCC SUBPART B AND C; RSS-GEN and RSS-247 – RADIATED EMISSIONS – ABOVE 1 GHz PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS REAR VIEW MESA LABORATORIES, INC. 900 MHz ACCESS POI NT MODEL: VIEWPOINT ACCESS POINT 1.1 EXTERNAL POWER – INTERNAL ANTENNA FCC SUBPART B AND C; RSS-GEN and RSS-247 – RADIATED EMISSIONS – ABOVE 1 GHz PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS FRONT VIEW MESA LABORATORIES, INC. 900 MHz ACCESS POINT MODEL: VIEW POINT ACCESS POINT 1.1 EXTERNAL POWER – EXTERNAL ANTENNA FCC SUBPART B AND C; RSS-GEN and RSS-247 – RADIATED EMISSIONS – BELOW 1 GHz PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS REAR VIEW MESA LABORATORIES, INC. 900 MHz ACCESS POINT MODEL: VIEW POINT ACCESS POINT 1.1 EXTERNAL POWER – EXTERNAL ANTENNA FCC SUBPART B AND C; RSS-GEN and RSS-247 – RADIATED EMISSIONS – ABOVE 1 GHz PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS FRONT VIEW MESA LABORATORIES, INC. 900 MHz ACCESS POINT MODEL: VIEW POINT ACCESS POINT 1.1 EXTERNAL POWER – EXTERNAL ANTENNA FCC SUBPART B AND C; RSS-GEN and RSS-247 – RADIATED EMISSIONS – ABOVE 1 GHz PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS REAR VIEW MESA LABORATORIES, INC. 900 MHz ACCESS POINT MODEL: VIEW POINT ACCESS POINT 1.1 EXTERNAL POWER – EXTERNAL ANTENNA FCC SUBPART B AND C; RSS-GEN and RSS-247 – RADIATED EMISSIONS – BELOW 1 GHz PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS FRONT VIEW MESA LABORATORIES, INC. 900 MHz ACCESS POINT MODEL: VIEW POINT ACCESS POINT 1.1 POE POWER – INTERNAL ANTENNA FCC SUBPART B AND C; RSS-GEN and RSS-247 – RADIATED EMISSIONS – BELOW 1 GHz PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS REAR VIEW MESA LABORATORIES, INC. 900 MHz ACCESS POINT MODEL: VIEW POINT ACCESS POINT 1.1 POE POWER – INTERNAL ANTENNA FCC SUBPART B AND C; RSS-GEN and RSS-247 – RADIATED EMISSIONS – BELOW 1 GHz PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS FRONT VIEW MESA LABORATORIES, INC. 900 MHz ACCESS POIN T MODEL: VIEWPOINT ACCESS POINT 1.1 POE POWER – INTERNAL ANTENNA FCC SUBPART B AND C; RSS-GEN and RSS-247 – RADIATED EMISSIONS – ABOVE 1 GHz PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS REAR VIEW MESA LABORATORIES, INC. 900 MHz ACCESS POI NT MODEL: VIEWPOINT ACCESS POINT 1.1 POE POWER – INTERNAL ANTENNA FCC SUBPART B AND C; RSS-GEN and RSS-247 – RADIATED EMISSIONS – ABOVE 1 GHz PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS FRONT VIEW MESA LABORATORIES, INC. 900 MHz ACCESS POINT MODEL: VIEW POINT ACCESS POINT 1.1 POE POWER – EXTERNAL ANTENNA FCC SUBPART B AND C; RSS-GEN and RSS-247 – RADIATED EMISSIONS – BELOW 1 GHz PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS REAR VIEW MESA LABORATORIES, INC. 900 MHz ACCESS POINT MODEL: VIEW POINT ACCESS POINT 1.1 POE POWER – EXTERNAL ANTENNA FCC SUBPART B AND C; RSS-GEN and RSS-247 – RADIATED EMISSIONS – BELOW 1 GHz PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS FRONT VIEW MESA LABORATORIES, INC. 900 MHz ACCESS POINT MODEL: VIEW POINT ACCESS POINT 1.1 POE POWER – EXTERNAL ANTENNA FCC SUBPART B AND C; RSS-GEN and RSS-247 – RADIATED EMISSIONS – ABOVE 1 GHz PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS REAR VIEW MESA LABORATORIES, INC. 900 MHz ACCESS POINT MODEL: VIEW POINT ACCESS POINT 1.1 POE POWER – EXTERNAL ANTENNA FCC SUBPART B AND C; RSS-GEN and RSS-247 – RADIATED EMISSIONS – ABOVE 1 GHz PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS FRONT VIEW MESA LABORATORIES, INC. 900 MHz ACCESS POINT MODEL: VIEW POINT ACCESS POINT 1.1 EXTERNAL POWER – EXTERNAL ANTENNA FCC SUBPART B AND C; RSS-GEN and RSS-247 – CONDUCTED EMISSIONS PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS REAR VIEW MESA LABORATORIES, INC. 900 MHz ACCESS POINT MODEL: VIEW POINT ACCESS POINT 1.1 EXTERNAL POWER – EXTERNAL ANTENNA FCC SUBPART B AND C; RSS-GEN and RSS-247 – CONDUCTED EMISSIONS PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS FRONT VIEW MESA LABORATORIES, INC. 900 MHz ACCESS POINT MODEL: VIEW POINT ACCESS POINT 1.1 EXTERNAL POWER – INTERNAL ANTENNA FCC SUBPART B AND C; RSS-GEN and RSS-247 – CONDUCTED EMISSIONS PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS REAR VIEW MESA LABORATORIES, INC. 900 MHz ACCESS POINT MODEL: VIEW POINT ACCESS POINT 1.1 EXTERNAL POWER – INTERNAL ANTENNA FCC SUBPART B AND C; RSS-GEN and RSS-247 – CONDUCTED EMISSIONS PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS FRONT VIEW MESA LABORATORIES, INC. 900 MHz ACCESS POINT MODEL: VIEW POINT ACCESS POINT 1.1 POE POWER – INTERNAL ANTENNA FCC SUBPART B AND C; RSS-GEN and RSS-247 – CONDUCTED EMISSIONS PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS REAR VIEW MESA LABORATORIES, INC. 900 MHz ACCESS POINT MODEL: VIEW POINT ACCESS POINT 1.1 POE POWER – INTERNAL ANTENNA FCC SUBPART B AND C; RSS-GEN and RSS-247 – CONDUCTED EMISSIONS PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS FRONT VIEW MESA LABORATORIES, INC. 900 MHz ACCESS POINT MODEL: VIEW POINT ACCESS POINT 1.1 POE POWER – EXTERNAL ANTENNA FCC SUBPART B AND C; RSS-GEN and RSS-247 – CONDUCTED EMISSIONS PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS REAR VIEW MESA LABORATORIES, INC. 900 MHz ACCESS POINT MODEL: VIEW POINT ACCESS POINT …
