UVS-WP1PTilt Sensor Transmitter

1 1 IOM00057-04 9470 Meridian Way West Chester, Ohio 45069 Phone: 513-874-3195 Fax: 513-874-3269 www.ventekllc.com Wireless Tilt Monitor Quick Setup Sheet WP1P/WP2P Page 1 of 3 Wireless That Makes Perfect Sense Sensor Temperature Range: -20 o C to 70 o C (-4 o F to 158 o F) Environmental Classification: NEMA 4X Transmission Frequency WP1P = 418 MHz WP2P = 433 MHz Sensor Transmission Rate: 10 to 17 seconds (random) Parts List: Quantity Part 1 WPxP Tilt Monitor with bracket 1 Magnetic Key Fob 2 1” x 2” (25 x 50mm) Dual-Lock Strips 4 #6 x 1” Self-drilling Screw Description: The WP1P/WP2P Wireless Tilt Monitor is a low-power device that monitors discrete angular position and maintains a count of tilt events. The count is incremented when the sensor is tilted forward from a vertical orientation as shown below. The transmitter sends data at random intervals between 10 and 17 seconds. On state changes, it transmits the updated data within one second. The battery will typically last from 2 to 5 years depending on angular position change frequency. Mounting: The sensor must be installed as shown below or it may not accurately indicate position. The sensor bottom should be horizontal as shown in the center figure. Option #1: Attach the Wireless Tilt Monitor to the tilting surface using the provided Dual-Lock strips. Option #2: Attach the Wireless Tilt Monitor to the tilting surface using the provided #6 x 1” self-drilling screws or other suitable screws. Option #3: Attach the Wireless Tilt Monitor to the tilting surface using the optional Mag-Mount Universal Mounting Bracket (P/N# UMB-S2N - not shown). 2 2 IOM00057-04 9470 Meridian Way West Chester, Ohio 45069 Phone: 513-874-3195 Fax: 513-874-3269 www.ventekllc.com Wireless Tilt Monitor Quick Setup Sheet WP1P/WP2P Page 2 of 3 Wireless That Makes Perfect Sense Monitor Setup: 1. Loosen the four cover screws to remove cover. Install battery to turn power on (circuit board is labeled to indicate correct polarity). 2. Press the transmitter’s service button to configure it to the sensor’s specifications. 3. When the monitor system is active, the LED will flash every 10 to 17 seconds. Pressing the service button will immediately flash the LED to indicate the functionality of the monitor. 4. Replace the cover and tighten all four cover screws. e-Guard OPC Data Manager - Quick Sensor Setup: 1. Start e-Guard OPC Data Manager (consult installation instructions if software is not already installed). 2. Click the Server Settings menu, then Device Registration in the upper left corner. 3. Press the transmitter’s service button to register the sensor. Its serial number will appear in the SN column with default values appearing in the other columns (serial numbers are listed sequentially). 4. Modify e-Guard software settings as desired: Column Default Value Permissible Entries Topic Sensor serial no. Alphanumeric characters (25 max; blanks and dashes ok) representing sensor name Active Yes Yes = e-Guard OPC Data Manager publishes sensor data No = e-Guard OPC Data Manager does not publish sensor data Dashboard Yes Yes = Sensor data is logged in the database No = Sensor data is not logged in the database ShowTile Yes Yes = Sensor data is displayed on a tile in the e-Guard Dashboard No = Sensor data is not displayed in the e-Guard Dashboard Baseline 0 Integer value (6 digits max) representing the baseline measurement value for the specific sensor (not used for this sensor type). TransmitFrequency 12 DO NOT CHANGE – this value is used to calculate sensor efficiency SaveInterval 1 Integer value between 0 and 32,767 specifying the data logging interval for the VenTek Sensor Database in minutes. A zero (0) value will log every data packet. 5. Close the Registered Devices window when finished. The window will close automatically after 1 minute of inactivity. 6. Leave e-Guard OPC Data Manager running to continue data logging. Close the program to end. VenTek eGuard Software Sensor Configuration: This sensor is a standard device, so the software should already be programmed with the proper information. If the software does not recognize the sensor, verify that both sensor types below appear in the software by clicking the Server Settings menu, then Type Settings in the upper left corner: Type LoRaw HiRaw LoEng HiEng Units LoRaw2 HiRaw2 LoEng2 HiEng2 Units2 ServiceBit Legacy 74 0 0 0 0 Counts 0 0 0 0 Units 73 0 03 0 0 0 0 Counts 0 0 0 0 Units 73 0 Resetting the Count: 1. Press and hold the blue service button. 2. Pass the Magnetic Key Fob slowly across the sensor side opposite service button (see central figure on Page 1). The reset switch is internal and magnetically activated. 3. Release the blue service button. The sensor will begin transmitting in approximately one minute. 3 3 IOM00057-04 9470 Meridian Way West Chester, Ohio 45069 Phone: 513-874-3195 Fax: 513-874-3269 www.ventekllc.com Wireless Tilt Monitor Quick Setup Sheet WP1P/WP2P Page 3 of 3 Wireless That Makes Perfect Sense Wireless Communication Conditions of Use: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by VenTek, LLC for compliance could void the user's authority to operate the equipment. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that permitted for successful communication. This device has been designed to operate with the antennas listed below, and having a maximum gain of 2 dBi. Antennas not included in this list or having a gain greater than 2 dBi are strictly prohibited for use with this device. The required antenna impedance is 50 ohms. ANT1N44RM (included with Tilt Position Monitor) ANT1N44…

Text truncated - open the document above for the full version.

Letter of Agency Date: November 26, 2007 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: Please be advised that VenTek, LLC authorizes D.L.S. Electronic Systems, Inc. to act on our behalf, until otherwise notified, for applications submitted to American Telecommunications Certification Body, Inc. (ATCB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse ACT of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002(b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you for your attention to this matter. Signatory, Arnom C. Rowe EMC ENGINEER EMC-001375-NE D.L.S. Electronic Systems, Inc. FCC Labeling Requirements and Information Date: November 26, 2007 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: FCC Labeling Requirements FCC ID: UVS-WP1P The following label information is required by the FCC Rules and Regulations for certified devices. Also attached, please find marketing information required by the FCC Rules and Regulations. Thank you for your attention to these matters. Sincerely, Arnom C. Rowe EMC ENGINEER EMC-001375-NE D.L.S. Electronic Systems, Inc. Modification Letter Date: November 26, 2007 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: Certification Application FCC ID: UVS-WP1P Please be advised that the following information is a list of modifications that will be included in the production process for the above-referenced equipment. Change 1: There were no modifications made during testing. Change 2: Change 3: Change 4: Change 5: Change 6: Change 7: Change 8: Change 9 Change 10: Thank you for your attention to this matter. Signatory Arnom C. Rowe EMC ENGINEER EMC-001375-NE D.L.S. Electronic Systems, Inc. Manufacturer’s Letter Date: November 26, 2007 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: Certification Application FCC ID: UVS-WP1P To Whom It May Concern: Please be advised that the manufacturer will ensure that the above-referenced model will be manufactured in accordance with the FCC Rules and Regulations. Thank you for your attention to this matter. Signatory Arnom C. Rowe EMC ENGINEER EMC-001375-NE D.L.S. Electronic Systems, Inc.

Request for Confidentiality Date: November 26, 2007 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: Certification Application FCC ID: UVS-WP1P Pursuant to 47 CFR Section 0.459 VenTek, LLC understands that requests for non disclosure and confidential treatment is being made for the following information as stated under the Code of Federal Regulations Chapter 47, Part 0.459 and behalf of APPLICANT NAME: • Block Diagram • Schematics • Technical Product Description The above materials contain trade secrets, proprietary and technical information that would customarily be guarded from competitors under 47 CFR section 0.457(d)(2). Disclosure or publication of any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. VenTek, LLC understands that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Thank you for your attention to this matter. Signatory Arnom C. Rowe EMC ENGINEER EMC-001375-NE D.L.S. Electronic Systems, Inc.

________________________________________________________________________ 9470 Meridian Way, West Chester, OH 45069 PH: (513) 874-3195 FAX: (513) 874-3269 DLS Electronics, 10-23-2007 Dear Bill Stumpf, The e-Guard product that we are having DLS Electronics test, is primarily used in industrial applications and is installed by trained professionals at the installed facility, this would include engineers, technicians and maintenance personal. The up keep and maintenance are also provided on site by appropriate maintenance department. This product is also professionally integrated by System integrators and onsite Information Technology departments. This product under the existing instruction set is not provided to non commercial or industrial applications. It is not intended to be sold in any application that can not have professional installation. Regards, Robert B. Fitzpatrick Robert B. Fitzpatrick Director of Engineering

Company: VenTek Model: WP1P Date: 10-09-2007 Photo Description: Front of EUT Company: VenTek Model: WP1P Date: 10-09-2007 Photo Description: Back of EUT Company: VenTek Model: WP1P Date: 10-09-2007 Photo Description: Service button Company: VenTek Model: WP1P Date: 10-09-2007 Photo Description: Antenna port Company: VenTek Model: WP1P Date: 10-09-2007 Photo Description: Back of EUT with mounting plate removed Company: VenTek Model: WP1P Date: 10-09-2007 Photo Description: Antenna options

EN T V ek 14 SCREWALUMINUM UNTHREADED ROUND MOUNTING PLATE, ALUMINUM W/BLACK EM00367 DATA PIN JUMPER 1 SCREW 1/4 WAVE 418 MHz MINI RIGHT ANGLE 1 2 15 THIS CONSTRUCTION OR TO FURNISH THIS INFORMATION TOONLY AND IS NOT AN AUTHORIZATION -OR- LICENSE TO MAKEVENTEK LLC. IT IS FURNISHED FOR VENDOR INFORMATIONWAS ORIGINATED BY, AND IS THE EXCLUSIVE PROPERTY OF A 9470 Meridian Way Ph: (513) 874-3195 SIZE MM00717 13 SPACER 14 OTHERS. ALL DRAWINGS MUST BE RETURNED TO VENTEKCOPIED IN ANY FORM WITHOUT THE EXPRESS WRITTEN PER- DO NOT SCALE DRAWINGS RBF DWN. DATE NAME CHECKED DATE DATESTATUS DRAWING NO. REV RBS DESCRIPTION RBS 06/04/07 08/27/07 08/27/07 WT-418 02 West Chester, OH 45069 Fax: (513) 874-3269 ON DEMAND. THIS DRAWING IS NOT TO BE REPRODUCED ORMISSION OF VENTEK LLC. ALUM. SPACER, DATA PIN JUMPERS & BATTERY NOT SHOWN IN DETAIL PC. NO. QTY VENTEK PART # ASSEMBLY BILL OF MATERIAL 1 2 3 THE DESIGN AND DISCLOSURE CONTAINED IN THIS DRAWING = ±0.003 RADIO BOARD ASSEMBLY, INSIDE NEOPRENE & BRASS WASHERS, IS SERIES, ISR3SAD-1 WASHER, STAR, GALV. (OUTSIDE) EA00161 FW00030 1 1 APEM, PUSHBUTTON SWITCH ASSY, MACHINED MM00709 4 1 ENCON 418 MHz TILT SENSOR ENCLOSURE, POLYCARBONATE, ASSEMBLY 5 1 6 7 1 EA00158 RADIO TRANSMITTER BOARD ANTENNA ANT1N44RM 8 FW00027 WASHER, BRASS, (INSIDE) 9 10 111 EM00203 AA BATTERY ML00055 LABEL, FCC NUT, BRASS, BLACK OXIDE COATING FN00022 WASHER, NEOPRENE (INSIDE) FW00025 MM00697 FS00136 1112 1 1 12 #6-32 x 1/4" Lg. PAN HEAD PHILLIPS S.S.ANNODIZED COATING UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN INCHES. TOLERANCES: - ANGLES ±0° 30' - DECIMALS .XX = ±0.01 .XXX = ±0.005 -COAXIALITY NOTES: #6-19 x 5/8" Lg. PLASTITE PHILLIPS S.S. FS00142 5 10 6 1 2 11 3 12 15 13 49 7 8 12 13

Company: VenTek Model: WP1P Date: 10-09-2007 Photo Description: Front cover removed Company: VenTek Model: WP1P Date: 10-09-2007 Photo Description: Battery removed Company: VenTek Model: WP1P Date: 10-09-2007 Photo Description: Circuit board side 1 Company: VenTek Model: WP1P Date: 10-09-2007 Photo Description: Circuit board side 2 Company: VenTek Model: WP1P Date: 10-09-2007 Photo Description: Inside covers

1250 Peterson Dr., Wheeling, IL 60090 Company: VenTek, LLC Model Tested: WP1P Report Number: 13641 FCC Rules and Regulations / Intentional Radiators Periodic operational in the 40.66-40.70 MHz Band and above 70 MHz. Part 15, Subpart C, Section 15.231 THE FOLLOWING ''MEETS'' THE ABOVE TEST SPECIFICATION Formal Name: e-Guard Tilt Sensor Kind of Equipment: Wireless Sensor/Monitor Test Configuration: Stand alone Tested at 3.6 vdc Model Number(s): WP1P Model(s) Tested: WP1P Serial Number(s): 030000A0 Date of Tests: January 2, 3, & October 9, 2007 Test Conducted For: VenTek, LLC 9470 Meridian Way West Chester, Ohio 45069 NOTICE: “This report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S. Government”. Please see the "Additional Description of Equipment Under Test" page listed inside of this report. © Copyright 1983- 2007 D.L.S. Electronic Systems, Inc COPYRIGHT NOTICE This report or any portion their of, may not be reproduced or modified in any form without the expressed written consent of D.L.S. Electronic Systems, Inc. Page -1 of 37- 1250 Peterson Dr., Wheeling, IL 60090 Company: VenTek, LLC Model Tested: WP1P Report Number: 13641 SIGNATURE PAGE Report By: Arnom C. Rowe Test Engineer EMC-001375-NE Reviewed By: William Stumpf OATS Manager Approved By: Brian Mattson General Manager Company Official: VenTek, LLC Page -2 of 37- 1250 Peterson Dr., Wheeling, IL 60090 Company: VenTek, LLC Model Tested: WP1P Report Number: 13641 TABLE OF CONTENTS i. Cover Page .......................................................................................................................................... 1 ii. Signature Page .................................................................................................................................... 2 iii. Table of Contents ............................................................................................................................ 3 iv. NVLAP Certificate of Accreditation .............................................................................................. 4 1.0 Summary of Test Report ................................................................................................................. 5 2.0 Introduction..................................................................................................................................... 5 3.0 Object .............................................................................................................................................. 5 4.0 Test Set-Up ..................................................................................................................................... 6 5.0 Test Equipment ............................................................................................................................... 6 6.0 Ambient Measurements .................................................................................................................. 7 7.0 Description of Test Sample............................................................................................................. 8 8.0 Additional Description of Test Sample........................................................................................... 9 9.0 Photo Information and Test Set-Up .............................................................................................. 10 10.0 Radiated Photos Taken During Testing ........................................................................................ 11 11.0 Results of Tests ............................................................................................................................. 15 12.0 Conclusion .................................................................................................................................... 15 TABLE 1 – EQUIPMENT LIST .............................................................................................................. 16 Appendix A – Electric Field Radiated Emissions Test............................................................................. 18 1.0 Pulsed Operation (Duty Cycle Correction Factor)........................................................................ 19 1.0 Graph(s) taken of the Pulsed Operation (DCCF).......................................................................... 20 2.0 Graph(s) taken of the Transmit Duration Emissions .................................................................... 27 2.0 Bandwidths ................................................................................................................................... 29 2.0 Graph(s) taken of the 99% Power Bandwidth Emissions ............................................................. 30 3.0 Restricted Bands ........................................................................................................................... 32 4.0 Field Strength of Spurious Emission Measurements .................................................................... 33 4.0 Graph(s) taken of the Fundamental, Spurious Emissions and Restricted Bands .......................... 34 Page -3 of 37- 1250 Peterson Dr., Wheeling, IL 60090 Company: VenTek, LLC Model Tested: WP1P Report Number: 13641 Page -4 of 37- 1250 Peterson Dr., Wheeling, IL 60090 Company: VenTek, LLC Model Tested: WP1P Report Number: 13641 1.0 SUMMARY OF TEST REPORT It was found that the e-Guard Tilt Sensor, Model Number(s) WP1P, ''meets'' the radio interference radiated emission requirements of the FCC ''Rules and Regulations'', Part 15, Subpart C, Section 15.231 for periodic operational in the 40.66-40.70 MHz Band and above 70 MHz. The AC Power Line conducted emissions test was not required because the e-Guard Tilt Sensor is powered from a D.C. power source. It does not have a line cord to plug into the A.C. power line. 2.0 INTRODUCTION On January 2, 3, & October 9, 2007, a series of radio frequency interference measurements was performed on e-Guard…

Text truncated - open the document above for the full version.

MONOPOLE MONOPOLE CLOSEUP 90 DEGREE MONOPOLE 90 DEGREE MONOPOLE CLOSEUP
