1 1 IOM00024-03 9470 Meridian Way West Chester, Ohio 45069 Phone: 513-874-3195 Fax: 513-874-3269 www.ventekllc.com Universal Wireless Transmitter Quick Setup Sheet WVN05P Page 1 of 2 Wireless That Makes Perfect Sense Transmitting Frequency: 418 MHz ISM band Environmental Classification: NEMA 4X Battery: 3.6V lithium battery (½ AA) Battery Life: 1-year minimum Temperature Range: -20 o C to 70 o C -4 o F to 158 o F Range: 600 feet (1) Transmission Rate: 10 to 17 seconds (random) Parts List: Quantity Part 1 e-Guard Wireless Transmitter 2 2” Dual-Lock Adhesive Strips 4 #6 x 1” Self-tapping Screws Description: The VenTek WVNO5P Universal Wireless Transmitter is a low-power self-configuring device with a 600 ft (1) range and will configure itself to work with any VenTek V-BUS sensor. The transmitter sends data from the sensor at random intervals between 10 and 17 seconds. To conserve battery life and reduce the number of transmission collisions while the transmitter is not in use, the transmitter remains turned off until a V-BUS sensor is plugged in. The battery will last at least 1 year of continuous use and can exceed 2 years, depending on the sensor being used. Mounting: Attach the Universal Wireless Transmitter to the mounting surface using either the #6 x 1” self-tapping mounting screws or the dual-lock adhesive strips as shown. Mount the transmitter away from metal objects such as steel beams, catwalks and shelving. Such objects may interfere with the transmission signals. The preferred mounting surface is non-metallic. If the mounting surface is metallic, the receiver should be in front of the Universal Wireless Transmitter. (See VenTek document TIPS1 for more information). (1) Transmitter range is typicaly 600 feet in an industrial environment, but can be much further. A site evaluation should be conducted to find the best locations for transmitters and receivers. 2 2 IOM00024-03 9470 Meridian Way West Chester, Ohio 45069 Phone: 513-874-3195 Fax: 513-874-3269 www.ventekllc.com Universal Wireless Transmitter Quick Setup Sheet WVN05P Page 2 of 2 Wireless That Makes Perfect Sense Monitor Setup: When the transmitter is connected to a V-BUS sensor, the system becomes an e-Guard Wireless Monitor. 1. Securely connect a VenTek V-BUS sensor to the transmitter to power up the wireless monitor system. * The transmitter remains powered down unless a sensor is securely plugged into it. 2. Press the service button on the transmitter to configure the transmitter to the specifications of the sensor. 3. When the monitor system is active, the LED on the sensor will flash every 10 to 17 seconds. Pressing the service button will immediately flash the LED to indicate the functionality of the monitor. VenTek OPC Server Sensor Setup: 1. Open up the VenTek OPC Server software. 2. Click on the File menu, then Device Registration. 3. Press the service button on the transmitter. The serial number of the sensor will appear in a new window asking to add the device. 4. To activate this sensor select Yes. The sensor will be registered and appear in the list sorted by serial number. The tile in the Active column should say “yes.” * The sensor can be deactivated by changing the tile in the Active column to say “no.” 5. In the Topic column, rename the sensor with a meaningful name (i.e. Motor A) if desired. 6. To log the sensor’s data in the database using the VenTek Dashboard software, make sure the tile in the Dashboard column says “yes.” 7. To view the sensor’s readings on the VenTek Dashboard screen, make sure the tile in the ShowTile column says “yes.” 8. Close the Registered Devices and the OPC Server software window. * Consult the VenTek OPC Server installation instructions if the software is not already installed. Rules subject to operation “Changes or modifications not expressly approved by VenTek, LLC for compliance could void the user's authority to operate the equipment.” “Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.” “This device has been designed to operate with the antennas listed below, and having a maximum gain of 2 dBi. Antennas not included in this list or having a gain greater than 2 dBi are strictly prohibited for use with this device. The required antenna impedance is 50 ohms.” – (ANT-418-CW-RAH, ANT418-MHW-RPS, ANT-418-CW-RH) “To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that permitted for successful communication.” FCC ID: -UVS-WV418 IC:6886A-WV418 "This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired o peration."

Request for Confidentiality Date: March 9, 2007 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: Certification Application FCC ID: UVS-WV418 Pursuant to 47 CFR Section 0.459 VenTek, LLC understands that requests for non disclosure and confidential treatment is being made for the following information as stated under the Code of Federal Regulations Chapter 47, Part 0.459 and behalf of APPLICANT NAME: • Block Diagram • Schematics • Technical Product Description The above materials contain trade secrets, proprietary and technical information that would customarily be guarded from competitors under 47 CFR section 0.457(d)(2). Disclosure or publication of any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. VenTek, LLC understands that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Thank you for your attention to this matter. Signatory Arnom C. Rowe EMC ENGINEER EMC-001375-NE D.L.S. Electronic Systems, Inc.

Letter of Agency Date: March , 2007 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: Please be advised that VenTek, LLC authorizes D.L.S. Electronic Systems, Inc. to act on our behalf, until otherwise notified, for applications submitted to American Telecommunications Certification Body, Inc. (ATCB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse ACT of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002(b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you for your attention to this matter. Signatory, Arnom C. Rowe EMC ENGINEER EMC-001375-NE D.L.S. Electronic Systems, Inc. FCC Labeling Requirements and Information Date: March 9, 2007 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: FCC Labeling Requirements FCC ID: UVS-WV418 The following label information is required by the FCC Rules and Regulations for certified devices. Also attached, please find marketing information required by the FCC Rules and Regulations. Thank you for your attention to these matters. Sincerely, Arnom C. Rowe EMC ENGINEER EMC-001375-NE D.L.S. Electronic Systems, Inc. Modification Letter Date: March 9, 2007 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: Certification Application FCC ID: UVS-WV418 Please be advised that the following information is a list of modifications that will be included in the production process for the above-referenced equipment. Change 1: There were no modifications made during testing. Change 2: Change 3: Change 4: Change 5: Change 6: Change 7: Change 8: Change 9 Change 10: Thank you for your attention to this matter. Signatory Arnom C. Rowe EMC ENGINEER EMC-001375-NE D.L.S. Electronic Systems, Inc. Manufacturer’s Letter Date: March 9, 2007 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: Certification Application FCC ID: UVS-WV418 To Whom It May Concern: Please be advised that the manufacturer will ensure that the above-referenced model will be manufactured in accordance with the FCC Rules and Regulations. Thank you for your attention to this matter. Signatory Arnom C. Rowe EMC ENGINEER EMC-001375-NE D.L.S. Electronic Systems, Inc.

________________________________________________________________________ 9470 Meridian Way, West Chester, OH 45069 PH: (513) 874-3195 FAX: (513) 874-3269 LETTER OF AUTHORIZATION FCC Authorization & Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21045-0429 Ladies and or Gentlemen: I appoint Brian J. Mattson or Arnom C. Rowe to act as agent in the preparation of applications under Part 15 of the Rules and Regulations of the Federal Communications Commission. I certify that the exhibits properly describe the device being submitted under this application and will implement any changes described in the test report. The following statement is required by the Federal Communications Commission: By checking yes, the applicant certifies that, in the case of an individual applicant, he or she is not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti- Drug Abuse Act of 1988, 21 U.S.C. 853(a), or, in the case of an non-individual applicant (e.g. corporation, partnership or other unincorporated association), no party to the application is subject to a denial of federal benefits, that includes FCC benefits, pursuant to that section. __X___ YES _____ NO Dated this 17th day of January, 2007 Agency agreement expiration date: None By Mark E. Peters Printed Mark E. Peters Signature Title Founder and CTO Telephone 513-874-3195 Ext. 101 Applicant Ventek, LLC

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 March 21, 2007 RE: FCC ID: UVS-WV418_ATCB004649 Attention: Arnom C. Rowe I have a few comments on this Application. Please note that further comments may arise in response to answers provided to the questions below. 1. Please note that the non-modification statement in the manual states “Changes or modifications not expressly approved by FCC/IC for compliance could void the user’s authority to operate the equipment.” Please note that 15.21 specifically states that it is the “ approved by the party responsible for compliance: that must make this statement. Please note that the statement currently in the manual is not correct as it infers that the FCC is the responsible party. The grantee is the party responsible. Please correct the manual 15.21 statement to be inline with the requirements of the FCC. 2. Please note that the operational description states that external antenna(s) are used. Please note that the documentation does not clearly state or identify the connectors used for this antenna. Please also note that the schematics clearly state that both reverse polarity and standard polarity SMA are used. Please note that a standard polarity SMA is not unique and do not fit the restrictions of 15.203/15.204. Therefore it is not possible to determine if the antenna requirements of 15.203 and 15.204 have been properly met and addressed. Please note that the text note from the lab in the manual is not sufficient to show how the manufacturer meets the antenna requirements. Please properly address the non-standard antenna connector requirement of 15.203/15.204 (i.e. clearly show how this is a non-standard antenna connector). 3. Please note that part 15 devices cannot have other than non-standard or professionally installed antenna(s). Please note that in respect to item 2 above the schematics clearly state that “other terminations available for volume orders.” Please explain what this statement means and how it prevents the use of standard antenna connectors. Dennis Ward mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Company: VenTek Model: WVN05P FCC ID: UVS-xxxx IC: 6886A-xxxx Date: 01-05-2007 Photo Description: Front of EUT Company: VenTek Model: WVN05P FCC ID: UVS-xxxx IC: 6886A-xxxx Date: 01-05-2007 Photo Description: Sensor port side of EUT Company: VenTek Model: WVN05P FCC ID: UVS-xxxx IC: 6886A-xxxx Date: 01-05-2007 Photo Description: Push button side of EUT Company: VenTek Model: WVN05P FCC ID: UVS-xxxx IC: 6886A-xxxx Date: 01-05-2007 Photo Description: RF port side of EUT Company: VenTek Model: WVN05P FCC ID: UVS-xxxx IC: 6886A-xxxx Date: 01-05-2007 Photo Description: Back of EUT Company: VenTek Model: WVN05P FCC ID: UVS-xxxx IC: 6886A-xxxx Date: 01-05-2007 Photo Description: Back of EUT – Screws removed

EN T V ek NOT SHOWN 13 .5 .5 2.0 1.0 14 2 3 1 6 4 9 NOT SHOWN 8 8 NOT SHOWN 12 8 8 LABEL, ON-OFF - PART # ML00038 1 LABEL, FCC ML00037 1 1 13 12 BOTTOM FOAM INSERT, NO CUTOUT TOP FOAM INSERT W/CUTOUT A 9470 Meridian Way Ph: (513) 874-3195 SIZE FM00021-2 02 2 WVN05P 14 MM00654 1 1/2 AA BATTERY WAS ORIGINATED BY, AND IS THE EXCLUSIVE PROPERTY OFONLY AND IS NOT AN AUTHORIZATION -OR- LICENSE TO MAKEOTHERS. ALL DRAWINGS MUST BE RETURNED TO VENTEKCOPIED IN ANY FORM WITHOUT THE EXPRESS WRITTEN PER- DO NOT SCALE DRAWINGS RBF DWN. DATE NAME CHECKED DATE DATESTATUS DRAWING NO. REV RBS DESCRIPTION RBS 03/08/06 01/04/07 01/04/07 1/4 WAVE 418 MHz MINI ANTENNA VENTEK LLC. IT IS FURNISHED FOR VENDOR INFORMATIONTHIS CONSTRUCTION OR TO FURNISH THIS INFORMATION TOON DEMAND. THIS DRAWING IS NOT TO BE REPRODUCED ORMISSION OF VENTEK LLC. & 2 FOAM INSERTS NOT SHOWN IN DETAIL PC. NO. QTY VENTEK PART # ASSEMBLY BILL OF MATERIAL 1 ANT1N44S West Chester, OH 45069 Fax: (513) 874-3269 THE DESIGN AND DISCLOSURE CONTAINED IN THIS DRAWING = ±0.003 RADIO BOARD ASSEMBLY, INSIDE LABEL, BATTERY, SERIES, ISR3SAD-1 WASHER, NEOPRENE 2 3 1 1 APEM, PUSHBUTTON SWITCH, IS CAST ALUMINUM ALLOY, MACHINED EM00302 MM00625 1 e-GUARD WIRELESS MONITOR, NEMA 4X NEMA 4X RADIO ENCLOSURE, DIE ASSEMBLY 5 1 6 7 MM00622 4 1 EA00130 RADIO TRANSMITTER BOARD SELF-DRILLING MOUNTING SCREW FS00124 8 4 ML00023 ML00014 LABEL, OUTSIDE COVER LABEL, INSIDE COVER 9 10 11 11 1 EM00059 MM00655 UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN INCHES. TOLERANCES: - ANGLES ±0° 30' - DECIMALS .XX = ±0.01 .XXX = ±0.005 -COAXIALITY NOTES: #6-20 x 1" Lg. FLAT HEAD PHILLIPS S.S. DUAL LOCK FASTENER 7 10 5 11

EN T V ek NOT SHOWN 13 .5 .5 2.0 1.0 14 2 3 1 6 4 9 NOT SHOWN 8 8 NOT SHOWN 12 8 8 LABEL, ON-OFF - PART # ML00038 1 LABEL, FCC ML00037 1 1 13 12 BOTTOM FOAM INSERT, NO CUTOUT TOP FOAM INSERT W/CUTOUT A 9470 Meridian Way Ph: (513) 874-3195 SIZE FM00021-2 02 2 WVN05P 14 MM00654 1 1/2 AA BATTERY WAS ORIGINATED BY, AND IS THE EXCLUSIVE PROPERTY OFONLY AND IS NOT AN AUTHORIZATION -OR- LICENSE TO MAKEOTHERS. ALL DRAWINGS MUST BE RETURNED TO VENTEKCOPIED IN ANY FORM WITHOUT THE EXPRESS WRITTEN PER- DO NOT SCALE DRAWINGS RBF DWN. DATE NAME CHECKED DATE DATESTATUS DRAWING NO. REV RBS DESCRIPTION RBS 03/08/06 01/04/07 01/04/07 1/4 WAVE 418 MHz MINI ANTENNA VENTEK LLC. IT IS FURNISHED FOR VENDOR INFORMATIONTHIS CONSTRUCTION OR TO FURNISH THIS INFORMATION TOON DEMAND. THIS DRAWING IS NOT TO BE REPRODUCED ORMISSION OF VENTEK LLC. & 2 FOAM INSERTS NOT SHOWN IN DETAIL PC. NO. QTY VENTEK PART # ASSEMBLY BILL OF MATERIAL 1 ANT1N44S West Chester, OH 45069 Fax: (513) 874-3269 THE DESIGN AND DISCLOSURE CONTAINED IN THIS DRAWING = ±0.003 RADIO BOARD ASSEMBLY, INSIDE LABEL, BATTERY, SERIES, ISR3SAD-1 WASHER, NEOPRENE 2 3 1 1 APEM, PUSHBUTTON SWITCH, IS CAST ALUMINUM ALLOY, MACHINED EM00302 MM00625 1 e-GUARD WIRELESS MONITOR, NEMA 4X NEMA 4X RADIO ENCLOSURE, DIE ASSEMBLY 5 1 6 7 MM00622 4 1 EA00130 RADIO TRANSMITTER BOARD SELF-DRILLING MOUNTING SCREW FS00124 8 4 ML00023 ML00014 LABEL, OUTSIDE COVER LABEL, INSIDE COVER 9 10 11 11 1 EM00059 MM00655 UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN INCHES. TOLERANCES: - ANGLES ±0° 30' - DECIMALS .XX = ±0.01 .XXX = ±0.005 -COAXIALITY NOTES: #6-20 x 1" Lg. FLAT HEAD PHILLIPS S.S. DUAL LOCK FASTENER 7 10 5 11

Company: VenTek Model: WVN05P FCC ID: UVS-xxxx IC: 6886A-xxxx Date: 01-05-2007 Photo Description: Back cover removed Company: VenTek Model: WVN05P FCC ID: UVS-xxxx IC: 6886A-xxxx Date: 01-05-2007 Photo Description: Battery removed Company: VenTek Model: WVN05P FCC ID: UVS-xxxx IC: 6886A-xxxx Date: 01-05-2007 Photo Description: Circuit board removed Company: VenTek Model: WVN05P FCC ID: UVS-xxxx IC: 6886A-xxxx Date: 01-05-2007 Photo Description: Circuit board – Side 1 Company: VenTek Model: WVN05P FCC ID: UVS-xxxx IC: 6886A-xxxx Date: 01-05-2007 Photo Description: Circuit board – Side 2 Company: VenTek Model: WVN05P FCC ID: UVS-xxxx IC: 6886A-xxxx Date: 01-05-2007 Photo Description: Inside covers Company: VenTek Model: WVN05P FCC ID: UVS-xxxx IC: 6886A-xxxx Date: 01-05-2007 Photo Description: Complete System with optional antennas and sensors

1250 Peterson Dr., Wheeling, IL 60090 Company: VenTek, LLC Model Tested: WVN05P Report Number: 12974 FCC Rules and Regulations / Intentional Radiators Periodic operational in the 40.66-40.70 MHz Band and above 70 MHz. Part 15, Subpart C, Section 15.231 THE FOLLOWING ''MEETS'' THE ABOVE TEST SPECIFICATION Formal Name: e-Guard Monitor Kind of Equipment: Wireless Sensor/Monitor Test Configuration: Cable with Pin Connector (Tested at 3.6 vdc) Model Number(s): WVN05P Model(s) Tested: WVN05P Serial Number(s): NA Date of Tests: January 2, 3, 4, 5, and February 15 & 16, 2007 Test Conducted For: VenTek, LLC 9470 Meridian Way West Chester, Ohio 45069 NOTICE: “This report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S. Government”. Please see the "Additional Description of Equipment Under Test" page listed inside of this report. © Copyright 1983- 2006 D.L.S. Electronic Systems, Inc COPYRIGHT NOTICE This report or any portion their of, may not be reproduced or modified in any form without the expressed written consent of D.L.S. Electronic Systems, Inc. Page -1 of 36- 1250 Peterson Dr., Wheeling, IL 60090 Company: VenTek, LLC Model Tested: WVN05P Report Number: 12974 SIGNATURE PAGE Report By: Arnom C. Rowe Test Engineer EMC-001375-NE Reviewed By: William Stumpf OATS Manager Approved By: Brian Mattson General Manager Company Official: VenTek, LLC Page -2 of 36- 1250 Peterson Dr., Wheeling, IL 60090 Company: VenTek, LLC Model Tested: WVN05P Report Number: 12974 TABLE OF CONTENTS i. Cover Page .......................................................................................................................................... 1 ii. Signature Page .................................................................................................................................... 2 iii. Table of Contents ............................................................................................................................ 3 iv. NVLAP Certificate of Accreditation .............................................................................................. 4 1.0 Summary of Test Report ................................................................................................................. 5 2.0 Introduction..................................................................................................................................... 5 3.0 Object .............................................................................................................................................. 5 4.0 Test Set-Up ..................................................................................................................................... 6 5.0 Test Equipment ............................................................................................................................... 6 6.0 Ambient Measurements .................................................................................................................. 7 7.0 Description of Test Sample............................................................................................................. 8 8.0 Additional Description of Test Sample......................................................................................... 10 9.0 Photo Information and Test Set-Up .............................................................................................. 11 10.0 Radiated Photos Taken During Testing ........................................................................................ 12 11.0 Results of Tests ............................................................................................................................. 15 12.0 Conclusion .................................................................................................................................... 15 TABLE 1 – EQUIPMENT LIST .............................................................................................................. 16 Appendix A – Electric Field Radiated Emissions Test............................................................................. 17 1.0 Pulsed Operation (Duty Cycle Correction Factor)........................................................................ 18 1.0 Graph(s) taken of the Pulsed Operation (DCCF).......................................................................... 19 2.0 Bandwidths ................................................................................................................................... 26 2.0 Graph(s) taken of the 20 dB Bandwidth Emissions...................................................................... 27 3.0 Field Strength of Spurious Emission Measurements .................................................................... 29 3.0 Data taken of the Fundamental, Harmonic Emissions and Restricted Bands............................... 30 4.0 Restricted Bands ........................................................................................................................... 36 Page -3 of 36- 1250 Peterson Dr., Wheeling, IL 60090 Company: VenTek, LLC Model Tested: WVN05P Report Number: 12974 Page -4 of 36- 1250 Peterson Dr., Wheeling, IL 60090 Company: VenTek, LLC Model Tested: WVN05P Report Number: 12974 1.0 SUMMARY OF TEST REPORT It was found that the e-Guard Monitor, Model Number(s) WVN05P, ''meets'' the radio interference radiated emission requirements of the FCC ''Rules and Regulations'', Part 15, Subpart C, Section 15.231 for periodic operational in the 40.66-40.70 MHz Band and above 70 MHz. The conducted emissions test was not required because the e-Guard Monitor is powered from a D.C. power source. It does not have a line cord to plug into the A.C. power line. 2.0 INTRODUCTION On January 2, 3, 4, 5, and February 15 & 16, 2007, a series of radio frequency interference measurements was performed on e-Guard Monitor, Model Number(s) WVN05P, Serial Number: NA. The tests were performed according to the…

Text truncated - open the document above for the full version.

1250 Peterson Dr., Wheeling, IL 60090 Company: VenTek, LLC Model Tested: WVN05P Report Number: 12975 LOW-POWER LICENCE-EXEMPT RADIO COMMUNICATION DEVICES (ALL FREQUENCY BANDS: CATEGORY I EQUIPMENT) RADIO STANDARDS SPECIFICATION RSS-210, ISSUE 6 SEPTEMBER 2005 THE FOLLOWING ''MEETS'' THE ABOVE TEST SPECIFICATION Formal Name: e-Guard Monitor Kind of Equipment: Wireless Sensor/Monitor Test Configuration: Cable with Pin Connector (Tested at 3.6 vdc) Model Number(s): WVN05P Model(s) Tested: WVN05P Serial Number(s): NA Date of Tests: January 2, 3, 4, 5 and February 15 & 16, 2007 Test Conducted For: VenTek, LLC 9470 Meridian Way West Chester, Ohio 45069 NOTICE: “This test report relates only to the items tested and must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S. Government”. Please see the "Additional Description of Equipment Under Test" page listed inside of this report. © Copyright 1983- 2006 D.L.S. Electronic Systems, Inc COPYRIGHT NOTICE This report or any portion their of, may not be reproduced or modified in any form without the expressed written consent of D.L.S. Electronic Systems, Inc. Page - 1 of 36 - 1250 Peterson Dr., Wheeling, IL 60090 Company: VenTek, LLC Model Tested: WVN05P Report Number: 12975 SIGNATURE PAGE Report By: Arnom C. Rowe Test Engineer EMC-001375-NE Reviewed By: William Stumpf OATS Manager Approved By: Brian Mattson General Manager Company Official: VenTek, LLC Page - 2 of 36 - 1250 Peterson Dr., Wheeling, IL 60090 Company: VenTek, LLC Model Tested: WVN05P Report Number: 12975 TABLE OF CONTENTS i. Cover Page .......................................................................................................................................1 ii. Signature Page .................................................................................................................................2 iii. Table of Contents .............................................................................................................................3 iv. NVLAP Certificate of Accreditation ...............................................................................................4 1.0 Summary of Test Report ..................................................................................................................5 2.0 Introduction......................................................................................................................................5 3.0 Test Facility .....................................................................................................................................5 4.0 Test Equipment ................................................................................................................................5 5.0 Description of Test Sample..............................................................................................................6 6.0 Additional Description of Test Sample............................................................................................8 7.0 Photo Information and Test Set-Up .................................................................................................9 8.0 Radiated Photos Taken During Testing .........................................................................................10 9.0 Conclusion .....................................................................................................................................13 Appendix A – Electric Field Radiated Emissions Test..............................................................................14 1.0 Supply Voltage – (Section 4.1) ......................................................................................................15 2.0 Frequency Range ...........................................................................................................................15 3.0 Types of Modulation – (Section 3.2 & 4.1) ...................................................................................15 4.0 Pulsed Operation (Duty Cycle Correction Factor).........................................................................16 4.0 Graph(s) taken of the Pulsed Operation (DCCF)...........................................................................17 5.0 Emission Bandwidth – (Section 4.4) .............................................................................................24 5.0 Graphs Taken of the 99% Occupied Emission Bandwidth............................................................25 6.0 AC Line Conducted Spurious Emissions Measurements – (Section 7.2)......................................27 7.0 Restricted Bands ............................................................................................................................28 8.0 Radiated Fundamental and Spurious Emissions (RSS-210, Annex 1) ..........................................29 8.0 Radiated Data taken of the Fundamental, Harmonic Emissions and Restricted Bands.................30 TABLE 1 – EQUIPMENT LIST ...............................................................................................................36 Page - 3 of 36 - 1250 Peterson Dr., Wheeling, IL 60090 Company: VenTek, LLC Model Tested: WVN05P Report Number: 12975 Page - 4 of 36 - 1250 Peterson Dr., Wheeling, IL 60090 Company: VenTek, LLC Model Tested: WVN05P Report Number: 12975 1.0 SUMMARY OF TEST REPORT It was found that the e-Guard Monitor, Model Number(s) WVN05P, ''meets'' the radio interference radiated emission requirements of the RSS-210 Issue 6, September 2005. The Power Line Conducted emissions test was not required because the e-Guard Monitor is powered from a D.C. power source. It does not have a line cord to plug into the A.C. power line. 2.0 INTRODUCTION On January 2, 3, 4, 5 and February 15 & 16, 2007, a series of radio frequency interference measurements was performed on e-Guard Monitor, Model Number(s) WVN05P, Serial Number: NA. The tests were performed according to the proced…

Text truncated - open the document above for the full version.

90 DEGREE MONOPOLE ANTENNA MONOPOLE ANTENNA DIPOLE ANTENNA
