UZ7AP7502Dual Radio Wallplate AP

Introduction The AP-7502 11ac Wireless Wallplate is designed to leverage the existing category 5/5e/6 cabling already in the walls of any enterprise building. Ideally suited for hotels, dormitory housing, and similar multi-tenant buildings, the AP-7502 provides high speed wireless LAN along with switched Ethernet and PoE output. Document Conventions The following graphical alerts are used in this document to indicate notable situations: NOTE Tips, hints, or special requirements that you should take note of. CAUTION Care is required. Disregarding a caution can result in data loss or equipment malfunction. WARNING! Indicates a condition or procedure that could result in personal injury or equipment damage. Warnings • This equipment should only be installed by qualified professional installers. • Read all installation instructions and site survey reports, and verify correct equipment installation before installing this equipment. • Remove jewelry and watches before installing this equipment. • Verify proper wiring and grounding for each installation location. • Verify there is adequate ventilation around the device, and that ambient temperatures meet equipment operation specifications ( 0° to 40° Celsius / 32° to 104° Fahrenheit). AP-7502 Wireless Wallplate Specifications Wireless InterfaceDual Radio; 802.11a/b/g/n/ac; 2.4 GHz and 5 GHz WAN Interface Auto-sensing 10/100/1000Mbps, Full/Half Duplex, with PoE receiving capability via RJ-45 LAN Interfaces3 x IEEE 802.3 10/100Mb, auto-sensing via RJ-45 PoE OutOne FE port with 802.3af output based on 802.3 at input MediumDSSS, OFDM, MCS, HT Network Standards802.11 a/b/g/n/ac, 802.11d, 802.11i, WPA, WMM PHY Data Rates 802.11b: 1, 2, 5.5, 11 Mbps 802.11g/a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11n: MCS 0-15 up to 300 Mbps 802.11ac: MCS 0-8 up to 867 Mbps Operating Frequencies 802.11 operating frequencies: 2.4GHz @2400-2483.5 MHZ, 5.2GHz @ 5150-5250 MHz and 5725-5850 MHz Bluetooth LE2400-2483.5 KHz in 2 MHz channels Transmit Power 1dBm to 20dBm in 1dBm increments Actual transmit power is dependent upon national limits. Antenna Configuration 2.4 GHz: 2 internal, 1x2, 2x2 MIMO, 5.8dBi peak gain 5 GHz: 2 internal, 1x2, 2x2, MIMO, 7.3dBi peak gain Managementtelnet, SSH, HTTP, HTTPS, SNMPv2/v3 MOTOROLA SOLUTIONS, INC. 1303 E. ALGONQUIN ROAD SCHAUMBURG, IL 60196 http://www.motorolasolutions.com AP-7502 11ac Wireless Wallplate Installation Guide MN000912A01 Revision A July 2014 (2) (1) (3)(4)(5)(6) Installing the AP-7502 Wallplate The AP-7502 wallplate can be installed over an existing structured wiring wallplate. When installing the wallplate over an existing 70mm x 115mm wallplate as is commonly found in North America, South America and Japan, install the decor facade (optional) only after the AP-7502 has been installed. 1.Remove the existing wallplate. 2.Install the wallplate mounting bracket. 3.Attach the bottom of the wallplate to the mounting bracket and rotate the wallplate until it snaps onto the latch. 4.Install the security screw provided (optional). 5.If desired, install the decor facade. Basic AP-7502 Configuration To provide the Access Point with a basic configuration and access WiNG management functions, open a browser and enter the IP address printed on the serial label on the Access Point: https://<IP address of Access Point> Login to the system using the default username admin and password motorola. 1. On the Configuration -> Basic Settings screen, enter the AP Name and Country Name. 2. On the Configuration -> Wireless screen, enter the desired Name, SSID, Security, and WPA2 Key parameters. Additional WiNG configuration documentation is available at: https://portal.motorolasolutions.com/Support/US-EN Regulatory Information This device is approved under Motorola Solutions, Inc. This guide applies to Model Number AP-7502. All Motorola devices are designed to be compliant with rules and regulations in locations where they are sold and will be labeled as required. Local language translations are available at the following website: http://www.motorolasolutions.com/support . Any changes or modifications to Motorola equipment, not expressly approved by Motorola Solutions, could void the user's authority to operate the equipment. When Motorola devices are professionally installed, the Radio Frequency Output Power will not exceed the maximum allowable limit for the country of operation. Antennas: Use only the supplied or an approved replacement antenna. Unauthorized antennas, modifications, or attachments could cause damage and may violate regulations. This device is only to be used with a Motorola Wireless Switch. Declared maximum operating temperature: 40°C. Bluetooth® Wireless Technology This is an approved Bluetooth® product. For more information or to view End Product Listing, please visit https://www.bluetooth.org/tpg/listings.cfm Wireless Device Country Approvals Regulatory markings, subject to certification, are applied to the device signifying the radio(s) is/are approved for use in the following countries: United States, Canada, Japan, China, S. Korea, Australia, and Europe. Please refer to the Declaration of Conformity (DoC) for details of other country markings. This is available at http://www.motorolasolutions.com/doc . Note: Europe includes, Austria, Belgium, Bulgaria, Czech Republic, Cyprus, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Liechtenstein, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovak Republic, Slovenia, Spain, Sweden, Switzerland and the United Kingdom. Operation of the device without regulatory approval is illegal. Country Selection Select only the country in which you are using the device. Any other selection will make the operation of this device illegal. Some Access Points are specifically designed to operate in certain countries (Example; -US for the United States, -EU for the European Union) . Frequency of Operation - FCC and IC…

Text truncated - open the document above for the full version.

Motorola Solutions, Inc. One Motorola Plaza, | Holtsville, NY 11742 | 1.631.738.2400 phone | 1.631.627.7179 fax | www.motorolasolutions.com Regulatory Engineering July 31, 2014 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia MD 21046 Subject: FCC - Declaration for no non-US channel operation We, declare that the device does not support channel 12 ~ 13 in 2.4GHz band and any non-US channels in all the operational mode(s) for the following product. FCC ID: UZ7AP7502 If you should have any question(s) regarding this declaration, please don’t hesitate to contact me. Respectfully, Mark S. Luksich Motorola Solutions, Inc. 631 738 5134 [email protected]

Regulatory Engineering Motorola Solutions, Inc. One Motorola Plaza, | Holtsville, NY 11742 | 1.631.738.2400 phone | 1.631.627.7179 fax | www.motorolasolutions.com August 14, 2014 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia MD 21046 Subject: FCC - Authorization to act as Agent Letter To the Commission: I, hereby authorize Amanda Wu of Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan) of Taiwan to act on our behalf, as our agent, in the following matters related to the FCC approval of the AP-7502 under FCC ID: UZ7AP7502: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by Amanda Wu of BV CPS Taoyua within the scope of this authorization shall have the same effects my own. Respectfully, Mark S. Luksich DMTS, Regulatory Engineering Tel: 631 738 5134 [email protected]

Regulatory Engineering Motorola Solutions, Inc. One Motorola Plaza, | Holtsville, NY 11742 | 1.631.738.2400 phone | 1.631.627.7179 fax | www.motorolasolutions.com July 31, 2014 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia MD 21046 Subject: Confidentiality requests for FCC ID: UZ7AP7502 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Theory of Operation Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 2014/12/31 External Photos Internal Photos Test setup Photos User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Respectfully, Mark S. Luksich Motorola Solutions, Inc. 631 738 5134 [email protected]

Report No.: 140702E01 Page 1 CONSTRUCTION PHOTOS OF EUT Report No.: 140702E01 Page 2

(Fig.1) FCC ID: UZ7AP7502 FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. Back Side: Label Here 246000000954A UL LABEL WAP1022A-FLF-D8 US Carry MAY07.14 Lin MAY07.14 01 246000000954A R01 XX XX MODEL:AP-7502 Made in XXX MFG Factory 4 4 4 37.81 20.80 14.05 12.84 R6.59 1.50 R9.71 32.35 FCC ID: UZ7AP7502 12V 0.83A 44-57V 0.57A (PoE) 9 . 0 0 m m 4 . 5 6 m m 4 . 5 6 m m 4 . 5 6 m m 246000000954A R01 XX XX MODEL:AP-7502 Made in XXX 12V 0.83A 44-57V 0.57A (PoE) FCC ID: UZ7AP7502

Report No.: 140702E01 Page 1 CONSTRUCTION PHOTOS OF EUT Report No.: 140702E01 Page 2 Report No.: 140702E01 Page 3 Report No.: 140702E01 Page 4 Report No.: 140702E01 Page 5 Report No.: 140702E01 Page 6 Report No.: 140702E01 Page 7 Report No.: 140702E01 Page 8

Report No.: SA140702E01 1 of 9 Report Format Version 5.0.0 RF EXPOSURE REPORT REPORT NO.: SA140702E01 MODEL NO.: AP-7502 FCC ID: UZ7AP7502 RECEIVED: July 02, 2014 TESTED: Aug. 01 to 04, 2014 ISSUED: Aug. 12, 2014 APPLICANT: Motorola Solutions, Inc. ADDRESS: One Motorola Plaza Holtsville, NY 11742-1300 MA NUFACTURER: Accton Technology Corporation ADDRESS: 1, Creation 3rd Rd., Science-based Industrial Park, Hsinchu 300, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: SA140702E01 2 of 9 Report Format Version 5.0.0 TABLE OF CONTENTS RELEASE CONTROL RECORD .................................................................................... 3 1. CERTIFICATION ...................................................................................................... 4 2. RF EXPOSURE LIMIT .............................................................................................. 5 3. MPE CALCULATION FORMULA ............................................................................. 5 4. CLASSIFICATION .................................................................................................... 5 5. ANTENNA GAIN....................................................................................................... 6 6. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER ........................... 7 Report No.: SA140702E01 3 of 9 Report Format Version 5.0.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA140702E01 Original release Aug. 12, 2014 Report No.: SA140702E01 5 of 9 Report Format Version 5.0.0 2. RF EXPOSURE LIMIT LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 3. MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale pi = 3.1416 r = distance between observation point and center of the radiator in cm 4. CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA140702E01 6 of 9 Report Format Version 5.0.0 5. ANTENNA GAIN The antenna provided to the EUT, please refer to the following table: WLAN (2.4GHz) Transmitter Circuit PCB Chain NO. Antenna Type Antenna Gain(dBi) Including cable loss Connector type Frequency range (GHz to GHz) Chain (0) ALA140-051025 PCB-Dipole 5.81 I-Pex 2400~2483.5 Chain (1) ALA140-051024 PCB-Dipole 4.52 I-Pex 2400~2483.5 WLAN (5GHz) Transmitter Circuit PCB Chain NO. Antenna Type Antenna Gain(dBi) Including cable loss Connector type Frequency range (GHz to GHz) Chain (0) ALA140-091020 PCB-Dipole 7.22 I-Pex 5150~5850 Chain (1) ALA140-091020 PCB-Dipole 7.3 I-Pex 5150~5850 BT Transmitter Circuit PCB Chain NO. Antenna Type Antenna Gain(dBi) Including cable loss Connector type Frequency range (GHz to GHz) Chain (0) ALC140-051020 PCB-Dipole 4.74 I-Pex 2400~2483.5 Report No.: SA140702E01 7 of 9 Report Format Version 5.0.0 6. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER For WLAN: 15.247(2.4GHz) 802.11b FREQUENCY (MHz) CONDUCTED POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 2412 - 2462 185.368 8.20 20 0.24365 1.00 NOTE: Directional gain = 10 log[(10 G1/20 + 10 G2/20 ) 2 / 2] = 8.20dBi. 802.11g FREQUENCY (MHz) CONDUCTED POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 2412 - 2462 342.766 8.20 20 0.45053 1.00 NOTE: Directional gain = 10 log[(10 G1/20 + 10 G2/20 ) 2 / 2] = 8.20dBi. 802.11n (HT20) FREQUENCY BAND (MHz) CONDUCTED POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 2412 - 2462 341.779 8.20 20 0.44924 1.00 NOTE: Directional gain = 10 log[(10 G1/20 + 10 G2/20 ) 2 / 2] = 8.20dBi. 802.11n (HT40) FREQUENCY BAND (MHz) CONDUCTED POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 2422 - 2452 152.641 8.20 20 0.20063 1.00 NOTE: Directio…

Text truncated - open the document above for the full version.

Report No.: RF140702E01-2 1 of 47 Report Format Version 5.2.1 FCC TEST REPORT (DTS) REPORT NO.: RF140702E01-2 MODEL NO.: AP-7502 FCC ID: UZ7AP7502 RECEIVED: July 02, 2014 TESTED: July 21 to Aug. 01, 2014 ISSUED: Aug. 12, 2014 APPLICANT: Motorola Solutions, Inc. ADDRESS: One Motorola Plaza Holtsville, NY 11742-1300 MANUFACTURER: Accton Technology Corporation ADDRESS: Creation 3rd Rd., Science-based Industrial Park, Hsinchu 300, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, Taiwan, R.O.C. TEST LOCATION (2): No.49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: RF140702E01-2 2 of 47 Report Format Version 5.2.1 TABLE OF CONTENTS RELEASE CONTROL RECORD ........................................................................................................ 4 1 CERTIFICATION ................................................................................................................ 5 2 SUMMARY OF TEST RESULTS ......................................................................................... 6 2.1 MEASUREMENT UNCERTAINTY ...................................................................................... 7 3 GENERAL INFORMATION ................................................................................................. 8 3.1 GENERAL DESCRIPTION OF EUT (DTS).......................................................................... 8 3.2 DESCRIPTION OF TEST MODES .....................................................................................10 3.3 TEST MODE APPLICABLITY AND TESTED CHANNEL DETAIL: ...................................... 11 3.4 GENERAL DESCRIPTION OF APPLIED STANDARDS .....................................................13 3.5 DUTY CYCLE OF TEST SIGNAL ......................................................................................14 3.6 DESCRIPTION OF SUPPORT UNITS ...............................................................................15 3.7 CONFIGURATION OF SYSTEM UNDER TEST.................................................................16 4 TEST TYPES AND RESULTS ............................................................................................18 4.1 CONDUCTED EMISSION MEASUREMENT .....................................................................18 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT....................................................18 4.1.2 TEST INSTRUMENTS .......................................................................................................18 4.1.3 TEST PROCEDURES .......................................................................................................19 4.1.4 DEVIATION FROM TEST STANDARD ..............................................................................19 4.1.5 TEST SETUP ....................................................................................................................19 4.1.6 EUT OPERATING CONDITIONS .......................................................................................20 4.1.7 TEST RESULTS (MODE 1) ...............................................................................................21 4.1.8 TEST RESULTS (MODE 2) ...............................................................................................23 4.2 RADIATED EMISSION AND BANDEDGE MEASUREMENT ..............................................25 4.2.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT ............................25 4.2.2 TEST INSTRUMENTS .......................................................................................................26 4.2.3 TEST PROCEDURES .......................................................................................................27 4.2.4 DEVIATION FROM TEST STANDARD ..............................................................................28 4.2.5 TEST SETUP ....................................................................................................................28 4.2.6 EUT OPERATING CONDITIONS .......................................................................................28 4.2.7 TEST RESULTS ................................................................................................................29 4.3 6dB BANDWIDTH MEASUREMENT .........................…

Text truncated - open the document above for the full version.

Report No.: RF140702E01 1 of 83 Report Format Version 5.2.1 FCC TEST REPORT (WLAN 15.247) REPORT NO.: RF140702E01 MODEL NO.: AP-7502 FCC ID: UZ7AP7502 RECEIVED: July 02, 2014 TESTED: July 24 to Aug. 04, 2014 ISSUED: Aug. 12, 2014 APPLICANT: Motorola Solutions, Inc. ADDRESS: One Motorola Plaza Holtsville, NY 11742-1300 MANUFACTURER: Accton Technology Corporation ADDRESS: 1, Creation 3rd Rd., Science-based Industrial Park, Hsinchu 300, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: RF140702E01 2 of 83 Report Format Version 5.2.1 Table of Contents RELEASE CONTROL RECORD ........................................................................................ 4 1. CERTIFICATION .................................................................................................... 5 2. SUMMARY OF TEST RESULTS ............................................................................ 6 2.1 MEASUREMENT UNCERTAINTY .......................................................................... 7 3. GENERAL INFORMATION ..................................................................................... 8 3.1 GENERAL DESCRIPTION OF EUT (WLAN) .......................................................... 8 3.2 DESCRIPTION OF TEST MODES ....................................................................... 11 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ........................ 12 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ....................................... 15 3.4 DUTY CYCLE OF TEST SIGNAL ......................................................................... 16 3.5 DESCRIPTION OF SUPPORT UNITS .................................................................. 17 3.6 CONFIGURATION OF SYSTEM UNDER TEST ................................................... 18 4. TEST TYPES AND RESULTS .............................................................................. 20 4.1 CONDUCTED EMISSION MEASUREMENT ........................................................ 20 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ...................................... 20 4.1.2 TEST INSTRUMENTS .......................................................................................... 20 4.1.3 TEST PROCEDURES .......................................................................................... 21 4.1.4 DEVIATION FROM TEST STANDARD ................................................................. 21 4.1.5 TEST SETUP ....................................................................................................... 21 4.1.6 EUT OPERATING CONDITIONS ......................................................................... 22 4.1.7 TEST RESULTS (MODE 1) .................................................................................. 23 4.1.8 TEST RESULTS (MODE 2) .................................................................................. 25 4.2 RADIATED EMISSION AND BANDEDGE MEASUREMENT ................................ 27 4.2.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT .............. 27 4.2.2 TEST INSTRUMENTS .......................................................................................... 28 4.2.3 TEST PROCEDURES .......................................................................................... 29 4.2.4 DEVIATION FROM TEST STANDARD ................................................................. 29 4.2.5 TEST SETUP ....................................................................................................... 30 4.2.6 EUT OPERATING CONDITIONS ......................................................................... 30 4.2.7 TEST RESULTS ................................................................................................... 31 4.3 6dB BANDWIDTH MEASUREMENT .................................................................... 55 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT .................................................. 55 4.3.2 TEST INSTRUMENTS .......................................................................................... 55 4.3.3 TEST PROCEDURE ............................................................................................. 55…

Text truncated - open the document above for the full version.

Report No.: 140407E07 1 of 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST (MODE 1) Report No.: 140407E07 2 of 5 CONDUCTED EMISSION TEST (MODE 2) Report No.: 140407E07 3 of 5 RADIATED EMISSION TEST (Below 1GHz) Report No.: 140407E07 4 of 5 RADIATED EMISSION TEST (Above 1GHz) Report No.: 140407E07 5 of 5
