UZ7CR0078Bluetooth Cradle with RS232 and USB

Regulatory Engineering Motorola, Inc., Enterprise Mobility Solutions One Motorola Plaza, | Holtsville, NY 11742 | 1.631.738.2400 phone | 1.631.627.7179 fax | www.motorola.com Technical Description Bluetooth Cradle, Model CR0078 Overview The CR0078 Bluetooth Cradle provides a power and communications link for the Motorola DS6878 Wireless Imager Scanner and LS4278 Laser Scanner. The CR0078 contains a Bluetooth EDR radio capable of transferring data at up to 3Mbps and also supports USB, RS232, Synapse, Keyboard Wedge and IBM46XX (RS485) interfaces for cradle to host communication. Cradle to Scanner Communication The Broadcom BCM2046 Bluetooth v2.1 + EDR radio provides a Bluetooth link to the DS6878 and LS4278 scanners allowing the transfer of images and barcode data at a maximum data transfer rate of 3Mbps. RF power from the Bluetooth radio is routed to a GigaAnt omni-directional antenna. The DS6878 automatically pairs with the CR0078 upon insertion in to the cradle. The CR0078 cradle also supports presentation scanning, utilizing the cradle contacts as GPIO’s when the DS6878 is docked in the cradle. Cradle to Host Communication The CR0078 cradle is a multi-interface product supporting USB, RS232, Synapse, Keyboard Wedge and IBM46XX (RS485.) This is achieved using a modified Multi-Interface architecture based off the Multi-Interface Micro (MIMIC). Using this standard allows compatibility with the existing Universal Cable Set and enables auto detection of the interface cable type. Power Supply Use ONLY a LISTED Motorola, Type no. 50-14000, or PWRS-14000, Direct Plug-In Power supply, marked Class 2 or LPS, or SELV, Rated 12 Vdc, 0.65 A Min. (IEC60950-1). Use of Alternative Power Supply will invalidate any approvals given to this unit and may be dangerous. Regulatory Engineering Motorola, Inc., Enterprise Mobility Solutions One Motorola Plaza, | Holtsville, NY 11742 | 1.631.738.2400 phone | 1.631.627.7179 fax | www.motorola.com CR0078Technical Specifications The following table summarizes the CR0078 intended operating environment and hardware specifications. Physical Characteristics Dimensions: 5.4 in L x 4 in W , 3.6 in H Weight: Approximately 7.9 oz Typical Voltage and Current (CR0078 Base): Voltage Typical Current 12 +/-10% VDC 650 mA Color: Gray User Environment Sealing Test to casual spill test: room temp., 4oz fluid of water, coffee and soda. Test method to be determined with Quality. (Note that this applies to desk mount configuration only) Operating Temperature: +32° to 122° F (0 to 40° C) Storage Temperature: +32 to 104° F (-20 to 70° C) Humidity: 5 % to 95 % RH (Non-Condensing) Drop Specifications: Tabletop drop: 30-inch drop to tile, 1 drop per side (6 drops total) at room temperature

Regulatory Engineering Motorola, Inc., Enterprise Mobility Solutions One Motorola Plaza, | Holtsville, NY 11742 | 1.631.738.2400 phone | 1.631.627.7179 fax | www.motorola.com Date: 10 th May, 2010 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia MD 21046 Subject: Letter of Authorization To the Commission: As the signatory for FCC applications under the Grantee code UZ7 (Motorola, Inc.), I hereby authorize Xinjian Zhang to sign all corresponding application documents relating to the processes of FCC Approval. This authorization is limited to the following Model(s): CR0078 If you have questions regarding the authorization, please don’t hesitate to contact me. Respectfully, Mark Luksich Motorola, Inc. Tel: 631 738 5134 [email protected]

Regulatory Engineering Motorola, Inc., Enterprise Mobility Solutions One Motorola Plaza, | Holtsville, NY 11742 | 1.631.738.2400 phone | 1.631.627.7179 fax | www.motorola.com Date: 2 nd September, 2010 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request FCC ID: UZ7CR0078 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram Parts List Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Yours sincerely, _______________________________ Contact person: Xinjian Zhang Title: Motorola EMS Regulatory Tel: +861084735117 Mail: [email protected]

Regulatory Engineering Motorola, Inc., Enterprise Mobility Solutions One Motorola Plaza, | Holtsville, NY 11742 | 1.631.738.2400 phone | 1.631.627.7179 fax | www.motorola.com Date: 2 nd September 2010 Federal Communications Commission Authorization and Evaluation Division Short-Term Confidentiality Request FCC ID: UZ7CR0078 Pursuant to DA 04-1705 of the Commission’s public notice, we request short- term confidential treatment for the following information until 45 days after the Grant Date of Equipment Authorization in order to ensure sensitive business information remains confidential until the actual marketing of the device: ‹ External Photos (file: CR0078 _TCF_Picture_of_Product.pdf) ‹ Internal Photos (file: CR0078_TCF_Picture_of_Product.pdf) ‹ Test Setup Photos (file: CR0078_Regulatory_Test_instructions.pdf) ‹ User Manual (file: CR0078_TCF_user_guide.pdf) Yours sincerely, ________________________________ Contact person: Xinjian Zhang Title: Motorola EMS Regulatory Tel: +861084735117 Mail: [email protected]

FCC ID: UZ7CR0078 IC ID:109AN-CR0078 Motorola Inc CR0078 2010 Not to be reproduced, except in its entirety, Page 1 of 6 without the Permission of TUV Product Service Ltd Reference: 75909238 PHOTOGRAPHS OF EQUIPMENT Front View FCC ID: UZ7CR0078 IC ID:109AN-CR0078 Motorola Inc CR0078 2010 Not to be reproduced, except in its entirety, Page 2 of 6 without the Permission of TUV Product Service Ltd Reference: 75909238 PHOTOGRAPHS OF EQUIPMENT Rear View FCC ID: UZ7CR0078 IC ID:109AN-CR0078 Motorola Inc CR0078 2010 Not to be reproduced, except in its entirety, Page 3 of 6 without the Permission of TUV Product Service Ltd Reference: 75909238 PHOTOGRAPHS OF EQUIPMENT Top View FCC ID: UZ7CR0078 IC ID:109AN-CR0078 Motorola Inc CR0078 2010 Not to be reproduced, except in its entirety, Page 4 of 6 without the Permission of TUV Product Service Ltd Reference: 75909238 PHOTOGRAPHS OF EQUIPMENT Bottom View FCC ID: UZ7CR0078 IC ID:109AN-CR0078 Motorola Inc CR0078 2010 Not to be reproduced, except in its entirety, Page 5 of 6 without the Permission of TUV Product Service Ltd Reference: 75909238 PHOTOGRAPHS OF EQUIPMENT Left Hand Side View FCC ID: UZ7CR0078 IC ID:109AN-CR0078 Motorola Inc CR0078 2010 Not to be reproduced, except in its entirety, Page 6 of 6 without the Permission of TUV Product Service Ltd Reference: 75909238 PHOTOGRAPHS OF EQUIPMENT Right Hand Side View

S/N: XXXXXXXXXXX S/N: BAR CODE BD_ADDR BAR CODE BD_ADDR: XXXXXXXXXXXXX MOTOROLA INC., HOLTSVILLE, N.Y. 0168 FCC ID: UZ7CR0078 IC: 109AN-CR0078 PART:CR0078-XXXXXXXXXXX MFD: XXXXXXX XXXX R XXXXXXXXXXXXXXX 30 S&E CMIIT ID:XXXXXXXXXX MODEL: CR0078 MADE IN MEXICO 12V 650mA ... ICES/NMB-003 CLASS B CCXXxxYYyyyZzW DISCARD PROD FAM: DS6878 DESCRIPTION: LBL:LCD, CR0078 CTRY CODE:NA COUNTRY: NA SN POOL: STANDARD LBL STOCK PN: 63-71186-01 SEE NOTE 2 LBL SCRIPT :C221401X C=13 *SEE NOTE 1 CCG1: S805 SEE NOTES 6 AND 8 SEE NOTE 4 SEE NOTE 7 NOTES: UNLESS OTHERWISE SPECIFIED 1. SCRIPT FILE TO BE CREATED BY MANUFACTURING PER SP-10083-01 SCRIPT FILE MUST MATCH THIS DOCUMENT EXACTLY AND HAVE SAME REVISION. 2. LABEL STOCK P/N IS SUBJECT TO CHANGE. CHECK BOM FOR ACTUAL P ART NUMBER. 3. IN ALL CASES "XXX......" REPRESENTS VARIABLE FIELDS IN SCRIPT FILE. ACTUAL NUMBER OF CHARACTERS IN SCRIPT FILE MAY V ARY. 4. SERIAL NUMBER MUST BE 4PT MINIMUM CHARACTER HEIGHT IN SCRIPT FILE. 5. PART NUMBER MAY OR MAY NOT HAVE DASH BEFORE COUNTRY CODE. SEE BOM FOR ACTUAL MODEL DESCRIPTION. 6. "MFD:" REPRESENTS MANUFACTURE DAY, MONTH, YEAR (IE: 12SEP03 ) 7. COUNTRY OF ORIGIN REQUIRED 8. PLANT CODE REQUIRED. TO BE LOCATED BY MANUFACTURING FOR BEST FIT IN SCRIPT FILE. REVISIONS DESCRIPTIONDATE REV.BYE.C.ZONEAPVD. No. REL'D PER EDR100492 REV'D PER EC47683 ALL A XZ 12/7/09 SIZE DWG. NO. SCALE: 1 / 1 ILLUSTRATOR SHEET 1 OF 1 X LBL:LCD, CROO78 69-132214-01 REV A B LJM XZ 6/15/10 LJM MIN-CR0078(B) 9B97 LOGOS OUTLINED IN RED TO BE ADDED TO SCRIPT FILE AT A LATER DATE WHEN APPROVALS ARE RECEIVED B

FCC ID: UZ7CR0078 IC ID:109AN-CR0078 Motorola Inc CR0078 2010 Not to be reproduced, except in its entirety, Page 1 of 3 without the Permission of TUV Product Service Ltd Reference: 75909238 PHOTOGRAPHS OF EQUIPMENT Internal View 1 FCC ID: UZ7CR0078 IC ID:109AN-CR0078 Motorola Inc CR0078 2010 Not to be reproduced, except in its entirety, Page 2 of 3 without the Permission of TUV Product Service Ltd Reference: 75909238 PHOTOGRAPHS OF EQUIPMENT Internal View 2 FCC ID: UZ7CR0078 IC ID:109AN-CR0078 Motorola Inc CR0078 2010 Not to be reproduced, except in its entirety, Page 3 of 3 without the Permission of TUV Product Service Ltd Reference: 75909238 PHOTOGRAPHS OF EQUIPMENT Internal View 3

Document 75909238 Report 04 Issue 2 September 2010 Report On FCC and IC Testing of the Motorola Inc CR0078 Cradle COMMERCIAL-IN-CONFIDENCE FCC ID: UZ7CR0078 IC ID: 109AN-CR0078 TUV Product Service Ltd, Octagon House, Concorde Way, Segensworth North, Fareham, Hampshire, United Kingdom, PO15 5RL Tel: +44 (0) 1489 558100. Website: www.tuvps.co.uk COMMERCIAL-IN-CONFIDENCE Document 75909238 Report 04 Issue 2 Page 1 of 27 COMMERCIAL-IN-CONFIDENCE REPORT ON FCC and IC Testing of the Motorola Inc CR0078 Cradle Document 75909238 Report 04 Issue 2 September 2010 PREPARED FOR Motorola Inc One Motorola Inc Plaza Holtsville NY 11742-1300 USA PREPARED BY S C Hartley EMC Engineer APPROVED BY C Lewis Authorised Signatory DATED 02 September 2010 ENGINEERING STATEMENT The measurements shown in this report were made in accordance with the procedures described on test pages. All reported testing was carried out on a sample equipment to demonstrate limited compliance with FCC CFR 47: Part 15 and RSS-Gen. The sample tested was found to comply with the requirements defined in the applied rules. Test Engineer(s); S C Hartley G Lawler A R Hubbard This report has been up-issued to Issue 2 to remove the photographs. COMMERCIAL-IN-CONFIDENCE Document 75909238 Report 04 Issue 2 Page 2 of 27 COMMERCIAL-IN-CONFIDENCE CONTENTS Section Page No 1 REPORT SUMMARY ................................................................................................................... 3 1.1 Introduction ................................................................................................................................... 4 1.2 Brief Summary of Results ............................................................................................................. 5 1.3 Declaration of Build Status ........................................................................................................... 6 1.4 Product Information ...................................................................................................................... 8 1.5 Test Conditions ........................................................................................................................... 10 1.6 Deviations From the Standard .................................................................................................... 10 1.7 Modification Record .................................................................................................................... 10 2 TEST DETAILS .......................................................................................................................... 11 2.1 Radiated Emissions (Enclosure Port) ......................................................................................... 12 2.2 Conducted Emissions (AC Power Port) ...................................................................................... 18 3 TEST EQUIPMENT USED ......................................................................................................... 23 3.1 Test Equipment Used ................................................................................................................. 24 3.2 Measurement Uncertainty .......................................................................................................... 25 4 ACCREDITATION, DISCLAIMERS AND COPYRIGHT ............................................................ 26 4.1 Accreditation, Disclaimers and Copyright ................................................................................... 27 COMMERCIAL-IN-CONFIDENCE Document 75909238 Report 04 Issue 2 Page 3 of 27 COMMERCIAL-IN-CONFIDENCE SECTION 1 REPORT SUMMARY FCC and IC Testing of the Motorola Inc CR0078 Cradle COMMERCIAL-IN-CONFIDENCE Document 75909238 Report 04 Issue 2 Page 4 of 27 COMMERCIAL-IN-CONFIDENCE 1.1 INTRODUCTION The information contained in this report is intended to show verification of the Motorola Inc, CR0078 Cradle to the requirements of FCC CFR 47 Part 15B and Industry Canada RSS-Gen. Objective To perform FCC and IC Testing to determine the Equipment Under Test's (EUT’s) compliance with the Test Specification, for the series of tests carried out. Manufacturer Motorola EUT Model Number(s) Cradle: CR0078 Cradle PSU (HIPRO): HP-0204D3 EUT Serial Number(s) Cradle: 9YZTX Cradle PSU: F3-09100155550D Support Equipment Model Number(s) Symbol Scanner: DS6878 Motorola RS232 AC Adaptor: DCH-050MV-0301 Support Equipment Serial Number(s) Symbol Scanner: MXA4VY34 Motorola RS232 AC Adaptor: 50-14000-253R Software Version Rev A Hardware Version Rev A Number of Samples Tested 1 (Cradle) Test Specification/Issue/Date FCC CFR 47 Part 15B: 2009 RSS-Gen, Issue 2: 2007 Incoming Release Date Declaration of Build Status 15 July 2010 Disposal Reference Number Date Held Pending Disposal Not Applicable Not Applicable Order Number Date NP5084073 09 March 2010 Start of Test 24 June 2010 Finish of Test 01 July 2010 Name of Engineer(s) S C Hartley G Lawler A R Hubbard Related Document(s) ANSI C63.4 : 2003 COMMERCIAL-IN-CONFIDENCE Document 75909238 Report 04 Issue 2 Page 5 of 27 COMMERCIAL-IN-CONFIDENCE 1.2 BRIEF SUMMARY OF RESULTS A brief summary of results for each configuration, in accord ance with FCC CFR 47 Part 15B and RSS-Gen is shown below. Configuration 1 - Stand Alone Section Spec Clause Test Description Mode Mod State Result Base Standard FCC IC 2.1 15.109 7.2.3, Table 1 Radiated Emissions (Enclosure Port) Char ge (Charging Scanner) 0 Pass ANSI C63.4 2.2 15.107 7.2.2, Table 2 Conducted Emissions (AC Power Port) Charge (Charging Scanner) 0 Pass ANSI C63.4 Configuration 2 - BT & RS232 Section Spec Clause Test Description Mode Mod State Result Base Standard FCC IC 2.1 15.109 7.2.3, Table 1 Radiated Emissions (Enclosure Port) Char ge (Charging Scanner) 0 Pass ANSI C63.4 2.2 15.107 7.2.2, Table 2 Conducted Emissions (AC Power Port) Charge (Charging Scanner) 0 Pass ANSI C63.4 Configuration 3 – USB Section Spec Clause Test Description Mode Mod State Result Base Standard F…
