RFS4011 Series Integrated Services Controller Installation Guide M RFS4000_Baseline.book Page 1 Tuesday, September 28, 2010 9:55 AM MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. Symbol is a registered trademark of Symbol Technologies, Inc. All other product or service names are the property of their respective owners. © Motorola, Inc. 2010. All rights reserved. RFS4000_Baseline.book Page 2 Tuesday, September 28, 2010 9:55 AM 1.0 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 2.0 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 3.0 LED Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 4.0 Hardware Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 5.0 Quick Start Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 6.0 Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 7.0 Part Numbers, Support, and Sales . . . . . . . . . . . . . . . . . . . . . 35 8.0 End-User License Agreement . . . . . . . . . . . . . . . . . . . . . . . . . 36 9.0 RFS4011 China ROHS Compliance . . . . . . . . . . . . . . . . . . . . . 39 Contents RFS4000_Baseline.book Page 3 Tuesday, September 28, 2010 9:55 AM RFS4000_Baseline.book Page 4 Tuesday, September 28, 2010 9:55 AM Introduction 1 1Introduction The Motorola RFS4011 Series Integrated Services Controller is a member of Motorola’s RFS Series Integrated Services Controller family. The RFS4011 provides centralized Wireless LAN (WLAN) configuration and management by coalescing a network “intelligence” previously spread across physically distributed access points. The RFS4011 simplifies deployment of a Wired/Wireless 802.11 a/b/g/n network, for a SME/SMB. With the integrated Layer 2/Layer 3 Networking Services such as integrated Layer 2 Switching with PoE+ ports, Onboard DHCP Server, Security Services like Wired/Wireless Firewall, Wireless IDS/IPS, Onboard AAA Server and IPSEC VPN Gateway, and QoS mechanisms to support Voice & Video , the RFS4011 transforms the enterprise by delivering a SMART Branch. The RFS4011 is the WLAN’s point of management reducing wireless networking complexity by moving management out of the ceiling and into the wiring closet. The RFS4011 can adopt up to 36 Adaptive APs or 6 Thin Access Points. The RFS4011 has integrated dual 802.11n radios, that are band unlocked, to provide access in both 2.4GHz and 5GHz simultaneously, or provide access in either band with the second radio capable of doing 24 by 7 security monitoring in both bands. This document is written for the network device installer. 1.1 Package Contents Inspect the package contents and report any missing or damaged items to your sales representative. The package should contain the following: •RFS4011 Series Integrated Services Controller •Console Cable •Installation Guide (this document) •Rubber Feet •Power Supply Unit 1.2 Document Conventions The following graphical alerts are used in this document to indicate notable situations: NOTETips, hints, or special requirements that you should take note of. RFS4000_Baseline.book Page 1 Tuesday, September 28, 2010 9:55 AM RFS4011 Series Integrated Services Controller: Installation Guide 2 1.3 Warnings •Read all installation instructions and site survey reports, and verify correct equipment installation before connecting the system to its power source. •Remove jewelry and watches before installing this equipment. •Install the equipment in a rack or on a desktop with adequate dimensions and weight allowances. •Verify the unit is grounded before connecting it to the power source. •Verify any device connected to this unit is properly wired and grounded. •Connect all power cords to a properly wired and grounded electrical circuit. •Verify the electrical circuits have appropriate overload protection. •Motorola strongly recommends the use of an Uninterruptible Power Supply (UPS) that supports the RFS4011 Series Integrated Services Controller power rating. Not using a UPS can result in data loss or equipment damage due to a power surge or power failure. •Verify that the power connector and socket are accessible at all times during the operation of the equipment. •Do not work with power circuits in dimly lit spaces. •Do not install this equipment or work with its power circuits during thunderstorms or other weather conditions that could cause a power surge. •Verify there is adequate ventilation around the device, and ambient temperatures meet equipment operation specifications. •This product is designed for in building installation only and is not intended to be connected to exposed (outside plant) networks. 1.4 Site Preparation •Consult your site survey and network analysis reports to determine specific equipment placement, port capacity, power drops, and so on. •Assign installation responsibility to the appropriate personnel. •Identify where all installed components are located. •Verify appropriate rack mounting requirements, as required. •Provide a sufficient number of power drops for your equipment. •Ensure adequate, dust-free ventilation to all installed equipment. •Identify and prepare Ethernet and console port connections. •Verify that cable lengths are within the maximum allowable distances for optimal signal transmission. •Verify that the RFS4011 Series Integrated Services Controller is powered through an Uninterruptible Power Supply (UPS). CAUTIONCare is required. Disregarding a caution can result in data loss or equipment malfunction. WARNING!Indicates a condition or procedure that could result in personal injury or equipment damage. ! RFS4000_Baseline.book Page 2 Tuesday, September 28, 2010 9:55 AM Specifications 3 2Specifications 2.1 Physical Specifications 2.2 Power Cord Specifications A power supply is included, however a power cord is not supplied with the controller…

Text truncated - open the document above for the full version.

Regulatory Engineering SYMBOL TECHNOLOGIES, INC. One Symbol Plaza, Holtsville, NY 11742-1300 • 516-738-2400 Website: http://www.symbol.com Symbol Technologies, Inc., a wholly owned subsidiary of Motorola, Inc. Date: July 28, 2010 GENERAL DECLARATION FCC ID: UZ7RFS4011 We, Motorola, Inc. declare that A d-Hoc mode for 5GHz operation is limited to the frequency band 5150 – 5250 MHz. If you have any questions regarding declaration, please don’t hesitate to contact us. Yours sincerely, ________________________________ Marco Belli Manager - Motorola EMS Regulatory +44 1256 484296 [email protected]

Regulatory Engineering Motorola, Inc., Enterprise Mobility Solutions One Motorola Plaza, | Holtsville, NY 11742 | 1.631.738.2400 phone | 1.631.627.7179 fax | www.motorola.com August 27, 2010 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia MD 21046 Subject: 5.60 - 5.65 GHz Restricted band Declaration for FCC: UZ7RFS4011 To the Commission: We, the undersigned, attest that this device does not support operation in the 5.60 – 5.65 GHz Restricted Band. The firmware on the device restricts the operation in this frequency band and does not utilize the channels in this band. Respectfully, Contact person: Marco Belli Title: Manager - Motorola EMS Regulatory Tel: +44 1256 484296 Mail: [email protected]

Regulatory Engineering Motorola, Inc., Enterprise Mobility Solutions One Motorola Plaza, | Holtsville, NY 11742 | 1.631.738.2400 phone | 1.631.627.7179 fax | www.motorola.com Date: September 23, 2010 Professional Installation Attestation To Whom It May Concern: Please be advised that due to the unique Market and function targeted by this product, this product will need special trained professional in configuring and installing the product. We hereby declare that the product will be distributed through controlled distribution channel which has special trained professional to install this product and will not be sold directly to the general public through retail store. This attestation is limited to the following products: Model name: RFS-4011, FCC ID: UZ7RFS4011 Yours sincerely, ________________________________ Contact person: Marco Belli Title: Manager - Motorola EMS Regulatory Tel: +44 1256 484296 Mail: [email protected]

Regulatory Engineering Motorola, Inc., Enterprise Mobility Solutions One Motorola Plaza, | Holtsville, NY 11742 | 1.631.738.2400 phone | 1.631.627.7179 fax | www.motorola.com Date: July 28, 2010 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request FCC ID: UZ7RFS4011 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Yours sincerely, ________________________________ Marco Belli Manager - Motorola EMS Regulatory +44 1256 484296 [email protected]

Regulatory Engineering Motorola, Inc., Enterprise Mobility Solutions One Motorola Plaza, | Holtsville, NY 11742 | 1.631.738.2400 phone | 1.631.627.7179 fax | www.motorola.com Date: July 28, 2010 Federal Communications Commission Authorization and Evaluation Division Short-Term Confidentiality Request FCC ID: UZ7RFS4011 Pursuant to DA 04-1705 of the Commission’s public notice, we request short- term confidential treatment for the following information until 180 days after the Grant Date of Equipment Authorization in order to ensure sensitive business information remains confidential until the actual marketing of the device: ‹ External Photos ‹ Internal Photos ‹ Test Setup Photos ‹ User Manual Yours sincerely, ________________________________ Marco Belli Manager - Motorola EMS Regulatory +44 1256 484296 [email protected]

Regulatory Engineering Motorola, Inc., Enterprise Mobility Solutions One Motorola Plaza, | Holtsville, NY 11742 | 1.631.738.2400 phone | 1.631.627.7179 fax | www.motorola.com Date: July 28, 2010 AGENCY AUTHORIZATION LETTER To whom it may concern: We, the undersigned, hereby authorize Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan) of Taiwan to act on our behalf, as our agent, in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by BV CPS Taoyuan within the scope of this authorization shall have the same effects as our own. This authorization shall expire 6 months from original date. If you have any questions regarding the authorization, please don’t hesitate to contact us. Yours Sincerely, ________________________________ Contact person: Marco Belli Title: Manager - Motorola EMS Regulatory Tel: +44 1256 484296 Mail: [email protected]

Regulatory Engineering Motorola, Inc., Enterprise Mobility Solutions One Motorola Plaza, | Holtsville, NY 11742 | 1.631.738.2400 phone | 1.631.627.7179 fax | www.motorola.com Date: July 28, 2010 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia MD 21046 Letter of Authorization As the designated signatory for FCC applications under the Grantee code UZ7 (Motorola, Inc.), I hereby authorize Marco Belli to sign all corresponding application documents relating to the processes of FCC Approval. This authorization is limited to the following Model: RFS-4011 under the FCC ID: UZ7RFS4011 If you have any questions regarding the authorization, please don’t hesitate to contact me. Respectfully, Mark Luksich Motorola, Inc. Tel: 631 738 5134 [email protected]

Page 1 CONSTRUCTION PHOTOS OF EUT Antenna type: PIFA Page 2 Page 3 Antenna type: Ceiling mounted patch Page 4 Page 5 Antenna type: Dipole Page 6 Page 7 Antenna type: Panel Page 8 Page 9 Page 10 Page 11 Page 12 Page 13

表面覆PET膜之Product Label 測試規範: 項次 測試項目 測試方法 測試要求 1. 冷熱衝擊 -30 O C / H -> 75 O C / H,共20循環 表面無脫落、水泡、捲翹 2. 低溫測試 -30 O C / 72H 表面無脫落、水泡、捲翹 3. 高溫測試 75 O C / 72H 表面無脫落、水泡、捲翹 4. 高溫高濕測試 70 O C，90%RH，72H 表面無脫落、水泡、捲翹 5. 3M 膠帶測試 膠帶貼附(90度抽離) 表面無脫落 6. 密著性 1mm方格 / 100格膠帶貼附(90度抽離) 表面無脫落 7. 耐磨耗性測試 橡皮擦荷重500g來回100次(60cycle/min) 不露底材 8. 耐酒精性測試 荷重500g/cm 2 下，以浸含工業酒精99.5%之棉花棒 以6cm距離，以每分鐘60來回之速度擦拭覆膜 不露底材 9. 鹽霧測試 5%鹽水，35 O C，pH6.5~7.2，48H 表面無脫落、水泡、捲翹 項次 測試項目 測試方法 測試要求 1. 冷熱衝擊 -30 O C / H -> 75 O C / H,共20循環 表面無脫落、水泡、捲翹 2. 低溫測試 -30 O C / 72H 表面無脫落、水泡、捲翹 3. 高溫測試 75 O C / 72H 表面無脫落、水泡、捲翹 4. 高溫高濕測試 70 O C，90%RH，72H 表面無脫落、水泡、捲翹 5. 鹽霧測試 5%鹽水，35 O C，pH6.5~7.2，48H 表面無脫落、水泡、捲翹 Product Label 測試規範:

Bottom Label location

Page 14 Page 15 Page 16 Page 17 Page 18 Page 19 Page 20 Page 21

FCC ID: UZ7RFS4011 Report No.: RF990114L03 Operational Description This device is a RF Switch, which operates in both of the 2.4GHz and 5GHz bands and can’t transmitting simultaneously, the maximum data rate could be up to 300Mbps which OFDM technique. If the signal to noise radio is too poor which could not support 300Mbps, the 11Mbps data rate with DSSS technique will be applied. The transmitter of the EUT is powered by ac adapter. The information of antennas listed as below: NO. ANTENNA MODEL TYPE 2.4G GAIN5.0G GAIN CONNECTOR TYPE 1 ML-2452-PTA4M3X3-1 PIFA 2.1dBi 3.95dBi RSMA 2 ML-2452-PTA3M3-036 Ceiling mounted patch 3.5dBi 5.0dBi RP-SMA-Male x 3 3 ML-2452-HPA5-036 Dipole 3.1dBi 4.6dBi RP-SMA-Male 4 ML-2452-PNA7-01R Panel 7.5dBi 6.3dBi for 4900-5250MHz 10.0dBi for 5250~5900MHz Type N-Male For more detailed instruction, please take a look at the user’s manual. FCC 15.407(c) states: The device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude the transmission of control or signaling information or the use of repetitive codes used by certain digital technologies to complete frame or burst intervals. Applicants shall include in their application for equipment authorization a description of how this requirement is met” Data transmission is always initiated by software, which is then pass down through the MAC, through the digital and analog baseband, and finally to the RF chip. Several special packets (ACKs, CTS, PSPoll, etc...) are initiated by the MAC. There are the only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on only while one of the aforementioned packets are being transmitted.

Report No.: SA990114L03 Report Format Version 3.0.1. 1 RF EXPOSURE REPORT REPORT NO.: SA990114L03 MODEL NO.: RFS-4011 FCC ID: UZ7RFS4011 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: Motorola, Inc. ADDRESS: One Motorola Plaza Holtsville NY 11742-1300 USA ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien 244, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. Report No.: SA990114L03 Report Format Version 3.0.1. 2 1. RF EXPOSURE LIMIT LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 2. MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r2) where Pd = power density in mW/cm2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 3. CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this dev1ice is classified as Mobile Device. Report No.: SA990114L03 Report Format Version 3.0.1. 3 4. CALCULATION RESULT OF MAXIMUM EIRP For 2412~2462MHz ANTENNA TYPE MAX CONDUCTED POWER (dBm) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) ANT 1 : ML-2452-PTA4M3X3-1 29.8 2.1 20 0.308 1.00 ANT 2 : ML-2452-PTA3M3-036 29.8 3.5 20 0.425 1.00 ANT 3 : ML-2452-HPA5-036 29.3 3.1 20 0.346 1.00 ANT 4 : ML-2452-PNA7-01R 28.1 7.5 20 0.722 1.00 For 5180~5240MHz ANTENNA TYPE MAX CONDUCTED POWER (dBm) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) ANT 1 : ML-2452-PTA4M3X3-1 15.6 3.95 20 0.018 1.00 ANT 2 : ML-2452-PTA3M3-036 15.7 5 20 0.023 1.00 ANT 3 : ML-2452-HPA5-036 16.7 4.6 20 0.027 1.00 ANT 4 : ML-2452-PNA7-01R 15.8 6.3 20 0.032 1.00 For 5745~5825MHz ANTENNA TYPE MAX CONDUCTED POWER (dBm) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) ANT 1 : ML-2452-PTA4M3X3-1 28.4 3.95 20 0.342 1.00 ANT 2 : ML-2452-PTA3M3-036 28.5 5 20 0.445 1.00 ANT 3 : ML-2452-HPA5-036 29.6 4.6 20 0.523 1.00 ANT 4 : ML-2452-PNA7-01R 25.7 10 20 0.739 1.00

Report No.: RF990114L03 1 Report Format Version 3.0.1 REVISED VERSION: Ver. 2 FCC TEST REPORT (15.247) REPORT NO.: RF990114L03 MODEL NO.: RFS-4011 FCC ID: UZ7RFS4011 RECEIVED: Jan. 14, 2010 TESTED: Feb. 05 ~ Jun. 07, 2010 ISSUED: Aug. 05, 2010 APPLICANT: Motorola, Inc. ADDRESS: One Motorola Plaza Holtsville NY 11742-1300 USA ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien 244, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 320 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval or endorsement by TAF or any government agency. The test results in the report only apply to the tested sample. Report No.: RF990114L03 2 Report Format Version 3.0.1 REVISED VERSION: Ver. 2 TABLE OF CONTENTS 1. CERTIFICATION........................................................................................................... 5 2. SUMMARY OF TEST RESULTS .................................................................................. 6 2.1 MEASUREMENT UNCERTAINTY................................................................................ 6 3. GENERAL INFORMATION ........................................................................................... 7 3.1 GENERAL DESCRIPTION OF EUT ............................................................................. 7 3.2 DESCRIPTION OF TEST MODES ............................................................................... 9 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST ........................................................ 10 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ............................. 12 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ............................................ 18 3.4 DESCRIPTION OF SUPPORT UNITS ....................................................................... 18 4. TEST TYPES AND RESULTS (FOR 2.4GHz BAND)................................................. 19 4.1 RADIATED EMISSION MEASUREMENT .................................................................. 19 4.1.1 LIMITS OF RADIATED EMISSION MEASUREMENT................................................ 19 4.1.2 TEST INSTRUMENTS................................................................................................ 20 4.1.3 TEST PROCEDURES ................................................................................................ 21 4.1.4 DEVIATION FROM TEST STANDARD....................................................................... 21 4.1.5 TEST SETUP.............................................................................................................. 22 4.1.6 EUT OPERATING CONDITIONS ............................................................................... 22 4.1.7 TEST RESULTS ......................................................................................................... 23 4.2 CONDUCTED EMISSION MEASUREMENT ............................................................. 75 4.2.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT........................................... 75 4.2.2 TEST INSTRUMENTS................................................................................................ 75 4.2.3 TEST PROCEDURES ................................................................................................ 76 4.2.4 DEVIATION FROM TEST STANDARD....................................................................... 76 4.2.5 TEST SETUP.............................................................................................................. 77 4.2.6 EUT OPERATING CONDITIONS ............................................................................... 77 4.2.7 TEST RESULTS ......................................................................................................... 78 4.3 6dB BANDWIDTH MEASUREMENT.......................................................................... 86 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT ....................................................... 86 4.3.2 TEST INSTRUMENTS................................................................................................ 86 4.3.3 TEST PROCEDURE................................................................................................... 86 4.3.4 DEVIATION FROM TEST STANDARD....................................................................... 86 4.3.5 TEST SETUP.............................................................................................................. 87 4.3.6 EUT OPERATING CONDITIONS ............................................................................... 87 4.3.7 TEST RESULTS ......................................................................................................... 88 4.4 MAXIMUM OUTPUT POWER .................................................................................. 104 4.4.1 LIMITS OF MAXIMUM OUTPUT POWER MEASUREMENT................................... 104 4.4.2 INSTRUMENTS ........................................................................................................ 104 4.4.3 TEST PROCEDURES .............................................................................................. 104 4.4.4 DEVIATION FROM TEST STANDARD..................................................................... 105 4.4.5 TEST SETUP............................................................................................................ 105 4.4.6 EUT OPERATING CONDITIONS ............................................................................. 105 4.4.7 TEST RESULTS ....................................................................................................... 106 4.5 POWER S…

Text truncated - open the document above for the full version.

Report No.: RF990114L03-1 1 Report Format Version 3.0.1 REVISED VERSION: Ver. 2 FCC TEST REPORT (15.407) REPORT NO.: RF990114L03-1 MODEL NO.: RFS-4011 FCC ID: UZ7RFS4011 RECEIVED: Jan. 14, 2010 TESTED: Feb. 05 ~ Jun. 07, 2010 ISSUED: Aug. 05, 2010 APPLICANT: Motorola, Inc. ADDRESS: One Motorola Plaza Holtsville NY 11742-1300 USA ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien 244, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 179 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval or endorsement by TAF or any government agency. The test results in the report only apply to the tested sample. Report No.: RF990114L03-1 2 Report Format Version 3.0.1 REVISED VERSION: Ver. 2 TABLE OF CONTENTS 1. CERTIFICATION........................................................................................................... 4 2. SUMMARY OF TEST RESULTS .................................................................................. 5 2.1 MEASUREMENT UNCERTAINTY................................................................................ 5 3. GENERAL INFORMATION ........................................................................................... 6 3.1 GENERAL DESCRIPTION OF EUT ............................................................................. 6 3.2 DESCRIPTION OF TEST MODES ............................................................................... 8 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST .......................................................... 9 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ............................. 11 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ............................................ 14 3.4 DESCRIPTION OF SUPPORT UNITS ....................................................................... 14 4. TEST TYPES AND RESULTS .................................................................................... 15 4.1 RADIATED EMISSION MEASUREMENT .................................................................. 15 4.1.1 LIMITS OF RADIATED EMISSION MEASUREMENT................................................ 15 4.1.2 LIMITS OF UNWANTED EMISSION OUT OF THE RESTRICTED BANDS .............. 15 4.1.3 TEST INSTRUMENTS................................................................................................ 16 4.1.4 TEST PROCEDURES ................................................................................................ 17 4.1.5 DEVIATION FROM TEST STANDARD....................................................................... 17 4.1.6 TEST SETUP.............................................................................................................. 18 4.1.7 EUT OPERATING CONDITION.................................................................................. 18 4.1.8 TEST RESULTS ......................................................................................................... 19 4.2 CONDUCTED EMISSION MEASUREMENT ............................................................. 55 4.2.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT........................................... 55 4.2.2 TEST INSTRUMENTS................................................................................................ 55 4.2.3 TEST PROCEDURES ................................................................................................ 56 4.2.4 DEVIATION FROM TEST STANDARD....................................................................... 56 4.2.5 TEST SETUP.............................................................................................................. 57 4.2.6 EUT OPERATING CONDITIONS ............................................................................... 57 4.2.7 TEST RESULTS ......................................................................................................... 58 4.3 MAXIMUM CONDUCTED OUTPUT POWER MEASUREMENT ............................... 66 4.3.1 LIMITS OF MAXIMUM CONDUCTED OUTPUT POWER MEASUREMENT............. 66 4.3.2 TEST INSTRUMENTS................................................................................................ 66 4.3.3 TEST PROCEDURE................................................................................................... 67 4.3.4 DEVIATION FROM TEST STANDARD....................................................................... 67 4.3.5 TEST SETUP.............................................................................................................. 67 4.3.6 EUT OPERATING CONDITIONS ............................................................................... 67 4.3.7 TEST RESULTS ......................................................................................................... 68 4.4 PEAK POWER EXCURSION MEASUREMENT ........................................................ 84 4.4.1 LIMITS OF PEAK POWER EXCURSION MEASUREMENT...................................... 84 4.4.2 TEST INSTRUMENTS................................................................................................ 84 4.4.3 TEST PROCEDURE................................................................................................... 84 4.4.4 DEVIATION FROM TEST STANDARD....................................................................... 85 4.4.5 TEST SETUP.............................................................................................................. 85 4.4.6 EUT OPERATING CONDITIONS ............................................................................... 85 4.4.7 TEST RESULTS .............................................................................…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST (Test Mode A) 2 CONDUCTED EMISSION TEST (Test Mode B) 3 CONDUCTED EMISSION TEST (Test Mode C) 4 CONDUCTED EMISSION TEST (Test Mode D) 5 RADIATED EMISSION TEST (Test Mode A) 6 RADIATED EMISSION TEST (Test Mode B) 7 RADIATED EMISSION TEST (Test Mode C) 8 RADIATED EMISSION TEST (Test Mode D)
