Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|
| 4 | 15C | 5.75 GHz - 5.79 GHz | 124.00 mW |
Modular TypeSingle Modular ApprovalConfidentialityLong Term Grant NotesSingle Modular Transmitter. Power listed is maximum combined conducted output power. Device operates with specific antennas in MIMO configurations as described in this filing. Compliance of this device in all final host configurations is the responsibility of the Grantee. This device is to be used only for mobile and fixed applications. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not transmit simultaneously with any other antenna or transmitter, except as evaluated in this filing or in accordance with FCC multi-transmitter product procedures. The antenna(s) used for this transmitter must not exceed a maximum gain of -1.57dBi and 3.71dBi in 2.4GHz and 5.8GHz bands, respectively. End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. This device has 20MHz and 40MHz bandwidth modes.
