UZ7XWING1XWING1

MPA Project Document 70-147018-01 REV A Copyright 2011 Motorola Solutions, Inc. 20110307-A i Confidential Material – Disclosure Strictly Prohibited. Title: XWING1 Users Guide Description/Abstract/Synopsis: The purpose of this document is to provide a user’s and integrator’s guide targeted for module integrators Motorola Solutions Document Number: Agile Released Revision #: Document Status: In Progress 70-XXXXXX-01 [ ] – Released Version MPA Document Number: 0 [ ] – Next Release In Process NA Division: Sub-team: [ ] – Document Obsolete Working Revision: XXXXX- MCD RF-SYS Obsolete Document Replaced By: Last Updated: 06/17/2011 Document Type: SPEC / IG N/A Confidentiality Statement: Classification: N/A [ x ] - Contains Motorola Solutions partner NDA related material (Disclosure requires a three- way NDA.) Partner Name Agreement Number [x] - For Motorola Solutions Internal Use Only [ ] - Disclosure allowed under Motorola Solutions NDA Only [x] - Does or may contain Motorola Solutions patentable property *** Direct this document’s disclosure inquires to (Job Title): TNT Archive Location/Path: Agile Current Owner: Giovanni Ritieni Authors / Contributors: Kevin Lamb MPA Project Document 70-147018-01 REV A Copyright 2011 Motorola Solutions, Inc. 20110307-A ii Confidential Material – Disclosure Strictly Prohibited. Revision History Rev # Author Date Notes 0.00 RITIENI 100422 Initial Revision Supporting or Reference Documentation MPA or Motorola Solutions Document Number Title MPA Project Document 70-147018-01 REV A Copyright 2011 Motorola Solutions, Inc. 20110307-A iii Confidential Material – Disclosure Strictly Prohibited. Release Signatures Required Divisional Role Motorola Solutions Associate Copyright Information No part of this document may be reproduced, stored in or introduced into a retrieval system, or transmitted in any form or by any means (electronic, mechanical, photocopying, recording, or otherwise) for any purposes, without the express written permission of Motorola Solutions, Inc. Motorola Solutions, Inc. may have patents, patent applications, trademarks, copyrights, or other intellectual property rights covering subject matter in this document. Except as expressly provided in any written license agreement from Motorola Solutions, Inc., the furnishing of this document does not give you any express or implied rights to these patents, trademarks, copyrights, or other intellectual property. © 2011 Motorola Solutions, Incorporated. All rights reserved. MPA Project Document 70-147018-01 REV A Copyright 2011 Motorola Solutions, Inc. 20110307-A iv Confidential Material – Disclosure Strictly Prohibited. • Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. IMPORTANT NOTE: FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. MPA Project Document 70-147018-01 REV A Copyright 2011 Motorola Solutions, Inc. 20110307-A v Confidential Material – Disclosure Strictly Prohibited. This device is intended only for OEM integrators under the following conditions: 1) The antenna must be installed such that 20 cm is maintained between the antenna and users, and 2) The transmitter module may not be co-located with any other transmitter or antenna, 3) For all products market in US, OEM has to limit the operation channels in CH1 to CH11 for 2.4G band by supplied firmware programming tool. OEM shall not supply any tool or info to the end-user regarding to Regulatory Domain change. As long as 3 conditions above are met, further transmitter test will not be required. However, the OEM integrator is still responsible for testing their end-product for any additional compliance requirements required with this module installed IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop configurations or co-location with another transmitter), then the FCC authorization is no longer considered valid and the FCC ID can not be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC authorization. • End Product Labeling …

Text truncated - open the document above for the full version.

Regulatory Engineering Motorola Solutions, Inc. One Motorola Plaza, | Holtsville, NY 11742 | 1.631.738.2400 phone | 1.631.627.7179 fax | www.motorola.com 27 JULY 11 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia MD 21046 To the Commission: This is a letter of declaration, attestations and requests for FCC ID: UZ7XWING1. DFS - “Ad HOC” Declaration We, the undersigned, attest that this device does not support “Ad-Hoc on non-US frequencies” and/or “on DFS frequencies”. The client software and associated drivers will not initiate any transmission on DFS frequencies. This includes transmissions for beacon ad-hoc or peer-to-peer modes. The radio supports 802.11d and will not transmit until a valid Master device is detected. In the case when 802.11d is not activated then only non-DFS channels are actively probed. This device does not act as an Access Point on 5.15 – 5.25 GHz but does support Ad- Hoc mode in this band. 2.4 GHz band: The product does support Access Point function (master) on 2.4 GHz Band but can only transmit on US channel (ch1 to ch13). Request for Permanent Confidentiality Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant Hereby requests confidential treatment of information accompanying this Application As outlined below: Operational Description Block Diagram Schematic Diagrams Regulatory Engineering Motorola Solutions, Inc. One Motorola Plaza, | Holtsville, NY 11742 | 1.631.738.2400 phone | 1.631.627.7179 fax | www.motorola.com The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Short Term Confidentiality is not requested. Respectfully, Mark Luksich DMTS, Regulatory Engineering 631-738-5134 [email protected]

Regulatory Engineering Motorola Solutions, Inc. One Motorola Plaza, | Holtsville, NY 11742 | 1.631.738.2400 phone | 1.631.627.7179 fax | www.motorola.com 27 JULY 11 Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia MD 21046 Subject: FCC - Authorization to act as Agent Letter To the Commission: We, the undersigned, hereby authorize Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan) of Taiwan to act on our behalf, as our agent, in the following matters related to the FCC approval of the XWING1 under FCC ID: UZ7XWING1 report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by BV CPS Taoyuan within the scope of this authorization shall have the same effects as our own. Respectfully, Mark Luksich DMTS, Regulatory Engineering 631-738-5134 [email protected]

FCC ID: UZ7XWING1 Report No.: RF110408E05 Modular Approval Request Letter Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch August 3, 2011 Dear Application Examiner, Motorola Solutions, Inc., It’s a XWING1, FCC ID: UZ7XWING1 would like to have your authorization as a modular device. The requirements of section 15.212 of FCC rules have been met and shown on the following statements. 1. “The modular transmitter must have its own RF shielding.”: The radio portion of this module has been shielded, please see exhibition External Photo. 2. “The modular transmitter must have buffered modulation/data inputs.” The EUT has buffered data inputs, it is integrated in chip T1WL1273WSP. 3. “The modular transmitter must have its own power supply regulation.” The part number of this regulator is T1WL1273WSP. 4. “The modular transmitter must comply with the antenna requirements of section 15.203 and 15.204(C).” The EUT meets the FCC antenna requirements. The spurious emission, unique antenna connector and photo of antennas are shown in the test report. 5. “The modular transmitter must be tested in a stand-alone configuration” The EUT was tested in a stand-alone configuration via extender. Please see section Photographs of Test Configuration in the test report, the EUT was plugged in this extender. 6. “The modular transmitter must be labeled with its own FCC ID number.” Please see exhibition Label Sample for the FCC ID of this module. And also in the exhibition Users Manual, there are instructions give to the OEM on how to label the end product. FCC ID: UZ7XWING1 Report No.: RF110408E05 7. “The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements.” The EUT is compliant with all applicable FCC rules. Detail instructions for maintaining compliance are given in the Users Manual. 8. “The modular transmitter must comply with any applicable RF exposure requirements.” The EUT is compliant with all applicable RF exposure requirements. RF Exposure is addressed in the RF exposure exhibition. Please contact me if you have any further questions. Thanks for your attention. Best Regards, signature Hank Chung Assistant Manager Bureau Veritas Consumer Products Services (H.K.) Ltd., Hsinchu Branch

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2

Label Location

Page 3 Page 4

Report No.: SA110408E05 Report Format Version 4.0.0 1 RF EXPOSURE REPORT REPORT NO.: SA110408E05 MODEL NO.: XWING1 FCC ID: UZ7XWING1 APPLICANT: Motorola Solutions, Inc. ADDRESS: One Motorola Plaza, Holtsville, NY 11742-1300 USA ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan This test report consists of 6 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced, except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval or endorsement by any government agency. The test results in the report only apply to the tested sample. Report No.: SA110408E05 Report Format Version 4.0.0 2 TABLE OF CONTENTS RELEASE CONTROL RECORD....................................................................................3 1. CERTIFICATION......................................................................................................4 2. RF EXPOSURE LIMIT..............................................................................................5 3. MPE CALCULATION FORMULA.............................................................................5 4. CLASSIFICATION....................................................................................................5 5. ANTENNA GAIN.......................................................................................................5 6. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER...........................6 Report No.: SA110408E05 Report Format Version 4.0.0 3 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA110408E05 Original release July 28, 2011 Report No.: SA110408E05 Report Format Version 4.0.0 4 1. CERTIFICATION PRODUCT: XWING1 BRAND NAME: MOTOROLA MODEL NO.: XWING1 TEST SAMPLE: ENGINEERING SAMPLE APPLICANT: Motorola Solutions, Inc. STANDARDS: FCC Part 2 (Section 2.1091) FCC OET Bulletin 65, Supplement C (01-01) IEEE C95.1 The above equipment (Model: XWING1) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: June 22, 2011 ( Claire Kuan, Specialist ) APPROVED BY : , DATE: June 22, 2011 ( May Chen, Deputy Manager ) Report No.: SA110408E05 Report Format Version 4.0.0 5 2. RF EXPOSURE LIMIT LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 3. MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r2) where Pd = power density in mW/cm2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 4. CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. 5. ANTENNA GAIN There is antenna provided to this EUT, please refer to the following table: Antenna Model Antenna Type Antenna Gain(dBi) cable loss (dBi) Net Gain (dBi) Connecter Type Frequency range (MHz) ML-2452-APA2-01 Dipole 3 dBi (2.4GHz) 5 dBi (5GHz) 0.4 dBi (2.4GHz) 0.8 dBi (5GHz) 2.6 dBi (2.4GHz) 4.2 dBi (5GHz) SMA Female 2400 ~ 2500 5150 ~ 5850 Report No.: SA110408E05 Report Format Version 4.0.0 6 6. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER For 15.247(2.4GHz): FREQUENCY BAND (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 2412-2462 269.2 2.6 20 0.097 1.00 For 15.247(5GHz): FREQUENCY BAND (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 5745-5825 166.0 4.2 20 0.087 1.00 For 15.407(5GHz): FREQUENCY BAND (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 5180-5240 72.4 4.2 20 0.038 1.00 --- END ---

Report No.: RF110408E05-2 1 Report Format Version 4.0.0 FCC TEST REPORT (15.407) REPORT NO.: RF110408E05-2 MODEL NO.: XWING1 FCC ID: UZ7XWING1 RECEIVED: Apr. 08, 2011 TESTED: Apr. 28 to June 16, 2011 ISSUED: July 28, 2011 APPLICANT: Motorola Solutions, Inc. ADDRESS: One Motorola Plaza, Holtsville, NY 11742-1300 USA ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan TEST LOCATION (2): No.49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan This test report consists of 140 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF110408E05-2 2 Report Format Version 4.0.0 Table of Contents RELEASE CONTROL RECORD..............................................................................4 1. CERTIFICATION...........................................................................................5 2. SUMMARY OF TEST RESULTS...................................................................6 2.1 MEASUREMENT UNCERTAINTY.....................................................................7 3. GENERAL INFORMATION...........................................................................8 3.1 GENERAL DESCRIPTION OF EUT..............................................................8 3.2 DESCRIPTION OF TEST MODES..............................................................10 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL:.............11 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS.............................14 3.4 DESCRIPTION OF SUPPORT UNITS........................................................15 3.5 CONFIGURATION OF SYSTEM UNDER TEST.........................................15 4. TEST TYPES AND RESULTS.....................................................................17 4.1 CONDUCTED EMISSION MEASUREMENT..............................................17 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT............................17 4.1.2 TEST INSTRUMENTS................................................................................17 4.1.3 TEST PROCEDURES.................................................................................18 4.1.4 DEVIATION FROM TEST STANDARD.......................................................18 4.1.5 TEST SETUP..............................................................................................19 4.1.6 EUT OPERATING CONDITIONS................................................................19 4.1.7 TEST RESULTS..........................................................................................20 4.2 RADIATED EMISSION MEASUREMENT...................................................22 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT.................................22 4.2.2 LIMITS OF UNWANTED EMISSION OUT OF THE RESTRICTED BANDS23 4.2.3 TEST INSTRUMENTS................................................................................24 4.2.4 TEST PROCEDURES.................................................................................26 4.2.5 DEVIATION FROM TEST STANDARD.......................................................26 4.2.6 TEST SETUP..............................................................................................27 4.2.7 EUT OPERATING CONDITION..................................................................27 4.2.8 TEST RESULTS..........................................................................................28 4.3 OUTPUT TRANSMIT POWER MEASUREMENT.......................................63 4.3.1 LIMITS OF OUTPUT TRANSMIT POWER MEASUREMENT.....................63 4.3.2 TEST INSTRUMENTS................................................................................63 4.3.3 TEST PROCEDURE...................................................................................63 4.3.4 DEVIATION FROM TEST STANDARD.......................................................63 4.3.5 TEST SETUP..............................................................................................64 4.3.6 EUT OPERATING CONDITIONS................................................................64 4.3.7 TEST RESULTS(MODE A)..........................................................................65 4.3.8 TEST RESULTS(MODE B).........................................................................91 4.4 PEAK POWER EXCURSION MEASUREMENT.........................................93 4.4.1 LIMITS OF PEAK POWER EXCURSION MEASUREMENT.......................93 4.4.2 TEST INSTRUMENTS................................................................................93 4.4.3 TEST PROCEDURE...................................................................................93 4.4.4 DEVIATION FROM TEST STANDARD.......................................................94 4.4.5 TEST SETUP..............................................................................................94 4.4.6 EUT OPERATING CONDITIONS................................................................94 4.4.7 TEST RESULTS..........................................................................................95 Report No.: RF110408E05-2 3 Report Format Version 4.0.0 4.5 PEAK POWER SPECTRAL DENSITY MEASUREMENT.........................109 4.5.1 LIMITS OF PEAK POWER SPECTRAL DENSITY MEASUREMENT.......109 4.5.2 TEST INSTRUMENTS..............................................................................109 4.5.3 TEST PROCEDURES...............................................................................109 4…

Text truncated - open the document above for the full version.

Report No.: RF110408E05 1 Report Format Version 4.0.0 DFS TEST REPORT REPORT NO.: RF110408E05 MODEL NO.: XWING1 RECEIVED: July 26, 2011 TESTED: July 26, 2011 ISSUED: July 28, 2011 APPLICANT : Motorola Solutions, Inc. ADDRESS : One Motorola Plaza, Holtsville, NY 11742-1300 USA ISSUED BY : Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C This test report consists of 24 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF110408E05 2 Report Format Version 4.0.0 Table of Contents RELEASE CONTROL RECORD..............................................................................3 1 LAB DECLARATION.....................................................................................4 2 EUT INFORMATION.....................................................................................5 2.1 OPERATING FREQUENCY BANDS AND MODE OF EUT...........................5 2.2 EUT SOFTWARE AND FIRMWARE VERSION............................................5 2.3 DESCRIPTION OF AVAILABLE ANTENNAS TO THE EUT..........................5 2.4 EUT MAXIMUM CONDUCTED POWER......................................................5 2.5 EUT MAXIMUM E.I.R.P. POWER.................................................................6 2.6 TRANSMIT POWER CONTROL (TPC).........................................................6 2.7 STATEMENT OF MAUNFACTURER............................................................6 3 U-NII DFS RULE REQUIREMENTS.............................................................7 3.1 WORKING MODES AND REQUIRED TEST ITEMS....................................7 3.2 TEST LIMITS AND RADAR SIGNAL PARAMETERS...................................8 4 TEST & SUPPORT EQUIPMENT LIST.......................................................12 4.1 TEST INSTRUMENTS................................................................................12 4.2 DESCRIPTION OF SUPPORT UNITS........................................................12 5 TEST PROCEDURE...................................................................................13 5.1 ADT DFS MEASUREMENT SYSTEM:........................................................13 5.2 CALIBRATION OF DFS DETECTION THRESHOLD LEVEL:.....................14 5.3 DEVIATION FROM TEST STANDARD.......................................................15 5.4 CONDUCTED TEST SETUP CONFIGURATION........................................15 2.1.1 CLIENT WITHOUT RADAR DETECTION MODE.......................................15 6 TEST RESULTS..........................................................................................16 6.1 SUMMARY OF TEST RESULTS.................................................................16 6.2 DETAIL TEST RESULTS.............................................................................17 6.2.1 DFS DETECTION THRESHOLD..................................................................17 6.2.2 CHANNEL CLOSING TRANSMISSION AND CHANNEL MOVE TIME.......18 6.2.3 NON- OCCUPANCY PERIOD.....................................................................19 6.2.4 NON- CO-CHANNEL TEST........................................................................21 7 TESTING LABORATORIES INFORMATION..............................................22 7.1 APPENDIX-A-MODIFICATIONS OR ADDING COMPONENTS DURING THE TEST..................................................................................................23 7.2 APPENDIX-B..............................................................................................24 Report No.: RF110408E05 3 Report Format Version 4.0.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED RF110408E05 Original release July 28, 2011 Report No.: RF110408E05 4 Report Format Version 4.0.0 1 LAB DECLARATION PRODUCT: XWING1 BRAND: MOTOROLA MODEL: XWING1 TEST SAMPLE: ENGINEERING SAMPLE APPLICANT: Motorola Solutions, Inc. TESTED: Jul. 26, 2011 STANDARDS: FCC Part 15, Subpart E (Section 15.407) FCC 06-96 The above equipment (model: XWING1) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: July 27, 2011 ( Claire Kuan, Specialist ) APPROVED BY : , DATE: July 27, 2011 ( May Chen, Deputy Manager ) Report No.: RF110408E05 5 Report Format Version 4.0.0 2 EUT INFORMATION 2.1 OPERATING FREQUENCY BANDS AND MODE OF EUT TABLE 1: OPERATING FREQUENCY BANDS AND MODE OF EUT OPERATING FREQUENCY RANGE OPERATIONAL MODE 5250~5350MHz 5470~5725MHz Client without radar detection and ad hoc function ̧ ̧ 2.2 EUT SOFTWARE AND FIRMWARE VERSION TABLE 2: THE EUT SOFTWARE/FIRMWARE VERSION NO. PRODUCT MODEL NO. SOFTWARE/FIRMWARE VERSION 1 XWING1 XWING1 Driver Version: X_1.00.0.0.36B Firmware: Rev 6.1.3.11.54 2.3 DESCRIPTION OF AVAILABLE ANTENNAS TO THE EUT TABLE 3: ANTENNA LIST Ant Set Model Type Operation Frequency Range Max. Gain(dBi) 1 ML-2452-APA2-01 Dipole 5150-5850 MHz 5 2.4 EUT MAXIMUM CONDUCTED POWER TABLE 4: THE MEASURED CONDUCTED OUTPUT POWER IEEE 802.11n HT20 MAX. POWER ANT SET. FREQUENCY BAND (MHz) OUTPUT POWER(dBm) OUTPUT POWER(mW) 1 5250~5350 17.6 57.5 1 5470~5725 17.8 60.3 Report No.: RF110408E05 6 Report Format Version 4.0.0 2.5 EUT MAXIMUM E.I.R.P. POWER TABLE 5: THE E.I.R.P OUTPUT POWER LIST IEEE 802.11n HT20 MAX. POWER ANT SET. FREQUENCY BAND (MHz) OUTPUT POWER(dBm) O…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST 2 RADIATED EMISSION TEST (below 1GHz) 3 RADIATED EMISSION TEST 1 PHOTOGRAPHS OF THE TEST CONFIGURATION Set UUT as Client without radar detection mode (Radar injected into Master) UUT Master
