V37-OR6222-7DW7DW Digital Photo Frame

Table of Contents....................................................................2 Important Safety Precautions.......................................................3 Cleaning the LCD Screen.....................................................3 Cleaning the Digital Picture Frame........................................3 What's in the Box.....................................................................4 Identifying the Parts...........................................................4 Replacing Remote Control Battery........................................5 Product Specification...............................................................6 Features...........................................................................6 Specification.....................................................................6 Using the Digital Picture Frame..................................................7 Select Mode......................................................................7 Card Selection...................................................................7 Photo...............................................................................8 Music...............................................................................8 Video...............................................................................9 File Management...............................................................9 Time...............................................................................10 Frequently Asked Questions....................................................11 Table of Contents 3 Important Safety Precautions Always follow these basic safety precautions when using your Digital Picture Frame. This will reduce the risk of fire, electric shock, and injury. Warning: To reduce the risk of fire or shock hazard, do not expose this product to rain or moisture. Warning: To prevent the risk of electric shock, do not remove the cover. There are no user-serviceable parts inside. Refer all servicing to qualified personnel.  The Digital Picture Frame is for indoor use only.  Unplug the Digital Picture Frame before performing care and maintenance.  Do not clock the ventilation holes on the back of the Digital Picture Frame at any time.  Keep your Digital Picture Frame out of direct sunlight and heat sources.  Protect the power cord. Route power cords so that they are not likely to be walked on or pinched by items places on or against them. Pay particular attention to the point where the cord attaches to the Digital Picture Frame.  Only use the AC adapter included with the Digital Picture Frame. Using any other power adapter will void your warranty.  Unplug the power cord from the outlet when the unit is not in use. Cleaning the LCD Screen Treat the screen gently. To clean fingerprints or dust from the LCD screen, it is recommended to use a soft, non-abrasive cloth such as a camera lens cloth to clean the LCD screen. If you use a commercial LCD cleaning kit, do not apply the cleaning liquid directly to the LCD screen. Clean the LCD screen with cleaning cloth moistened with the liquid. Cleaning the Digital Picture Frame Clean the outer surface of the Digital Picture Frame (excluding the screen) with a soft cloth dampened with water. What's In the Box Digital Picture Frame Power Adapter Remote Control USB Cable User's Manual Identifying the Parts 4 DIGITAL PICTURE FRAME SETUP 5 Replacing the Remote Control Battery If the remote control stops working or works improperly, replace the battery (CR2025 lithium battery) with a new one. 1.Pull out the battery holder. 2.Remove the old battery from the holder and then put a new battery with “+” facing up. 3.Insert the battery holder back to the remote control. Notes When the lithium battery becomes weak, the operating distance of the Remote Control may shorten, or the Remote Control may not function properly. In this case, replace the battery with a CR2025 lithium battery. Use of another battery may present a risk of fire or explosion. Dispose the used batteries as specified by the local authorities. Do not leave the Remote Control in a very hot and humid place. Incorrect use of the battery may cause leaking and corrosion. -When the Remote control will not be used for a long period of time, remove the battery from the remote control to prevent leaking and corrosion. -Incorrectly inserting, shorting, dismantling, or heating the battery, or throwing it into a fire may cause the battery to rupture and leak. Warning Battery may explode if mistreated. Do not recharge, disassemble or dispose of in fire Product Specification Features  Supports JPEG and BMP image formats Image rotation, zoom in, background music Display files by name or by date ArcSoft™ effects: Dynamic Lighting, Face Beautify, and Face Tracking Specification Product 7” Digital Photo Frame Resolution 800 x 480pixel Memory Card Formats Secure Digital™, Multi-Media Card™, Memory Stick™, Memory Stick Pro™, Memory Stick Duo™, Memory Stick Pro Duo™, and USB flash drives Image FormatsJPEG Audio FormatsMp3 Video FormatsMPEG1, M-JPEG, AVI, Divx USB PortsUSB 2.0 (Host) x 1, mini-USB x 1 Power InputAC 100V~240V, 50~60Hz Power OutputDC 5V / 1.5A Internal Speakers 0.5W x 2 Certification CE / FCC / RoHS 6 Using the Digital Picture Frame After the Digital Picture Frame is turned on, the slide show starts automatically after 2 seconds. Press EXIT button to Select Mode screen.  Select Mode In Select Mode, you will see below screen. There are 6 options: Card Selection, Photo, Music, Video, File Management, and Time. Card Photo Music Video File Time  Card Selection If there is not any memory card inserted, “Internal Memory” shows. When the memory card is inserted, ex. SD card, the icon will change to SD; if the MS card is inserted, the icon will change to MS. The card also can be selected by pressing ENTER on the Card Selection icon. 7  Photo  By pressing SETUP, there are options of File Sorting, Copy Photo(memor…

Text truncated - open the document above for the full version.

5 5 4 4 3 3 2 2 1 1 DD CC BB AA 3.3V 33M HZ(CLK) SDRAM - 8Mx16bit POWER KEY,ON/OFF USB HOST SPEAKER SD/MS/XD/MMC CARD 32.768K RTC OSC 24M SYS OSC 144 M HZ USB Device 2.0 AML6222D 2 X 0.5W LDO 3.3V 1.2V 7''HANNSTAR Digital Panel 800X480 LDO 1.2V DC 5V IN 5 Function Key PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 Revised wording (current) 1.0 2.0 Sept–25-2007 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 WIN ACCORD LTD. June 28, 2010 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, WIN ACCORD LTD. to act as a Certification Body for certifying for the following project(s): Product: 7DW Digital Photo Frame Model Name: DF07109-14-XXX, VFD724W, DF07108-14-XXX(X=A-Z,a-z,0-9) We affirm that between SIEMIC and WIN ACCORD LTD. any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Kelly Chen Board Chairman WIN ACCORD LTD. 12F, NO. 225, SEC 5, 105 SONG SHAN DIST., NAN JING EAST ROAD, TAIPEI, TAIWAN Tel: +886-2-2749-3837 Fax: +886-2-2749-3918 E-mail: [email protected]

General Appearance of the EUT

IC ID Lable Location On EUT

Dongguan EMTEK Co., Ltd. Report No. ：ED10060056-2 Page 1 of 35 FCC TEST REPORT For 7DW Digital Photo Frame MODEL No.: DF07109-14-XXX, VFD724W, DF07108-14-XXX(X=A-Z,a-z,0-9) Trademark: N/A FCC ID: V37-OR6222-7DW REPORT NO: ED10060056-2 ISSUE DATE: June 26, 2010 Prepared for WIN ACCORD LTD. 12F, NO. 225, SEC 5, 105 SONG SHAN DIST., NAN JING EAST ROAD, TAIPEI, TAIWAN Prepared by DONGGUAN EMTEK CO., LTD No. 281, Guantai Road, Nancheng District, Dongguan, Guangdong, China TEL: +86-769-22807078 FAX: +86-769-22807079 Dongguan EMTEK Co., Ltd. Report No. ：ED10060056-2 Page 2 of 35 TABLE OF CONTENTS 1. GENERAL INFORMATION ............................................................................................................... 4 1.1 Description of Device (EUT)........................................................................................................................... 4 1.2. Description of Support Device ....................................................................................................................... 5 1.3 Test Facility ..................................................................................................................................................... 6 1.4 Measurement Uncertainty................................................................................................................................ 6 2. POWER LINE CONDUCTED MEASUREMENT ............................................................................ 7 2.1. Test Equipment ............................................................................................................................................... 7 2.2. Block Diagram of Test Setup.......................................................................................................................... 8 2.3. Power Line Conducted Emission Measurement Limits.................................................................................. 8 2.4. Configuration of EUT on Measurement ......................................................................................................... 9 2.5. Operating Condition of EUT .......................................................................................................................... 9 2.6. Test Procedure ................................................................................................................................................ 9 2.7. Power Line Conducted Emission Measurement Results .............................................................................. 10 3. RADIATED EMISSION MEASUREMENT .................................................................................... 19 3.1. Test Equipment ............................................................................................................................................. 19 3.2. Block Diagram of Test Setup........................................................................................................................ 20 3.3. Radiated Emission Limit .............................................................................................................................. 21 3.4. EUT Configuration on Measurement ........................................................................................................... 21 3.5. Operating Condition of EUT ........................................................................................................................ 21 3.6. Test Procedure .............................................................................................................................................. 22 3.7. Radiated Emission Noise Measurement Results........................................................................................... 22 4. PHOTOGRAPHS ................................................................................................................................ 31 Dongguan EMTEK Co., Ltd. Report No. ：ED10060056-2 Page 3 of 35 TEST REPOTR DESCRIPTION Applicant : WIN ACCORD LTD. Manufacturer : WIN ACCORD LTD. EUT : 7DW Digital Photo Frame FCC ID No. : V37-OR6222-7DW Test Voltage : AC 120V 60Hz File Number : ED10060056-2 Date of Test : June 11, 2010 to June 26, 2010 Measurement Procedure Used: FCC Rules and Regulations Part 15 Subpart B Class B October 2009 & FCC / ANSI C63.4-2009 The device described above is tested by Dongguan EMTEK Co., Ltd. to determine the maximum emission levels emanating from the device. The maximum emission levels are compared to the FCC Part 15 Subpart Class B limits both radiated and conducted emissions. The measurement results are contained in this test report and Dongguan EMTEK Co., Ltd. is assumed full responsibility for the accuracy and completeness of these measurements. Also, this report shows that the Equipment Under Test (EUT) is to be technically compliant with the FCC requirements. This report applies to above tested sample only. This report shall not be reproduced in part without written approval of Dongguan EMTEK Co., Ltd. Approved By Nicol Lee / Q.A. Manager DONGGUAN EMTEK CO., LTD. Dongguan EMTEK Co., Ltd. Report No. ：ED10060056-2 Page 4 of 35 1. GENERAL INFORMATION 1.1. Description of Device (EUT) EUT : 7DW Digital Photo Frame Model Number : Basic Model: DF07109-14-XXX (X=A-Z, a-z, 0-9); Additional Model: VFD724W, DF07108-14-XXX(X=A-Z, a-z, 0-9) (Note: These models are the same except model number, all models use the same FCC ID Number.) Cable : USB Line, 1.5m shielded line, with a core. FCC ID Number : V37-OR6222-7DW Trade Mark : N/A Power Supply : AC 120V 60Hz Adapter : Manufacturer: E-TEK Electronics Manufactory Ltd. M/N: ZDA050150US Input: AC 100~240V 50/60Hz 0.35A Output: DC 5V 1.5A Applicant : WIN ACCORD LTD. Address : 12F, NO. 225, SEC 5, 105 SONG SHAN DIST., NAN JING EAST ROAD, TAIPEI, TAIWAN Manufacturer : WIN ACCORD LTD. Address : 12F, NO. 225, SEC 5, 105 SONG SHAN DIST., NAN JING EAST ROAD, TAIPEI, TAIWAN Date of sample receiver : June 11, 2010 Date o…

Text truncated - open the document above for the full version.

Conducted Emission Setup Photos Radiated Emission Setup Photos
