V7IAREI9LFRFID Reader

Manual ACM 9 ARE i9 Manual ACM 9 - ARE i9 release Version: 05 Page: 2 / 45 Manual ACM9_ARE i9 release V05.docx 1. Introduction ................................................................................................................................................... 5 2. ACM 9 ............................................................................................................................................................. 6 2.1 Hardware ............................................................................................................................................... 6 2.1.1 Dimensions ........................................................................................................................................ 6 2.1.2 Protection Class ................................................................................................................................ 6 2.1.3 Connectivity ...................................................................................................................................... 7 2.1.4 Grounding .......................................................................................................................................... 9 2.2 Firmware ............................................................................................................................................. 10 2.2.1 Industrial Ethernet description files ............................................................................................. 10 2.2.2 Output data telegram from Industrial Ethernet master ............................................................. 10 2.2.3 Input data telegram to Industrial Ethernet master ..................................................................... 10 2.2.4 ACM 9 error messages ..................................................................................................................... 11 2.2.5 Error messages coming through from ARE i9 .............................................................................. 12 3. ARE i9 ........................................................................................................................................................... 13 3.1 Hardware ............................................................................................................................................. 13 3.1.1 Dimensions ...................................................................................................................................... 13 3.1.2 Protection Class .............................................................................................................................. 13 3.1.3 Connectivity .................................................................................................................................... 14 3.1.4 Transponder orientation relative to ARE i9 ................................................................................. 15 3.1.5 Read range for SEMI application ................................................................................................... 16 3.1.6 Read range for miscellaneous applications .................................................................................. 17 3.2 Firmware ARE i9 LF hdx - SEMI Industry .......................................................................................... 18 3.2.1 Instruction Set ................................................................................................................................. 18 3.2.2 General format of instruction set .................................................................................................. 18 3.2.3 VER ................................................................................................................................................... 18 3.2.4 GT ..................................................................................................................................................... 19 3.2.5 TOR .................................................................................................................................................. 19 3.2.6 NID ....................................................................................................................................................20 3.2.7 CID ....................................................................................................................................................20 3.2.8 CN ..................................................................................................................................................... 21 3.2.9 RD ..................................................................................................................................................... 21 3.2.10 WD ................................................................................................................................................ 21 Manual ACM 9 - ARE i9 release Version: 05 Page: 3 / 45 Manual ACM9_ARE i9 release V05.docx 3.2.11 LD ................................................................................................................................................. 22 3.2.12 VSAVE ......................................................................................................................................... 22 3.2.13 INIT .............................................................................................................................................. 22 3.2.14 Error messages ........................................................................................................................... 23 3.3 Firmware ARE i9 LF ............................................................................................................................ 24 3.3.1 Instruction Set ................................................................................................................................. 24 3.3.2…

Text truncated - open the document above for the full version.

Ersteller: D. Brandhorst Revision: 00 Erstelldatum: 02.01.2012 Datum: 00.00.0000 Seite 1 von 1 Long/Short-term Confidentiality Request PHOENIX TESTLAB GmbH Date: 06 January 2021 Product Certification Königswinkel 10 D 32825 Blomberg FCC ID: V7IAREI9LF To Whom it may concerns, Pursuant to sections 0.457(d) and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, we hereby requests long-term confidential treatment of information accompanying this application as outlined below: Schematics Parts List Block Diagram Tune-Up Info Operational Description In addition we hereby request the following exhibits contained in this application to be temporarily (short-term confidentilality) withheld from the public disclosure for an initial period of days until: not applicable External Photos Test Setup Photos Internal Photos Users Manual The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to rule 0.457(d), disclosure of this application and all accompanying documentation will not be made before the date of the GRANT for this application. Thank you for your attention in this matter. Applicant’s Company address :EMCE GmbH / Untere Wiesen 1 / 88483 Burgrieden / Germany Signature : ____________________________ Job Title and Dept. :Agent / Christian Vogelmann / Dipl. Ing. (FH)

AEG Identifikationssysteme GmbH Hörvelsinger Weg 47, D-89081 Ulm | P: +49 (0)731 140088-0 | F: +49 (0)731 140088-9000 E-Mail: [email protected] | www.aegid.de AEG is a registered trademark used under license from AB Electrolux (publ). DATASHEET Industrial Reader ARE i9 LF Electrical Characteristics Reading System ASK, PSK, FSK Operational Frequency 134,2 kHz Interface RS232 (M12 – 5-Pin A coded male) Compatibility Communication module ACM 9 (Industrial Ethernet) Software Easy serial ASCII based control protocol Power supply ACM 9 (7V DC) Antenna Internal air core coil Environment Storage Temperature -20°C up to +85°C Operating Temperature -20°C up to +60°C Protection Class IP 67 Shock&Vibration IEC 68-2-6 / 29 Mounting Option 2 mounting holes for M4 cylinder head screw Length: min. 30mm Dimensions Weight Ca. 100 g Length 55.8 mm Width 40.8 mm Height 24 mm Material PC

Operational Description - RFID Reader ARE i9-LFV7IAREI9LF 13.07.2016, MK, Rev 3 For reading a passive transponder, the RFID reader is generating an electromagnetic field. This happens, depending on the operation mode, permanently or when the reader is receiving a command. The electromagnetic field is powering the transponder which is modulating its UID on the exitation field. The reader receives the signal, demodulates the UID and transfers it via RS232. 13.11.2020, HL, Rev 1

Test report AIR44a03 Product / EUT: RFID Reader Type designation: ARE i9 - LF Tested type: ARE i9 - LF EUT authorization: Certification SDoC FCC ID V7IAREI9LF for ARE i9 – LF Production level: n/a S/N: 0000144 Manufacturer: AEG Identifikationssysteme GmbH Hörvelsinger Weg 47 89081 Ulm / Germany Test remit: FCC Rules 47 CFR Part 15 – Subpart B Unintentional radiators in accordance with the procedures given in ANSI C63.4-2014 The standards were: kept * not kept * *Remark: Validation covered by the accredited scope Validation not covered by the accredited scope according:__________ Validation of the EMC-requirements partly proceeded Remark: The test results effects only to the related items tested at the time of the test. The test report shall not be reproduced except in full without the written approval of the testing laboratory. Information provided by the customer are identified in italic letters. Test report AIR44a03 11/05/2020 Page 2 of 41 Applicant: AEG Identifikationssysteme GmbH Hörvelsinger Weg 47 89081 Ulm / Germany EUT- Date of arrival: 10/01/2020 Test ID: PRR40_16 Date(s) of test: 10/06/2020 – 10/09/2020 Burgrieden, 01/14/2021 Released by: _______________________________________________ Principal Engineer - Christian Vogelmann Test laboratory: EMCE GmbH Ingenieurbüro für EMV-Prüfungen und Schaltungsentwicklung Untere Wiesen 1 / 88483 Burgrieden DAkkS-Registration No: D-PL-12122-01-01 D-PL-12122-01-02 CAB-Registration No.: BnetzA-CAB-02/21-01/1 FCC-Registration No.: 239304 Accredited by: Bundesnetzagentur Deutsche Akkreditierungsstelle GmbH Test report AIR44a03 11/05/2020 Page 3 of 41 Responsible inspector: Mr. S. Vogelmann EMCE GmbH Ingenieurbüro für EMV-Prüfungen und Schaltungsentwicklung Contact person: Mr. Leuthe / AEG Identifikationssysteme GmbH EUT Sampling: The device was selected and provided by the customer. Description: LF-RFID reader Voltage supply: 120 V / 60 Hz Frequency list: 32.768 kHz; 134.2 kHz; 16 MHz; 17.1776 MHz; 84 MHz Temperature range: n/a Size: (LxWxH) / mm 70 x 40 x 25 Supplied / used equipment: Designation Type Manufacturer S/N Power supply APS 1612 T ANSMANN n/a Laptop W25CSW Terra n/a Laptop power supply A12-065N2A Chicony F134091506009041 USB-A converter 151801 manhattan n/a Supplied / used software: Designation Type Version Manufacturer Termite Serial Terminal 3.4 CompuPhase Test report AIR44a03 11/05/2020 Page 4 of 41 Configuration: As-delivered condition* Modified* *_________ Cable designation Type Length Remarks Power and signal line 5-core 3.0 m n/a Pictures of the EUT: Remarks: n/a Test report AIR44a03 11/05/2020 Page 5 of 41 State of revision: Source document New Document Date / Reviser Modifications AIR44_03 AIR44a03 01/14/2021 Chr. Vogelmann Authorization procedure changed to Certification. Test report AIR44a03 11/05/2020 Page 6 of 41 Test equipment list of EMCE GmbH: Inv.- No. Designation Type Manufacturer S/N Calibration: Interval /valid until 001 Test receiver ESS 5Hz - 1000MHz Rohde & Schwarz 833776/008 Firmware: Main: 1.21 OTP: 02.01 GRA: 02.03 1 Year(s)/ 2020-11-22 003 LISN 1 ESH3-Z5 Rohde & Schwarz 835268/007 1 Year(s)/ 2021-03-10 004 LISN 2 ESH3-Z5 Rohde & Schwarz 835268/003 1 Year(s)/ 2021-02-28 006 LISN NNBM 8125 Schwarzbeck 8125371 1 Year(s)/ 2021-02-28 007 Absorbing clamp MDS 21 Schwarzbeck 942436 1 Year(s)/ 2021-02-23 008 Loop antenna 9kHz-30MHz HFH2-Z2 Rohde & Schwarz 835776/0002 3 Year(s)/ 2022-11-20 009 Antenna 30-300MHz VHBA9123 / BBA9106 Schwarzbeck 435 3 Year(s)/ 2021-12-05 010 Antenna 250-1200MHz UHALP 9108A Schwarzbeck 108 3 Year(s)/ 2022-11-25 011 Antenna 30-300MHz VHBA9123 / BBA9106 Schwarzbeck 0403/94 3 Year(s)/ 2022-11-25 012 Antenna 250-1200MHz UHALP 9108A Schwarzbeck 166 3 Year(s)/ 2021-12-05 013 Antenna 9 kHz-30 MHz Ø 1.5 m EMCE GmbH 1 Year(s)/ 2021-10-31 014 OATS Test site 3 m referred to ANSI C63.4-2014 EMCE GmbH 3 Year(s)/ 2021-08-31 015 OATS Test site 10 m referred to ANSI C63.4-2014 EMCE GmbH 3 Year(s)/ 2021-04-21 020 Coupling clamp IP4A Haefely 082672-13 1 Year(s)/ 2021-10-31 024 RF-Generator SMY01 Rohde & Schwarz 844146/046 2 Year(s)/ 2022-08-21 025 Current clamp BCI F-120-2 FCC 47 1 Year(s)/ 2021-08-31 026 Coupling-/ Decoupling Network M3 CDN 801-M3-25 FCC 92 1 Year(s)/ 2021-07-31 Test report AIR44a03 11/05/2020 Page 7 of 41 Inv.- No. Designation Type Manufacturer S/N Calibration: Interval /valid until 030 Coupling-/ Decoupling Network S1 - 9-pol. D-Sub CDN 801-S1/ 9pol. DSUB EMCE GmbH 1 Year(s)/ 2021-07-31 031 Coupling-/ Decoupling Network S1 - 9-pol. D-Sub CDN 801-S1/ 9pol. DSUB EMCE GmbH 1 Year(s)/ 2021-07-31 032 RF Power Amplifier 75A250 Amplifier Research 22789 3 Year(s)/ 2023-08-31 034 Coupling-/ Decoupling Network AF2 CDN-AF2 EMCE GmbH 1 Year(s)/ 2021-07-31 038 Helmholtz coil 1 m x 1 m EMCE GmbH 1 Year(s)/ 2021-09-30 039 Helmholtz coil 1 m x 1 m EMCE GmbH 1 Year(s)/ 2021-09-30 040 Current transformer EMCE GmbH 1 Year(s)/ 2021-09-30 041 Loop antenna shielded HZ-10 0816.2511.02 Rohde & Schwarz 849788/0020 3 Year(s)/ 2022-12-02 042-2 AC-Source EMV D 5000/PAS/SyCore Spitzenberger & Spies A274700 / 00501 3 Year(s)/ 2022-10-30 042-1 Analyser Reference System ARS 16/3 Spitzenberger & Spies A274707 / 00501 3 Year(s)/ 2021-11-07 043 Receiver 3DH/E Fieldmeter ESM-100 Maschek 971521 3 Year(s)/ 2023-08-13 044 CDN CN-U EMC-Partner 86 1 Year(s)/ 2021-09-30 045 CDN DN-HF EMC-Partner 86 1 Year(s)/ 2021-09-30 046 CDN DN-LF2 EMC-Partner 86 1 Year(s)/ 2021-09-30 047 CDN DN-LF1 EMC-Partner 86 1 Year(s)/ 2021-09-30 050 Data Acquisition/ Switch Unit Agilent 34970A Agilent Technologies MY41019453 3 Year(s)/ 2023-02-06 051 20 Channel Multiplexer Agilent 34901A Agilent Technologies MY41013531 3 Year(s)/ 2023-02-06 054 Helmholtz coil 1.25 m x 1.25 m EMCE GmbH 1 Year(s)/ 2021-09-30 055 Helmholtz coil 1.25 m x 1.25 m EMCE GmbH 1 Year(s)/ 2021-09-30 Test report AIR44a03 11/05/2020 Page 8 of 41 Inv.- No. Designation Type Manufacturer S/N Calibration: Interval /valid until 058 Receiver ESIB 40 Rohde & Schwarz 100200/ Firmware 4.35…

Text truncated - open the document above for the full version.
