V7IAREI9XLF-SRFID Reader

Manual ACM 9 ARE i9 – ARE i9x Manual ACM 9 - ARE i9 release Version: 12 Page: 2 / 52 Manual ACM9_ARE i9 release V12.docx 1. Introduction ................................................................................................................................. 5 2. ACM 9 .......................................................................................................................................... 6 2.1 Hardware ............................................................................................................................. 6 2.1.1 Dimensions ....................................................................................................................... 6 2.1.2 Protection Class ................................................................................................................. 6 2.1.3 Connectivity ...................................................................................................................... 7 2.1.4 Grounding ......................................................................................................................... 9 2.2 Firmware ............................................................................................................................ 10 2.2.1 Industrial Ethernet description files .................................................................................. 10 2.2.2 Output data telegram from Industrial Ethernet master ...................................................... 10 2.2.3 Input data telegram to Industrial Ethernet master ............................................................. 10 2.2.4 ACM 9 – control via RS-232 serial interface ........................................................................ 11 2.2.5 ACM 9 error messages ...................................................................................................... 12 2.2.6 Error messages coming through from ARE i9 ..................................................................... 13 3. ARE i9 - family ............................................................................................................................ 14 3.1 ARE i9 Hardware ................................................................................................................. 14 3.1.1 Dimensions ..................................................................................................................... 14 3.1.2 Protection Class ............................................................................................................... 14 3.1.3 Connectivity .................................................................................................................... 15 3.1.4 Transponder orientation relative to ARE i9 ....................................................................... 16 3.1.5 Read range for SEMI application ....................................................................................... 17 3.1.6 Read range for miscellaneous applications ........................................................................ 19 3.2 ARE i9x Hardware ............................................................................................................... 20 3.2.1 Dimensions ..................................................................................................................... 20 3.2.2 Protection Class ............................................................................................................... 21 3.2.3 Connectivity .................................................................................................................... 21 3.2.4 Transponder orientation relative to AAN Xi9F ................................................................... 22 3.2.5 Read Range for SEMI Applications using AAN Xi9F ............................................................ 23 3.3 Firmware ARE i9 LF hdx - SEMI Industry ............................................................................... 24 3.3.1 Instruction Set ................................................................................................................. 24 3.3.2 General format of instruction set ...................................................................................... 24 Manual ACM 9 - ARE i9 release Version: 12 Page: 3 / 52 Manual ACM9_ARE i9 release V12.docx 3.3.3 VER ................................................................................................................................ 24 3.3.4 GT .................................................................................................................................. 25 3.3.5 TOR ................................................................................................................................ 25 3.3.6 NID ................................................................................................................................. 26 3.3.7 CID .................................................................................................................................. 26 3.3.8 CN .................................................................................................................................. 27 3.3.9 RD .................................................................................................................................. 27 3.3.10 WD .............................................................................................................................. 27 3.3.11 LD ............................................................................................................................... 28 3.3.12 VSAVE ........................................................................................................................ 28 3.3.13 INIT ............................................................................................................................. 28 3.3.14 Error messages ...........................................................…

Text truncated - open the document above for the full version.

EXTERNAL PHOTOS

EXTERNAL ANTENNA 1 A 2 3 4 5 678 12 3 4 5 678 B C D E F A B C D E F Dept.Technical referenceCreated byApproved by Document typeDocument status TitleDWG No. Rev.Date of issueSheet 30.11.2022 01 #tbd approvedtechnical drawing 01.12.202201.12.2022 1/1 999.336 EZ ASP Xi9F Antenne M. MüllerM. ObkircherXi9 antenna LFProID 20 35 5 30 Ferritstab / ferrite rod: Fair-Rite: RFID Ferrit: RFID rod:50kHz - 25MHz

INTERNAL PHOTOS

Operational Description - RFID Reader ARE i9x hdx-SEMIV7IAREI9XLF-S The passive transponder are powered by the energy of electromagnetic field generated by the external reader antenna, powered by the RFID reader. This happens, when the reader receives a command to the read transponder data and the transponder ist within the interrogation zone (coupling area of the electromagnetic field). The transponder is transmits its data (identification information, memory content) by modulation on the couped electromagnetic field (ASK/PSK/FSK), serially coded . The reader receives via the antenna the signal, filters, amplfies and demodulates the signal in it‘s hardware receiver stage. The data is extrated from demodulated signal by the CPU and processed according due to the coding format of the specific transponder used. The decoded data (identification information, memory content) is send to the data processing host via RS232 connection. 23.11.2022, HL, Rev 1 disc transponder external Antenna AAN XI9F electromagnetic field (134.2kHz) coupling with transponder data modulation RFID reader ARE i9x power supply and RS232 connection cable

Test report 22-0188RP48-002 Product / EUT: RFID Reader Type designation: ARE i9x – hdx - SEMI Tested type: ARE i9x – hdx – SEMI FCC-ID: V7IAREI9XLF-S EUT authorization: Certification Suppliers Declaration of Conformity Production level: n/a S/N: 000560 Manufacturer: AEG Identifikationssysteme GmbH Hörvelsinger Weg 47 89081 Ulm / Germany Test remit: FCC Rules 47 CFR Part 15 – Subpart C – Intentional radiators in accordance with the procedures given in ANSI C63.10-2013 The standards were: kept * not kept * *Remark: Validation covered by the accredited scope Validation not covered by the accredited scope according:__________ Validation of the EMC-requirements partly proceeded Remark: The test results effects only to the related items tested at the time of the test. The test report shall not be reproduced except in full without the written approval of the testing laboratory. Information provided by the customer are identified in italic letters. Test report 22-0188RP48-002 12/02/2022 Page 2 of 63 Applicant: AEG Identifikationssysteme GmbH Hörvelsinger Weg 47 89081 Ulm / Germany EUT- Date of arrival: 11/15/2022 Test ID: 22-0188PR46-004 Date(s) of test: 11/25/2022, 11/28/2022 Burgrieden, 2023-01-10 Released by: _______________________________________________ Principal Engineer - Christian Vogelmann Test laboratory: EMCE GmbH Ingenieurbüro für EMV-Prüfungen und Schaltungsentwicklung Untere Wiesen 1 / 88483 Burgrieden DAkkS-Registration No: D-PL-12122-01-01 D-PL-12122-01-02 D-PL-12122-01-03 D-PL-12122-01-04 CAB-Registration No.: BnetzA-CAB-02/21-01/1 FCC-Registration No.: 239304 Accredited by: Bundesnetzagentur Deutsche Akkreditierungsstelle GmbH Test report 22-0188RP48-002 12/02/2022 Page 3 of 63 Responsible inspector: Mr. S. Vogelmann EMCE GmbH Ingenieurbüro für EMV-Prüfungen und Schaltungsentwicklung Contact person: Mr. Leuthe / AEG Identifikationssysteme GmbH EUT Sampling: The device was selected and provided by the customer. Description: LF-RFID reader with a working frequency of 134.2 kHz for different LF algorithms: ISO 11784/11785 ARE i9 – LF The reader is designed to be connected to an external antenna. Voltage supply: 120 V / 60 Hz Frequency list: 134.2 kHz; RF Application: 134.2 kHz Temperature range: n/a Size: EUT (LxWxH) / mm: 85 x 40 x 25 Antenna (LxWxH) / mm: 45 x 30 x 10 Supplied / used equipment: Designation Type Manufacturer S/N Antenna (external) AAN Xi9F flex 2m AEG ID 108 RFID Tag n/a n/a n/a Notebook W25CSW Terra n/a Notebook Supply A12-065N2A Chicony F134091506009041 RS232-to-USB adapter n/a IC Intracom Vertriebs GmbH n/a DC Supply (EUT) APS 1612T ANSMANN n/a Test report 22-0188RP48-002 12/02/2022 Page 4 of 63 Supplied / used software: Cable designation Type Manufacturer Version Software Demo Terminal DL AEG ID V72 Configuration: As-delivered condition* Modified* *_________ Cable designation Type Length Remarks AC Supply (EUT) 2 core 1.0 m unshielded DC Supply (EUT) 2 wires 2.2 m unshielded AC Supply (Notebook) 2 core 1.0 m unshielded DC Supply (Notebook) 2 core 1.8 m unshielded Antenna cable 3 core 2.0 m unshielded Interconnection cable 4 core 3.2 m unshielded Test report 22-0188RP48-002 12/02/2022 Page 5 of 63 Pictures of the EUT: Test report 22-0188RP48-002 12/02/2022 Page 6 of 63 Remarks: n/a State of revision: Source document New Document Date / Reviser Modifications Test report 22-0188RP48-002 12/02/2022 Page 7 of 63 Test equipment list of EMCE GmbH: Inv.- No. Designation Type Manufacturer S/N Calibration: Interval /valid until 003 LISN 1 ESH3-Z5 Rohde & Schwarz 835268/007 1 Year(s)/ 2023-02-10 004 LISN 2 ESH3-Z5 Rohde & Schwarz 835268/003 1 Year(s)/ 2023-02-10 006 LISN NNBM 8125 Schwarzbeck 8125371 1 Year(s)/ 2023-02-28 007 Absorbing clamp MDS 21 Schwarzbeck 942436 1 Year(s)/ 2023-01-15 008 Antenna 9kHz - 30MHz HFH2-Z2 Rohde & Schwarz 835776/0002 3 Year(s)/ 2025-11-20 009 Antenna 30-300MHz VHBA9123 / BBA9106 Schwarzbeck 435 3 Year(s)/ 2024-12-22 011 Antenna 30-300MHz VHBA9123 / BBA9106 Schwarzbeck 0403/94 3 Year(s)/ 2023-01-31 014 OATS Test site 3 m referred to ANSI C63.4-2014 EMCE GmbH 3 Year(s)/ 2024-04-23 015 OATS Test site 10 m referred to ANSI C63.4-2014 EMCE GmbH 3 Year(s)/ 2024-04-26 042-2 AC-Source EMV D 5000/PAS/SyCore Spitzenberger & Spies A274700 / 00501 3 Year(s)/ 2023-01-30 042-1 Analyser Reference System ARS 16/3 Spitzenberger & Spies A274707 / 00501 3 Year(s)/ 2024-12-28 043 Receiver 3DH/E Fieldmeter ESM-100 Maschek 971521 3 Year(s)/ 2023-08-13 058 Receiver ESIB 40 Rohde & Schwarz 100200/ Firmware 4.35 1 Year(s)/ 2023-08-02 059 Log.-per. antenna HL050 Rohde & Schwarz 100006 3 Year(s)/ 2025-10-21 062-2 Semi-Anechoic Chamber 13.5x6.1x5.5 m 30 - 1000 MHz referred to ANSI C63.4-2014 EMC-Technik & Consulting GmbH 3 Year(s)/ 2024-01-31 062-1 Semi-Anechoic Chamber 13.5x6.1x5.5 m 1 - 18 GHz referred to CISPR16 1-4: 2010-04 Ed. 3 EMC-Technik & Consulting GmbH 3 Year(s)/ 2024-05-14 067 LISN ESH2-Z5 Rohde & Schwarz 872460/043 1 Year(s)/ 2023-02-10 Test report 22-0188RP48-002 12/02/2022 Page 8 of 63 Inv.- No. Designation Type Manufacturer S/N Calibration: Interval /valid until 068 LISN ESH2-Z5 Rohde & Schwarz 872460/042 1 Year(s)/ 2023-02-10 070 Pulse limiter + 10 dB Attenuator ESH3-Z2 Rohde & Schwarz n/a 1 Year(s)/ 2023-08-31 073 Absorbing clamp MDS21 Schwarzbeck 881757 1 Year(s)/ 2023-01-15 116 Vertical rod antenna VAMP 9243 Schwarzbeck 9243-205 3 Year(s)/ 2023-02-19 117 LISN ESH3-Z6 Rohde & Schwarz 100521 1 Year(s)/ 2023-02-28 174 LISN ESH3-Z6 Rohde & Schwarz 101003 1 Year(s)/ 2023-02-28 175 EMI Test receiver ESR7 Rohde & Schwarz 101108 Firmware: FW V3.46 SP3 1 Year(s)/ 2023-11-18 178 V-LISN 5 μH NNHV 8123-400 Schwarzbeck 018 1 Year(s)/ 2023-02-28 184 V-LISN 5 μH NNHV8123-400 Schwarzbeck 019 1 Year(s)/ 2023-02-28 211 Broadband Amplifier BBA150 800 - 3000 MHz Rohde & Schwarz 102104 1 Year(s)/ 2023-01-31 212 Broadband Amplifier BBA150 2500 - 6000 MHz Rohde & Schwarz 102105 1 Year(s)/ 2023-01-31 222 Broadband Preamplifier 0.5- 18GHz BBV 9718 Schwarzbeck 9718-316 1…

Text truncated - open the document above for the full version.
