V8YFWA1FUS38000WWiMAX 802.16e USB Adapter

USER GUIDE Mobile WiMAX USB Adapter US330 USER GUIDE US330 IEEE 802.16e-2005 Mobile WiMAX USB Adapter, with 3.8 GHz Frequency Band Model US330 E082012-AP-R03 150200000248W – 3 – COMPLIANCES FEDERAL COMMUNICATION COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: ◆Reorient or relocate the receiving antenna ◆Increase the separation between the equipment and receiver ◆Connect the equipment into an outlet on a circuit different from that to which the receiver is connected ◆Consult the dealer or an experienced radio/TV technician for help This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. IMPORTANT NOTE: FCC R ADIATION EXPOSURE STATEMENT This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance. To maintain compliance with FCC RF exposure compliance requirements, please follow operation instruction as documented in this manual. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. The availability of some specific channels and/or operational frequency bands are country dependent and are firmware programmed at the factory to match the intended destination. The firmware setting is not accessible by the end user. COMPLIANCES – 4 – Due to the essential high output power nature of WiMAX devices, use of this device with other transmitters at the same time may exceed the FCC RF exposure limit and such usage must be prohibited (unless such co- transmission has been approved by FCC in the future). SAR (SPECIFIC ABSORPTION RATE) COMPLIANCES STATEMENT SAR compliance has been established in typical laptop computer (s) with a USB slot, and the product can be used in typical laptop computers with USB slots. Other applications, such as handheld PCs or similar devices have not been verified and may not be in compliance with related RF exposure rules and such use shall be prohibited. EC CONFORMANCE DECLARATION Marking by the above symbol indicates compliance with the Essential Requirements of the R&TTE Directive of the European Union (1999/5/EC). This device is intended for use in the following European Community countries. 0560 – 5 – ABOUT THIS GUIDE PURPOSEThis guide details the hardware features of the WiMAX USB Adapter, including its physical and performance-related characteristics, and how to install the device and use its configuration software. AUDIENCEThis guide is for PC users with a working knowledge of computers. You should be familiar with Windows operating system concepts. CONVENTIONSThe following conventions are used throughout this guide to show information: NOTE: Emphasizes important information or calls your attention to related features or instructions. CAUTION: Alerts you to a potential hazard that could cause loss of data, or damage the system or equipment. WARNING: Alerts you to a potential hazard that could cause personal injury. RELATED PUBLICATIONSThe following publication gives basic information on how to install and use the WiMAX USB Adapter. Quick Installation Guide Also, as part of the card’s configuration software, there is online help that describes all management features. REVISION HISTORYThis section summarizes the changes in each revision of this guide. AUGUST 2012 REVISION This is the third revision of this guide. This guide is valid for software version 1.0.2.0 NOVEMBER 2011 REVISION This is the second revision of this guide. This guide is valid for software version 1.0.1.5. ABOUT THIS GUIDE – 6 – JANUARY 2011 REVISION This is the first revision of this guide. This guide is valid for software version 1.0.1.3. – 7 – CONTENTS COMPLIANCES 3 A BOUT THIS GUIDE 5 C ONTENTS 7 1I NTRODUCTION 9 Features 9 System Requirements 10 Package Checklist 10 Hardware Description 10 USB Connector 10 LED Indicators 11 2INSTALLATION 12 3C ONFIGURATION 17 Accessing the WCM Utility 17 Connection Management 18 Adapter Settings 20 WiMAX Connection Statistics 21 About WiMAX Connection Manager 22 4ADMINISTRATOR MODE 23 Accessing Administrator Mode 23 Editing a Profile 24 ATROUBLESHOOTING 28 Diagnosing LED Indicators 28 Network Connection Problems 28 Uninstalling the WCM Software 29 BSPECIFICATIONS 30 G LOSSARY 33 CONTENTS – 8 – INDEX 37 – 9 – 1INTRODUCTION The WiMAX USB Adapter is a network adapter that enables a notebook PC to connect to a service provider’s 3.8 GHz mobile WiMAX network. The USB adapter plugs directly into a PC’s compatible USB port and includes its own driver and configuration software for Windows XP, Windows Vista, and Windows 7. Figure 1: WiMAX USB Adapter FEATURES The WiMAX USB Adapter supports the following features: ◆Mobile WiMAX IEEE 802.16e-2005 Wave 2 compliant ◆Full Non-Line-of-Sight (NLOS) operation ◆Two LED indicators for power and link status ◆Easy insta…

Text truncated - open the document above for the full version.

Accton Wireless Broadband Corp. 3F, No. 1 Creation Rd. III, Science-based Industrial Park Hsinchu 30077, Taiwan, R.O.C. 2012/6/27 To whom it may concern, We Accton Wireless Broadband Corp. declare that Product name：WiMAX 802.16e USB Adapter Brand name：AWB FCC ID: V8YFWA1FUS38000W By V8YFWA1FUS38000W hardware configuration, the maximum ratio of DL:UL is 29:18. That means it can not support the higher ratio than 29:18, for example, 26:21. The ratio can not be modified to higher ratio than 29:18 by any method. ____________________ Abby Wei / Compliance Manager Accton Wireless Broadband Corp. TEL: 886-3-505-3780 FAX: 886-3-578-3821 Email: [email protected]

Accton Wireless Broadband Corp. 3F, No. 1 Creation Rd. III, Science-based Industrial Park Hsinchu 30077, Taiwan, R.O.C. 2012/5/28 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request FCC ID: V8YFWA1FUS38000W Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Block Diagram Schematics Operational Description Parts list Tune up procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, ____________________ Abby Wei / Compliance Manager Accton Wireless Broadband Corp. TEL: 886-3-505-3780 FAX: 886-3-578-3821 Email: [email protected]

Accton Wireless Broadband Corp. 3F, No. 1 Creation Rd. III, Science-based Industrial Park Hsinchu 30077, Taiwan, R.O.C. Power of Attorney 2012/5/28 To whom it may concern: We, the undersigned Accton Wireless Broadband Corp. hereby authorize Bureau Veritas Consumer Product Service (Hong Kong) Limited, Taoyuan Branch of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 90Z approval and any communication needed with the national authority. Any and all acts carried out by BVCPS Taoyuan on our behalf shall have the same effects as acts of our own. This authorization is limited to the following products： FCC ID: V8YFWA1FUS38000W If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, ____________________ Abby Wei / Compliance Manager Accton Wireless Broadband Corp. TEL: 886-3-505-3780 FAX: 886-3-578-3821 Email: [email protected]

Report No.: 120314E03 Page 1 CONSTRUCTION PHOTOS OF EUT

(Fig.1) FCC ID: V8YFWA1FUS38000W FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. Bottom: LABEL HERE

Report No.: 120314E03 Page 2 Report No.: 120314E03 Page 3

© 2012 PCTEST Engineering Laboratory, Inc. APPENDIX A: SAR TEST DATA PCTEST ENGINEERING LABORATORY, INC. DUT: V8YFWA1FU38000W; Type:USB Dongle; Serial: AWB 1 Communication System: WIMAX - 5 MHz; Frequency: 3652.5 MHz;Duty Cycle: 1:2.7 Medium: 3700 Body Medium parameters used (interpolated): f = 3652.5 MHz; σ = 3.575 mho/m; ε r = 53.239; ρ = 1000 kg/m 3 Phantom section: Flat Section; Space: 0.5 cm Test Date: 06-13-2012; Ambient Temp: 23.0°C; Tissue Temp: 21.4°C Probe: EX3DV4 - SN3645; ConvF(6.15, 6.15, 6.15); Calibrated: 10/26/2011; Sensor-Surface: 2mm (Mechanical Surface Detection) Electronics: DAE4 Sn1333; Calibrated: 4/12/2012 Phantom: SAM 5.0 front; Type: QD000P40CD; Serial: TP:-1648 Measurement SW: DASY52, Version 52.8 (0);SEMCAD X Version 14.6.5 (6469) Mode: WIMAX, Low channel, QPSK, 5 MHz Bandwidth, PUSC Horizontal Up, Antenna 0 Area Scan (6x11x1): Measurement grid: dx=12mm, dy=12mm Zoom Scan (7x7x8)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=4mm Reference Value = 11.778 V/m; Power Drift = -0.145 dB Peak SAR (extrapolated) = 1.397 mW/g SAR(1 g) = 0.554 mW/g; SAR(10 g) = 0.243 mW/g 0 dB = 0.866 mW/g = -1.24 dB mW/g A1 PCTEST ENGINEERING LABORATORY, INC. DUT: V8YFWA1FU38000W; Type:USB Dongle; Serial: AWB 1 Communication System: WIMAX 3.7 -10 MHz; Frequency: 3662.5 MHz;Duty Cycle: 1:3.2 Medium: 3700 Body Medium parameters used (interpolated): f = 3662.5 MHz; σ = 3.591 mho/m; ε r = 53.224; ρ = 1000 kg/m 3 Phantom section: Flat Section; Space: 0.5 cm Test Date: 06-13-2012; Ambient Temp: 23.0°C; Tissue Temp: 21.4°C Probe: EX3DV4 - SN3645; ConvF(6.15, 6.15, 6.15); Calibrated: 10/26/2011; Sensor-Surface: 2mm (Mechanical Surface Detection) Electronics: DAE4 Sn1333; Calibrated: 4/12/2012 Phantom: SAM 5.0 front; Type: QD000P40CD; Serial: TP:-1648 Measurement SW: DASY52, Version 52.8 (0);SEMCAD X Version 14.6.5 (6469) Mode: WIMAX, Mid. Ch., QPSK, 10 MHz Bandwidth, PUSC Horiz ontal Up, Antenna 0 Area Scan (6x11x1): Measurement grid: dx=12mm, dy=12mm Zoom Scan (7x7x8)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=4mm Reference Value = 10.684 V/m; Power Drift = -0.16 dB Peak SAR (extrapolated) = 1.272 mW/g SAR(1 g) = 0.496 mW/g; SAR(10 g) = 0.214 mW/g 0 dB = 0.834 mW/g = -1.58 dB mW/g A2 PCTEST ENGINEERING LABORATORY, INC. DUT: V8YFWA1FU38000W; Type:USB Dongle; Serial: AWB 1 Communication System: WIMAX - 5 MHz; Frequency: 3652.5 MHz;Duty Cycle: 1:2.7 Medium: 3700 Body Medium parameters used (interpolated): f = 3652.5 MHz; σ = 3.575 mho/m; ε r = 53.239; ρ = 1000 kg/m 3 Phantom section: Flat Section; Space: 0.5 cm Test Date: 06-13-2012; Ambient Temp: 23.0°C; Tissue Temp: 21.4°C Probe: EX3DV4 - SN3645; ConvF(6.15, 6.15, 6.15); Calibrated: 10/26/2011; Sensor-Surface: 2mm (Mechanical Surface Detection) Electronics: DAE4 Sn1333; Calibrated: 4/12/2012 Phantom: SAM 5.0 front; Type: QD000P40CD; Serial: TP:-1648 Measurement SW: DASY52, Version 52.8 (0);SEMCAD X Version 14.6.5 (6469) Mode: WIMAX, Low channel, QPSK, 5 MHz Bandwidth, PUSC Horizontal Down, Antenna 0 Area Scan (6x11x1): Measurement grid: dx=12mm, dy=12mm Zoom Scan (7x7x8)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=4mm Reference Value = 12.197 V/m; Power Drift = -0.10 dB Peak SAR (extrapolated) = 1.833 mW/g SAR(1 g) = 0.723 mW/g; SAR(10 g) = 0.307 mW/g 0 dB = 1.08 mW/g = 0.63 dB mW/g A3 PCTEST ENGINEERING LABORATORY, INC. DUT: V8YFWA1FU38000W; Type:USB Dongle; Serial: AWB 1 Communication System: WIMAX - 10 MHz; Frequency: 3662.5 MHz;Duty Cycle: 1:3.2 Medium: 3700 Body Medium parameters used (interpolated): f = 3662.5 MHz; σ = 3.591 mho/m; ε r = 53.224; ρ = 1000 kg/m 3 Phantom section: Flat Section; Space: 0.5 cm Test Date: 06-13-2012; Ambient Temp: 23.0°C; Tissue Temp: 21.4°C Probe: EX3DV4 - SN3645; ConvF(6.15, 6.15, 6.15); Calibrated: 10/26/2011; Sensor-Surface: 2mm (Mechanical Surface Detection) Electronics: DAE4 Sn1333; Calibrated: 4/12/2012 Phantom: SAM 5.0 front; Type: QD000P40CD; Serial: TP:-1648 Measurement SW: DASY52, Version 52.8 (0);SEMCAD X Version 14.6.5 (6469) Mode: WIMAX, Mid. Ch., QPSK, 10 MHz Bandwidth, PUSC Horiz ontal Down, Antenna 0 Area Scan (6x11x1): Measurement grid: dx=12mm, dy=12mm Zoom Scan (7x7x8)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=4mm Reference Value = 10.948 V/m; Power Drift = -0.17 dB Peak SAR (extrapolated) = 1.565 mW/g SAR(1 g) = 0.596 mW/g; SAR(10 g) = 0.250 mW/g 0 dB = 0.991 mW/g = -0.08 dB mW/g A4 PCTEST ENGINEERING LABORATORY, INC. DUT: V8YFWA1FU38000W; Type: USB Dongle; Serial: AWB 1 Communication System: WIMAX - 5 MHz; Frequency: 3652.5 MHz;Duty Cycle: 1:2.7 Medium: 3700 Body Medium parameters used (interpolated): f = 3652.5 MHz; σ = 3.575 mho/m; ε r = 53.239; ρ = 1000 kg/m 3 Phantom section: Flat Section; Space: 0.5 cm Test Date: 06-13-2012; Ambient Temp: 23.0°C; Tissue Temp: 21.4°C Probe: EX3DV4 - SN3645; ConvF(6.15, 6.15, 6.15); Calibrated: 10/26/2011; Sensor-Surface: 2mm (Mechanical Surface Detection) Electronics: DAE4 Sn1333; Calibrated: 4/12/2012 Phantom: SAM 5.0 front; Type: QD000P40CD; Serial: TP:-1648 Measurement SW: DASY52, Version 52.8 (0);SEMCAD X Version 14.6.5 (6469) Mode: WIMAX, Low channel, QPSK, 5 MHz Bandwidth, PUSC Tip, Antenna 0 Area Scan (6x6x1): Measurement grid: dx=12mm, dy=12mm Zoom Scan (7x7x8)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=4mm Reference Value = 8.564 V/m; Power Drift = -0.19 dB Peak SAR (extrapolated) = 0.610 mW/g SAR(1 g) = 0.230 mW/g; SAR(10 g) = 0.097 mW/g 0 dB = 0.335 mW/g = -9.51 dB mW/g A5 PCTEST ENGINEERING LABORATORY, INC. DUT: V8YFWA1FU38000W; Type: USB Dongle; Serial: AWB 1 Communication System: WIMAX - 10 MHz; Frequency: 3662.5 MHz;Duty Cycle: 1:3.2 Medium: 3700 Body Medium parameters used (interpolated): f = 3662.5 MHz; σ = 3.591 mho/m; ε r = 53.224; ρ = 1000 kg/m 3 Phantom section: Flat Section; Space: 0.5 cm Test Date: 06-13-2012; Ambient Temp: 23.0°C; Tissue Temp: 21.4°C Probe: EX3DV4 - SN3645; ConvF(6.15, 6.15, 6.15); Calibrated: 10/26/2011; Sensor-Surface: 2mm (Mechanical Surface Detection) Electronics: DAE4 Sn1333; Calibrated: 4/12/2012 P…

Text truncated - open the document above for the full version.

FCC ID: V8YFWA1FUS38000W SAR EVALUATION REPORT Reviewed by: Quality Manager Document S/N: Test Date: DUT Type: Page 1 of 30 0Y1206040773-R3.V8Y 6/13/2012 USB Dongle © 2012 PCTEST Engineering Laboratory, Inc. REV 11.3 M 04/23/2012 Applicant Name: Date of Testing: AcctonWireless Broadband Corp. 6/13/2012 3F, No. 1 Creation Rd. III Test Site/Location: Science-based Industrial Park Hsinchu 30077 PCTEST Lab, Columbia, MD, USA Taiwan, R.O.C Document Serial No.: 0Y1206040773-R3.V8Y FCC ID: V8YFWA1FUS38000W APPLICANT: ACCTON WIRELESS BROADBAND CORP. DUT Type: USB Dongle Application Type: Certification FCC Rule Part(s): Model(s): CFR §2.1093 US330-3.8, US330, US330-3.8-FLF-81, US330-3.8-FLF-81RT, US330-3.8-FLF-8F Test Device Serial No.: AWB 1 Note: Powers in the above table represent output powers for the SAR test configurations and may not represent the highest output powers for all configurations for each mode. Note: This revised Test Report (S/N: 0Y1206040773-R3.V8Y) supersedes and replaces the previously issued test report on the same subject EUT for the same type of testing as indicated. Please discard or destroy the previously issued test report(s) and dispose of it accordingly. This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE C95.1-1992 and has been tested in accordance with the measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001), IEEE 1528-2003 and in applicable Industry Canada Radio Standards Specifications (RSS); for North American frequency bands only. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Test results reported herein relate only to the item(s) tested. PCTEST certifies that no party to this application has been subject to a denial of Federal benefits that includes FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. 1 gm Body (W/kg) WIMAX - 5 MHz Bandwidth3652.5 - 3672.5 MHz 16.08 WIMAX - 10 MHz Bandwidth3655 - 3670 MHz 19.80 1.50 W/kg Simulta ne ous SAR pe r KDB 690783 D01: 0.80 SAR Band & ModeTx Frequency Individual Antenna Conducted Power [dBm] PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. +1.410.290.6652 / Fax +1.410.290.6654 http://www.pctestlab.com SAR EVALUATION REPORT FCC ID: V8YFWA1FUS38000W SAR EVALUATION REPORT Reviewed by: Quality Manager Document S/N: Test Date: DUT Type: Page 2 of 30 0Y1206040773-R3.V8Y 6/13/2012 USB Dongle © 2012 PCTEST Engineering Laboratory, Inc. REV 11.3 M 04/23/2012 TABLE OF CONTENTS 1 DEVICE UNDER TEST ................................................................................................................... 3 2 WIMAX CHECKLIST PER KDB 615223 ......................................................................................... 5 3 INTRODUCTION ............................................................................................................................. 6 4 SAR MEASUREMENT SETUP ....................................................................................................... 7 5 DOSIMETRIC ASSESSMENT ........................................................................................................ 8 6 FCC RF EXPOSURE LIMITS .......................................................................................................... 9 7 SAR TEST CONFIGURATIONS ................................................................................................... 10 8 WIMAX CONSIDERATIONS ......................................................................................................... 11 9 SYSTEM VERIFICATION .............................................................................................................. 21 10 SAR DATA SUMMARY ................................................................................................................. 23 11 FCC MULTI-TX AND ANTENNA SAR CONSIDERATIONS ......................................................... 25 12 EQUIPMENT LIST ......................................................................................................................... 26 13 MEASUREMENT UNCERTAINTIES ............................................................................................ 27 14 CONCLUSION ............................................................................................................................... 28 15 REFERENCES .............................................................................................................................. 29 FCC ID: V8YFWA1FUS38000W SAR EVALUATION REPORT Reviewed by: Quality Manager Document S/N: Test Date: DUT Type: Page 3 of 30 0Y1206040773-R3.V8Y 6/13/2012 USB Dongle © 2012 PCTEST Engineering Laboratory, Inc. REV 11.3 M 04/23/2012 1 DEVICE UNDER TEST 1.1 Device Overview 1.2 DUT Antenna Locations Figure 1-1 DUT Antenna Locations 1.3 Simultaneous Transmission Capabilities According to KDB 648474 D01, transmitters are considered to be transmitting simultaneously when there is overlapping transmission, with the exception of transmissions during network hand-offs with maximum hand-off duration less than 30 seconds. Possible transmission paths for the DUT are shown in Figure 1-2 and are color-coded to indicate communication modes which share the same path. Modes which share the same transmission path cannot transmit simultaneously with one another. Figure 1-2 Simultaneous Transmission Paths This device contains multiple transmitters that may operate simultaneously, and therefore requires a simultaneous transmission analysis according to KDB 447498 D01 3) procedures. The manufacturer has confirmed tha…

Text truncated - open the document above for the full version.

Report No.: RF120314E03 1 Report Format Version 4.2.0 FCC TEST REPORT (Part 90 Subpart Z) REPORT NO.: RF120314E03 MODEL NO.: US330-3.8, US330, US330-3.8-FLF-81, US330-3.8-FLF -81RT, US330-3.8-FLF -81F FCC ID: V8YFWA1FUS38000W RECEIVED: Mar. 14, 2011 TESTED: Apr. 17, 2012 ISSUED: July 04, 2012 APPLICANT: Accton Wireless Broadband Corp. ADDRESS: 3F, No. 1 Creation Rd. III, Science-based Industrial Park Hsinchu 30077, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This test report consists of 129 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF120314E03 2 Report Format Version 4.2.0 TABLE OF CONTENTS RELEASE CONTROL RECORD ................................................................................ 4 1 CERTIFICATION .............................................................................................. 5 2 SUMMARY OF TEST RESULTS ...................................................................... 6 2.1 MEASUREMENT UNCERTAINTY ......................................................................... 6 3 GENERAL INFORMATION .............................................................................. 7 3.1 GENERAL DESCRIPTION OF EUT ...................................................................... 7 3.2 DESCRIPTION OF TEST MODES ........................................................................ 8 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ........................ 9 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ..................................... 12 3.4 DESCRIPTION OF SUPPORT UNITS ................................................................ 13 3.4.1 CONFIGURATION OF SYSTEM UNDER TEST ................................................. 13 4 TEST TYPES AND RESULTS ........................................................................ 14 4.1 OUTPUT POWER AND POWER DENSITY MEASUREMENT ........................... 14 4.1.1 LIMITS OF OUTPUT POWER AND POWER DENSITY ..................................... 14 4.1.2 TEST INSTRUMENTS ......................................................................................... 14 4.1.3 TEST PROCEDURES ......................................................................................... 15 4.1.4 TEST SETUP ....................................................................................................... 16 4.1.5 EUT OPERATING CONDITIONS ........................................................................ 16 4.1.6 TEST RESULTS .................................................................................................. 17 4.2 FREQUENCY STABILITY MEASUREMENT ....................................................... 67 4.2.1 LIMITS OF FREQUENCY STABILIITY MEASUREMENT ................................... 67 4.2.2 TEST INSTRUMENTS ......................................................................................... 67 4.2.3 TEST PROCEDURE ............................................................................................ 68 4.2.4 TEST SETUP ....................................................................................................... 68 4.2.5 EUT OPERATING CONDITIONS ........................................................................ 68 4.2.6 TEST RESULTS .................................................................................................. 69 4.3 EMISSION BANDWIDTH MEASUREMENT ....................................................... 70 4.3.1 LIMITS OF EMISSION BANDWIDTH MEASUREMENT ..................................... 70 4.3.2 TEST INSTRUMENTS ......................................................................................... 70 4.3.3 TEST PROCEDURE ............................................................................................ 70 4.3.4 TEST SETUP ....................................................................................................... 70 4.3.5 EUT OPERATING CONDITIONS ........................................................................ 70 4.3.6 TEST RESULTS .................................................................................................. 71 4.4 EMISSION MASKS .............................................................................................. 81 4.4.1 LIMITS OF EMISSION MASKS ........................................................................... 81 4.4.2 TEST INSTRUMENTS ......................................................................................... 81 4.4.3 TEST SETUP ....................................................................................................... 81 4.4.4 TEST PROCEDURES ......................................................................................... 82 4.4.5 EUT OPERATING CONDITION ........................................................................... 82 Report No.: RF120314E03 3 Report Format Version 4.2.0 4.4.6 TEST RESULTS .................................................................................................. 83 4.5 CONDUCTED SPURIOUS EMISSIONS ............................................................. 95 4.5.1 LIMITS OF CONDUCTED SPURIOUS EMISSIONS MEASUREMENT .............. 95 4.5.2 TEST INSTRUMENTS ......................................................................................... 95 4.5.3 TEST PROCEDURE ............................................................................................ 96 4.5.4 TEST SETUP .................................................................................................…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION RADIATED EMISSION TEST

FCC ID: V8YFWA1FUS38000W SAR EVALUATION REPORT Reviewed by: Quality Manager Test Date: DUT Type: Page D1 of D4 6/13/2012 USB Dongle © 2012 PCTEST Engineering Laboratory, Inc. REV 11.3 M 04/23/2012 APPENDIX D: SAR TEST SETUP PHOTOGRAPHS FCC ID: V8YFWA1FUS38000W SAR EVALUATION REPORT Reviewed by: Quality Manager Test Date: DUT Type: Page D2 of D4 6/13/2012 USB Dongle © 2012 PCTEST Engineering Laboratory, Inc. REV 11.3 M 04/23/2012 SAR Test Setup Photo 1 Horizontal Up at 0.5 cm SAR Test Setup Photo 2 Horizontal Down at 0.5 cm FCC ID: V8YFWA1FUS38000W SAR EVALUATION REPORT Reviewed by: Quality Manager Test Date: DUT Type: Page D3 of D4 6/13/2012 USB Dongle © 2012 PCTEST Engineering Laboratory, Inc. REV 11.3 M 04/23/2012 SAR Test Setup Photo 3 Tip at 0.5 cm SAR Test Setup Photo 4 Vertical Front at 0.5 cm FCC ID: V8YFWA1FUS38000W SAR EVALUATION REPORT Reviewed by: Quality Manager Test Date: DUT Type: Page D4 of D4 6/13/2012 USB Dongle © 2012 PCTEST Engineering Laboratory, Inc. REV 11.3 M 04/23/2012 SAR Test Setup Photo 5 Vertical Back at 0.5 cm
