V8YFWE81MC30000WWiMAX 802.16e Mini Card

FCC ID: V8YFWE81MC30000W Report No.: RF110704E02 Modular Approval Request Letter July 27, 2011 Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Dear Application Examiner, Accton Wireless Broadband Corp., It’s a WiMAX 802.16e Mini Card. FCC ID: V8YFWE81MC30000W would like to have your authorization as a modular approval specific to the mobile device. The requirements of section 15.212 of FCC rules have been met and shown on the following statements. 1. “The modular transmitter must have its own RF shielding.” The radio portion of this module has been shielded, please see exhibition External Photo. 2. “The modular transmitter must have buffered modulation/data inputs.” The EUT has buffered data inputs, it is integrated in chip BCSM350. 3. “The modular transmitter must have its own power supply regulation.” The part number of this regulator is BCSM350. 4. “The modular transmitter must comply with the antenna requirements of section 15.203 and 15.204(C).” The EUT meets the FCC antenna requirements. The spurious emission, unique antenna connector and photo of antennas are shown in the test report. 5. “The modular transmitter must be tested in a stand-alone configuration” The EUT was tested in a stand-alone configuration via a PCMCIA to mini-PCI extender. Please see section Photographs of Test Configuration in the test report, the EUT was plugged in this extender. 6. “The modular transmitter must be labeled with its own FCC ID number.” Please see exhibition Label Sample for the FCC ID of this module. And also in the exhibition Users Manual, there are instructions give to the OEM on how to label the end product. FCC ID: V8YFWE81MC30000W Report No.: RF110704E02 7. “The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements.” The EUT is compliant with all applicable FCC rules. Detail instructions for maintaining compliance are given in the Users Manual. 8. “The modular transmitter must comply with any applicable RF exposure requirements.” The EUT is compliant with all applicable RF exposure requirements. RF Exposure is addressed in the RF exposure exhibition. Please contact me if you have any further questions. Thanks for your attention. Best Regards, signature Hank Chung Assistant Manager Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch

(Fig.1) FCC ID: V8YFWE81MC30000W FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. Front Side : LABEL HERE

Page 6

Report No.: SA110704E02A Report Format Version 4.0.0 Reference No.: 110722E01 1 RF EXPOSURE REPORT REPORT NO.: SA110704E02A MODEL NO.: MC300-2.7-FLF-81, MC300-2.7 FCC ID: V8YFWE81MC30000W APPLICANT: Accton Wireless Broadband Corp. ADDRESS: 3F, No. 1 Creation Rd. III, Science-based Industrial Park Hsinchu 30077, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan This test report consists of 6 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced, except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval or endorsement by any government agency. The test results in the report only apply to the tested sample. Report No.: SA110704E02A Report Format Version 4.0.0 Reference No.: 110722E01 2 TABLE OF CONTENTS RELEASE CONTROL RECORD....................................................................................3 1. CERTIFICATION........................................................................................................4 2. RF EXPOSURE LIMIT...............................................................................................5 3. MPE CALCULATION FORMULA...............................................................................5 4. CLASSIFICATION......................................................................................................5 5. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER.............................6 Report No.: SA110704E02A Report Format Version 4.0.0 Reference No.: 110722E01 3 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA110704E02A Original release July 25, 2011 Report No.: SA110704E02A Report Format Version 4.0.0 Reference No.: 110722E01 4 1. CERTIFICATION PRODUCT: WiMAX 802.16e Mini Card BRAND NAME: AWB MODEL NO.: MC300-2.7-FLF-81, MC300-2.7 TEST SAMPLE: R&D SAMPLE APPLICANT: Accton Wireless Broadband Corp. STANDARDS: FCC Part 2 (Section 2.1091) FCC OET Bulletin 65, Supplement C (01-01) IEEE C95.1 The above equipment (Model: MC300-2.7-FLF-81) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: July 25, 2011 ( Claire Kuan, Specialist ) APPROVED BY : , DATE: July 25, 2011 ( May Chen, Deputy Manager ) Report No.: SA110704E02A Report Format Version 4.0.0 Reference No.: 110722E01 5 2. RF EXPOSURE LIMIT LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 3. MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r2) where Pd = power density in mW/cm2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 4. CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as user stations. Report No.: SA110704E02A Report Format Version 4.0.0 Reference No.: 110722E01 6 5. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER All test data was copied from the original test report (Report No.: SA110704E02) For WiMAX: FREQUENCY BAND (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 2502.5-2687.5 229.087 2 20 0.072 1.00 --- END ---

Report No.: RF110704E02 1 Report Format Version 4.0.0 FCC TEST REPORT (PART 27) REPORT NO.: RF110704E02 MODEL NO.: MC300-2.7-FLF-81, MC300-2.7 FCC ID: V8YFWE81MC30000W RECEIVED: July 04, 2011 TESTED: July 14 to 19, 2011 ISSUED: July 25, 2011 APPLICANT: Accton Wireless Broadband Corp. ADDRESS: 3F, No. 1 Creation Rd. III, Science-based Industrial Park Hsinchu 30077, Taiwan, R.O.C. ISSUED BY : Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan This test report consists of 74 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF110704E02 2 Report Format Version 4.0.0 TABLE OF CONTENTS RELEASE CONTROL RECORD.................................................................................4 1 CERTIFICATION..............................................................................................5 2 SUMMARY OF TEST RESULTS......................................................................6 2.1 MEASUREMENT UNCERTAINTY.......................................................................7 3 GENERAL INFORMATION...............................................................................8 3.1 GENERAL DESCRIPTION OF EUT.....................................................................8 3.2 DESCRIPTION OF TEST MODES.....................................................................10 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL......................11 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS.....................................14 3.4 DESCRIPTION OF SUPPORT UNITS...............................................................15 3.4.1 CONFIGURATION OF SYSTEM UNDER TEST................................................15 4 TEST TYPES AND RESULTS........................................................................16 4.1 OUTPUT POWER MEASUREMENT.................................................................16 4.1.1 LIMITS OF OUTPUT POWER MEASUREMENT...............................................16 4.1.2 TEST INSTRUMENTS.......................................................................................16 4.1.3 TEST PROCEDURES........................................................................................16 4.1.4 TEST SETUP.....................................................................................................16 4.1.5 EUT OPERATING CONDITIONS.......................................................................17 4.1.6 TEST RESULTS.................................................................................................18 4.2 FREQUENCY STABILITY MEASUREMENT......................................................19 4.2.1 LIMITS OF FREQUENCY STABILIITY MEASUREMENT..................................19 4.2.2 TEST INSTRUMENTS.......................................................................................19 4.2.3 TEST PROCEDURE..........................................................................................20 4.2.4 TEST SETUP.....................................................................................................20 4.2.5 TEST RESULTS.................................................................................................21 4.3 EMISSION BANDWIDTH MEASUREMENT.......................................................22 4.3.1 LIMITS OF EMISSION BANDWIDTH MEASUREMENT....................................22 4.3.2 TEST INSTRUMENTS.......................................................................................22 4.3.3 TEST SETUP.....................................................................................................22 4.3.4 TEST PROCEDURES........................................................................................23 4.3.5 TEST RESULTS.................................................................................................24 4.4 CHANNEL EDGE MEASUREMENT..................................................................28 4.4.1 LIMITS OF CHANNEL EDGE MEASUREMENT................................................28 4.4.2 TEST INSTRUMENTS.......................................................................................28 4.4.3 TEST SETUP.....................................................................................................28 4.4.4 TEST PROCEDURES........................................................................................29 4.4.5 EUT OPERATING CONDITION.........................................................................29 Report No.: RF110704E02 3 Report Format Version 4.0.0 4.4.6 TEST RESULTS.................................................................................................30 4.5 CONDUCTED SPURIOUS EMISSIONS............................................................36 4.5.1 LIMITS OF CONDUCTED SPURIOUS EMISSIONS MEASUREMENT.............36 4.5.2 TEST INSTRUMENTS.......................................................................................36 4.5.3 TEST PROCEDURE..........................................................................................37 4.5.4 TEST SETUP.....................................................................................................37 4.5.5 EUT OPERATING CONDITIONS.......................................................................37 4.5.6 TEST RESULTS.................................................................................................38 4.6 RADIATED EMISSION MEASUREMENT (BELOW 1GHz)................................50 4.6.1 LIMITS OF RADIATED EMISSION MEASUREMENT........................................50 4.6.2 TEST INSTRUMENTS.......................…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION RADIATED EMISSION TEST(PIFA ANTENNA) 2 3 RADIATED EMISSION TEST(DIPOLE ANTENNA) 4
