VBA-EFEMW202T-1Remote Control Transmitter

Instruction Manual for RF Remote Transmitter Ref: EMW202T-1 A. Function 1. Fix code 2. Please use together with the receivers in the same pack set 3. This product is intended to control the connected receivers ON/OFF B. Diagram NO. Introduction Function 1 LED Indicator Indicate the receiver's working status 2 ON/OFF Control the related receiver ON/OFF C. Instruction 1. Plug the receiver into an outlet 2. Remove the insulating strap from the back of the transmitter 3. Press ON/OFF button on the transmitter to switch the related channel's receiver ON/OFF D. Caution 1. Low battery voltage in the transmitter would impact the transmitting distance. 2. If LED indicator doesn’t light up or becomes dark when press the buttons, please change the battery E. Specification Transmitter battery： CR2032L DC3V Frequency： 433.92 MHz Effective distance： 25 meters (open area) 2 1 FCC CAUTION: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. The equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. IC WARNING: This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présentappareilestconforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitationestautorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareildoit accepter tout brouillageradioélectriquesubi, mêmesi le brouillageest susceptible d'encompromettre le fonctionnement. This Class B digital apparatus complies with Canadian ICES-003. Cetappareilnumérique de la classe B estconformeà lanorme NMB-003 du Canada. Les communications effectuées au moyen de cetappareil ne sont pas nécessairement protégées des indiscrétions. the device is compliance with RF exposure guidelines, user can obtain Canadian information on RF exposure and compliance. Le présentappareilestconforme Après examen de ce materiel aux conformitéou aux limitesd'intensitè de champ RF, Les utilisateurspeuventsurl'exposition aux radiofréquenceset la conformité and compliance d'acquérir. Manufacturer: Manufacturer: Ningbo EverFlourish Smart Technology Corp. Ltd. Address: 77 Wuxiang East Road, Yinzhou, Ningbo, 315111, P.R.China

Agent Authorization Letter 23/12/2019 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Eurofins Product Testing Service (Shanghai) Co., Ltd. to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Company name：Ningbo EverFlourish Smart Technology Corp., Ltd. Address：77 Wuxiang East Road, Yinzhou, Ningbo, 315111, China

Long Term Confidentiality Request Letter 23/12/2019 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR Product type：Remote Control Transmitter Model name: EMW202T-1 FCC ID: VBA-EFEMW202T-1 To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the -Block Diagram -Schematics -Circuit Description required to be submitted with this application be permanently withheld from public review. The above documents are company proprietary information that could never get into the possession of your competition. Please contact me if there is any information you may need. Sincerely, Company name：Ningbo EverFlourish Smart Technology Corp., Ltd. Address：77 Wuxiang East Road, Yinzhou, Ningbo, 315111, China

Antenna

RF Exposure compliance IC 7098A-EFEMW202T11 HVIN EMW202T-1 Applicant Ningbo EverFlourish Smart Technology Corp., Ltd Applicable procedure: 2.5.1 Exemption Limits for Routine Evaluation – SAR Evaluation SAR evaluation is required if the separation distance between the user and/or bystander and the antenna and/or radiating element of the device is less than or equal to 20 cm, except when the device operates at or below the applicable output power level (adjusted for tune-up tolerance) for the specified separation distance defined in Table 1. Output power level shall be the higher of the maximum conducted or equivalent isotropically radiated power (e.i.r.p.) source-based, time-averaged output power. For controlled use devices where the 8 W/kg for 1 gram of tissue applies, the exemption limits for routine evaluation in Table 1 are multiplied by a factor of 5. For limb-worn devices where the 10 gram value applies, the exemption limits for routine evaluation in Table 1 are multiplied by a factor of 2.5. If the operating frequency of the device is between two frequencies located in Table 1, linear interpolation shall be applied for the applicable separation distance. For test separation distance less than 5 mm, the exemption limits for a separation distance of 5 mm can be applied to determine if a routine evaluation is required. For medical implants devices, the exemption limit for routine evaluation is set at 1 mW. The output power of a medical implants device is defined as the higher of the conducted or e.i.r.p to determine whether the device is exempt from the SAR evaluation. Evaluation for SAR test: Frequency (MHz) Maximum EIRP(dBm) Maximum tune-up Conducted power(dBm) Threshold (distance≤5mm) (mW) Verdict 433.92 -7.55 0.176 54 Compliance, SAR test is exempted Note: the maximum fundamental emission at 3m is 87.65dBμV/m, i.e. -7.55dBm EIRP, in accordance with C63.10-2013 Annex G.

Test Report No.: EFGX19120067-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 101 and 201, Building 2, Dongfangming Industrial Area, No 83. Dabao Rd., Area 33 Shanghe Neibourhood, Xin’an Community, Bao’an District, Shenzhen, P.R. China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 1 of 25 EUROFINS ELECTRICAL TESTING SERVICE (SHENZHEN) CO., LTD. RADIO TEST - REPORT FCC/IC Compliance Test Report Test Report Number: EFGX19120067-IE-01-E01 Test Report No.: EFGX19120067-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 101 and 201, Building 2, Dongfangming Industrial Area, No 83. Dabao Rd., Area 33 Shanghe Neibourhood, Xin’an Community, Bao’an District, Shenzhen, P.R. China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 2 of 25 Content 1 General Information 3 1.1 Notes 3 1.2 Testing laboratory 4 1.3 Details of approval holder 4 1.4 Details of Manufacturer 4 1.5 Application details 4 1.6 Test item 4 1.7 Test standards 5 2 Technical test 6 2.1 Summary of test results 6 2.2 Test environment 6 2.3 Measurement uncertainty 6 2.4 Test mode 6 2.5 Test equipment utilized 7 2.6 Auxiliary Equipment Used during Test: 7 2.7 Test software information 7 2.8 Customized Configurations 7 2.9 Test Environments 7 2.10 Test results 8 3 Technical Requirement 9 3.1 Conducted Emission 9 3.2 Automatically Deativate 10 3.3 20dB & 99% bandwidth 12 3.4 Frequency Stability 14 3.5 Field strength of fundamental and Field strength of spurious emission for transmitter 16 Test Report No.: EFGX19120067-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 4 of 25 1.2 Testing laboratory Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone : +86-755-82911867 Fax : +86-755-82910749 The Laboratory has passed the Accreditation by the American Association for Laboratory Accrediation (A2LA). The Accreditation number is 5376.01 The Laboratory has been listed by industry Canada to perform electromagnetic emission measurements, The CAB identifier is CN0088 1.3 Details of approval holder Name : Ningbo EverFlourish Smart Technology Corp.,Ltd Address : 77 Wuxiang East Road,Yinzhou,Ningbo, 315111, China Telephone : N/A Fax : N/A 1.4 Details of Manufacturer Name : Ningbo EverFlourish Smart Technology Corp.,Ltd Address : 77 Wuxiang East Road,Yinzhou,Ningbo, 315111, China Telephone : N/A Fax : N/A 1.5 Application details Date of receipt of application : December 10, 2019 Date of receipt of test item : December 10, 2019 Date of test : December 10, 2019 – December 19, 2019 Date of issue December 19, 2019 1.6 Test item Product type : Remote Control Transmitter Model name : EMW202T-1 Brand : Everflourish Serial number : N/A Ratings : 3.0Vdc supplied by a type “CR2032” Battery Test voltage : 3.0Vdc FCC ID : VBA-EFEMW202T-1 IC : 7098A-EFEMW202T11 PMN : Remote Control Transmitter HVIN : EMW202T-1 Additional information : N/A RadioTechnical data Frequency range : 433.92MHz Radio Tech. : N/A Frequency channel : 1 Channel Modulation : ASK Antenna type : PCB antenna Antenna gain : 1dBi Test Report No.: EFGX19120067-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 5 of 25 1.7 Test standards Test Standards FCC Part 15 Subpart C 2018 Edition PART 15 - RADIO FREQUENCY DEVICES Subpart C - Intentional Radiators RSS-210 Issue 9 August 2016 Licence-Exempt Radio Apparatus: Category I Equipment RSS-GEN Issue 5 March 2019 RSS-Gen — General Requirements for Compliance of Radio Appa- ratus Test Method 1: ANSI C63.4-2014, American National Standard for Methods of Measurement of Radio-Noise Emis- sions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz. 2: ANSI C63.10-2013, American National Standard for Testing Unlicensed Wireless Devices. Test Report No.: EFGX19120067-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 6 of 25 2 Technical test 2.1 Summary of test results No deviations from the technical specification(s) were ascertained in the course of the tests performed. or The deviations as specified were ascertained in the course of the tests performed. 2.2 Test environment Temperature : 20 ... 25°C Relative humidity content : 30 ... 60% Air pressure : 100 ... 101kPa 2.3 Measurement uncertainty The uncertainty is calculated using the methods suggested in the "Guide to the Expression of Uncer- tainty in Measurement" (GUM) published by ISO. System Measurement Uncertainty Test Items Extended Uncertainty Uncertainty for Conducted RF test RF Power Conducted: 1.16dB Frequency test involved: 1.05×10-7 or 1% Uncertainty for Radiated Spurious Emission 25MHz-3000MHz Horizontal: 4.46dB; Vertical: 4.54dB; Uncertainty for Radiated Spurious Emission 3000MHz-18000MHz Horizontal: 4.42dB; Vertical: 4.41dB; Uncertainty for Radiated Spurious Emission 18000MHz- 40000MHz Horizontal: 4.63dB; Vertical: 4.62dB; 2.4 Test mode The EUT was set at continuously transmitting during the test. Test Report No.: EFGX19120067-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 7 of 25 2.5 Test equipment utilized EQUIPMENT ID EQUIPMENT NAME MODEL NO. CAL. DUE DA…

Text truncated - open the document above for the full version.

Radiated Spurious Emission 30MHz – 1GHz Radiated Spurious Emission above 1GHz
