VBNEXPB-01Flexi EDGE Base Transceiver Station (BTS)

Restricted Access of Equipment and Documentation Notice Proprietary and Confidential Nokia Siemens Networks RESTRICTED ACCESS OF EQUIPMENT AND DOCUMENTATION NOTICE This Restricted Access of Equipment and Documentation Notice is to inform [insert name of FCC licensee] that access to equipment and related documentation supplied by Nokia Siemens Networks is to be restricted to only authorized users by means to ensure the security of the equipment and confidentiality of related documentation at all times, and only designated professionals shall be allowed to maintain or service the equipment. This notice includes, but is not limited to, internal photographs and user manuals to be held confidential and out of the public domain. Nokia Siemens Networks By: Name: Title: Date: Place:

Restricted Access of Equipment and Documentation Notice Proprietary and Confidential Nokia Siemens Networks RESTRICTED ACCESS OF EQUIPMENT AND DOCUMENTATION NOTICE This Restricted Access of Equipment and Documentation Notice is to inform [insert name of FCC licensee] that access to equipment and related documentation supplied by Nokia Siemens Networks is to be restricted to only authorized users by means to ensure the security of the equipment and confidentiality of related documentation at all times, and only designated professionals shall be allowed to maintain or service the equipment. This notice includes, but is not limited to, internal photographs and user manuals to be held confidential and out of the public domain. Nokia Siemens Networks By: Name: Title: Date: Place:

FCC ID Label for EXPB (FCC ID: VBNEXPB-01)

Master: ktlPT24BASE Date: April 19, 1999 Nemko Test Report: 33241RUS1 Applicant: Nokia Siemens Networks 6000 Connection Drive Irving, TX 75039 USA Equipment Under Test: EXPB (E.U.T.) FCC ID: VBNEXPB-01 In Accordance With: CFR 47, Part 24, Subpart E Broadband PCS Base Stations Tested By: Nemko USA, Inc. 802 N. Kealy Lewisville, TX 75057-3136 TESTED BY: DATE: 06 October 2009 David Light, Senior Wireless Engineer APPROVED BY: DATE: 6 November 2009 Tom Tidwell, Telecom Direct Number of Pages: 53 Nemko USA, Inc. CFR 47, PART 24, SUBPART E BROADBAND PCS BASE STATIONS EQUIPMENT: EXPB PROJECT NO.: 33241RUS1 Page 2 of 53 Table of Contents Section 1. Summary of Test Results.......................................................................... 3 Section 2. General Equipment Specification.............................................................. 5 Section 3. RF Power Output ...................................................................................... 6 Section 4. Occupied Bandwidth ................................................................................. 8 Section 5. Spurious Emissions at Antenna Terminals ............................................. 11 Section 6. Field Strength of Spurious...................................................................... 40 Section 7. Frequency Stability................................................................................. 41 Section 8. Test Equipment List................................................................................ 43 ANNEX A - TEST DETAILS .......................................................................................... 44 ANNEX B - TEST DIAGRAMS ...................................................................................... 50 Nemko USA, Inc. CFR 47, PART 24, SUBPART E BROADBAND PCS BASE STATIONS EQUIPMENT: EXPB PROJECT NO.: 33241RUS1 Page 3 of 53 Section 1. Summary of Test Results Manufacturer: Nokia Siemens Networks Model No.: EXPB Serial No.: L9093200297 General: All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with FCC Part 24, Subpart E. New Submission Production Unit Class II Permissive Change Pre-Production Unit THIS TEST REPORT RELATES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. See “ Summary of Test Data”. Nemko USA Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko USA Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. Nemko USA, Inc. CFR 47, PART 24, SUBPART E BROADBAND PCS BASE STATIONS EQUIPMENT: EXPB PROJECT NO.: 33241RUS1 Page 4 of 53 Summary Of Test Data NAME OF TEST PARA. NO. SPEC. RESULT RF Power Output 24.232 1640 W Complies Occupied Bandwidth 24.238 Complies Spurious Emissions at Antenna Terminals 24.238(a) -13 dBm Complies Field Strength of Spurious Emissions 24.238(a) -13 dBm E.I.R.P. Complies Frequency Stability 24.235 Must stay in block Complies Footnotes For N/A’s: Nemko USA, Inc. CFR 47, PART 24, SUBPART E BROADBAND PCS BASE STATIONS EQUIPMENT: EXPB PROJECT NO.: 33241RUS1 Page 5 of 53 Section 2. General Equipment Specification Supply Voltage Input: -48 Vdc nominal Frequency Band: 1930 to 1990 MHz Type of Modulation and Designator: GSM 300KGXW EDGE 300KG7W Maximum No. of Carriers: 1 Output Impedance: 50 ohms 50.0 W GMSK: Combiner Bypass RF Output (Rated): 89.0 W GMSK: Double Combining 31.6 W 8PSK: Combiner Bypass 56.2 W 8PSK: Double Combining Software Duplexer Fullband Band Selection: System Description The EXPB is an 1900 MHz Base Station Transceiver. The configurations tested consisted of 3 modules: System Module, Dual Duplex filter module, Dual Transceiver module, and Wideband combiner module (needed for double power). Two types of RF outputs were measured: Combiner Bypass and Double Power Combining. Combiner Bypass consisted of a single carrier and Double Power Combining consisted of two carriers on the same channel combined with phase adjustment in order to increase the transmitted RF output power. Nemko USA, Inc. CFR 47, PART 24, SUBPART E BROADBAND PCS BASE STATIONS EQUIPMENT: EXPB PROJECT NO.: 33241RUS1 Page 6 of 53 Section 3. RF Power Output NAME OF TEST: RF Power Output PARA. NO.: 2.1046 TESTED BY: David Light DATE: 02 October 2009 Test Results: Complies. Measurement Data: Refer to table on next page. Equipment Used: 1036-1082-1055-1064-1065 Measurement Uncertainty: +/- 1.7 dB Temperature: 22 °C Relative Humidity: 35 % Nemko USA, Inc. CFR 47, PART 24, SUBPART E BROADBAND PCS BASE STATIONS EQUIPMENT: EXPB PROJECT NO.: 33241RUS1 Page 7 of 53 Test Data – RF Power Output Double Power Combining Mode Modulation Type Frequency (MHz) Measured Output Power (dBm) Measured Output Power (W) GMSK 1930.2 32.9 1.9 GMSK 1930.4 49.1 81.3 GMSK 1960.0 49.5 89.0 GMSK 1989.6 34.0 2.5 GMSK 1989.8 48.6 72.4 8PSK 1930.2 39.6 9.1 8PSK 1930.4 47.5 56.2 8PSK 1960.0 47.5 56.2 8PSK 1989.6 37.3 5.6 8PSK 1989.8 47.4 55.0 Combiner Bypass Mode Modulation Type Frequency (MHz) Measured Output Power (dBm) Measured Output Power (W) GMSK 1930.2 33.6 2.5 GMSK 1930.4 45.8 38.0 GMSK 1960.0 47.0 50.0 GMSK 1989.6 32.8 1.9 GMSK 1989.8 44.9 30.9 8PSK 1930.2 37.4 5.5 8PSK 1930.4 45.0 31.6 8PSK 1960.0 45.0 31.6 8PSK 1989.6 36.1 4.1 8PSK 1989.8 45.0 31.6 Note: The peak power needs to be lowered at the lowest and highest frequencies per above to ensure compliance at the band edges. Refer to plots in section 5. Supply voltage was varied +/- 15%. No fluctuation in output power resulted. Nemko USA, Inc. CFR 47, PART 24, SUBPA…
